Network Video Recorder
User Manual
2.5.0.78
Information in this document is subject to change without notice.
© Copyright 2024. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-1200 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Digiever DS-1200 Series

Summary of Contents for Digiever DS-1200 Series

  • Page 1 Network Video Recorder User Manual 2.5.0.78 Information in this document is subject to change without notice. © Copyright 2024. All rights reserved.

  • Page 2: Table Of Contents

    Table of Contents Chapter 1. Introduction ................7 Hardware Description ................8 1.1.1 DS-1200 Series ................... 8 1.1.2 DS-2200 UHD Series................9 1.1.3 DS-2200 UHD+ Series ..............10 1.1.4 DS-4200 UHD Series................. 11 1.1.5 DS-4200 UHD+ Series ..............12 1.1.6 DS-4200-RM UHD Series ..............
  • Page 3 2.2.2 Connect to the NVR Through Computer in Local Network Environment ....................39 2.2.3 Connect the Computer to The NVR Directly ......... 42 Utility Software ..................43 2.3.1 NVR Search ..................43 2.3.2 Upgrade Tool .................. 50 2.3.3 NVRPlayer ..................64 2.3.4 NVR Check ..................
  • Page 4 3.4.1. Steps to Playback Videos ............125 3.4.2. Description of Recording Types ........... 128 3.4.3. Main Functions of Playback ............130 3.4.4. Data Search .................. 133 3.4.5. AI Search ..................136 3.4.6. Export Files ..................141 3.4.7. Snapshot ..................142 3.4.8.
  • Page 5 4.2.8 Save/Load E-Map configuration ..........196 Playback ....................197 4.3.1 Steps to Playback Videos ............197 4.3.2 Description of Recording Types ........... 202 4.3.3 Multi-NVR Playback ..............203 4.3.4 Time-divided Search ..............206 4.3.5 Smart Search ................. 208 4.3.6 AI Search ..................211 4.3.7 Bookmark ..................
  • Page 6 5.2.7 Event & Action Management ............270 5.2.8 Advanced Setting ................ 284 5.2.9 Chain Event ................... 286 5.2.10 Data Management ............... 287 5.2.11 Event & Action Summary ............. 288 5.2.12 E-Mail ..................... 289 Disk Management ................291 5.3.1 iSCSI ....................291 5.3.2 Disk Management ................
  • Page 7 5.7.1 PoE Control ..................368 5.7.2 POS System ................... 370 5.7.3 Device Web Link ................372 5.7.4 Modbus IO Device ............... 373 5.7.5 AI Box .................... 375 5.7.6 AXIS IO Device ................378 5.7.7 Access Control ................379 5.7.8 UPS Management ................. 385 5.7.9 Stack Light ..................

  • Page 8: Chapter 1. Introduction

    Chapter 1. Introduction Before You Use This Product When you first open the product’s package, verify that all the accessories listed on the “Package Contents” of “Quick Installation Guide” are included. Before installing the NVR, please read the instructions in the “Quick Installation Guide” to avoid misuse and then follow the instructions in the “Hard Disk Installation”...

  • Page 9: Hardware Description

    1.1 Hardware Description 1.1.1 DS-1200 Series Figure 1-1 Front & Rear View Power button Power LED indicator System Status LED Indicator Network LED Indicator USB LED indicator HDD LED Indicator One-Touch Backup button 1 x USB 3.2 Gen 1x1 port (for auto video backup) HDD1 10.

  • Page 10: Ds-2200 Uhd Series

    1.1.2 DS-2200 UHD Series Figure 1-2 Front & Rear View Power LED Indicator System LED Indicator HDD LED Indicator Network LED Indicator USB backup button with LED indicator USB 3.2 Gen 1x1 port (for auto video backup) HDD1 HDD2 2 x HDMI 2.0a output (upper port is HDMI2, lower port is HDMI1) 10.

  • Page 11: Ds-2200 Uhd+ Series

    1.1.3 DS-2200 UHD+ Series Figure 1-3 Front & Rear View Power LED Indicator System LED Indicator HDD LED Indicator Network LED Indicator USB backup button with LED indicator 1 x USB 3.2 Gen 2x1 port (for auto video backup) HDD1 HDD2 2 x 2.5 Gigabit Ethernet ports 10.

  • Page 12: Ds-4200 Uhd Series

    1.1.4 DS-4200 UHD Series Figure 1-4 Front & Rear View Power LED Indicator System LED Indicators HDD LED Indicator Network LED Indicator USB backup button with LED indicator USB 3.2 Gen 1x1 port (for auto video backup) HDD1 HDD2 HDD3 10.

  • Page 13: Ds-4200 Uhd+ Series

    1.1.5 DS-4200 UHD+ Series Figure 1-5 Front & Rear View Power LED Indicator System LED Indicators HDD LED Indicator Network LED Indicator USB backup button with LED indicator USB 3.2 Gen 2x1 port (for auto video backup) HDD1 HDD2 HDD3 10.

  • Page 14: Ds-4200-Rm Uhd Series

    1.1.6 DS-4200-RM UHD Series Figure 1-6 Front & Rear View HDD LED Indicator Network LED Indicator Power LED Indicator One-touch backup button with LED indicator 2 x USB 3.2 Gen 1x1 ports HDD1 HDD2 HDD3 HDD4 10. Reset button 11. Digital Input/Digital Output (4-in, 4-out) (L) VIN (max 24V), DI_GND, DI-4, DI-3, DI-2, DI-1, OCOM, DO-4, DO-3, DO-2, DO-1 (R) 12.

  • Page 15: Ds-8X00-Rm Uhd Series

    1.1.7 DS-8x00-RM UHD Series (DS-8200-RM UHD, DS-8300-RM UHD, DS-8400-RM UHD, DS-8500-RM UHD) Figure 1-7 Front & Rear View HDD LED Indicator Network LED Indicator Power LED Indicator One-touch backup button with LED indicator 2 x USB 3.2 Gen 1x1 ports HDD1 HDD2 HDD3...

  • Page 16: Ds-16X00-Rm Uhd Series

    *Note: The HDD sequence in horizontal order is for the serial numbers starting with 'N'. 1.1.8 DS-16x00-RM UHD Series (DS-16300-RM UHD, DS-16400-RM UHD, DS-16500-RM UHD, DS-167000-RM UHD) Figure 1-8 Front & Rear View HDD LED Indicator Network LED Indicator Power LED Indicator One-touch backup button with LED indicator 2 x USB 3.2 Gen 1x1 ports HDD1...

  • Page 17: Mn-2100 Uhd Series

    *Note: The HDD sequence in horizontal order is for the serial numbers starting with 'N'. 1.1.9 MN-2100 UHD Series Figure 1-9 Front & Rear View Power button LED indicators HMDI 2 (HDMI 1.4b) USB 3.2 Gen1x1 HDMI 1 (HDMI 1.4b) SD card, SIM1/2 socket (with cover) MIC (reserved) Line out (reserved)

  • Page 19: Led Indicators Status

    1.2 LED Indicators Status 1.2.1 DS-1200 Series Figure 2-1. Front Panel & RJ-45 Port LED on Front Panel Indicate LED Color & Status Power Off Blue Power On Power Blue blinking Waking from sleep mode Orange NVR is in sleep mode because UPS battery is too low.
  • Page 20 LED on RJ-45 Connection at Rear Panel LED Position Indicate LED/State No connection Speed Orange 1000 Mbps/100Mbps connection (Top LED) Green 2500Mbps connection LAN link is not established Link/Activity Green LAN Link is established (Bottom LED) Green LAN activity is occurring Note: Once users press reset button, configuration of Camera Setting, Recording Settings, Event &...

  • Page 21: Ds-2200 Uhd Series

    1.2.2 DS-2200 UHD Series Figure 2-2. Front Panel & RJ-45 Port LED on Front Panel Indicate LED Color & Status Power Off Blue Power On Power UPS power is from AC power mode to battery mode System is off or in sleep mode when UPS battery is too low Green blinking System goes on or goes off...
  • Page 22 LED on RJ-45 Connection at Rear Panel LED Position Indicate LED/State No connection/10Mbps connection LAN1 Speed Orange 1G/100Mbps connection LAN2 (Top LED) Green 2.5G connection LAN Link is not established LAN1 Link/Activity Green LAN Link is established LAN2 (Bottom LED) Green blinking LAN activity is occurring Note: *USB BACKUP will start and beep after 3 seconds user presses BACKUP button.

  • Page 23: Ds-2200 Uhd+ Series

    1.2.3 DS-2200 UHD+ Series Figure 2-3. Front Panel & RJ-45 Port LED on Front Panel Indicate LED Color & Status Power Off Blue Power On Power UPS power is from AC power mode to battery mode System is off or in sleep mode when UPS battery is too low Green blinking System goes on or goes off...
  • Page 24 LED on RJ-45 Connection at Rear Panel LED Position Indicate LED/State No connection/10Mbps connection LAN1 Speed Orange 1G/100Mbps connection LAN2 (Top LED) Green 2.5G connection LAN Link is not established LAN1 Link/Activity Green LAN Link is established LAN2 (Bottom LED) Green blinking LAN activity is occurring Note: *USB BACKUP will start and beep after 3 seconds user presses BACKUP button.

  • Page 25: Ds-4200 Uhd Series

    1.2.4 DS-4200 UHD Series Figure 2-4. Front Panel & RJ-45 Port LED on Front Panel Indicate LED Color & Status Power Off Blue Power On Power UPS power is from AC power mode to battery mode System is off or in sleep mode when UPS battery is too low Green blinking System goes on or goes off...
  • Page 26 LED on RJ-45 Connection at Rear Panel LED Position Indicate LED/State No connection/ 10Mbps connection LAN1 Speed Orange LAN2 (Top LED) 1G /100Mbps connection Green 2.5G connection LAN Link is not established LAN1 Link/Activity Green LAN Link is established LAN2 (Bottom LED) Green blinking LAN activity is occurring Note:...

  • Page 27: Ds-4200 Uhd+ Series

    1.2.5 DS-4200 UHD+ Series Figure 2-5. Front Panel & RJ-45 Port LED on Front Panel Indicate LED Color & Status Power Off Blue Power On Power UPS power is from AC power mode to battery mode System is off or in sleep mode when UPS battery is too low Green blinking System goes on or goes off...
  • Page 28 LED on RJ-45 Connection at Rear Panel LED Position Indicate LED/State No connection/ 10Mbps connection LAN1 Speed Orange LAN2 (Top LED) 1G /100Mbps connection Green 2.5G connection LAN Link is not established LAN1 Link/Activity Green LAN Link is established LAN2 (Bottom LED) Green blinking LAN activity is occurring Note:...

  • Page 29: Ds-4200-Rm Uhd Series

    1.2.6 DS-4200-RM UHD Series Figure 2-6. Front Panel & RJ-45 Port LED on Front Panel Indicate LED Color & Status LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed Hard disk drive device is not established 1.
  • Page 30 LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection connection LAN1 Speed 100Mbps connection LAN2 (Left LED) Green 1000Mbps connection...

  • Page 31: Ds-8X00-Rm Uhd Series

    1.2.7 DS-8x00-RM UHD Series (DS-8200-RM UHD, DS-8300-RM UHD, DS-8400-RM UHD, DS-8500-RM UHD) Figure 2-7. Front Panel & RJ-45 Port LED on Front Panel Indicate LED Color & Status LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed Hard disk drive device is not established 1.
  • Page 32 LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection connection LAN1 Speed 100Mbps connection LAN2 (Left LED) Green 1000Mbps connection...

  • Page 33: Ds-16X00-Rm Uhd Series

    1.2.8 DS-16x00-RM UHD Series (DS-16300-RM UHD, DS-16400-RM UHD, DS-16500-RM UHD, DS-167000-RM UHD) Figure 2-8. Front Panel & RJ-45 Port LED on Front Panel Indicate LED Color & Status LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed Hard disk drive device is not established 1.
  • Page 34 LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection connection LAN1 Speed 100Mbps connection LAN2 (Left LED) Green 1000Mbps connection...

  • Page 35: Mn-2100 Uhd Series

    1.2.9 MN-2100 UHD Series Figure 2-9. Front Panel Indicate LED Color & Status Power off Power Blue Power on Hardware Failure, please contact supplier LAN Link is not established Green blinking LAN is being accessed 4G/5G network is not established WWAN Yellow 4G/5G network is ready...

  • Page 36: Dual/Mirror Display Solution: Hdmi Connection

    1.3 Dual/Mirror Display Solution: HDMI Connection NVR with 2 video outputs (HDMI) allows users to connect either one HDMI output or connect both two video outputs (HDMI+HDMI) at the same time for local display. Note: Dual display is supported in NVR UHD and UHD+ series. Note: 1024x768 resolution is not supported in dual display.
  • Page 37 2. Dual display scenario (for Full HD display resolution) Scenario: If both monitors are Full HD (1920x1080), those will be shown as Full...

  • Page 38: Chapter 2. Nvr Installation

    Chapter 2. NVR Installation Remote Client PC System Requirements The following information is the minimum required specification for remote Windows PC, which users can open a remote browser from the PC to access the Linux NVR server on the network. Operating System ...
  • Page 39 Remote Computer Requirement to Enable DG-Decode Powered by Intel GPU technology, Linux NVR server supports GPU hardware acceleration decode for H.265 and H.264 IP camera on remote monitoring and playback to reduce CPU utilization and enhance video fluidity to display multi- channel high-resolution cameras.

  • Page 40: Connect To Nvr

    Connect to NVR There are 3 methods to connect to the NVR: Local display via HDMI connection Connect to the NVR through computer in local network environment Web browser Install NVR Search to quickly find NVR in the local network Connect the computer to the NVR directly 2.2.1 Local Display via HDMI Connection...
  • Page 41 Web Browser (Microsoft Edge, Chrome, Firefox, Opera) Step 1. Connect the NVR to the local network (router or switch) Step 2. Enter the NVR’s IP address in the web browser. Note: There are 2 methods to set network: Obtain an IP address automatically (NVR Default) ...
  • Page 42 Note: All browsers will be closed when installing the software application. Install NVR Search to quickly find NVR in the local network Step 1. Please download NVR Search from official website (or request from our sales team) and install it to client’s computer. Step 2.

  • Page 43: Connect The Computer To The Nvr Directly

    2.2.3 Connect the Computer to The NVR Directly If you need to use a computer to set up the NVR in a non-networked environment, you can use the docking method. Step 1. Please connect NVR and computer via LAN cable. Step 2.

