Summary of Contents for Electrolux Professional Compass Pro EED-620
- Page 1 Installation manual Washer extractor EED–618, EED–620, EED–625, EED–630, EED–645, EED–665, EED–685 Compass Pro Type W3..438917559/US 2024.02.12...
- Page 3 Safety WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR MACHINE. MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE REFERENCE. PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S) DATA PLATE(S).
-
Page 4: Important Safety Instructions
Safety IMPORTANT SAFETY INSTRUCTIONS WARNING - To reduce the risk of fire, electric shock, or injury to persons when using your appliance, including the following: 1. Read all instructions before using the appliance. 2. This machine must be securely bolted to an uncovered concrete floor. 3. - Page 5 Safety NOTICE TO: OWNERS, OPERATORS AND DEALERS IMPROPER INSTALLATION AND INADEQUATE MAINTENANCE, POOR HOUSEKEEPING AND WILLFUL NEGLECT OR BYPASSING OF SAFETY DEVICES MAY RESULT IN SERIOUS ACCIDENTS OR INJURY. TO ASSURE THE SAFETY OF CUSTOMERS AND/OR OPERATORS OF YOUR MACHINE, THE FOLLOWING MAINTENANCE CHECKS MUST BE PERFORMED ON A DAILY BASIS. Prior to operation of the machine, check to make certain that all operating instructions and warning signs are affixed to the machine and legible.
-
Page 6: Notice To Installer
Improper fastening of this machine to its foundation, inferior foundation materials, an undersized foundation, the use of fabricated steel bases not provided by Electrolux Professional or its approved supplier(s), the use of an improper type, number, or size of mounting bolts, or failure to use proper hardware on mounting bolts may result in damage to the machine that will not be covered by the manufacturer's warranty. -
Page 7: Table Of Contents
Contents Contents 1 Safety Precautions ..........................9 General safety information......................9 Commercial use only........................9 Copyright ..........................10 Symbols..........................10 2 Warranty terms and exclusions......................11 3 Technical data...........................12 Drawing ..........................12 3.1.1 EED-618, EED-620, EED-625 ..................12 3.1.2 EED-630 ........................13 3.1.3 EED-645 ........................14 3.1.4 EED-665, EED-685 .......................15 Technical data .........................16 Connections ..........................17 4 Setup ...............................18... -
Page 9: Safety Precautions
Installation manual 1 Safety Precautions • Servicing shall be carried out only by authorized personnel. • Only authorized spare parts, accessories and consumables shall be used. • Only use detergent intended for water-wash of textiles. Never use dry cleaning agents. •... -
Page 10: Copyright
Installation manual 1.3 Copyright This manual is intended solely for consultation by the operator and can only be given to third parties with the permis- sion of Electrolux Professional AB company. 1.4 Symbols Caution Caution, high voltage Read the instructions before using the machine... -
Page 11: Warranty Terms And Exclusions
Warranty will be applicable where the customer has used only genuine spare parts and has performed maintenance in accordance with Electrolux Professional user and maintenance documentation made available in paper or elec- tronic format. Electrolux Professional strongly recommends using Electrolux Professional approved cleaning, rinse and descaling agents to obtain optimal results and maintain product efficiency over time. -
Page 12: Technical Data
Installation manual 3 Technical data 3.1 Drawing 3.1.1 EED-618, EED-620, EED-625 fig.X01719 Operating panel Door opening, EED-618, EED-620: ⌀ 310 mm / 12 3/16 inch, EED-625: ⌀ 365 mm / 14 3/8 inch Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection... -
Page 13: Eed-630
Installation manual 3.1.2 EED-630 fig.X01720 Operating panel Door opening, EED-630: ⌀ 365 mm / 14 3/8 inch Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection inch EED-630 1220 1335 28 3/8 31 1/8 48 1/16 14 9/16... -
Page 14: Eed-645
Installation manual 3.1.3 EED-645 fig.X01721 Operating panel Door opening, EED-645: ⌀ 395 mm / 15 9/16 inch Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection Cold water (for detergent container) / Hot water inch EED-645 1345... -
Page 15: Eed-665, Eed-685
Installation manual 3.1.4 EED-665, EED-685 fig.X01722 Operating panel Door opening, EED-665, EED-685: ⌀ 435 mm / 17 1/8 inch Detergent container Cold water Hot water Re-used water Drain valve Liquid detergent supply Electrical connection Steam connection inch EED-665 1030 1430 1590 1135 32 11/... -
Page 16: Technical Data
Installation manual 3.2 Technical data EED-618 EED-620 EED-625 EED-630 EED-645 EED-665 EED-685 Weight, net Drum volume litres 11.7 Drum diameter inch 20 1/2 20 1/2 23 7/16 23 7/16 25 9/16 28 9/16 31 5/16 Drum speed during wash Drum speed during extraction G-factor, max. -
Page 17: Connections
Installation manual 3.3 Connections EED-618 EED-620 EED-625 EED-630 EED-645 EED-665 EED-685 Water valves 3/4” 3/4” 3/4” 3/4” 3/4” * 3/4” 3/4” Recommended water pressure 200–600 200–600 200–600 200–600 200–600 200–600 200–600 30–90 30–90 30–90 30–90 30–90 30–90 30–90 Continuous operating pressure 50–800 50–800 50–800... -
Page 18: Setup
