NOTICE:
The chain saw is not filled with oil at the time of
purchase. It is essential to fill the tank with oil before use.
The chain is automatically lubricated with chain oil during
operation, if there is sufficient oil in the oil tank.
1. Position the chain saw on its side with the tank cap
facing upwards.
2. Clean the oil tank cap and the area around it to ensure
that no dirt falls into the oil tank.
3. Lift up the semicircular plate and rotate the oil tank
cap counterclockwise to remove it (Fig. H).
4. Carefully pour the bar and chain oil into the tank. Fill to
the bottom of the fill neck.
5. Wipe off any excessive oil and replace the cap.
NOTICE:
Check the oil level frequently and fill when the
oil level falls below the minimum line. Never operate the
chain saw if the oil is not visible.
USING THE LANYARD EYELET (Fig. H)
WARNING:
Always cover the saw chain and
guide bar with chain sheath when hanging the chain
saw on a tool belt. Saw chain is sharp and may cause
serious injuries.
WARNING:
Make sure the lanyard is sufficiently
strong to support the combined weight of the chain
saw and the battery pack. Serious injuries and property
damage could result if the chain saw falls.
ATTACHING/DETACHING THE BATTERY PACK
Use only with EGO's battery packs and chargers listed
in Fig. A2.
Fully charge before first use.
To Attach
Align the battery ribs with the mounting slots and press
the battery pack down until you hear a "click" (Fig. I).
To Detach
Depress the battery-release button and pull the battery
pack out (Fig. J).
WARNING:
To keep comfortable balance during
cutting, please use only with the battery pack BA1400/
BA1400T.
STARTING/STOPPING THE CHAIN SAW
NOTICE:
Before starting the chain saw, check for the oil
level, chain tension, saw teeth sharpness and properly
working kickback brake paddle. Besides, balanced footing
and proper distance away from the ground are needed.
56 VOLT LITHIUM-ION CORDLESS TOP HANDLE CHAIN SAW — CS1200E
To Start (Fig. K)
1. Pull the chain-kickback brake paddle towards the front
handle to the operating position (Fig. K).
2. Firmly grasp the front handle with the left hand and
the rear handle with the right hand.
WARNING:
To avoid injury, always use the chain
saw with the right hand grasping the gripping area of the
rear handle (Fig. L).
3. Move the locking tongue forward and then press the
trigger switch to start the saw (Fig. L).
L-1 Gripping Area
4. Release the locking tongue and continue to squeeze
the trigger switch for continued operation.
5. The further the trigger switch is depressed, the
greater the chain speed. Adjust the speed to suit the
task at hand.
WARNING:
Do not attempt to start the saw when the
saw chain is in a cut.
To Stop
1. Move the chain saw away from cutting area, and
then release the trigger switch to stop the chain saw.
2. Push the chain-kickback brake paddle forward to the
brake position to engage the chain brake (Fig. K).
WARNING:
Always remove the battery pack from
the machine during work breaks and after finishing work.
PROPER GRIP ON HANDLES (FIG. M)
◾
Wear non-slip gloves for maximum grip and protection.
◾
With the saw on a firm, flat surface, hold the saw firmly
with both hands.
◾
Always grasp the front handle with the left hand and
the rear handle with the right hand.
◾
The fingers should encircle the handle, with the thumb
wrapped under the front handle.
WARNING:
Never use a left-handed (cross-handed)
grip, or any stance which would place your body or arm
across the chain line.
WARNING:
Do not operate the trigger switch with
your left hand and hold the front handle with your right
hand. Never allow any part of your body to be in the chain
line while operating a chain saw (Fig. N).
PROPER CUTTING STANCE (FIG. O)
◾
Both feet should be on solid ground, with weight evenly
spread between them.
