Sherco SEF250 / SEF300
What's in the box ?
2 NE01-11-001 - THF 6x25mm screws
3 NE01-04-002 - Clamped bolts
2 NE01-02-002 - TFHC 6x20mm screws
1 NE01-02-003 - TFHC 6x25mm screws
4 NE01-02-004 - TFHC 6x30mm screws
6 NE01-04-003 - EM6F bolts
6 NE01-03-001 - M6 washers
2 PM01-04-288 - HDPE rear hooks
1 NE04-01-274 - Sticker
1 PM01-06-086 - Rear plate n°51
The paper instructions may be limitless, scan the QR
code to watch the tutorial video online.
This tutorial shows a different skid plate but the mounting
is the same.
Approximate time of assembly: 15 minutes.
A skid plate is made to protect the vital components of your bike and does not have a « life warranty ».
However, production default may happen and we cover it during the first year of use.
In case of premature breakage, please write to contact@axpracing.com
AX1758
Xtrem skid plate
Factory 4-stroke
Assembling
instructions