  • Page 44: Utility Software

    Utility Software Please download the utility software to your PC from our webiste or contact our sales team for request. 2.3.1 NVR Search NVR Search can help you to quickly find NVR in the local network Please follow the instructions to install and NVR Search will run automatically. When installing NVR Search, Shield Wizard window for NVR Search will pop up.
  • Page 45 Read the license agreement and click “I accept the terms of the license agreement”. Click “Next” to continue installation. Select a location of destination and select a folder where the setup can install files. The default location is: C:\Program Files (x86)\NVR\NVR Search. Users can also install NVR Search in other folder by clicking “Change”...
  • Page 46 The window shows that the InstallShield Wizard is installing NVR Search. Please wait until the Wizard completes the installation. The InstallShield has successfully installed NVR Search. Select “Create Desktop Shortcut”/ “Create Quick Launch Shortcut”/ “Create Start Menu Shortcut” and please click “Next” to continue.
  • Page 47 The installation is complete. Please click “Launch application when done installing” to execute NVR Search. After finishing the setup, the window of NVR Search will pop up. NVR Search will execute automatically and show NO., Name, IP Address, Mac Address and Model name of connected NVR. Users can click “Search”...
  • Page 48 Introduction of NVR Search NVR Search provides three kinds of toolbars for users: File You can click “Exit” to leave NVR Search and close the window. Setting Configure UPnP and Network by clicking “Setting” in the top left or in the middle right.
  • Page 49 When accessing the NVR setting, users will be prompted to enter username and password. For the first-time use, the default username and password are admin/admin. When the correct username and password have been entered, click “Login” to continue. 1) UPnP Universal Plug and Play (UPnP) simplifies the process of adding a NVR to a local area network.
  • Page 50 2) Network NVR provides two network settings: DHCP and Static IP. Option Option provides users to change language.

  • Page 51: Upgrade Tool

    2.3.2 Upgrade Tool “Upgrade Tool” helps you to upgrade several NVRs to the latest firmware version. Please follow the instructions to install and Upgrade Tool will run automatically. When installing Upgrade Tool, Shield Wizard window for Upgrade Tool will pop Click “Next”...
  • Page 52 The window shows that the InstallShield Wizard is installing Upgrade Tool. Please wait until the Wizard completes the installation. The installation is completed. Please click “Launch application when done installing” to execute Upgrade Tool. And click “Finish”.
  • Page 53 Find the NVR [Method1] Search NVR that is in the same LAN with the PC After finishing the setup, the window of NVR Search will pop up. Upgrade Tool shows No., Device Name, Model Name, IP Address, Current Firmware and Password of the connected devices. Click “Search”...
  • Page 54 If the device password is NOT the default password, user can manually enter the password in the password bar and then press “Enter” on the keyboard. After typing the correct password, the password bar will show “Passed” and current firmware will show automatically.
  • Page 55 If the password is not correct, the password bar will show “Failed”. [Method2] Add NVR in WAN Click “Add” button to add the internet and unsearchable device. A window will pop up to ask for the information to add the device.
  • Page 56 Type the IP Address, Port and Password and click “ ”. The Device will be added in the device list. Select NVRs and upload firmware Select the devices at the left column to upgrade firmware. Users can click “Select All” or “Cancel All” button to select or cancel all the devices.
  • Page 57 Click “Browse” to upload firmware file to upgrade the devices. A window will pop up to ask for the folder to upload the firmware.
  • Page 58 Select the file and click “Open”. After selecting the file, firmware file path will show. Please click “Upgrade” button. Start to upgrade Upgrade tool offers two upgrade methods: [Method1] Upgrade Now [Method2] Schedule Upgrade [Method1] Upgrade Now Select “Upgrade now” and click “OK” button.
  • Page 59 A window will pop up to make sure the execution . Please click “Yes” button. The window will show the upgrade process of each device. Uploading firmware file… Executing firmware upgrading… After upgrading successfully, the progress column will show Firmware upgrade successful.
  • Page 60 Users can double click the device to log in NVR. If the upgrading is not successful, the progress column will show the message. Progress column information Status Progress Column Suggestion Firmware upgrade Successful successful. Failed! Please check the Check if the password is correct in username device list.
  • Page 61 [Method2] Schedule Upgrade Users can upload firmware in user-defined date and time. Note: Please ensure “Upgrade Tool” is running to execute schedule upgrade. Select “Schedule upgrade” ① Edit date/time. ② Click “OK” button. ③ After finished “Schedule upgrade” setting, the device will be marked in orange. Note: The device marked in orange cannot be selected.
  • Page 62 Users can go to “Schedule Upgrade” page to check the status. Status column information: Upgrade procedure: Status Indicate Standby for the configured schedule time to Standby upgrade. Uploading file... Please Uploading firmware. wait a few minutes Upgrading The device is upgrading. Firmware upgrade Upgrade is finished...
  • Page 63 (1) Modify “firmware path” and “schedule time” Select device(s) ① Note: Users can click “Select All ” or “Cancel All ” button to select or cancel all the devices. Click “Modify” button ② Modify “firmware path” and “schedule time” ③ Click “OK”...
  • Page 64 Settings User can change the language of Upgrade Tool. Note: The default language is based on Windows OS”s language setting.

  • Page 65: Nvrplayer

    2.3.3 NVRPlayer NVRPlayer allows users to view the recorded videos exported from NVR. It is a portable tool with no need to install on PC. NVRPlayer can play multi-channel videos via playlist which is exported from instant export. For more information about export videos to PC, please refer to 4.3.10 Export. One-channel playback Users can intuitively add multi-files by 2 methods: [Method 1]: Select desired videos or playlist from desktop...
  • Page 66 Note: You can click “Don’t remind me next time” to ensure the function is enabled. The pop-up dialog box will not display next time. Play all videos from the same camera in the folder The feature allows users to select one video of specific camera and all videos of this camera will be listed in NVRPlayer’s camera list.
  • Page 67 [Method 2]: Enabling/disabling the feature from setting. Go to NVRPlayer Click Setting ① Enable/disable “Play all videos from the same camera in the folder” ② Press “OK” ③ Multi-channel playback via playlist Click to select the desired video or playlist. If users select a playlist to play multi-channel videos, please select cameras, start/end time.
  • Page 68 NVRPlayer will display playback video time on the top-left corner for time reference. Right-click on the video to execute fisheye camera dewarping. Users can move “Time Bar” to desired time when playing recorded video. Draggable column: After videos files are added to NVRPlayer, the files will list on the right column.
  • Page 69 Feature introduction (1) Frame by Frame Playback Please click “Pause” button and click “Next Frame” or “Previous Frame” to find the desired video precisely. (2) Snapshot Please click “Snapshot” button to take a photo to your PC. (3) Settings View settings: to display camera name or video time ①...

  • Page 70: Nvr Check

    2.3.4 NVR Check NVR Check is a useful tool to verify whether the video files are originated from NVR. Please follow the instructions to install and NVR Check will run automatically. Install Shield Wizard window will pop up and please click “Next” to continue installation.
  • Page 71 agreement.” Click “Next” to continue installation. Select a folder where the setup can install files. The default location is: C:\Program Files (x86)\NVR\NVR Check. Users can also install NVR Check in other folder by clicking “Change” and select a location as below. Once a folder is selected, please click “OK”...
  • Page 72 The window shows that the InstallShield Wizard is installing NVR Check. Please wait until the Wizard completes the installation. The InstallShield has successfully installed NVR Check. Select “Create Desktop Shortcut”/ “Create Quick Launch Shortcut”/ “Create Start Menu Shortcut” and please click “Next” to continue.
  • Page 73 The installation is completed. Please click “Launch application when done installing” to execute NVR Check. After finishing the setup, the window of NVR Check will pop up. Introduction of NVR Check While NVR is recording video and snapshot files, the digital watermark will be embedded automatically in the images.
  • Page 74 If the recording file is originated from NVR, NVR Check will show “No error occur.” If the recording file has been changed, NVR Check will show “There is an error in the video file.” To know more information, please ask the manufacturer by providing detailed information in “Detail”...

  • Page 75: Quick Configuration

    Quick Configuration After users log in NVR, the system will direct you to set Quick Configuration in five main steps. Follow the instructions of the Overview of wizard to complete system setup. 2.4.1 Start System will lead you to “Start” from the drop-down menu of Configuration Utility to begin.

  • Page 76: Network Settings

    2.4.2 Network Settings Please select “Network Settings” from the drop-down menu of Configuration Utility to begin. Users need to adjust the settings in the Network Setup page in order to let NVR work properly within network. There are 2 methods to configure IP address 1.

  • Page 77: Server Settings

    To assign a static IP address to the NVR: 1. Select “Specify an IP address” 2. Enter the IP address, Subnet Mask, Default Gateway IP Address and DNS server address. 3. If IP address is changed, user needs to log out NVR and login in again. Click “Next”...

  • Page 78: Date & Time

    2.4.4 Date & Time Please select “Date & Time” from the drop-down menu of Configuration Utility to begin. Manual setting Define a suitable date format for local display’s liveview and playback. Note: For NVR-Client (Liveview and Playback) and NVRPlayer, date format is specified for operating system (Windows OS).

  • Page 79: Disk Management

    Time Zone: Synchronize with an Internet time server automatically. Select the time zone of your area and update the date and time of the NVR automatically with an NTP server. User also has an option to automatically adjust daylight saving time. Configure the time and date by verifying and adjusting current local time and daylight saving to avoid the following errors: Incorrect display time for playback videos.
  • Page 80 Once an available hard disk drive is inserted into the tray, Disk Information will show in Device Information and users can start to create new RAID Disk. Disk Information Device Information provides details of the hard disk drive: HDD Model, Serial NO., Capacity, Status, S.M.A.R.T Status, HDD temperature information, and etc.
  • Page 81 NVR will pop out a notice on liveview page. Please select one HDD and set up warning degree of power-on hours. When the HDD has been active over user-defined hours, Power-on Hours will turn from black to orange, a pop-out message will display on Liveview, HDD status remains Ready, and the HDD LED will remain Green light.
  • Page 82 (3) Smart System Fan Control and HDD’s Temperature Display Smart system fan control will detect HDD’s temperature every 10 minutes and adjust to suitable fan speed automatically. The figure below is a comparison table of smart system fan control and a safe hard disk temperature range: (4) Erase Data for RAID Rebuilding When you encounter RAID degraded, it is necessary to replace the failed HDD...
  • Page 83 Note: NVR will automatically rebuild RAID when you replace the failed HDD with a brand- new HDD. Note: If you replace the failed HDD with a HDD used on other device before (not a brand- new HDD), NVR will not execute RAID rebuilding until you erase data. Create As the hard disk drive is available, the status of Device Information shows “Ready,”...
  • Page 84 Meanwhile, Target RAID Disk is ready to build RAID disk and it shows 6 types of disk configuration. Select a type of disk configuration, and click “Apply” to execute building new RAID disk. Note: Don’t turn off the server or unplug any hard drives when RAID Disk is in building process The introduction of disk configuration is in the below table.
  • Page 85 Fault A minimum of 3 hard disk drives are required to create RAID5. Tolerant The data are striped in all hard drives in a RAID5 array and the (RAID 5) parity information is stored in each drive. If a hard disk drive fails, the array enters degraded mode.
  • Page 86 NVR will show its approximate rebuilding time and percentage if it is created to RAID 1/5/6/10 (with fault tolerance ability). Finally, the RAID disk building is complete when the progress shows none. After the RAID disk is created, RAID List shows RAID Name and available storage devices.
  • Page 87 Please change the failed inactive FAILED RAID is abnormal. HDD immediately Note: NVR supports single HDD storage volume that allows NVR to store videos to each HDD one by one. Note: NVR supports multi-RAID configuration that allows users to quickly add extra HDD for future HDD expansion requests with no need to stop current recording task.
  • Page 88 User can remove or format RAID disk by selecting the RAID disk. In the table, RAID Name, RAID type, Capacity and Status are shown. Volume Status Introduction: Volume Status Subject Description Main volume Only main volume is in used. Can be No volume is in used (RAID A) removed.
  • Page 89 To delete RAID Disk, click “OK” to proceed. Please wait. The deletion is in a process. If users want to change the RAID level setting, please click “Remove.” After the RAID Disk is removed, the Status in Device information shows “Ready,” then users can go back to Create page to continue the new RAID level configuration.
  • Page 90 Once “Format” is clicked, a window will pop up to ensure the execution. To format RAID disk, click “OK” to continue. Hard disk drive is formatting. Please wait for formatting until 100%. After the RAID disk is formatted, device Information shows status - “active”...

  • Page 91: Camera Settings

    2.4.6 Camera Settings NVR offers 2 modes to add camera, including Online Mode: Add online camera to NVR (Default) Offline Editing: Pre-add offline camera information to NVR for users who have no camera on hand (It is designed for system integrator’s time to quickly connect IP camera to NVR at the site.) Depending on whether users have cameras on hand or not, users can select a proper mode to add camera.
  • Page 92 After clicking “Apply” button, vendor, username and password will be automatically filled in by vendor’s default information. Note: By enabling RTSP port, users can edit camera’s RTSP port number, especially when camera is set in the WAN. Note: Users can enable HTTPs port it is supported by the integrated camera. Please wait for NVR processing.
  • Page 93 To delete the camera, click “OK” to proceed. Note: NVR will pop-out a message when new settings are not saved. [Method 2] UPnP Search: UPnP Search Click “UPnP Search” to find out UPnP devices within the LAN. Note: Please make sure IP camera supports UPnP Search function. Note: Please go to IP Camera web page to enable UPnP search function.
  • Page 94 Note: Users can click “All” to add cameras in Added column. Note: The Added column will show two numbers to display the total channels of the NVR and the channel numbers that has been already added in the NVR. Please check camera information in Group add page. Then, click “Add All” button to start adding cameras.
  • Page 95 You may click “Cancel” button to stop camera adding progress. Status column in camera list will display “Successful” when cameras are successfully added in NVR. Please click “Go to Camera Settings” button to check all camera information camera list that is successfully added in NVR. [Method 3] ONVIF Search For cameras that cannot be found via UPnP search, please use ONVIF Search.
  • Page 96 [Step 1] Search camera via ONVIF Search in the same LAN Press ONVIF Search ① Select the desired cameras from the list or All to add all cameras ② Press Add ③ [Step 2] Add camera via Quick Add...
  • Page 97 The selected cameras are listed. ① Edit camera name, username, and password if needed Press Quick Add. ② The result shows Successful. The cameras have been added. ③ Press Go to Camera Settings to view camera lists that have been added. ④...
  • Page 98 After users click “OK” button, the header of camera information will turn to blue as below Fill in camera information one by one and Click “Save” button. [Step2] On-site Setup: Make camera and NVR at the same LAN [Step3] Online Mode 1.
  • Page 99 Note: In camera setting page’s camera list, camera in offline editing mode will be shown in orange. Note: In camera setting page, NVR will pop-out a message as below if NVR detects any camera is in offline editing mode. The Description of Camera Settings: (1) Memorize modified username and password: NVR can memorize username and password which is modified by users after users click “Apply”...
  • Page 100 (2) Streaming Parameters NVR provides three options to set up stream parameters during adding cameras: Optimization by NVR, Settings from camera and Quick Add via ONVIF search. Note: Streaming Parameters will not be applied when users change Camera Name/Username/ Password/ Recording Enabled. This feature is designed for cameras that have been added to NVR so that camera parameter remains the same.
  • Page 101 adding cameras. This option allows NVR to receive basic camera settings, parameter includes H.265/264, resolution, frame rate, audio, video quality, preset point. Comparison: 3 options of stream parameters setup (3) Multi-channel Video Server NVR supports multi-channel video server to connect analog cameras to NVR. Users are asked to enter IP Address.
  • Page 102 (5) Generic RTSP(TCP)/Generic MJPEG/Generic RTSP(UDP) (for Detect method only) For cameras without native integration, NVR allows users to add cameras via Generic RTSP(TCP), Generic MJPEG and Generic RTSP(UDP) to receive the video streaming from IP camera. The streaming will be applied to monitoring, recording and playback.

