ASSEMBLY INSTRUCTION
SALTA
QUEEN BED
ITEM CODE 73033/73035
Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please refer to your receipt
PRE-ASSEMBLY PREPARATION
Before you start:
1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product
2. Take care when lifting. Product should be assembled as near as possible to the point of use
3. Ensure that you have all required contents for complete assembly
4. Always read the assembly instructions carefully before beginning assembly.
5. Keep all hardware parts and packaging out of reach of small children.
6. Do not over tighten the screws and bolts as this may damage the threads.
Allow 20 minutes
For 2 person
Additional tools required
1
Advertisement
Table of Contents
Related Manuals for JWA SALTA 73033
Summary of Contents for JWA SALTA 73033
- Page 1 ASSEMBLY INSTRUCTION SALTA QUEEN BED ITEM CODE 73033/73035 Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt PRE-ASSEMBLY PREPARATION Before you start: 1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product 2.
- Page 2 PARTS LIST Bolt Washer Bolt Bolt Nylon Nut Allen Key Bolt M8 x 30mm 12 x A 2 x C M6 x 40mm 8 x B 2 x D 1 x F M8 x 50mm 4 x G M8 x 20mm 8 x E Metal Legs Bolt...
- Page 3 Step 5: Remove the Foam. Step 6: Rip the Velcro. Step 8: Slowly take out the Side Rail. Step 7: Remove the Foam. Step 9: Take out the Plastic Legs. Step 10: Take out the Metal Legs + Hardware. Step 11: Take out the Center Support Legs. Step 12: Slowly take out another Side Rail...
- Page 4 Step 14: Then take out the whole Slat. Step 13: Slowly move the Slat to the end. Carefully lift up one side. Step 15: Slowly move the Footboard to the end. Step 16: Then take out the whole Footboard. Carefully lift up one side. Step 17: Stick the Velcro.
- Page 5 Note : Please ensure the legs are fix and same position according to diagram 1. Step 21 : Attach the Legs (6.) to the bottom of Headboard (1.) and Footboard (2.) by screwing in a clockwise direction. Then tighten them before you continue to the next step. Slighly losen the pre x screw for hook in bracket...
- Page 6 Step 24 : Attach the 2 Center Rail (5.) with Center Support Rail (8.) using screw G. M8 x 50mm with D. M8 Bolt and C . M8 Washer on Center Rail (5.).Install the Support Leg (9) using screw G. M8 X 50mm on Center Rail (5.). C.
- Page 7 Use a clean, soft, dry, lint free absorbent cloth to clean your furniture. Do not use any detergent as they may contain ingredients that may react and damage the finish. Made In: Malaysia Imported By: JWA Furniture Pty Ltd Brisbane, Old, Australia Item Code: 73033 / 73035 Product Name: SALTA QUEEN BED...
