OPERATOR'S MANUAL
Model:
FXA4111
24V BRUSHLESS OSCILLATING MULTI-TOOL
WARNING: To reduce the risk of injury, the user must read and understand the
Owner's Manual before using this product. Save these instructions for future reference.
Please contact FLEX customer service in Australia 1300 000 346 or
New Zealand 0508 000 346 any time you have questions or warranty claims.
Advertisement
Related Manuals for Flex FXA4111
Summary of Contents for Flex FXA4111
- Page 1 WARNING: To reduce the risk of injury, the user must read and understand the Owner’s Manual before using this product. Save these instructions for future reference. Please contact FLEX customer service in Australia 1300 000 346 or New Zealand 0508 000 346 any time you have questions or warranty claims.
- Page 2 SAFETY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.
- Page 3 GENERAL POWER TOOL SAFETY WARNINGS Read all safety warnings, instructions, illustrations and specifications WARNING provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE. The term “power tool”...
- Page 4 Power tool use and care Battery tool use and care Do not force the power tool. Use the correct Recharge only with the charger specified by power tool for your application. The correct the manufacturer. A charger that is suitable for power tool will do the job better and safer at the one type of battery pack may create a risk of fire rate for which it was designed.
- Page 5 SAFETY WARNINGS FOR MULTI TOOL Hold power tools by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring. Contact with a "live" wire will make exposed metal parts of the tool "live" could give the operator an electric shock.
- Page 6 SYMBOLS IMPORTANT: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. Symbol Name Designation/Explanation Volts Voltage Amperes Current Hertz...
- Page 7 Symbol Name Designation/Explanation Wear eye protection symbol Alerts user to wear eye protection This product complies with applicable Regulatory compliance mark Australian standards.
- Page 8 Jaws Plunge-cut Blade (wood) Edge Guide Attachment Collar Depth Gauge Model No. FXA4111 Rated Voltage 24 V d.c. No Load Speed 10000 – 20000 /min (oscillations per minute) Oscillating Angle (left/right) 4º (2º) Accessory Interface Starlock, Starlock Plus, Starlock MAX Recommended Operating Temperature -20 –...
- Page 9 INSTALLING AND REMOVING ACCESSORIES Fig. 3 (FIG. 3 – 7) Original Position Only use FLEX WARNING accessories rated 20000 OPM or greater. Using accessories not designed for this tool may result in serious personal injury and property damage.
- Page 10 b. Continue to turn the lever counterclockwise Fig. 4 (this time you will feel some resistance) as Accessory far as it will go, which will be indicated by Release Lever the second "click". The clamping jaws of the accessory holder are now closed and the new accessory can be installed (Fig.
- Page 11 INSTALLING AND REMOVING THE Fig. 8a ATTACHMENT COLLAR (FIG. 8 & 9) Positioning Tabs Loosen the collar locking bolt by using the hexagon rod of the depth gauge or guide fence and align the four positioning tabs (Fig. 8a) of the clamp assembly with the grooves on the neck.
- Page 12 ADJUSTMENTS SETTING THE SPEED (FIG. 10) Fig. 10 There are five speed levels that can be changed Speed Setting Buttons using the speed setting buttons. Press the "︿" button to increase the speed. Press "﹀" button to decrease the speed. The LED lights above the numbers indicate the current speed level.
- Page 13 Use of this product with damaged or missing parts could result in serious personal injury. This multi-tool must be used only with the FLEX 24V series battery packs and chargers. Do not attempt to modify WARNING this tool or create...
- Page 14 LED WORK LIGHT (FIG. 12) Fig. 12 Your tool is equipped with an LED work light. This work light provides additional light on the surface of the workpiece for operation in lower- light areas. The work light will automatically turn on when the tool is turned on and will turn off approximately 10 seconds after the tool is turned off.
- Page 15 After turning the tool on, allow it to reach its full FLEX Multi Tool is designed to tackle a variety speed before contacting the workpiece with the of tasks. A range of available accessories easily...
- Page 16 USING ATTACHMENTS Detach the battery pack WARNING Fig. 13 from the tool before performing any assembly, adjustments, or changing accessories. Such preventive safety measures reduce the risk of starting the tool accidentally. Depth Your tool is shipped with the attachment collar Collar Gauge that accepts the depth gauge or the edge...
- Page 17 EDGE GUIDE (FIG. 14 & 15) Fig. 14 Locking Knob The edge guide is used to make thru cuts Clamp parallel to a straight edge or a piece of plywood Straight Edge temporarily secured to the workpiece with screws or clamps. Make sure that the clamps do not interfere with the free movement of the tool throughout the entire length of the cut.
- Page 18 We recommend that all tool service be plastic parts. Some of these are: gasoline, performed by a FLEX Factory Service Centre or carbon tetrachloride, chlorinated cleaning Authorized FLEX Service Station. solvents, ammonia and household detergents that contain ammonia.
- Page 19 If the Customer registers its purchase of the Product online at www.flex-tools.com.au or by calling • 1300 000 346 in Australia or www.flex-tools.co.nz or by calling 0508 000 346 in New Zealand within 30 days of the date of its purchase (Registration), the Warranty Period for the following Products is as follows: FLEX 24V Tools: 5 years;...
- Page 20 The Warranty does not apply if: a) the Product is not supplied in its final shape and form by Chervon or an authorised FLEX Dealer, which can be confirmed on the website store locator (for avoidance of doubt, third party online stores such as eBay, Gumtree, Amazon, etc.
- Page 21 *Original purchaser must register the product(s) within 30 days of purchase and retain their receipt as proof of purchase. This warranty applies only to the original purchaser from an authorised FLEX dealer and may not be transferred. If original purchaser does not register their product within 30 days, the warranty will apply for the duration set out in table above in column ‘LIMITED...