  • Page 103: Finish

    ote: The most correct URLs should be provided from each camera vendors. Note: Users may also refer to websites https://www.soleratec.com/rtsp/ - http://www.ispyconnect.com/sources.aspx 2.4.7 Finish Please select “Finish” from the drop-down menu of Configuration Utility to begin. Once 5-step Quick Configuration are completed, simply click “Start Liveview” to start monitoring.

  • Page 104: Chapter 3. Use Nvr By Local Display

    Chapter 3. Use NVR by Local Display NVR can be connected to a monitor via HDMI/VGA port to execute quick configuration and display live view. Note: Local display feature is supported in UHD and UHD+ series To start local display, please check the steps below: 1.

  • Page 105: Anonymous Login

    Note: If NVR detects that the monitor does not support 1920x1080 resolution, the resolution option in login page will show 1920x1080 (*). In this mode, NVR will be forced to offer the resolution of 1920x1080 to the monitor. Note: Remote login page locked will not affect to Local login and vice versa. 3.1.1.

  • Page 106: Microsoft Active Directory (Ad) Account

    3.1.2. Microsoft Active Directory (AD) Account NVR supports Microsoft Active Directory (AD) domain service to centralize user privilege accounts (power users and users) to log in NVR. Please refer to 5.6.1 User Management to enable AD account. Then, the option ”Use Active Directory (AD) Account” will be shown for AD account logon.

  • Page 107: Selectable Login Entry

    3.1.4. Selectable Login Entry Selectable Login Entrance enables user to directly access desired interface among liveview, playback and configuration page. Icon Description Liveview: Click “Liveview” to control the monitoring instantaneously. Playback: Click “Playback” to play recorded video files. Configuration: Click “Configuration” to configure camera, recording, event, management, network, quick configuration and system.

  • Page 108: Liveview

    Liveview After the Quick Configuration is complete, users can successfully monitor IP cameras. In live view page, users can monitor cameras in various display modes and control PTZ cameras. 3.3.1 Select View Modes on Liveview Page On top right of live view, users can select four view modes. Mode Description Liveview:...

  • Page 109: Main Functions Of Liveview

    3.3.2 Main Functions of Liveview 1. Camera status Icon Icon Color & Status Indicate White word with black background at the top left Camera name corner White word with black Video compression format, such background as H.265/ H.264/ M-JPEG/ MPEG- at the top middle corner 4/ MxPEG Recording...
  • Page 110 NVR information (1) Firmware version User can easily find out the firmware version in the live view page. (2) Disk space usage and system loading indicator: Users can find out Disk and system loading directly without entering configuration page. Disk space usage and system loading indicator shows blue when loading is 70% or under, and shows red as a warning when it exceeds 70%.
  • Page 111 Add all cameras from monitoring. Audio / Mute: Alter sound instrument of microphone and speaker Audio on Audio off (Mute) Date & Time: Show the specific day and time. Display mode NVR supports multi-display modes for monitoring. Click the icon of display mode to monitor live view.
  • Page 112 Click to choose the page of liveview 5. PTZ Control Panel If the IP camera supports PTZ function, user can use the control panel or joystick to adjust the viewing angle. The following functions are available depending on the camera models. Note: Please check the compatible list before using joystick to adjust PTZ cameras.
  • Page 113 Select a Preset Point from up to 128 preset points ① Enter Interval (3~1200 seconds) ② Select Moving Speed: Fast, Normal, Slow ③ Note: Moving Speed is supported for Canon cameras now. Click “Add” button (Up to 25 preset points can be ④...
  • Page 114 3. Define the maximum of auto cruising ① Click this option ② Enter the number (1-999) times Schedule for PTZ: Click “Go” to start PTZ patrol schedule. 6. Exclamation Mark Exclamation mark icon is designed to instantly notify users of camera disconnection and configured events.
  • Page 115 (1) General Change all channel setting at the same time: Video size & Tripwire display ① Only a right click on the video, users can set “all” video size either in original size or fit size and visible tripwire display or invisible tripwire display. (1) Video Size (2) Tripwire Display:...
  • Page 116 Highlight video window when an event is triggered ② A warning frame will be shown when an event is detected. User can simply click on the channel with mouse, the warning frame will be stopped. Liveview event notification with single and quattro video pop-out window ③...
  • Page 117 If user enable all cameras in the NVR will have event pop-out window, all channels in NVR camera list will pop-out a video when events happen. Note: NVR will pop-out video event window once at a time, depending on which event is triggered earlier when more than one event is triggered at the same time.
  • Page 118 > 16 CH: stream2 (lower resolution) Note: In 4K resolution mode, when NVR displays more than 9-channel on local liveview, NVR will switch to stream 2 by default. (≤ 9 CH: stream1; >9 CH: stream2) (2) Screen 2 Enable display mode for screen 2 Monitor connected with port of HDMI 1 is screen 1 and monitor connected with port of HDMI 2/VGA is screen 2.
  • Page 119 (3) Sequential Mode Setting To set up sequential interval: 4~6000 sec When users fill in unavailable numbers, a window will pop out to remind users: The “Sequential Interval” range: 4~6000 (4) Microphone Volume Based on camera site audio volume, users can adjust the volume percentage of USB type microphone from NVR local display.
  • Page 120 (5) OSD & Pointer Setting To show on-screen display information on liveview and snapshot. To define a suitable pointer to operate NVR for diverse distance of monitor. Note: Mobile NVR will display GPS data when OSD is enabled. The GPS data will be stored on the system HDD for one month.

  • Page 121: Right Click Functions On Video Window

    3.3.3 Right Click Functions on Video Window 1. Video Size: Original or Fit 2. Streaming change: NVR allows users to setup the dual streaming configurations in camera parameter page if cameras support dual stream. It is suggested stream 1 is set for higher resolution and stream 2 for lower resolution, which helps users to choose the proper streaming in live view with intuitive control.
  • Page 122 (1) 1/2/3/4/5+1/6/8/9/10/12/12+1-ch display mode: liveview image automatically show the main stream (stream1) (2) 16/20/25/30/36/42/49/56/64-ch display mode: liveview image automatically show the sub stream (stream2) When “Optimize” is disabled, users can manually adjust streaming type, which will be memorized in different display modes. Note: In 4K display mode, when users select the display mode with more than 9ch, NVR will automatically change to stream2 for smooth real time viewing experiences.
  • Page 123 4. Tripwire Display: to show/hide camera’s tripwire 5. Toggle Fullscreen: to execute/exit full screen 6. Camera Status Bar: Users can hide or display camera status bar depending on user preference. 7. Instant Playback: To instantly play recorded video while simultaneously views live-view. (Up to 15 minutes earlier) Users can take a snapshot or export a 5 minutes video to external USB device.
  • Page 124 Users can execute panomorph dewarp or set up video size via its right-click menu. Note: The resolution of instant playback is based on recording settings. 10. Moving Speed (PTZ): to adjust moving speed for ONVIF PTZ camera. 11. Auto Tracking: to efficiently monitor and track the suspicious locked persons or vehicles (support camera brand: Hanwha).

  • Page 125: Zooming With Mouse Scroll

    3.3.4 Zooming with Mouse Scroll In addition to digital zoom in/out button, users can use mouse scroll to prevent potential crisis in live-view monitoring. Note: For PTZ cameras, zooming with mouse in live-view is adopted optical zoom in/out. If users would like to view more detailed image, please use zooming with mouse scroll first and then click digital zoom in/out button.

  • Page 126: Playback

    Playback Playback is a function that allows users to view recorded videos from cameras connected to NVR. NVR offers synchronized playback up to 16 cameras with different perspectives at the same time and easy steps provided to help users sort through the recorded videos quickly. Note: NVR local playback supports: 7 consecutive calendar days to retrieve footage.
  • Page 127 Please follow the following four steps to start playback: 1. Select cameras from camera list 2. Select date and time period 3. Select recording type 4. Click “Play” 1. Select cameras from camera list Users can select up to five cameras to play the recorded video. 2.
  • Page 128 specific date and time in Start Time and End Time column. 3. Select recording type There are six types of recorded videos in different colors: Normal Record (gray), Event (red), Video Clip (yellow), Recovered File (blue), Time Overlap (green) Device(gray). The date will change the color of background when users select different recording type.

  • Page 129: Description Of Recording Types

    Frame by Frame Playback 1. Follow above four steps to playback 2. Click “Pause” button 3. Click “Backward” or “Forward” button Advanced Setting for Backward/Forward Button The feature provides flexibility in locating critical objects when using “Backward” or “Forward” button, and is aimed optimizing playback process for finding...
  • Page 130 Video Clip (yellow): Video Clip means a brief video clip set by user to manage on event triggered recording file, allowing to be sent by E-mail as well and user can change the Pre-time (up to 10 sec.) and Post-time (up to 10 sec.) in Configuration Page>...

  • Page 131: Main Functions Of Playback

    3.4.3. Main Functions of Playback 1. Display mode NVR supports multi-channel simultaneous playback. You can see the recording time of each channel on the top of each grid. Icon Description 1 screen 4 screen 5 screen Note: 1024x768 resolution does not support 5 screen Full Screen 2.
  • Page 132 4. Video playback speed control Stop: to clear playback videos ① Previous frame: to show the earlier frame (by second) ② Slow motion: to play in slower speed ③ Play/Pause: to play video file or to temporarily stop the playback ④...
  • Page 133 7. Video export and Snapshot Users can export specific time rage of videos and take snapshots to an external USB device. Please refer to 3.4.5 Export file and 3.4.6 Snapshot. 8. Thumbnail on Playback With the mouse over timeline, a thumbnail will show the snapshot, date, time and camera name.

  • Page 134: Data Search

    3.4.4. Data Search Data Search is designed to quickly find out key event data recorded in NVR. There are four main categories supported for data search: 1. Camera Event: Connection Lost, Motion Detection, Audio Detection, Cross- line Detection, Temperature Detection, Digital Input, Tampering Detection, Loiter Detection, Foreign Object Detection, Miss Object Detection, Advanced Motion Detection, Human Detection, etc 2.
  • Page 135 1. Export the list (csv file) 2. View and save snapshot 3. Play and save video clip Click “Data Search” button . A window will pop up to start configuration. Select event category, event type, time range and select device(s). Then, click “Search”...
  • Page 136 7. Video: click icon to review video clip Finally, users can click to export event list in csv file. Note: For people counting tab, NVR supports two search types, including event history (people counting threshold notice) and data analysis (5/15/30-minute, hourly, daily, weekly, monthly basis time analysis).

  • Page 137: Ai Search

    3.4.5. AI Search AI Search provides a metadata-based Video Analytics playback solution that aims to efficiently gather metadata from integrated AI cameras and general cameras through an integrated AI Box. Users can swiftly find key objects by configuring attributes such as people, vehicles, faces, and events, facilitating advanced playback and post-event analysis.
  • Page 138 User-interface introduction Device panel Attributes panel Search time range selector (HH:MM, max. 3 consecutive days) Search button Play Pre-event time setup Total result numbers Results listing Image’s date/time, Camera name Tool tips 10. Playback window 11. Playback control panel & seek bar...
  • Page 139 [How to use]: Please go to camera’s web configuration page to enable AI functions if needed. Add AI camera to NVR Please refer to 2.4.6 Camera Settings Launch AI Search Setup attributes: Select AI camera when searching from integrated AI cameras ①...
  • Page 140 Gender, Age, Gender: Male, Female Singular /Multiple Face Headwear, Mask, Age: Young, Adult, Middle, Choices Glasses Senior Event Type Supported Brand* Motion Detection 1, 2, 3, 4, 5, 6 Intrusion Detection 3, 4, 5, 6, Loitering Detection 3, 4, 5, 6 Cross Line Detection 3, 4, 5, 6 Audio Detection...
  • Page 141 Execute Search Click Search icon to start Searching View Results & Playback The result list ① View the total result numbers ② Move the mouse over any of results to view the tool tips ③ One-click any result to pop out playback window ④...

  • Page 142: Export Files

    3.4.6. Export Files Export function allows users to export file to USB device or USB type DVD burner directly. Please select cameras, video file types, date and the time period first, and then click the export button to copy the files. NVR will export Playlist for users to constantly view exported videos on both local NVR and remote PC (with NVRPlayer utility).

  • Page 143: Snapshot

    3.4.7. Snapshot Users can have the snapshot while having the playback in local display. It needs to plug in USB device for the export of snapshot images and it will have 10 sequential images to be saved in the USB dongle. 3.4.8.
  • Page 144 (1) Select a day from calendar, start/end time and Normal as video type (2) Select cameras from camera list (3) Click “Play” button (4) Focus a camera (shown in blue frame) (5) Click “Bookmark” button as bookmark start time (6) Click “Bookmark” button as bookmark end time. A window will pop out.

  • Page 145: Others

    3. Search Bookmark via Data Search – to filter bookmark results Click “Data Search” button Select Bookmark tab Select camera(s) Enter keyword (Optional) Select start/end time Click “Search” button Click 4 action icons: Play bookmark video ① Edit bookmark ② Export bookmark video ③...

  • Page 146: System Upgrade On Local Display

    3.5.2. System Upgrade on Local Display NVR supports system upgrade in local display. For more information, please refer to Chapter 5 - 5.8.5 System Upgrade. Note: System upgrade in local display is supported in UHD series and UHD+ series. 3.5.3. USB Backup by Hardware or Software USB BACKUP Buttons Users can easily back up recorded video by clicking “USB Backup”...