Installation manual 4 Setup 4.1 Unpacking Note! For EED–630–EED–685 two persons are recommended for the unpacking. Remove the front and rear panel. Remove the bolts between the machine and pallet. There is one to the right in the front of the machine and another diagonally opposed to it, at the back of the machine. -
Page 19: Recycling Instruction For Packaging
Installation manual 4.2 Recycling instruction for packaging fig.X02395 Fig. Description Code Type Wrapping film LDPE 4 Plastics Corner protection PS 6 Plastics Cardboard packaging PAP 20 Paper Pallet FOR 50 Wood Screw FE 40 Steel FE 40 Steel Plastic bag PET 1 Plastics... -
Page 20: Siting
Installation manual 4.3 Siting Install the machine close to a floor drain or open drain. The machine should be positioned so that there is plenty of room for working, both for the user and service personnel. The figure shows minimum distance to a wall and/or other machines. Failure to respect the prescribed distances will prevent easy access for maintenance and service operations. -
Page 21: Mechanical Installation
Installation manual 4.4 Mechanical installation Foundation requirement In this type of machine, the drum is attached directly to the frame. As a result the floor under the machine must be stable enough to absorb the dynamic forces generated during spin cycles. For that reason, the mounting bolts must be cast into the floor material itself. - Page 22 Installation manual After the machine has been placed over the other four M16 bolts, at the expansion M10 bolts (1), place the two square spacers (t = 4 mm / 3/16 inch) over the two holes. They shall be placed between the machine and foundation. Insert the expansion bolts (1) into the holes drilled in the floor.
-
Page 23: Casting A Plinth
Installation manual 4.4.1 Casting a plinth A plinth should be used where the existing floor is less than 200 mm / 7 7/8 inch thick or in order to ensure that the machine is above the level of any water leakages. The plinth should be approximately 150 - 200 mm / 5 7/8 —... -
Page 24: Chemical Bolts / Chemical Anchors
Installation manual 4.4.2 Chemical bolts / chemical anchors An alternative to breaking up the existing floor or foundation is to use chemical bolts M16. 1. Mark and drill four holes (⌀ 18 mm / 11/16 inch) 125 mm / 5 inch deep for the chemical bolts. Check the previous table for the correct position of the holes. - Page 25 Installation manual fig.7644C...
-
Page 26: Water Connection
Installation manual 5 Water connection All water intake connections to the machine should be fitted with manual shut-off valves and filters, to facilitate instal- lation and servicing. Water pipes and hoses should be flushed clean before installation. The machine shall be connected with new water hoses. Re-used water hoses must not be used. Hoses are to be of an approved type and grade and comply with national regulations. - Page 27 Installation manual Water-inlet fittings have either 3/4” NH (garden hose) or DN20 (3/4” BSP) threads. All models except EED-645 have 3/4" NH threaded on all inlet valves. On EED-645 there are DN20 (3/4” BSP) threaded at position (1), (2) and another one at position 3 which is 3/4” NH threaded.
-
Page 28: Connection Of External Dosing Systems
Installation manual 6 Connection of external dosing systems 6.1 Connection of the hoses The machine is prepared for connection of external dosing systems or water re-use systems etc. The connections are closed at delivery. Open any of the connections that shall be used by drilling a hole where the hoses shall be connected. -
Page 29: Electrical Connection Of External Dosing System
Installation manual 6.2 Electrical connection of external dosing system The power supply to the external dosing system must never be connected to the machine’s incoming terminal block or to the edge connectors on the I/O-board. 6.2.1 Machine with connectors Connect the external dosing system to connections A and B on the machine. Connect the signal cable to B and the power supply to A. -
Page 30: Machine Without Connectors
Installation manual 6.2.2 Machine without connectors Connect the external dosing system to the I/O board, which is located to the right of the incoming power supply. The I/O board has edge connectors for connecting external dosing systems. Edge connectors on the I/O board can be loosened for connecting cables. fig.6572 11 = N 18 = Program run... -
Page 31: Outputs
Installation manual 6.2.3 Outputs Connect the power supply (e.g. 24V DC) for the external liquid supplies to 9 and 10. If an internal power supply (from the machine) is being used, it can be taken from 1 (N) and connected to 9 and from 2 (L) and connected to 10. Max load on the outputs 0.5 A. -
Page 32: Inputs
Installation manual 6.2.4 Inputs The signal level can be 5-24V DC/AC or 100- 240V AC. For 5-24V, the signal reference is connected to 3 and for 100-240V to 4. Potentials on the inputs cannot be mixed. Note! The I/O board will be damaged if the voltage on connection 3 is too high > 24V. Connection 8 may be connected if the program is to pause, e.g. -
Page 33: Drain Connection
Installation manual 7 Drain connection Connect a 75 mm / 3 inch pipe or rubber hose to the machine’s drain pipe, ensuring a downward flow from the ma- chine. Avoid sharp bends which may prevent proper draining. fig.5330 Drain pump (for models EED-618, EED-620, EED-625) The drainage pipe should be located over a floor drain, drainage channel or the like. -
