Congratulations on your purchase of a high quality PUTCO product. Should you need any application or technical assistance, feel
P
LEASE READ ALL INSTRUCTIONS BEFORE BEGINNING INSTALLATION AND BE SURE TO CHECK TO SEE THAT ALL PARTS AND
HARDWARE ARE INCLUDED
STEP 1: Remove the protective plastic coating from the mud flap and SS trim.
STEP 2: Apply the protective black edge trim to ONLY the outer exposed edge. SEE FIGURE 1
STEP 3: Attach the stainless steel trim piece to the bottom of the rubber extension. SEE FIGURE 1
STEP 4: Attach the mud flap to the mud flap extension using 1/4" x 3/4" SS slot head bolts and nylon insert lock nuts.
FIGURE 2
INSTALLATION SHEET FOR STAINLESS STEEL MUD FLAP
Monday-Friday 8:00 a.m.- 5:00 p.m. (Central Standard Time)
Contact your PUTCO dealer for other quality accessories.
PUTCO Inc. - 216 West First Street - Story City, Iowa 50248
.
free to call us at:
1-800-247-3974
RUBBER
EXTENSION
S.S. TRIM
BOLT
WASHER
NUT
SEE
Advertisement
Related Manuals for PUTCO 79473
Summary of Contents for PUTCO 79473
- Page 1 INSTALLATION SHEET FOR STAINLESS STEEL MUD FLAP Congratulations on your purchase of a high quality PUTCO product. Should you need any application or technical assistance, feel free to call us at: 1-800-247-3974 Monday-Friday 8:00 a.m.- 5:00 p.m. (Central Standard Time) Contact your PUTCO dealer for other quality accessories.
- Page 2 Black products have a 90-day warranty on the painted surface. Any defects resulting from faulty material or workmanship will be warranted by Putco and repaired or replaced at our discretion. Putco assumes no extra labor costs. Damages caused by freight carriers, improper installation, misuse, collision, or neglect will not...