  • Page 147: Chapter 4. Use Nvr By Remote Client

    Chapter 4. Use NVR by Remote Client Users can monitor the network camera and view playback via NVR-Client. Via web browsers (Microsoft Edge/Chrome/Firefox/Opera browser in Windows), users can configure NVR’s settings. To execute liveview monitoring or video playback, it is necessary to install surveillance software application, NVR-Client.
  • Page 148 Read license agreement and click “I accept the terms of the license agreement.” Click “Next” to continue installation. Select a folder where the setup can install files. The default location is: C:\Program Files (x86)\NVR. Users can also install NVR-Client in other folder by clicking “Change”...
  • Page 149 Once a folder is selected, please click “OK” to continue installation. The window shows that the InstallShield Wizard is installing NVR-Client. Please wait until the Wizard completes the installation. Enable “Create Desktop Shortcut” and Click “Next” button. Via NVR-Client shortcut, users can log in liveview and playback page with no need of web browser.
  • Page 150 Note: When Microsoft Active Directory (AD) is enabled, “Use Active Directory (AD) Account” will be shown for AD account logon. Enable “Remember Username and Password” The NVR provides the option for enhancing user convenience, particularly for frequent visitors utilizing dedicated functions like Liveview, Playback or system management.

  • Page 151: Liveview

    Liveview After the Quick Configuration is complete, NVR will guide you to live view. Users can view live video stream from IP camera via network and monitor the instantaneous view remotely. Liveview displays the video according to the camera list which has been configured in camera settings of Quick Configuration.
  • Page 152 On top right of live view, users can select five modes. Mode Description Device Web Link: Click “Device Web Link” to access to external device web page. Note: Please refer to 5.7.3 Device Web Link to add external device information first. After configuration, select device(s) and click “OK”...

  • Page 153: Main Functions For Liveview

    4.1.2 Main Functions for Liveview (1) Multiplex window Multiplex window offers 3 modes. Click to switch the mode. (1) Camera list Camera list will be shown in default. To set up mini-CMS, please click below icon: for detail Please refer to 4.1.6 Built-in Mini-CMS Server information.
  • Page 154 (2) Camera status Icon Icon Color & Status Indicate White word with black background at the top left Camera name corner White word with black Video compression format, such as background H.265/ H.264/ M-JPEG/ MPEG-4/ MxPEG at the top middle corner Recording Red filled circle (Based on recording page’s setting)
  • Page 155 With changing the video configuration, like resolution, FPS and video quality or changing RAID type, can influence the CPU loading, and users can easily find the best balance in NVR. (4) Basic functions The function of each button will be briefly described below: Icon Description Snapshot:...
  • Page 156 Audio on Audio off (Mute) (5) Display mode NVR supports multi-display modes for monitoring. Click the icon of display mode to monitor live view. When you click a display mode, the mode icons will turn into blue. Icon Description 1 screen 4 screen 9 screen 12 screen...
  • Page 157 Sequential mode Click to choose the page of liveview (6) Camera Information NVR will show Camera name, IP address, bit rate and hardware decode status of the selected camera channel. Status Description Enable: H.265/H.264 hardware decode is enabled Disable: H.265/H.264 hardware decode is disabled Note: You can individually enable and disable hardware acceleration decode on liveview and playback’s setting page.
  • Page 158 Preset positions: Select the preset positions which are defined in PTZ camera and the camera will move to the position that user selects. Optical zoom in/out: If camera supports PTZ control, users can adjust PTZ camera to zoom out or zoom in. Focus near/far: If camera supports PTZ control, users can adjust the focus of the PTZ camera to focus near or focus far.
  • Page 159 Note: It is necessary to re-add the preset point, if its name has been modified. Note*: Canon & AXIS PTZ cameras supported [Advanced Settings] Modify PTZ auto cruising Select a Preset Point No. ① Change Interval and Moving Speed ② Click “Update”...
  • Page 160 Note: The default length of video clip for instant playback is 6 seconds. Users can edit the length of video clip by visiting configuration page: Recording & Event > Event & Action Management > Advanced Settings Enable Alert sound If users enable the function, the PC will sound the alarm to notify users when an event is triggered.
  • Page 161 Intuitive I/O alias name: User-defined I/O name to indicate what kind of ① event is triggered. Event pusher: Event will be pushed on the top of window and blink in ② color when I/O is triggered. Note: If there is more than one event are triggered, NVR will arrange them in I/O type order.
  • Page 162 A. Video size: original size or fit size Tripwire display: visible or invisible “Enable stream from Relay” for all channels ③ All cameras on liveview will take stream from NVR Relay server to satisfy multiple simultaneous monitoring requirements Highlight video window when event is triggered ④...
  • Page 163 When the motion event is awarded, user can simply click on the channel with mouse, the warning frame will be stopped. Enable alert sound ⑤ If users enable the function, PC will sound the alarm to notify users when motion detection is triggered. Liveview event notification with video pop-out window ⑥...
  • Page 164 A. __seconds later close the pop-out windows. (5-180) Users can select an optional feature to make the pop-out window automatically close after users assigned seconds. (Default is 10 seconds) B. All cameras in the NVR will have event pop-out window. If user enables event pop-out window for all cameras, all channels in NVR camera list will pop-out a video when an event is triggered.
  • Page 165 Snapshot Setting: ⑧ Bmp and jpg format are supported for snapshot. Enable auto-mute mode after idle operation lasts _______ seconds. ⑨ For preventing users from forgetting to hit the mute button after you finished the usage of two-way audio or two-way talk, users can define idle operation time range between 30 to 300 seconds.
  • Page 166 user-defined division. B. Multi-Server: Users can save the camera list of multi-server on live-view page. C. Sequential Mode Setting: General Sequential ① Click sequential interval to set the numbers of user-defined seconds for sequential mode. Focus Sequential Display (5+1, 12+1 display mode) ②...
  • Page 167 Focus Sequential Display offers three different sequential modes to provide high flexibility and meet varying monitoring demands: 1. Focus screen sequentially only (+1) 2. Secondary screens sequentially only (5 or 12-screen) 3. Focus screen and secondary screens sequentially simultaneously [Step1] Enable Focus sequential display feature Click Sequential Mode Setting ①...
  • Page 168 Select 5+1 or 12+1 display mode from the panel ① Click sequential icon to start (or stop) sequential display ② Drag any desired cameras from camera list to secondary screens. ③ D. Joystick Users are able to manipulate PTZ camera with USB joystick. Choose the joystick column and select joystick model then press “Apply”...
  • Page 169 E. OSD Setting 1) OSD Setting To show on-screen display information on liveview and snapshot. (Server name, camera name, time zone, and time) This setting applies to double-click to pop-out window on Emap. Note: Mobile NVR will display GPS data when OSD is enabled. The GPS data will store and keep for a month in OS HDD.
  • Page 170 Select “Position” ③ (Top left corner, top right corner, bottom left corner, and bottom right corner) Click OSD “color”setting button the select the OSD color and click ④ “OK”...
  • Page 171 OSD color and font size will be changed as below. ⑤ POS OSD Setting Enable this function, NVR will show on-screen display information from POS system on liveview and snapshot. (User-defined font size, color, and display time) More POS settings on configuration page, please refer to 5.7.2 POS System.
  • Page 172 Click OSD “color”setting button the select the OSD color and click ③ “OK” Select font size and click “OK” (Auto is default.) ④...
  • Page 173 Key in display time and click “OK” (1~60 secs) ⑤ OSD color and font size will be changed as below. ⑥...

  • Page 174: Right Click Functions On Video Window

    4.1.3 Right Click Functions on Video Window 1. Video Size: Original or Fit 2. Tripwire Display: to show/hide camera’s tripwire 3. Streaming change: to exchange the streaming resource. (1) Exchange Streaming NVR allows users to setup the dual streaming configurations in cameras parameters page if cameras support dual stream.
  • Page 175 (2) Enable Optimization Streaming type will be adjusted automatically for the user-defined division. When users select the division below 1/2/3/4/5/6/8/9/10/12 or “Low-resolution first”, NVR will automatically switch to the stream with the higher resolution or always low-resolution stream for liveview monitoring. When disable this feature, users can manually adjust streaming type, which will be memorized in different display modes.
  • Page 176 purpose and duplicate stream 1 for remote clients. The function allows users to minimize the influence of camera limitation and to reduce bandwidth usage. It also satisfies multiple clients simultaneous monitoring. For one camera in Full HD resolution, NVR allows up to 12 clients to adopt stream from NVR relay simultaneously.
  • Page 177 Select 5+1 or 7+1 display mode ① Define the areas of interest ② 10. Panomorph: To view the best image quality by dewarping engine. Note: NVR supports IP cameras equipped with Immervision’s Lens and VIVOTEK dewarping engine now. (1) Choose dewarp type: (2) Choose mounting type: (3) Choose display mode: 11.
  • Page 178 Users can configure image ratio/ full screen and execute panomorph dewarp/ROI via its right-click menu. Note: The resolution of instant playback is based on recording settings. 12. Speed Dry: to execute camera speed dry function 13. Digital Output: to turn on/off camera’s digital output 14.

  • Page 179: Zooming With Mouse Scroll

    16. Auto Tracking: to efficiently monitor and track the suspicious locked persons or vehicles (support for Hanwha camera) 17. Audio Pattern: remotely control TOA specific speakers from the NVR to broadcast emergency sounds or audio 4.1.4 Zooming with Mouse scroll In addition to digital zoom in/out button, users can use mouse scroll to prevent potential crisis in live-view monitoring.

  • Page 180: Two-Way Audio

    4.1.5 Two-way Audio Two-way audio allows user to remotely communicate via PC and IP cameras, which provides more flexibility in diverse surveillance applications. Applications: (1) Via speaker, users can hear sounds captured from remote camera sites to have the latest update. (2) Via microphone, users can reply it back to remote camera sites.
  • Page 181 Users can also select “Use Active Directory (AD) Account” to add NVR. NVR in LAN will appear, including the local NVR. Note: Multi-server list will show AD server connection successfully or not when users login with AD server account. Note: Rescan only supports NVR in LAN. Please choose NVR and camera which you are going to add to the local server, and click “OK”...
  • Page 182 [Method 2] Add Server Please click “Add Server” button to add NVR. Please enter IP address, port, username and password, and then click “OK” to apply. Users can also select “Use Active Directory (AD) Account” to add NVR. Note: “Login failed” will display due to AD login failure. Note: NVR can be manually added in WAN or LAN.
  • Page 183 Please choose NVR and camera which you are going to add to the local server and Click “OK” button. Then, new added channels will display in the cameras list on remote liveview page. 2. Delete NVR Right-click the NVR on camera list. Click “Delete” to delete NVR...

  • Page 184: Built-In Automatic Number Plate Recognition (Anpr/Lpr)

    4.1.7 Built-in Automatic Number Plate Recognition (ANPR/LPR) Automatic Number Plate Recognition is well-known as ANPR or LPR. NVR can be used as automatic number plate recognition solution for 24/7 real-time monitoring for traffic management and smartly analyze car number plates during video recording.
  • Page 185 Meanwhile, the camera icon will alter to 4 kinds of status based on the function in use (See Table 1). (2) Edit the detection area for ANPR/LPR Go to Liveview page 1. Right click on the camera channel 2. Select ANPR/LPR > Edit 3.

  • Page 186: Multi-Layer Dynamic E-Map

    (3) To activate dedicated ANPR/LPR channel Go to Configuration page & access URL http://Your_NVR_IP/cfg_management_licenseCheck.htm Select the license key file from your PC via “Browse” Press Check button License Verification page will pop-out if the license key is valid. Press Upgrade Note: System will display error message in status if error occurred.

  • Page 187: Feature Introduction

    Please click “E-Map” button to start monitoring via dynamic E-Map. An E-Map window will pop-out as below picture. 4.2.1 Feature Introduction Introduction of each column E-Map offers three columns for general setting: Edit map, Panel visibility and Settings. Users can drag the panels to the suitable place. (1) Edit map: please refer to 4.2.2 Add or Delete Multi-layer E-Maps for more information.
  • Page 188 Pin to Hide: To hide the panel to the edge of the window. Click the panel name to display the panel when needed. Delete: To close the panel. (3) Settings: to enable or disable automatically pop-up event window. Please refer to 4.2.4 Enable/ Disable Automatically Pop-up Event Window for more information.

  • Page 189: Add Or Delete Multi-Layer E-Maps

    Camera on Map: Camera in device panel is unable to drag to map since the camera has already added to one of maps. Icons for Modbus I/O devices: View the Modbus details: By hovering over the Modbus icon on the E-Map. Device Info includes NVR name, Modbus device name and DI Name.
  • Page 190 Note: The accepted image formats are PNG, BMP and JPEG. (2) Right-click on Map Panel: Right-click on the map to build sub-layer of map. 2. Zoom in / out the E-Map To zoom in or zoom out the E-Map, users can use the mouse scroll to enlarge or reduce the view of E-Map.

  • Page 191: Deploy Cameras

    4.2.3 Deploy Cameras 1. Add and delete camera on the map (1) Add a camera: Please drag and drop the camera icons in device list to the map to indicate camera location. After successfully adding camera on the map, camera icon in device panel will turn from (available camera) into (camera on map), and list under eMap panel.
  • Page 192 Note: Please refer to 5.7.4 Modbus IO Device for connecting to Modbus IO Device. (2) Camera Information: When you move the mouse cursor on a camera icon, camera information will display in a yellow column such as NVR IP address, Camera name and Camera IP address.

  • Page 193: Enable/ Disable Automatically Pop-Up Event Window

    Please right click on the camera icon to modify camera direction. 3. Change camera style Please right click on the camera icon to modify camera style. 4.2.4 Enable/ Disable Automatically Pop-up Event Window When a motion is triggered from IP camera or Modbus I/O device, a window will pop out to notify users and to display recording video.

  • Page 194: Double-Click To Pop-Out Video Window

    To close the window, users can manually close the pop-out event window. 4.2.5 Double-click to Pop-out Video Window Double-clicking to pop-out video window is designed for users check camera on E-map more efficiently. Users can have pop-out video window by two methods: (1) Double-click camera icon on map (2) Double-click camera name on device panel There are many functions on pop-out video window.

  • Page 195: Action Of Modbus I/O Event On E-Map

     The size of pop-out large video window is adjustable. Note: The adjusted size will be used the next pop-out video window. The adjusted size will be reset to default size when E-map window is closed. 4.2.6 Action of Modbus I/O event on E-Map The sequence of Modbus I/O event statuses: Normal >...
  • Page 196 ⚫ Enable Alert Sound When an event is triggered, The icons on map panel and map are blinking ② Click the icon to check the event, icon will switch from ③ *If enable alert sounds, the client PC will continuously receive alerts until the event is dismissed.

