Summary of Contents for Miele CS1322 BG
- Page 1 Installation Instructions CS1322 BG en - CA Installation, repair and maintenance work should be performed by a Miele authorized service technician in accordance with national and local safety regulations and the provided installation instructions.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Children WARNING- When using your Children should not be left appliance follow basic unattended in an area where the precautions, including the appliance is in use. Never allow following: children to sit or stand on any part of the appliance. - Page 3 Before servicing, disconnect the appliance from the main power supply. Installation, repair and maintenance work should be performed by a Miele Do not operate any appliance with a authorized service technician. Work by damaged cord or plug, or if the...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS Safety Be aware of loose fitting or hanging garments when operating the The appliance is hot during use and appliance, they may present a fire remains so for some time after being hazard. switched off. Be careful not to touch the appliance if it may still be hot.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS To prevent burns and breathing difficulty, allow the appliance to cool before cleaning. Some cleaners may produce toxic fumes if applied to a hot surface. When wiping spills on a hot appliance with a wet sponge or cloth, be careful to avoid steam burns.
-
Page 6: Safety Instructions For Installation
This appliance has not been designed for maritime use or for use in mobile installations such as recreational vehicles or aircraft. However, under certain conditions it may be possible for installation in these applications. Please contact the Miele Technical Service Department with specific requirements. - Page 7 SAFETY INSTRUCTIONS FOR INSTALLATION Safety distances above the If there is more than one appliance appliance beneath a hood (e.g. wok burner and electric grill), and they have different minimum safety distances always observe the greater distance. The minimum safety distance given by the hood manufacturer must be maintained between the grill and the hood above it.
- Page 8 SAFETY INSTRUCTIONS FOR INSTALLATION Safety distances to the sides of the appliance The appliance should only be installed as shown in the illustrations while 2 " (50 mm) maintaining the required safety distances shown. Do not install the appliance between two tall cabinets, this is a fire hazard.
-
Page 9: Installation
Installation Safety distance when installing the appliance near a wall with trim or a back splash A minimum distance of 2" (50 mm) between the trim or back splash and the countertop cut-out if required. This distance is only necessary if these items are made of combustible materials e.g. - Page 10 Installation Installation dimensions a Spring clips b Appliance front c Installation height d Power supply box with connection cable, L = 78 " (2000 mm) e Drain valve...
- Page 11 Installation Cut out If during installation the seal around ^ Make the worktop cut-out for one or the frame does not sit flush with the more appliances as applicable. countertop in the corners, the corner Remember to maintain a minimum radius, maximum "...
-
Page 12: Installation Of Multiple Appliances
Installation Installation of multiple appliances When installing more than one combiset appliance, a support bar b must be installed between the appliances. Countertop cut-out Countertop cut-out two appliances three appliances 6 " 6 " For the installation of two appliances For the installation of three appliances the width of the countertop cut-out D is the width of the countertop cut-out D is... - Page 13 Installation Sample calculations for a countertop cut-out for three appliances appliance width appliance width appliance width Countertop minus " (8 mm) minus " (8 mm) cut-out 11" " 11" " (280 mm) (280 mm) (848 mm) (288 mm) 11" 15" "...
- Page 14 Installation " 3 / 1 6 1 " - 1 0 m m ( 2 5 - 3 2 " 2 " ( 5 0 m ( 5 0 m 2 " 2 " " 3 / 1 6 ( 5 0 m ( 5 0 m 6 "...
-
Page 15: Attach The Spring Clips And Support Bars
Installation Attach the spring clips and support bars Wood or solid surface countertops Granite countertop " 3 / 1 6 " 3 / 1 6 1 " - 1 1 " - 1 0 m m ( 2 5 - 3 0 m m ( 2 5 - 3 ^ Position and attach the spring clips... - Page 16 Installation ^ Coat the edges of the spring clips a, ^ and the space d between the strips b and the countertop with silicone (supplied).
- Page 17 Installation Installing the appliance ^ Feed the power cord down through the cut-out. ^ Then place the front side of the appliance in the countertop cut-out. ^ Then with a hand on each side of the appliance press down evenly on the edges until it clicks into position.
-
Page 18: Tiled Surfaces
Installation Sealing Tiled surfaces The appliance must not be permanently The grouting a and shaded area under sealed into the countertop when the appliance frame must be flat and installed. The sealing strip under the even, so that the frame will lie evenly edge of the appliance provides a and the sealing strip under the edge of sufficient seal for the countertop. -
Page 19: Electrical Connection
Electrical connection Power supply CAUTION: Before installation or ^ Be sure your electrical supply servicing, disconnect the power matches the data plate. supply by either removing the fuse, shutting off the main power supply The combiset is equipped with a or manually "tripping"... - Page 20 Alteration rights reserved / 4608 M.-Nr. 07 374 400 / 00 For the most updated manual see the Miele web site.
