- Page 1 MANUAL INSTRUCTIONS ARON Electric Radiator PLEASE READ AND SAVE THESE INSTRUCTIONS...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS: • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 3 • The heater must not be located immediately below an electrical socket-outlet. • The heater must not be located in front of a socket-outlet • Don’t use this heater in the immediate surroundings of a bath, a shower or a swimming pool. •...
- Page 4 I / ELECTRICAL CONNECTION • Your heater must only be installed in a fixed position in accordance with national installation rules (for France, NFC 15100) • INDOORS USE ONLY • This installation must be done by a qualified electrician to avoid any danger.
- Page 5 correctly fixed to the wall.
-
Page 6: Technical Characteristics
Technical characteristics: Heating element Ceramic core Voltage 230V~ 50Hz Wattage 700W, 1000W, 1500W, 2000W Temperature setting Range 7–30 °C 0.5 °C Resolution IP rating IPX0... - Page 7 Appliance class Class II Motion sensor (5.8G band) Operation frequency 5725-5875MHz Max RF power transmitted -3.43 dBm WiFi frequency (2.4G band) Operation frequency 2400-2483.5MHz Max RF power transmitted 18.2 dBm Modes: Comfort Mode, Eco Mode, Anti-freeze Mode, Timer Mode, Sensor Mode LCD Display: Icon description Icon description UP button...
- Page 8 Operation descriptions to turn on the device, press key to switch between modes, browsing through Comfort , ECO , Anti-freeze , Timer , and Sensor mode 3.1 Comfort Mode to start Comfort mode, and tap key to adjust the temperature setting, stepping by 0.5 ℃.
- Page 9 3.3 Anti-freeze Mode to switch Anti--freeze mode. Default temperature is 7℃ . This is not adjustable. When the device is heating, heating icon will display on the screen; if not heating, the icon will disappear. 3.4 Timer Mode to switch Timer mode, displaying “00:00” 3.4.1 when first connection to electricity 3.4.2 Press and hold...
- Page 10 stepping by 1H. Press to run comfort mode displaying , press to run ECO mode, displaying For example: P1: Comfort mode--8:00-22:00 the rest time is ECO mode, shown as: It displays set time during the setting timescale under the working state. The icon flashes 3s and goes out 1s in Comfort mode;...
- Page 11 In OFF state, press key for 5S to set up internal settings, tap key to switch modes- temperature compensation(F0)→ Sensor mode(F1)→Open Window function(F2)→Limit function(F3)→WiFi function(F4)→time synchronization(F5) 4.1 Temperature compensation F0: keys to adjust the temperature, Adjustable range is -5~5℃,stepping by 1℃. Default is 0.
- Page 12 Wifi connection 1- Turn on WiFi function,WiFi icon flickers 2-Download APP name Smart life on Smart phone or certain web,( different Android/ IOS versions will affect partial APP function, also possible to cause its work) 3.Download APP, register and log-in ,Press Auto Scan to add device, when searching it, press next 4.
- Page 13 On the App : Open and log in Smart life, tap ‘add device’ to search for and add device ,shown as Step next and have it done, then come to home page, shown as Following the operations on homepage interface...
-
Page 14: Reset To Defaults
Reset to Defaults: When plugged to the power source, press button for 10S to reset factory configuration. Full screen displays for 3S and switch off,. press again to turn on the device, displaying COMFORT temperature- 19℃, ECO temperature- 15.5℃, time “0000”, day of the week “1”,P1-P7 is defaulted ECO, temperature compensation -“0”, Open Window function- “oF”, Sensor time- “15”, Limit function- “H0”, WiFi –“oN”,Time synchronization-oN... - Page 15 Information requirements for electric space heaters 700W Model 1000W 1500W 2000W Heat output Nominal heat output (Pnom/kw) Minimum heat output (indicative) (Pmin/Kw) Maximum continuous heat output (Pmax.c/kw) Auxiliary electricity consumption At nominal heat output (el /KW) At minimum heat output (el /KW) 1.05 1.05...
- Page 16 This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.