  • Page 197: Event Log History

    4.2.7 Event Log History Event log history offers a detailed and latest list of event history in event panel to make users easily control event situation. The event panel includes Instant Playback, Server Name, Date & Time, Camera Name, Camera No. and Description (Camera Connected, Camera Disconnected or Motion Detection.) By clicking in Instant Playback column, NVRPlayer will pop out to let users...

  • Page 198: Playback

    Playback Playback allows users to view recorded videos from cameras connected to NVR. NVR offers synchronized playback up to 16 cameras and easy steps to help users sort through the recorded videos quickly. Playback video can be viewed in full screen; snapshots can be taken and saved during a video playback.
  • Page 199 Enable DG-Decode (GPU hardware acceleration decode) Enable DG-Decode to leverage Intel GPU resource to playback multi-channel high-resolution cameras. The function can reduce CPU utilization and enhance video fluidity. Note: DG-Decode is enabled in default when your PC”s CPU specification is detected as supported.
  • Page 200 2. Select date and time Please select the date to search recorded videos. The date marked in blue background and white words has recorded video. If there is an event recording in the specific date, the date will be remarked as blue with red stripe aside.
  • Page 201 3. Select recording type Users can select five types of video file which is also displayed in Time table. These five types of video file are distinguished from different colors in timetable: Normal (Gray), Event (Red), Video Clip (Yellow), Recovery (Blue), Time overlap (Green)
  • Page 202 Frame by Frame Playback 1. Follow above four steps to playback 2. Click “Pause” button 3. Click “Backward” or “Forward” button Advanced Setting for Backward/Forward Button The feature provides flexibility in locating critical objects when using “Backward” or “Forward” button, and is aimed optimizing playback process for finding...

  • Page 203: Description Of Recording Types

    4.3.2 Description of Recording Types Normal (gray): Normal Record means there is no special conditions happened such as event, time overlap. It helps users to know at that time whether NVR has recorded videos or not. Event (red): Event means at least an event is triggered at that time, which helps users to efficiently find event recoded videos.

  • Page 204: Multi-Nvr Playback

    recording task. For examples, using NVR’s built-in NTP server to synchronize a required time, or alter the NVR server time manually, or change the time zone and enable daylight saving time. Failover (light blue): Failover means videos are recorded in failover server. Time-lapse (pink): Time-lapse means the video is condensed from capturing a series of...
  • Page 205 NVR in LAN will appear, including the local NVR. Note: Rescan only supports NVR in LAN. Please choose NVR and camera which you are going to add to the local server and click “OK” button. New added channels will display in the cameras list as below.
  • Page 206 [Method2] Add Server Please click “Add Server” button to add NVR. Please enter IP address, port, username and password, then click “OK” to apply. Note: NVR can be manually added in WAN or LAN. You can see the NVR in the list.

  • Page 207: Time-Divided Search

    Please choose NVR and camera which you are going to add to the local server and click “OK” button. Then, new added channels will display in the cameras list. 4.3.4 Time-divided Search The feature helps shorten searching time from the specified time range and quickly find out suspicious objects from divided videos in one window.
  • Page 208 [Step2] Split into more videos 1. Specify one channel, the time of the channel will turn to blue 2. Click “Next” to split more videos of specified period Note: 1. “Back” will direct you back to previous layer. 2. You may change display mode as optional choice. [Step3] Export videos or save snapshot Once finding the suspicious objects, users can click “Export Video”...

  • Page 209: Smart Search

    4.3.5 Smart Search Smart Search can efficiently save users’ precious time to find out key video moment without wasting extra effort and energy. Smart Search offers five quick search modes: motion detection, foreign object detection, missing object detection, camera tampering detection and lose focus. Please select cameras from camera list and the date that you would like to execute smart search.
  • Page 210 Select a specific camera, detection mode, time period and settings. Then, click “Search” button to start smart search. Introduction of settings: 1. Region of interest: the location for quick detection. Motion detection, foreign object detection and missing object detection are needed to arrange region of interest. (Motion detection has 3 regions of interest, and others have one region of interest.) 2.
  • Page 211 The smart search result window will pop-out. Users can set up event pre-time playing to playback the video before the event Please double-click on one of the smart search result to play the video.

  • Page 212: Ai Search

    4.3.6 AI Search AI Search provides a metadata-based Video Analytics playback solution that aims to efficiently gather metadata from integrated AI cameras and general cameras through an integrated AI Box. Users can swiftly find key objects by configuring attributes such as people, vehicles, faces, and events, facilitating advanced playback and post-event analysis.
  • Page 213 User-interface introduction Information of attributes & second layer options: Single/Multiple Attributes Items Second layer item & Options Choice Top: Color, Short, Middle, Long Singular/Multiple People Top, Bottom, Cap, Bag Bottom: Color, Short, Middle, Choices Long Car, Truck, Bus, Vehicle Motorcycle, Bike, Train, Color Singular Choice Forklift...
  • Page 214 Cross Line Detection 3, 4, 5, 6 Audio Detection 1,2, 5, 6 Missing Object Detection 3, 4, 5, 6 Tampering Detection 1, 2, 3, 4, 5, 6 Foreign Object Detection 3, 4, 5, 6 Restricted Zone Detection Shock Detection Face Detection Object Status Change 1, 2, 6 Social Distance Detection...
  • Page 215 Click on ① Select AI Search ② AI search will open in separate windows ③ Setup attributes People Select camera ① Select AI camera when searching from integrated AI cameras Select general camera when searching cameras from AI Box Click desired attributes: People ②...
  • Page 216 Description of icons: Vehicle Select camera ① Select AI camera when searching from integrated AI cameras Select general camera when searching cameras from AI Box Click desired attributes: Vehicle ② Setup search criteria for second layer: ③ Select Any to search all or, Select one specific vehicle type: Car, Truck, Bus, Motorcycle, Bike, Train, Forklift Click...
  • Page 217 Description of icons: Face Select camera ① Select AI camera when searching from integrated AI cameras Select general camera when searching cameras from AI Box Click desired attributes: Face ② Setup search criteria for second layer: ③ • Select Any to search all or, •...
  • Page 218 Description of icons: Event Select camera ① Select AI camera when searching from integrated AI cameras Select general camera when searching cameras from AI Box Click desired attributes: Event ② Setup event type: ③ Select Any to search all event or, Click to select desired event from the list (singular choice) Click “Apply”...
  • Page 219 Setup Search Date and Time Click on any column of date or time ① A calendar will pop up. ② Setup start/end date and time (up to 3 consecutive days) ③ Click “OK” to save the setting ④ Execute Search Click Search icon to start Searching ⑤...

  • Page 220: Bookmark

    The video is playing on the playback window (mouse over to view ④ advanced function menu and playback control panel) Change Play pre-event time (Optional) ⑤ (Range: 3~100 seconds, Default: 15 seconds) Sort by Time or Name (Optional) ⑥ the default sorting priority is 1.
  • Page 221 Enter Title (Maximum character is 512) ⑦ Enter Description (Maximum character is 512) (optional) ⑧ Click “OK” button ⑨ 2. Review Bookmark – for quick tracking Mouse over the bookmark footage shown in white. A thumbnail show with the information of title, description, date/time, camera name. There are 4 action icons for usage: Play bookmark video ①...

  • Page 222: Data Search

    3. Search Bookmark via Data Search – to filter bookmark results (1) Click “Data Search” button (2) Select Bookmark tab (3) Select camera(s) (4) Enter keyword (Optional) (5) Select start/end time (6) Click “Search” button (7) Click 4 action icons: Play bookmark video ①...
  • Page 223 Click “Data Search” button. A window will pop up to start configuration. Select event category, event type, time range and select device(s). Then, click “Search” button. NVR will show the event result as below picture, including 1. Time: to check event time 2.
  • Page 224 indicated after its name. Eg. Front Door (No.7) 3. NVR IP Address: designed for multi-server search to identify events with same device name 4. Event Type 5. Car Number: designed for license plate recognition keyword search 6. Snapshot: click icon to check event image Note: To save event snapshot in NVR, please enable “Save Snapshot when Event Triggered”...
  • Page 225 Note: For people counting”s data analysis, users can export the list or the whole database as below picture. Note: For License Plate Recognition tab, NVR supports fuzzy search when the car plate number is partially unknown. Note: The result will list underneath and each data will display all identified car number in the “car number”...

  • Page 226: Control Panel On Playback

    4.3.9 Control Panel on Playback Display mode NVR supports multi-channel simultaneous playback. You can see the recording time of each channel in the top of each grid. Icon Description Full screen 1 screen 4 screens 5 screens 9 screens 16 screens Mute control Users can choose whether to play audio when playback videos.
  • Page 227 The image can be enlarged by clicking digital zoom-in button. 4. Video playback speed control Stop: to clear playback videos ① Previous frame: to show the earlier frame (frame-based with I-frame, ② jump by second) Slow motion: to play in slower speed ③...
  • Page 228 6. Scale bar Users can move the bar to enlarge or narrow down time period to check video footage in time table. 7. Seek bar By moving seek bar, users can go to the specific recording time directly. Time is shown above seek bar to provide time reference. 8.
  • Page 229 From the thumbnail, users can also read the related information such as date, time and camera name. The thumbnail will be shown while pointer moves on the footage. 9. POS Thumbnail on Playback The thumbnail will be shown while the cursor moves over the footage. From the POS thumbnail, users can read the detailed sales information,...
  • Page 230 different orders from POS system, and the camera information (date & time, and name). (1) Play: to play POS video clips (2) Export: to export POS video clips More POS settings on configuration page, please refer to 5.7.2 POS System. 10.
  • Page 231 3) Select “Position” (Top left corner, top right corner, bottom left corner, and bottom right corner) 4) Click OSD “color” setting button, select the OSD color, and click “OK”...
  • Page 232 5) OSD color and font size will be changed as below. 11. Change POS OSD color and font size Users can select different OSD color while having the playback of POS recording files. (More POS settings on configuration page, please refer to 5.7.2 POS System 1) Click “Setting”...
  • Page 233 4) Select font size and click “OK” (Auto is default.) 5) Key in display time and click “OK” (1~60 secs) 6) OSD color and font size will be changed as below.

  • Page 234: Zooming With Mouse Scroll

    12. Dewarp for fisheye cameras By right click on the video, users can choose the proper dewarp engine for fisheye camera. a. Choose the dewarp engine: b. Choose the mounting type c. Choose the display mode 4.3.10 Zooming with Mouse scroll In addition to digital zoom in/out button, users can use mouse scroll to find out crucial proof in incident site in playback.

  • Page 235: Export

    View enlarged images: To press and hold left mouse button, drag the image to the place that you would like to monitor. 4.3.11 Export Export function allows users to retrieve recorded files from NVR. NVR offers two methods to export recorded videos for different export requirements: Method1.
  • Page 236 1) Select cameras, date, recording type and time period to playback (up to 16 channels) 2) Click “Export” button 3) Define export date and time (within 2 day’s range) 4) “Browser” export path 5) Re-define video format (NVR’s unique AVI file or General AVI file) [Optional] Note: For security concern, the default recorded video format is “NVR’s unique AVI file”.
  • Page 237 Select font size and position ④ Click “OK” to save watermark setting ⑤ 7) “Enable” cut and combine video(s) into a AVI file [Optional] 8) Double-click a camera to name the AVI file [Optional] Note: The default AVI file name is “NVR name_camera name”. 9) Click “OK”...
  • Page 238 A window will pop-out to cut videos. A window will pop-out to show adding watermark’s status. A window will pop-out when finishing adding watermark. NVR is combing 5-minute videos into a camera file when you enable combine AVI file. Please wait until 100%. All videos are completely exported and combined.
  • Page 239 1) Select camera, date and recording type 2) Click “Play” button 3) Move seek bar to desire export time 4) Click “Start/Stop Export” button to start export video 5) A window will pop out to display export status. On time table, exporting time period will be highlight in purple color...
  • Page 240 Once users click “Stop Export”, it will stop export from the current playback time, while the download will go on until it is finished. Note: If user clicks “Cancel Download”, the export will be canceled completely without any exported video files. 7) Once the export is finished, a playlist window will pop out to let user modify folder Name and Playlist Name.
  • Page 241 Note. Exported file can be found in “Setting” button on playback 2) Unzip and run NVRPlayer 3) Import Playlist to NVRPlayer by clicking “Open File” button 4) Select cameras, start time and end time. Then, click “Play” button to play videos For more information about NVRPlayer, please refer to 2.2.5 NVRPlayer.

  • Page 242: Play Video Files

    Play Video Files Users can access the video files by Windows Networking and FTP Service. Note: To use Windows Networking and FTP Service, please enable both in “File Sharing Service” in configuration page. By using the link button on file sharing service page, users can open the dialog directly after the service is enable.
  • Page 243 To acquire Mac address, users can refer to “System” > “Device Information” > “System Information” in configuration page. “Computer Name” is shown in “Network” > “Network Setup” > “Information” in configuration page. For example, the computer name is NVR005043000203. Thus, users can select a NVR in Network folder by this computer name. As you select the NVR, a window will pop up and ask to enter network password.
  • Page 244 If users don’t amend the username and password, please enter the default ones: “admin/admin.” After users enter accurate user name and password, the NVR will display the folder “Public” and “videodata1.” Please select “videodata1” to check video files. After entering “videodata1,” the folder displays Record Folder chronologically...
  • Page 245 by recording dates. Please select a folder to enter. All video files lists chronologically by recorded time and video length of each chunk is five minutes. Select a video file to play. Enter IP Address to Search Please enter NVR IP address from the Windows Start menu. As you enter the IP address, a window will pop up and ask for network password.

  • Page 246: Ftp Service

    4.4.2 FTP Service To access FTP service in a web-based interface, please open Windows Internet Explorer and enter NVR IP address which users configure. Note: To access FTP service in WAN, please enable router’s Internet access and specify the same port as NVR. (The default is 21)
  • Page 247 As you enter the IP address, a window will pop up and ask to type a user name and password to log in FTP server. If you don’t amend the user name and password, please enter the default ones:”admin/admin.” Please click “Log On” to proceed. Web browser shows the folders on FTP server.

  • Page 248: Naming Rule Of Video Files

    select a folder to enter. All video files list chronologically by recorded time and video length of each chunk is five minutes. Select a video file to play. 4.4.3 Naming Rule of Video files NVR writes and memorizes videos to HDD in every 5 minutes. This way can ensure all videos are well saved when encountering power outage or other accidents.

