Summary of Contents for Narwal YJCC012
- Page 1 Manufacturer:Yunjing Intelligence Innovation (Shenzhen) Co., Ltd. Address:Room A2901, Yunzhongcheng, Building 1, Vanke Yuncheng User’s Manual VI, Dashi 2nd Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, China WWW.NARWAL.COM Narwal FREO Robot Vacuum and Mop Model: YJCC012...
- Page 2 Notices Before Use Scan the QR code below on the right to download the Narwal app in advance, get familiar with First Use Manual electronic copy more functions and enjoy a more convenient smart life.
-
Page 3: Product Introduction
Product Introduction Robot*1 Base station*1 Dirty water level indicator float Water tank handles Speaker Clean water tank Dirty water tank latch Mopping module*2 Side brush*2 Dirty water tank Power cord*1 Specially formulated floor cleaner*1 Clean water tank sponge filter*2... - Page 4 Cleaning hook Automatic cleaner Cover feeding slot Power jack Base station touchscreen Picking cavities of Infrared sensor the base station Bumper Base station cleaning components Cleaning tray Pressure sensing radar cover Cleaning base Charging-electrode Wall-following sensor...
-
Page 5: Control Panel Overview
Control Panel Overview Carpet sensor Roller brush Vacuum inlet Tire Tire Omni-directional wheel Operations and Functions Click: Clean the whole house Filter cover Ring indicator light Solid white indicator: The device is powered on/drying/charging White breathing light: Standby Blue breathing light: Networking Filter handle Solid purple indicator: Task in progress Filter... -
Page 6: Standby Mode
Standby Mode 1. Click the Standby Mode. This product is only used to clean floors in household environments, and cannot be used outdoors (such as open balconies), areas other than floors (such as sofas or window sills), high places, or commercial/industrial environments. lofts or top of furniture) without guardrails 2. -
Page 7: Specifications
5. To prevent damages to the device, do not place the robot near any heat or water sources (such as the original packaging. radiators or faucets). 23. It is hazardous for the rotating brush to touch the power cord. Arrange the wires neatly before use. -
Page 8: Important Safety Instructions
: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE To Reduce the Risk of Fire and Electric Shock due to internal component damage, use only NARWAL cleaning fluid intended for use with this appliance. See the Cleaning Fluid section of this manual. - Page 9 • Do not leave applianc ended when plugged in. Unplug it from the power outlet when not in use and before servicing. • Use extra care when cleaning on stairs. • Do not use your robot without dust bag and/or filters in place. •...
- Page 10 The laser distance sensor of this product meets the standards for Class I Laser Products in IEC 60825-1: 2014 and will not generate hazardous laser radiation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
-
Page 11: Warranty Policy
Any updates to this Policy will be posted on Narwal.com and we encourage you to periodically review this Policy to ensure you are familiar with the most current version. If there is any inconsistency between this Policy on Narwal.com and any other documents included with or... - Page 12 INDIRECT LOSS OR DAMAGE, CONSEQUENTIAL LOSS OR DAMAGE OR SPECIAL LOSS OR DAMAGE. TO THE EXTENT PERMITTED BY APPLICABLE LAW, NARWAL’S LIABILITY SHALL BE LIMITED TO THE PURCHASE VALUE OF THE PRODUCT. THE ABOVE LIMITATIONS SHALL NOT APPLY IN CASE OF GROSS NEGLIGENCE OR INTENTIONAL MISCONDUCT OF NARWAL OR IN CASE OF DEATH OR PERSONAL INJURY RESULTING FROM NARWAL’S PROVEN NEGLIGENCE.