Page 34: Electrical Connection
Installation manual 8 Electrical connection 8.1 Electrical installation The electrical installation may only be carried out by qualified personnel. Machines with frequency-controlled motors can be incompatible with certain types of earth leakage circuit break- er. It is important to know that the machines are designed to provide a high level of personal safety, which is why items of external equipment such as earth leakage circuit breakers are not necessary but is recommended. -
Page 35: Electrical Connections
Installation manual 8.2 Electrical connections EED-618 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse ITCB A Electric heated 208-240V 1~ 3.0/5.4/7.5 3.4/5.7/7.8 20/30/40 208-240V 3~ 3.0/5.4/7.5 3.4/5.7/7.8 15/20/25 440V 3~ 5.4/7.5 5.7/7.9 15/15 480V 3~ 5.4/7.5 5.7/7.9 15/15 Non heated/Steam heated... - Page 36 Installation manual EED-645 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse ITCB A Electric heated 208-240V 1~ 4.8/13.0 5.3/13.5 30/70 208-240V 3~ 4.8/13.0 5.3/13.5 20/40 440V 3~ 13.0 13.5 480V 3~ 13.0 13.5 Non heated/Steam heated 120/440/480V 1/3~ 208-240V 1~ Total power and recommended fuse does not depend on the heating power in those cases.
-
Page 37: Machine Connection
Installation manual 8.3 Machine connection Connect the earth and other wires as shown. Single-phase connection Three-phase connection 1N/1 L2/N L2 L3... -
Page 38: Machine Connection With Ferrite
Installation manual 8.4 Machine connection with ferrite 8.4.1 EED-665, EED-685 To obtain approved level of EMC, it is mandatory to use the ferrite which is enclosed with above listed models. (Note that this is only valid for those models). Before connecting to the machine, the protective earth (PE) wire shall be wrapped around the ferrite. Prepare the power cord by making sure the protective earth (PE) wire is longer than the other wires according to the table. -
Page 39: Functions For I/O-Cards
Installation manual 8.5 Functions for I/O-cards The electrical schematic can be one of the following: 8.5.1 External coin meter/Central payment (2A) The signal received from external coin meters must be a pulse between 300–3000 ms (500 ms is recommended) with a minimum pause of 300 ms (500 ms is recommended) between two pulses. fig.6606A... -
Page 40: Central Payment (2B)
Installation manual 8.5.2 Central payment (2B) To start the machine from a central payment system, the payment system must transmit a start pulse to the machine. The start pulse can be either 230V or 24V. In order to receive a feedback signal once the machine has started, 230V or 24V must be connected to connection 19. -
Page 41: Central Payment (2C)
Installation manual 8.5.3 Central payment (2C) The central payment or booking system shall transmit an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the machine door is closed but the program has not started. -
Page 42: Outputs For Detergent Signals And Inputs For Pause Signals, "Empty" Signal And Price Reduction (2D)
Installation manual 8.5.4 Outputs for detergent signals and inputs for pause signals, "empty" signal and price reduction (2D) The figure shows standard function addressing for machines with the coin program package. By maintaining an active (high) signal on connection 5 ("Price red"), the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day. -
Page 43: Central Booking/Payment (2F)
Installation manual 8.5.5 Central booking/payment (2F) The central payment or booking system shall provide an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the program is running. -
Page 44: Machines With I/O Module Type 3
Installation manual 8.5.6 Machines with I/O module type 3 By maintaining an active (high) signal on connection 3 "Price reduction”, the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day. Whilst the sig- nal remains active (high), the price of the program is reduced by the percentage entered in the price programming menu. -
Page 45: Steam Connection
Installation manual 9 Steam connection Inlet pipes connected to the machine must be equipped with a manual shut-off valve to facilitate installation and serv- icing. The connection hose must be of type ISO/1307- 1983 or equivalent. Connection size at filter: DN 15 (BSP 1/2"). Demount the top panel (A). -
Page 46: At First Power Up
Installation manual 10 At first power up When the installation is complete and the power is connected for the first time you will be forced to make the following settings. When one setting is ready you will automatically enter the next one. •... -
Page 47: Function Check
Installation manual 11 Function check May only be carried out by qualified personnel. A function check must be made when the installation is finished and before the machine can be ready to be used. Open the manual water valves. Start a program. •... -
Page 48: Disposal Information
Installation manual 12 Disposal information 12.1 Disposal of appliance at end of life Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of the structure that can give or break during scrapping. The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. - Page 50 www.electroluxprofessional.com...