  • Page 249: Chapter 5. Configuration

    Chapter 5. Configuration In configuration page, users can configure Quick Configuration, IP Camera, Recording & Event, Disk Management, Network Management and System from each drop-down menu. Note: NVR will automatically log out from configuration page after idle for 10 minutes. IP Camera 5.1.1 Camera Settings...
  • Page 250 There are two parts in this section: Camera Parameter and Camera List. Please select a camera in Camera List first. As you click one column turning into blue, please wait and the window below will appear to allow user to configure camera parameter. Note: Via clicking the header row of camera list with the name of each column, camera list will be rearranged in alphabetical order (A→Z) of the selected column.
  • Page 251 After loading camera’s information, users can modify below camera parameter: (1) Camera No. Load Select a desired camera no. to switch camera in NVR’s camera list. (2) Stream 1/ Stream 2 (Recording Stream) Decide one stream as recording stream for video recording between stream 1 and stream 2, if cameras support dual streams.
  • Page 252 Please click “Apply” button to save modified camera parameter. Note: By selecting camera(s) in Camera List, uses can apply the parameter setting for the same camera model at the same time. You may click “Cancel” button to stop the execution. Furthermore, click “Go to Web”...

  • Page 253: Camera Status

    5.1.3 Camera Status Please select “Camera Status” from the drop-down menu of IP Camera to begin. Camera List shows connection status of recording. By clicking Camera No., NVR will direct you to modify camera parameter. Recording & Events Recording & Events can provide different event modes and recording schedule for users to configure IP camera.

  • Page 254: Recording Settings

    After the hard disk is ready, users can continue the following settings. 5.2.1 Recording Settings Recording Mode Users can set the mode of “No Recording,” “Recording by Schedule or Event” and “Always Recording” for each connected camera. (1) No Recording: This mode will make all cameras disable to record the video.
  • Page 255 Schedule” section. (3) Always Recording: Users can select the camera or click “All” camera to apply “Always Recording” function. The video will be recorded continuously. Manual Recording Enable: To record all cameras or individual cameras via one button on liveview page.

  • Page 256: Recording Schedule

    than threshold, NVR will start to delete the oldest videos. Note: When NVR total storage is less than 1TB, the maximum threshold becomes 90%. To check NVR total storage space, please refer to 5.3.3 Storage Volume Management. (2) Video Keeping Period: Users can set time period for keeping videos. The time period is based on NVR running day.
  • Page 257 2. Insert schedule Select time range (Start/End time), recording type and channel for recording schedule and click “Insert.” Recording type Depending on recording requirements, users can two recording types: (1) Always Record: If “Always Record” is selected, the video will be recorded continuously.

  • Page 258: Snapshot Schedule

    is in blue, Record by Event is in red. Click “Apply” to finish setting or “Reset” to rearrange time and camera channel. Note: A camera can set multi-recording schedule and two recording types at same time. The camera bar will display in purple when users set up both Always Record and Record by Event at the same time.
  • Page 259 The maximum snapshot storage is 10% of the total storage capacity. Note: Camera i-frame interval should be 1 sec for the accurate snapshot time spot. [Step1] Configure Schedule Snapshot Define snapshot keeping periods (1-999 days) Set up snapshot schedule: Start/End time (H=hour, M= minute) Snapshot interval (10 seconds ~ 2 hours) Select Camera(s) Note1: The maximum recommended usage of schedule snapshot:...
  • Page 260 Users can check configured schedule snapshot in Schedule List. Users can have up to 20 combination list of schedule snapshot. Via “Delete” button, users can delete any configured schedule list. [Step2] Check Schedule Snapshot Users can access snapshots via Windows Networking or FTP Service in the “Schedule Snapshot”...

  • Page 261: Event Smart Recording

    5.2.4 Event Smart Recording Event smart recording, an advanced recording function for always recording, is designed to save NVR storage space to keep video for longer period of time. For camera enabled event smart recording function, NVR will record event video of that camera in high video quality when event is triggered;...
  • Page 262 Then, visit “Recording Schedule” page to set up always record for specific camera as below picture. Click “Apply” button.
  • Page 263 [Recording Mode2] Always Recording Select Always Recording and select camera(s). Then, click “Apply” button Enable event smart recording for camera(s) Go to Recording & Event> Recording Settings>Event Smart Recording page: Select camera(s) and click “Apply” button. Set up event and action: Go to Recording &...

  • Page 264: Recording Group

    Note: Please ensure event and event triggered recording as action is configured. Check settings User can check camera recording status from NVR configuration page: IP Camera> Camera Status For camera with event smart recording setting, Rec. status will display Smart Recording.
  • Page 265 Click “Add Group” to enter the number of recording day. Move cameras to new group. Based on current camera setting, NVR will estimate storage space and percentage that each camera group will take in NVR. Finally, click “Apply” button to save setting. Note: If the estimated storage size is more than 90%, the top group color will be changed from green...

  • Page 266: Time-Lapse Recording

    5.2.6 Time-lapse Recording The NVR supports time-lapse recording for numerous cameras with varying parameters, which automatically captures a series of photos and transforms these sequences into a cohesive video. The NVR offers 3 key functions: Intuitive Settings The NVR offers two flexible capture plans for time-lapse recording. ①...
  • Page 267 Enabled: to activate or disable the feature Camera No.: cameras that have been added in the NVR Capture Plan: Recording duration: 600 Days, 24 hours, 60 minutes (default: 1 day)  Capture interval per shot: 1 Days, 24 hours, 60 minutes, 60 seconds/ per ...
  • Page 268 Camera List Easily review the configured settings and monitor the recording status Flexibly disable time-lapse recording on a specific camera when it’s not needed. Freely reactivate the camera with the same setting in the future. Enable Time-lapse Recording There are two capture plans, [Capture Plan 1: Recording duration] Click “Enabled”...
  • Page 269 [Capture Plan 2: Capture Interval] Click “Enabled” ① Select a camera ② Select “Capture Plan”: Capture interval per shot (days, hours, minutes, ③ seconds) Define “Video length” (0.5, 1~10 minutes) ④ Define “Playback FPS” (1~60FPS) ⑤ Set the “Initial Time” ⑥...
  • Page 270 Select camera ① Un-check/Re-check Enabled ② Click “Apply” ③ Un-check/Re-check from camera list ④ Click “Re-apply” ⑤ The status in camera list will change to Disable/Enable Playback Time-lapse Recording Go to Playback page Select Type: Time-lapse Recording ① Check calendar date marked in pink ②...

  • Page 271: Event & Action Management

    Log of Time-lapse Recording There are two parts of logs refer to Time-lapse recording, Activity log: Admin and power users have exclusive control over enabling or disabling the feature. The changes are recorded in the System > Log System > History of Users, ensuring accountability. Recording Log: The relevant recording log details, such as task initiation or completion and any changes to recording parameters, are consistently recorded in the System >...
  • Page 272 Note: The action will be only triggered when the action is added to the event. Note: If users select the event and no action is added, NVR will enable “highlight video window” and “video pop-out window.” Note: NVR will pop-out a message when new settings are not saved. 1.
  • Page 273 (14): Double-clicking on the list to rename. Missing Object Detection Foreign Object Detection (15): When the call button is triggered, the alarm Loitering Detection will be triggered. NVR will record the audio People Counting Threshold captured from door station only. Notice (This event is supported for AIPhone IX series for (10)
  • Page 274 When the primary NTP time sync is failed, NVR will synchronize its time with another 2 external NTP servers sequentially to keep system date & time synchronized. (7) For NVR equipped with rack-mount redundant power supply, NVR offers system buzzer and other system notification such as Email notification and Digital Output (DO) to notify users of the failure of power supply.
  • Page 275 2. Action types After setting an event, users can select the corresponding actions for notification. Action Type Description NVR can enable Event trigger record, Video Clip and store the video to External FTP when an event is triggered. Event Triggered Record Users can apply settings to other cameras.
  • Page 276 (1) Event Triggered Record Event triggered record: NVR records video every five minutes as the ① event continues happening. Recording type on playback page displays as Event in red footage. Video Clip: Video clip will be sent by E-mail. Please enable video clip ②...
  • Page 277 External FTP: ③  Enable “Snapshot” and “Video Clip” to store them to external FTP server when an event is triggered. Select “Apply Options.” To apply the settings of Event trigger record,  Video Clip and External FTP to other cameras. (2) Send E-Mail Please add a new contactor in the following section “E-Mail”...
  • Page 278 Select the contactor ① Edit the content on Subject and Message column ② You can choose whether to attach the snapshot with Email (Optional) ③ Apply same setting with other cameras in “Apply Options” (Optional) ④ Click “Ok” button to finish E-MAIL Configuration. ⑤...
  • Page 279 Select “Liveview Notification” ① Select cameras for “Highlight Video Window” (or apply all cameras) ② Select cameras for “Video Pop-out Window” ③ Click “OK” to save settings ④ Note: When users select more than two cameras for video pop-out window, NVR will show quattro video pop-out window.
  • Page 280 (5) User Defined Action (HTTP-out) Select “User Defined Action” ① Input information ② Select cameras or apply all cameras ③ Click “OK” to save settings ④ (6) SMS Select “SMS” ① Input information ② Press “Test” to ensure the account information and cell phone is ③...
  • Page 281 (7) Camera Preset Point Select “Camera Preset Point” ① Select cameras ② Select preset point name > click “Add” ③ Preset point list ④ Click “OK” to save settings ⑤ (8) Stack Light Select “Stack Light Device” ① Select “Stack Light Actions” ②...
  • Page 282 (9) Network Horn Speaker Note: NVR supports AXIS C3003-E, C1211-E, C1310-E for now. Note: Please go to camera setting on configuration page and click “Apply” button for network horn speaker again, when you add new pre-recorded audios to network horn speaker.
  • Page 283 3. Event Lifted (DO support) When enable event lifted, users will get continuous alarm from NVR’s digital output (DO) until the events are solved. It is a high-efficient method to maintain NVR IP video system. Note: This feature is available for DS-16x00-RM UHD, DS-8x00-RM UHD and DS-4200-RM UHD series.
  • Page 284 Note: For the event of camera disconnected, users can use “Quick Setup” to quickly apply the same setting to other cameras. Then, click “Apply” button to save the setting. Finally, enable “Set of Signal” in System > Buzzer/Digital Output page. Note: After “Set Of Signal”...

  • Page 285: Advanced Setting

    5.2.8 Advanced Setting 1. Action Triggered Interval Users can set proper time interval when events are triggered in sequence. 2. Video Clip Users can set Pre-time of record and Post-time of record for video clip and event recording. 3. Recording Settings Pre-time of record can up to 300 seconds before the event is triggered and Post-time of record can up to 300 seconds after the event ends.
  • Page 286 and set up corresponding action. 6. Digital I/O Settings (1) Status: shows active when external USB type GPIO is connected (2) DI/DO: to define functionality (DI/DO) for external USB type GPIO (3) Pin: to configure default value (High/Low) for digital input (DI) Default is Low.

  • Page 287: Chain Event

    9. Event Pop-out Message on Liveview NVR will pop-out message on local and remote liveview page, so that users can instantly notice of external events triggered while monitoring. Note: This function is enabled by default. 10. Save Snapshot when Event Triggered NVR will save snapshot when an event is triggered.

  • Page 288: Data Management

    2. Chain Event Setting: Enter Expire Time (30-999 seconds) ① Set up multiple events (up to 4) ② Set up multiple actions: Device (NVR/ Camera) and Corresponsive ③ Actions Click “Apply” button to save setting ④ The setup will be added to Rule List (max.64 rules) ⑤...

  • Page 289: Event & Action Summary

    5.2.11 Event & Action Summary This page is an efficient and useful page to confirm all events and actions are well-set after you finish NVR’s event configuration.

  • Page 290: E-Mail

    5.2.12 E-Mail Please select “E-Mail” from the drop-down menu of Recording & Event to begin. 1. SMTP Server  Server Address: Enter the Server Address of the SMTP server.  Sender: Specify sender’s E-Mail in the “Sender” field.  Subject: Enter the Subject. ...
  • Page 291 Below chart is the Server Address of common SMTP mail servers: Server Address Outgoing Port smtp.aol.com 25,465 Gmail smtp.gmail.com iCloud smtp.mail.me.com Outlook.com smtp-mail.outlook.com Outlook Office365 smtp.office365.com Yahoo smtp.mail.yahoo.com Note: The Outgoing Port (SMTP) number may not the same as your residential ISP and Cloud Hosting Provider.

  • Page 292: Disk Management

    Disk Management NVR can create new RAID disk or delete/format the RAID disk. Also, users can manage NVR’s storage device for data transmission and file sharing service. 5.3.1 iSCSI NVR supports iSCSI Server to expand storage capacity. Please select “iSCSI” from the drop-down menu of Disk Management to begin.
  • Page 293 A window will pop out when NVR successfully connects to iSCSI Server. Click “OK” button. Then, iSCSI Target List will show iSCSI Server information that connects to this NVR. To add iSCSI LUN into NVR, please visit next chapter 5.3.2 Disk Management for further instruction.

  • Page 294: Disk Management

    5.3.2 Disk Management Please select “Disk Management” from the drop-down menu of Disk Management to begin. Disk Information The steps for creating and deleting NVR’s hard disk, please refer to 2.4.5 Disk Management. 2. Add iSCSI Server to NVR NVR supports iSCSI initiator allowing users to easily expand NVR storage with no need to shut down NVR.

  • Page 295: Storage Volume Management

    Go to “External Disk” page. Follow below steps to format iSCSI LUN to add its volume into NVR’s volume pool. Note: Please make sure NVR and iSCSI LUN are power on with a complete RAID type, before you start to connect iSCSI LUN to NVR. A window will pop out after clicking “Format”...
  • Page 296 Disk Management to begin. Storage volume management provides an efficient method to organize data expected to be retained after a program is terminated by providing procedures to store, retrieve and update data, as well as manage the available space on the device. When there is no hard disk installed in the NVR, the page will show “Volume Main is not ready for Storage Volume Pool.”...
  • Page 297 (6) Capacity: The storage capacity of RAID (7) Size Used, Usage: The amount of the used storage and the percentage (8) Status: The recording status of RAID Green: Mounted recording  Gray: Mounted (but not in recording)  Orange: Conflict ...

  • Page 298: File Sharing Service

    Remove Volume Uses can follow below steps to remove Volume from NVR to prevent data loss. Format By clicking “Format” button, you can format all volumes in storage volume pool. 5.3.4 File Sharing Service Please select “File Sharing Service” from the drop-down menu of Disk Management to begin.
  • Page 299 Information Once the hard disk is installed, the filesystem will show status as below. Turn On or turn off sharing service to enable or disable Windows Networking and FTP service. Windows Networking Option After the service is enabled, the warning window may appear after clicking "Link"...
  • Page 300 need to allow “ftp://YourNVR_IP/” to be open in Internet Explorer mode in advance. Please open “Edge” browser > go to browser’s settings page (or type “edge://settings/defaultBrowser” in URL bar) > Select Default browser > Allow sites to be reloaded in Internet Explorer mode > Click “Add” > add “ftp://YourNVR_IP/ to the list。...
  • Page 301 Windows Networking In Windows Networking field, users can enable or disable the services and Computer Name is already shown. Computer Description and Domain or Workgroup Name can be changed. FTP Service In FTP Settings, users can enable or disable FTP Services. User can arrange Command Port and Passive Port.

