- Page 1 USER MANUAL TOUCH COMPUTER M1-156IC-W3-A2 M1-156IC-W5-A2 M1-215IC-W3-A2 M1-215IC-W5-A2 Rev 2081423.1...
-
Page 2: Table Of Contents
Table of Contents About This Document ................. 4 Compliance Information ................5 Important Safety Instructions ..............7 Usage Notice ......................7 Precautions....................... 7 Warnings ........................9 Installation Tips ..................10 Product Overview ..................11 Unpacking .......................11 Package Contents ....................12 Product Setup and Use ................ - Page 3 Optional Accessory Installation ............23 Installing the Stand ....................23 Removing the Stand ....................24 Installing the MSR ....................25 Removing the MSR....................25 Installing & Removing the Camera ................. 26 Installing & Removing the Barcode Scanner ............26 Installing & Removing the Light Bar ................ 26 Appendix ....................
-
Page 4: About This Document
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of MicroTouch a TES Company. -
Page 5: Compliance Information
Compliance Information For FCC (USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 6 Renseighements relatifs à la conformité Pour la FCC (États-Unis) Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe B selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
-
Page 7: Important Safety Instructions
Important Safety Instructions Before using this product, please read the user manual thoroughly to help protect against property damage and to ensure your personal safety and the safety of others. Be sure to observe the following instructions. For installation or adjustment, please follow the instructions in this manual and refer all servicing to qualified service personnel. - Page 8 Avis d’utilization Mise en garde Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à la terre. Précautions Veuillez suivre toutes les mises en garde, précautions et entretiens recommandés dans ce manuel d’utilisation pour maximiser la durée de vie de votre unité.
-
Page 9: Warnings
Warnings To turn off touch computer power, press the “Power” button on the right side on the back of the touch computer. When the Power button is pressed, the main power of the touch computer is not turned off completely. To disconnect power completely, remove the power plug from the outlet. -
Page 10: Installation Tips
Don’t use a damaged power plug or worn outlet. The use of extension cords is not recommended. The use of the power supply that comes with the MicroTouch product is strongly recommended. Don't place the touch computer on an unstable shelf or surface. -
Page 11: Product Overview
Product Overview These desktop touch computers with Windows operating system are designed and developed to provide a flexible desktop touch computer solution with easily installed optional MSR, Camera, Light Bar and Barcode Scanner accessories. Their versatility make them exceptional choices for applications in all business sectors, especially in the retail market. -
Page 12: Package Contents
Package Contents Part Picture LCD Touch computer M1-156IC-W3-A2 or M1-156IC-W5-A2 or M1-215IC-W3-A2 or M1-215IC-W5-A2 AC Power Cord (1.8 m) AC-DC converter... -
Page 13: Product Setup And Use
24VDC NOTE: USE THE CORRECT POWER SUPPLY. MicroTouch touch computer models have similar power connectors, but M1-156IC/215IC-A2 operate on 24 VDC. If you have a combination of different touch computer models, it is crucial to check the voltage rating on the power converter to ensure it matches the correct voltage requirement for your specific touch computer model. -
Page 14: Network Connection
There are four peripheral connection points, one on each side and the top and bottom sides. Connection is by provided USB Type-C connectors for both power and data. These peripheral points/ports are for MicroTouch-supplied accessories only. See the Optional Accessory Installation section for details. -
Page 15: Turning The Touch Computer On And Off
Turning the Touch Computer On and Off Function Description Power On Press and release the Power button Sleep, Restart, Use the Windows OS power controls and Shutdown Press and hold the Power button for 4 seconds to force power off Forced power Off (it is recommended to use the Windows Shutdown option) -
Page 16: Mounting Options
Mounting options The touch computer may be mounted to a stand, arm, or other device that has a 100mm x 100mm standard VESA mount hole pattern. VESA Mount The touch computer has an integral VESA standard mount pattern that conforms to the “VESA Flat Display Mounting Interface Standard”... -
Page 17: Specifications And Dimensions
Specifications and Dimensions Specifications Item Category Specifications Operating System Windows Windows 10 Enterprise LTSC W3 models: 1215UE W3 models: 6C8T, 3.3/4.4 GHz, 10M Cache Processor W5 models: 1245UE W5 models: 10C12T, 3.3/4.4 GHz, 12M Cache W3 models: 1215UE W3 models: Intel ®... - Page 18 Specifications Power Adapter Output 24VDC, 7.5A max Audio Speakers 2 x 2W MicroTouch optional Accessory Ports 4 x USB Type-C with mounting points accessories only 156IC-A2 models: 378.03 mm x 227.34 x 34.5 mm 14.88 in x 8.95 in x 1.36 in...
-
Page 19: Dimensions, 156Ic-A2 Models, Without Stand
Dimensions, 156IC-A2 models, without stand Front view Side View... -
Page 20: Dimensions, 215Ic-A2 Models, Without Stand
Dimensions, 215IC-A2 models, without stand Front view Side View... -
Page 21: Dimensions, 156Ic-A2 Models, With Stand
Dimensions, 156IC-A2 models, with stand Front view Side View... -
Page 22: Dimensions, 215Ic-A2 Models, With Stand
Dimensions, 215IC-A2 models, with stand Front view Side View... -
Page 23: Optional Accessory Installation
Optional Accessory Installation Note: Power the touch computer down before installing/ removing accessories. Note: Installation is the same regardless of which model you choose. Installing the Stand Place the touch computer face down on a clean padded surface. Step 1: Place the stand on the VESA mount and align the screw holes. Step 2: Install the four M4 screws to secure the stand to the touch computer. -
Page 24: Removing The Stand
Removing the Stand Step 1: Place the touch computer face down on a clean padded surface. Step 1: Loosen the four screws Step 2: Pull the stand away from touch computer and remove. -
Page 25: Installing The Msr
Installing the MSR The MSR is best installed on the right of the touch computer, as viewed from the front, to accommodate the majority right-handed users. Step 1: Insert a small, pointed tool into the notch in the middle of the accessory port cover and pry the cover loose from the accessory port. -
Page 26: Installing & Removing The Camera
Installing & Removing the Camera The steps are the same as for the MSR except that the camera should be installed in the top accessory port to preserve the proper image orientation. Installing & Removing the Barcode Scanner The steps are the same as for the MSR. Any accessory port may be used. Installing &... -
Page 27: Appendix
Appendix Cleaning Turn off the product and disconnect from AC power before cleaning. Turning the product off protects against accidental touch selections that could cause problems or hazardous results. Disconnecting power protects against hazardous interaction between accidental liquid entry and electricity. To clean the case, dampen a clean cloth lightly with water and a mild detergent and wipe gently. -
Page 28: Warranty Information
Warranty Information Except as otherwise stated herein, or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touch computer and its components is three years. Seller makes no warranty regarding the model life of components. -
Page 29: Rohs Declaration
RoHS Declaration Equipment name：Touch LCD Touch computer Type designation (Type) ： M1-156IC-W3-A2 M1-156IC-W5-A2 M1-215IC-W3-A2 M1-215IC-W5-A2 Restricted substances and their chemical symbols Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd) (PBDE) (PBB) Plastic Parts ○... - Page 30 TES AMERICA LLC | 215 Central Avenue, Holland, MI 49423 | (616) 786-5353 The information presented in this user manual is intended as general information about MicroTouch products and is subject to change. Product specifications and warranties will be governed by TES America, LLC. Standard terms and conditions of sale. Products are subject to availability.
