PCI6-AD-x8E3V-01
User's Manual
REV: 1.0
September. 2024
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the PCI6-AD-x8E3V-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Serial Cables PCI6-AD-x8E3V-01

Summary of Contents for Serial Cables PCI6-AD-x8E3V-01

  • Page 1 PCI6-AD-x8E3V-01 User’s Manual REV: 1.0 September. 2024...
  • Page 2 Change history Change history Date of Release New crea on Sept. 2024...
  • Page 3 PCI6-AD-x8E3V-01 Func on Descrip on For Connectors J2/J3 111mm 167mm Loca on Descrip ons Toggle switch Toward Up, EDSFF drive powered by AUX (Quarch PPM Connector). Toward Down, EDSFF drive powered by host (Golden finger). Quarch PPM connector 4Pins 2.54mm FAN connector...
  • Page 4 PCI6-AD-x8E3V-01 Func on Descrip on For Connectors Loca on Descrip ons Pin1_EDSFF_MFG: To EDSFF connector Pin B7. Pin2_EDSFF_RFU: To EDSFF connector Pin B8. Pin3_EDSFF_RFU1: To EDSFF connector Pin A42. Pin4_GND ON: Assert EDSFF_RST# in EDSFF connector Pin B10. OFF: De-assert EDSFF_RST# in EDSFF connector Pin B10.