  • Page 302: Backup

    Backup The server offers diverse backup solutions to ensure that critical recording videos are kept safe for longer period of time, including 1. Remote backup to NAS server 2. Local backup to USB devices 3. Remote backup to FTP server All backup solutions support two backup modes: schedule and manual.
  • Page 303 Resume backup technology The system will intelligently resume interrupted backups from breakpoint after power recovery or network reconnection to ensure the integrity of videos backups and to reduce the risk of any data loss. Backup delay warning The feature allows users to set preferred backup delay hours, ranging from 1~24 hours.

  • Page 304: Schedule/Manual

    5.4.1 Schedule/Manual In the section, users can assign backup methods via schedule or manual backup. Schedule [Step 1] Connect a destination device Please go to Configuration > Backup > Schedule/Manual > Device Note: ASUSTOR NAS is supported for now in LAN. A.
  • Page 305 Once the Server successfully connects to the device, the status will show “Connected” and display the total size of the device as well as the available size for remote backup. As above picture, the total size of the device is 1829.59GB and it has 1583GB available size for remote backup.
  • Page 306 [Step 2] Setup Schedule Backup Please go to Backup > Schedule/Manual > Schedule Select the desired backup preference of the Recorded Video includes ① Days, • Video period (start/end time), • Cameras selection (all/dedicate cameras) • Recording types • Select upload timing ②...
  • Page 307 [Step 3] Check Schedule Backup Please go to Backup > Schedule/Manual > Device Check Archive Information to know the process ① Click Detail ② View Job Description ③ [Step 4] Export Error Information when Manual backup failed • FTP recycle failed •...
  • Page 308 Manual Backup (1) All Videos Select “All videos” ① Click “Backup Start” button. ② Note: To backup all videos in the Server, please make sure the Server is in no recording mode.
  • Page 309 (2) Settings Select “Settings” ① Define Video Time to backup (yyyy-mm-dd_hh:mm) ② Enable Specified Period to back up the specific time range of ③ video time (Optional) Select camera channels ④ Select Recording Type(s) ⑤ Define Working Time (Backup Immediately / User-define time) ⑥...

  • Page 310: Usb Backup

    will show a job ID in Archive Information. Job ID: All the schedules that users have set up ① NVR ID: NVR name ② Mode: Backup mode ③ Job Start/ End: Backup process start time and end time ④ Status: Stand By, Running, Finished...
  • Page 311 USB Backup To format the USB device, to enable the USB Backup button function and to setup the USB Backup button’s channels and the latest time duration for future duplication, please select “USB Backup” from the drop-down menu of Backup. Format USB Device Manufacturer Info.: the manufacturer of the USB device ①...
  • Page 312 USB Backup Setting (1) Enabled: USB Backup function can be enabled or disabled, for security concern. (2) Preference: Latest Recordings Information: Set up days, hours and minutes to back ① up the latest video files. Video Period: Specify a time range to backup videos. ②...
  • Page 313 When the USB is ready to begin, the Device Information will show the status “Ready,” and the USB LED indicator will show blue. If you want to delete the current data in USB, please click “Format” to delete the current data of USB. When NVR is in backup progress, the Device Information will show the status “Working,”...
  • Page 314 DVD Backup (1) Enable: DVD Backup function can be enabled or disabled, for security concern. (2) The latest duration of recordings: Set the days and hours to back up the latest video files (3) Channel Selection: Select certain camera channels or click “All” channels for future backup (4) Apply: Click “Apply”...
  • Page 315 If you need to delete the current data in USB type DVD burner, please click “Format” to delete current data. If there is no USB type DVD burner inserted into NVR, the screen will show “There is no USB device…” Note: NVRPlayer and NVRCheck will be downloaded with video files.
  • Page 316 Note: “Original files with password “setting is supported on local playback for video export. Otherwise, NVR will export videos in zipped files with password. Note: Users can playback videos exported in “original files with password” on NVR (playback page) and PC (NVRPlayer) [Method1] On NVR playback page: Step1.
  • Page 317 Step2. Open a video file Step3. Enter password and NVRPlayer will start to playback video. Export Video on Playback Page A window will pop up after users click export button on playback page. NVR will display the capacity of video file on local NVR. On remote browser, a window will pop up to display download status.

  • Page 318: Edge Backup

    On remote client, a window will pop up to ask users to enter password for encryption after successfully exporting files. On local NVR, a window will pop up to ask users to enter password for encryption before exporting files. 5.4.3 Edge Backup Edge backup can ensure that your important camera videos are able to be firmly saved in another NVR for future viewing purpose.
  • Page 319 Note: Please make sure the time of host NVR and edge NVR is the same. Click “Enable” to enable edge backup. Enter Host NVR’s information (IP Address, Port, Username and Password.) Then, click “Check Settings” button. (NVR will automatically add/enable cameras shared with the same No. and IP address.) You can un-check edge backup camera.

  • Page 320: Backup Server

    between camera and NVRs. 5.4.4 Backup Server NVR can become a backup server to save crucial camera videos from multiple NVR. Users can directly view recorded videos on backup server’s playback page without installing extra tool. To fully utilize the storage space of backup server, users can preserve the key period of video on backup server.
  • Page 321 Add Cameras There are two methods to add cameras from NVR: Detect and NVR Search (Group Add) [Method 1] Detect: Enable backup server, choose backup mode, fill in NVR information and click “Apply” button. Backup server will display NVR’s camera list. Select cameras and click “Add All”...
  • Page 322 Select NVR for video backup. Then, click “Add” button. Fill in password of each NVR and click “Connect” button. Note: Backup server supports administrator (admin) as username only. Select cameras from multiple NVRs and click “Add All” button. Set up Backup Mode A.
  • Page 323 Select schedule type (Day or Week), define backup time (Start/End Time), and select applied cameras. Then, click “Insert” button. Users can check configured backup schedule as above. Finally, click “Apply” button to save the setting. B. Manual backup Backup recording files of specific video period or backup all recording files for all cameras.
  • Page 324 Click “Enable” ① Select Video Time ② A. Backup all recorded videos: Backup all files before the current date B. Video Period: Define the backup time range Click “Apply” ③ Check Backup Status A. Schedule backup Users can quickly check backup status of each camera on this page. Device information: ①...
  • Page 325 B. Data Size: the last backup video size Information: When the video is failed to back up from NVR to backup ④ server, NVR will show the information. Manual backup Users can quickly check manual backup status on this page.

  • Page 326: Network

    Network 5.5.1 Network Setup Please select “Network Setup” from the drop-down menu of Network to begin. This section explains how to configure network connection with NVR. Information Network information displays present network configuration including: Computer Name, IP address, Subnet mask, Default Gateway, Primary and...
  • Page 327 Secondary DNS. 2. Setup Users can rename Computer Name, assign IP address in DHCP or Static IP and set up IPv6. (1) Network Interfaces: Select Shared IP, Separated IP or Link Aggregation Note: Please assign a specific Gateway for a LAN as WAN port and set up gateway to communicate with router.
  • Page 328 Link Aggregation ③ For NVR with 2 LAN ports, users can configure link aggregation to have below two benefits: A. Boost Bandwidth: Combine two internet traffics into one faster connection in order to boost video transfer speed LAN Port Redundancy: Prevent the loss of connectivity to ensure...
  • Page 329 the storage of vital videos. The benefits of 7 link aggregation modes,...
  • Page 330 Applicable Switch Benefit Link Type Aggregati Description Fault Load Manage on Mode General tolerance balancing Balance- Transmits packets in sequential order from the first available (Round- connection to the next. Robin) Only one connection is active. A different connection becomes active if, and only if, the active Active- connection fails.
  • Page 331 (2) Computer Name: Rename NVR’s name (3) Internet Protocol: Define NVR’s IP address in DHCP or Static IP. DHCP: Obtain an available dynamic IP address assigned by a DHCP server. ① If this option is selected, NVR will automatically obtain an available dynamic IP address from the DHCP server when connecting to the LAN.
  • Page 332 (4) IPv6: Configure NVR in IPv6 (Internet Protocol version 6). Finally, please click “Apply” to execute the settings. 3. DHCP Setup Built-in DHCP server allows users to easily install IP surveillance systems without connecting another router providing network parameters. With built-in DHCP server, NVR can assign local IP addresses to multiple IP cameras in a local area network (LAN).
  • Page 333 To enable DHCP in IPv6 protocol, please enable IPv6 auto configuration. Select a mode from Stateful, Stateless Auto-configuration, Stateless DHCPv6. Then, configure router advertisement daemon and click “Apply” button to save setting. Note: For UHD(+) series, DHCP service will assign valid IP address via LAN2 port. Note: Please do not connect to another device containing DHCP server function such as router when utilizing built-in DHCP server 4.
  • Page 334 Note: HTTPS is designed for configuration usage.

  • Page 335: Network Service

    5.5.2 Network Service Please select “Network Service” from the drop-down menu of Network to begin. 1. Network Service UPnP ① • Enable or disable UPnP search. • Rename UPnP. Telnet Service ② • Enable or disable Telnet Service • Port: 23 (Default port) IP Forward: enable or disable ③...
  • Page 336 As White List is enabled, a window will pop up to make sure the execution. As Black List is enabled, a window will pop up to make sure the execution. Please enter the IP address range to add to White List or Black List. Note: The above IP address is only an example for reference.
  • Page 337 3. Relay Server NVR features built-in relay server allowing multiple clients to keep an eye on your region for different purposes. It can not only minimize the influence of camera limitation but also satisfy multiple clients simultaneous monitoring. Note: Based on liveview display mode, NVR will automatically switch streams (stream1 or stream2) to save bandwidth and to optimize monitoring experience.
  • Page 338 4. Web Surveillance Web Surveillance feature provides a user-friendly and convenient solutions for surveillance and security needs without the extra software requirement. By using a web browser (Chrome/Edge/Safari/Firefox/Opera), users can effortlessly monitor and playback video from any location. Via secured HTTPS connection, ensuring reliable and safe access to liveview.
  • Page 339 User Interface Introduction Web Liveview  Web Playback ...
  • Page 340 [Step 1] Enable the feature A. Go to Quick Configuration 1 Go to “Finish” 2 Click Web Surveillance Settings button The system will direct to setting page. Please refer to B for settings. B. Go to Network > Network Service > Relay server 1 Enable Relay Server 2 Fill in Management Port (Self-defined) 3 Enable Web Surveillance feature...
  • Page 341 Method 2: Direct access options from login page Go to Quick Configuration > Network Service > Relay Server Enable “Login with Web Surveillance” ① Press Apply ② Select the desired feature from login page for quick access. ③ [Step 3] Start Web Liveview Add camera: ①...
  • Page 342 [Step 4] Start Web Playback Select desired cameras or check the server icon to select all cameras ① Set the start date and time. (The start date and end date must be the same date.) ② Press “Play” button ③ Change display mode (Optional): Support 1, 4, 9, 12, 16 (1x1, 2x2, 3x3, 4x3, 4x4) ④...
  • Page 343 5. AIPhone SIF NVR supports IP video door intercom system. Users can record the video captured from door station (always recording), even when it is triggered by its call button (event recording). Please configure AIPhone setting first. (NVR supports AIPhone IX series for now.) To connect AIPhone and NVR, please enable AIPhone SIF and enter management port (the same as AIPhone).

  • Page 344: Network Tool

    [Scenario 3] Master station x 1 pc + Door station x 2 pcs: Answer door 1 only 5.5.3 Network Tool The Network Tool assists users in promptly identifying and resolving any connection issues, ensuring seamless operation of their security infrastructure. Please select “Network Tool”...

  • Page 345: Youtube Live

    DDNS links a domain name to an IP address, allowing users to easily access their camera even with a changing IP address. NVR is compatible with 5 DDNS service providers: (1) ipcam.jp (2) nwcam.jp (3)DynDNS (4) No-IP (5) ChangeIP Note: Before utilizing this function,please apply for a dynamic domain account from a DDNS provider.
  • Page 346 1. YouTube Live Before set up NVR, please go to YouTube Live page with YouTube account: https://www.youtube.com/live_dashboard_splash Go to YouTube Live page: Stream Edit new stream information: title, privacy, description, category, etc ① Copy “Default stream key” that will be added in step 2 ②...
  • Page 347 [Step 2] Define camera stream on NVR Select IP camera(s) ① Select a streaming: Stream1 or Stream2 ② Copy Stream URL on Youtube/Facebook and Paste it on RMTP Path ③ column Copy Stream Key on Youtube/Facebook, and Paste it on Key column ④...
  • Page 348 Enable the “Status” ⑤ Enable Send Email (Optional): ⑥ A window will pop-up when users enable Send E-mail. Select mail contact ① Edit mail subject (optional) ② Edit mail message (optional) ③ Click “OK” button ④ Click “Apply” button ⑦...

  • Page 349: Snmp Server

    2. Facebook Live Set up the live content on Facebook ① Click “Go Live” to start the live video ② Click “End Live Video” to end the live video ③ 5.5.6 SNMP Server SNMP server allows users to remotely check NVR(s) status in real-time across enterprise network of any size via two methods: 1.
  • Page 350 1. SNMP Setting Enable SNMP and select SNMP version (v2c). Then, fill in SNMP port and SNMP Trap port. Click “Apply” button to save the setting. 2. Advanced Settings (1) Community Setting: to let SNMP client get NVR status Fill in community name and click “Add” button. (2) Trap Setting: to automatically receive NVR status Fill in SNMP client’s Trap address and community name, so NVR will send NVR event status to SNMP client.
  • Page 351 4. What information you can get from NVR’s SNMP sever...

  • Page 352: Wireless

    5.5.7 Wireless Please select “Wireless” from the drop-down menu of Network to begin. Note: This function is supported for MN-2100 UHD series. 1. Information Users can check NVR’s wireless information in this page. 2. Basic Settings This page allows users to enable wireless function and execute wireless configuration.
  • Page 353 Click “Site Survey” button, select one wireless from site survey list and type password if necessary. Then, click “Apply” button. 3. Wi-Fi Protected setup (WPS) User can connect to router via PIN mode and PCB mode. 1) PIN mode Go to router’s WPS web page and type NVR’s PIN code. Then, click “Connect” button.
  • Page 354 2) PBC mode Please click WPS button on router. Please go to NVR’s configuration page (Wireless → Wi-Fi Protected setup) and click PBC button to connect the router. 5.5.8 3G/4G Please select “3G/4G” from the drop-down menu of Network to begin. Note: This function is supported for MN-2100 UHD series.

  • Page 355: Management

    Management In Management, users can easily create, modify and change users’ live view access and playback access. Also, users can read various log information through log system and quickly save or load configuration of NVR. Emergent backup of the latest video files as well as the external input and output control can also be set here.
  • Page 356 Create Users User List will display all user information when creating new users. To create users, please go to Create Users to create user in advance. (1) Username and Password: Fill in a username and password (or a random password). Please fill in Email address to send the password when clicking random password.
  • Page 357 Select AD user groups, and click “OK” Note: After finishing the setting, users can use AD account to log in NVR by enabling “Use Active Directory (AD) Account”. (5) Liveview and playback access: select liveview /playback channel and other functions (ex. PTZ control, multi-server, digital output, Manual Recording, Mute.) to be accessed.
  • Page 358 The selected account will turn to blue and the page for modifying user will appear as below. You can change Live View Access and Playback Access. Please click “Apply” to proceed. After User is modified, user list will display the renewed information. To delete the user account, please click “Delete”...
  • Page 359 Select username: “admin” or preferrable account ① Rename username ② Input Current Password ③ Input New Password ④ Confirm the new password (re-type) ⑤ Click Apply to save the changes ⑥ A logout message will pop up. Click OK to proceed. ⑦...
  • Page 360 Advanced Settings (1) Local anonymous access (on local display) Anonymous user can only view live monitoring and playback page on local monitor with no access of NVR configuration. Users can enable or disable this function in this page. For more information, please refer to 3.1.1 Anonymous login (2) Reboot auto access (on local display) NVR will automatically log into liveview page via previous user account...
  • Page 361 Please enable auto logout feature, set on which page(s) and idle time period to active auto logout. Enable auto login feature, set time period to active auto login after NVR log out to login page. Then, please click “Apply” button. Active Directory AD’s Domain admins can authorize diverse domain groups to have proper permissions to log in NVR.

  • Page 362: Failover

    5.6.2 Failover NVR failover is a reliable backup solution to maintain IP video surveillance in case of NVR recording server failure situation. One failover can monitor up to 4 NVR recording servers in default. One failover server can monitor up to 16 NVR recording server.
  • Page 363 (2) Add NVR Please select “Failover” from the drop-down menu of Management to begin. Click “NVR Search” to select NVR in LAN or manually fill in NVR information to add NVR recording server. NVR Search Manually Add A window will pop up before failover server starts adding NVR recording server.
  • Page 364 (3) NVR take-over priority setting: Set up NVR take-over priority in case more than two NVRs fail to recording video at the same time. Please click “Priority Setting” button. ① Configure priority for each NVR. ② Click “Apply” button to save the setting. ③...
  • Page 365 Set up “monitor interval” ① Set up “Failover Take-over Timing” ② Click “Apply” button. ③ How Failover server works Monitor mode: Monitor Multiple NVR ① Failover Server will check the NVR and RAID status of NVR recording servers user-defined interval (30-180 seconds).
  • Page 366 recycle. (Users can set up Failover Server’s recycle setting in advance.) B. Video Keeping Period: Based on NVR’s setting (3) Event and action settings (4) Email settings (5) Server settings: NVR’s UPnP and admin username/ password will be taken over by Failover server. When Failover Server takes over the failed NVR, Failover Server will check the NVR Status and NVR RAID Status every minute...

  • Page 367: Routine Notice

    Playback Page on Remote Client: ② • Video that is synchronized from Failover server will show the footage. • Video that is NOT synchronized from Failover server yet will show light blue footage. 5.6.3 Routine Notice Routine notice can remind users of IP video surveillance’s equipment maintenance.
  • Page 368 Enter Start Time, Interval, Subject and Message to add a routine notice. Then, click “Apply” button. Users check all notices from the list. The maximum number of routine notice is...

  • Page 369: External Device

    External Device NVR can be the brain of IP video surveillance system allowing you to centrally manage external devices such as PoE switches, access control, etc. 5.7.1 PoE Control Users can centrally manage PoE switches that are connected to NVR without entering PoE switch one by one.
  • Page 370 Via clicking “Setting” button, users can reboot, reset and configure switch information. By selecting a PoE switch in Switch List, users can check detail camera information of each port that is connected to NVR in PoE Port information. Via “On/off/Restart”, users can remote control each port of PoE switch. Please click “Apply”...

  • Page 371: Pos System

    5.7.2 POS System In remote configuration page, NVR supports POS terminals to make transactions safer between internal employees and external customers, and let shop owners be more at ease. [Step 1] Activate POS Licenses Go to configuration page: External Device > POS System > New License Click Choose File ①...
  • Page 372 [Step 3] Connect to POS Terminal and Set Up Associated Cameras Go to configuration page: External Device > POS System > POS Settings Select a device number ① Key in POS name ② Select POS Brand ③ Original Data: Display and record all POS data General: Display and record the filtered POS data Prox: Designed for Prox POS Select the POS’s encoding type...

  • Page 373: Device Web Link

    5.7.3 Device Web Link The Device Web Link feature is designed to enable users to quickly access external devices' web pages for further operations. Users can enter the complete URL of a network device to open desired webpages such as network device configurations, online technical support, useful links, or duty schedules.

  • Page 374: Modbus Io Device

    5.7.4 Modbus IO Device NVR supports Modbus Analog I/O-Digital I/O devices using Modbus protocol to make surveillance deployment more flexible to satisfy diverse project requirements such as factory and warehouse where users pay more attention on environment control. Users can configure desired events (digital Input or analog input) and corresponding actions (digital output or analog output) by connecting to external Modbus AI/O box.
  • Page 375 2. Device Parameter Please choose a device in Device List to set up its parameter. “Enable” I/O channel and select correct input range for AI/O parameter. Users can also edit I/O name for quick event and action setting. Click “Apply” button to save setting 3.

  • Page 376: Ai Box

    4. Device Event Select an event from event column, click “Add” button to add corresponding action. After all setting are done, please click “Apply” button to save event setting 5.7.5 AI Box The integration effortlessly upgrades a security system into a cost-effective AI- powered surveillance solution.
  • Page 377 The configuration process is shown as below: Note: One NVR can connect up to 64 cameras from integrated AI Box. Note: Please refer to 5.1.1 for step 1. Note: Please go to AI Box web configuration for Step 2, 3, 4. Device Setting (EdgeDX) Go to Configuration page >...
  • Page 378 Event & Action Management Go to Configuration page > External Device> AI Box > Event & Action Management Select the desired event of the channel ① Click “Add” ② Select the corresponding “Action” ③ Setup details on separate window ④ (For example: Event Triggered Recording) The action is added ⑤...

  • Page 379: Axis Io Device

    Note: URL is set on AI Box configuration page, the URL format is as below, [rtsp]://[NVR IP:http port]/NVR_streaming_request/from_nvr_record/ch_[number]/stream_[number] Green: Protocol type • Red: NVR information • Blue: IP camera channel No. and stream No. in NVR • Event & Action Summary The section provides a comprehensive event &...

  • Page 380: Access Control

    Click “Apply” button to save the setting. 2. Device Event Set up event and action. Then, click “Apply” button. Note: Liveview notification is supported on remote liveview page. 5.7.7 Access Control NVR supports access control system for door monitoring and card management.
  • Page 381 To connect access control device, please fill in Device Name, IP address, Port, Username and Password. Then, click “Apply” button to add advice. Note: If the access device has no username/password, please freely enter any words in Username and Password. Note: When adding numerous HID devices, each device needs a unique IP address, TCP/IP listen port and TCP/IP connection port.
  • Page 382 Mode description Access control mode means users can access the door via beeping a ① valid card to reader (HUNDURE) Roller shutter mode means users can push control button (up or down) to ② open roller shutter via beeping a valid card to the reader. (HUNDURE) Number means door number such as door1.
  • Page 383 Note: The maximum of access group is 3 in default Card Management In this page, users can add, modify and delete reader’s card information. Please select a device in Device List to start adding card information. Fill in Unique ID, Card Number and other optional card information such ①...
  • Page 384 Select the device to upload ① Select cards one by one, or click “All” to add all cards ② Click “Upload to reader” to directly upload card information to the ③ device Log System Log system allows users to easily check historical access information and export desired data to your PC.

  • Page 386: Ups Management

    5.7.8 UPS Management UPS (Uninterruptible Power Supply) is designed to provide emergency power to NVR when NVR encounters unexpected power outage. NVR features four steps of UPS management that users can have the up-to-date information from NVR, including: Please select “UPS Management” from the drop-down menu of External Device to begin.
  • Page 387 Smart Shutdown and Startup ① Smart Shutdown and Startup is designed to maintain usual surveillance performance when users encounter power outage. Users can set up when to automatically shut down NVR (Standby Mode). Once UPS battery is connected with power, NVR will start up automatically. Please enable this feature and fill a number to automatically shut down NVR.
  • Page 388 (2) SNMP Connection Smart Shutdown and Startup Select UPS type: SNMP Connection ① Fill in IP address of the device ② Define the time (1~99 minutes) to shut down the NVR server (standby ③ mode) after the AC power fails Click Apply to save the settings ④...

  • Page 389: Stack Light

    5.7.9 Stack Light NVR supports stack light, a visual and audible indicator, to notify users of NVR status and outside environment from 13 types of events. Based on surveillance scenario, users can flexibly configure multi-status indication such as LED light (red, yellow, green) and buzzer.

  • Page 390: System

    System 5.8.1 Device Information System Information System Information shows Operating System, OS Version, NVR Version, CPU, Network Adapter, MAC Address, and Network Flow. Locate Click “Locate”, the NVR buzzer will be triggered for 3 seconds. It helps the user to locate the NVR. Enclosure Information Note: Temperature of operation environment for NVR is 0~40˚C.

  • Page 391: Log System

    5.8.2 Log System If the hard disk is not installed, the following window will pop up when you click “Log System.” After the hard disk is ready, Log system starts to record the events of the NVR and to provide basic information for troubleshooting. Six types of log record are offered to check: Hardware Log, System Log, Event Log, Current User, Historical User Log, and File Access Log.
  • Page 392 Event Log The log information in Event Log includes “Camera is connected,” “The camera is disconnected,” “Digital Input,” “Motion detected” and “Storage usage is out of limit,” etc. Current User NVR allows admin/power users to check all current users’ log-in status including Date &...
  • Page 393  The basis of user count is calculated by a combination of accessed resource number on configuration, liveview, playback from NVR-client and mobile app (v.3.0.20 supported)  Please upgrade both firmware and NVR-Client to the latest version. If not, it will be shown as empty on current user list and it won’t be counted.

  • Page 394: Save/Load Configuration

    5.8.3 Save/Load Configuration Configuration Backup enables you to accelerate NVR deployment as well as to respond quickly to hardware failures and disasters. User can save NVR configuration file and E-Map configuration to NVR HDD, external USB device (via local site) and computer (via remote PC access). If the raid disk is not built, the following window will pop up.
  • Page 395 Load Configuration Load configuration can help users duplicate the same settings from one NVR to another without configuring system manually. Users can select Load Type as “Load Default Settings” or “Load Configuration.” A. “Load Default Settings”: all configurations (Camera Setting, Recording Settings, Event &...
  • Page 396 option > General Note: The accepted image formats are PNG, BMP and JPEG. Save E-Map configuration file (cfg): ② Go to Save Configuration page (Same steps as “1. Save Configuration”) The system will save “all maps” configuration to one cfg file. E-Map page destination...
  • Page 397 For the steps of adding a map, please refer to 4.2.2 Add or Delete Multi-layer E-Maps Load the configuration ④ Go to Load Configuration page (Same steps as “2. Load Configuration”) The NVR will automatically reboot after pressing “Apply” ⑤...

  • Page 398: Hardware Settings

    5.8.4 Hardware Settings In this section, users can setup for Buzzer, Digital Output and Reset Button. Buzzer Select “Enable” or “Disable” to set Buzzer Notice. Once the buzzer notice is enabled, the buzzer will have beep sound in below situations: 1.

  • Page 399: System Upgrade

    Disable the feature (system default: on) ① Press Apply ② Check the Log Go to Configuration page > System > Log System > Hardware Log 5.8.5 System Upgrade Users can do NVR firmware upgrade via Remote Web Browser (Microsoft Edge/ Chrome/Firefox/Opera) or Local Display (connect directly to a local monitor via HDMI or VGA connector).
  • Page 400 A window will pop up to ask for the folder to upload the firmware. (5) Click “Upgrade” button After selecting the file, please click “Upgrade” to renew the NVR. Once system upgrade is finished, NVR will reboot itself. Users could go to “Device Information” from the drop-down list of “System” so as to double check NVR firmware version.
  • Page 401 Note: If you want to upgrade the NVR via USB device on local display UI, after downloading and unzipping the file, please rename the unzipped .bin file name to “update” in the USB device, in order to have it recognized by the local NVR correctly.
  • Page 402 Once firmware upgrade finishes, NVR will reboot itself. Users could go to “Device Information” from the drop-down list of “System” so as to double check NVR firmware version.

  • Page 403: Date & Time

    5.8.6 Date & Time You can configure NVR’s date & time, time zone and external time- synchronized device in this page. 1. Manual (1) Date Format Define a suitable date format for local display’s liveview and playback. Note: For NVR-Client (Liveview and Playback) and NVRPlayer, date format is specified for operating system (Windows OS).
  • Page 404 2. Time zone (1) Time zone: set the time and date according to the correct time zone (2) Automatically adjust clock for Daylight Saving Time: adjust clock for daylight saving changes (3) Automatically synchronize with external NTP server: Define when to automatically synchronize with external NTP sever.

  • Page 405: Language

    Please insert USB device to NVR USB port first. (1) Enable “Power Sync” (2) Select “Automatically Sync” (3) Set automatically sync interval to execute automatically synchronize: Monthly, Weekly or Daily (4) Fill in the number to adjust time when time difference exceeds user- defined seconds (5) Click “Apply”...

  • Page 406: Reboot & Shutdown

    5.8.8 Reboot & Shutdown Reboot & Shutdown Click “Reboot” to restart the NVR. Click “Shutdown” to turn off the NVR. Power Button Password protection can protect system from carelessly or accidentally pressing the power button. When password protection is enabled, administrator and power user will be asked to enter their own account password to shut down system after pressing the power button for 3 seconds.

  • Page 407: Appendix 1: Notice And Warning

    Appendix 1: Notice and Warning Notice ＊ This equipment is for home use, and has acquired the electromagnetic conformity registration. So, it can be used not only in residential area, but also other areas. ＊ 이기기는가정용(B 급) 전자파적합기기로서주로가정에서사용하는것을목적으로하며, 모든지역에서사용할수있습니다. Warning ＊Risk of explosion if battery is replaced by an incorrect type.
