Network Video Recorder

User Manual

1.0.0.18
Information in this document is subject to change without notice.
© Copyright 2014, DIGIEVER Corporation. All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2009 and is the answer not in the manual?

Questions and answers

Related Manuals for Digiever DS-2009

Summary of Contents for Digiever DS-2009

  • Page 1: User Manual

    Network Video Recorder User Manual 1.0.0.18 Information in this document is subject to change without notice. © Copyright 2014, DIGIEVER Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Table of Contents Chapter 1. Introduction ................1 Hardware Description ................. 2 1.1.1 DS-2000 Series ................. 2 1.1.2 DS-4000 Series ................. 3 1.1.3 DS-1100 Pro Series ................4 1.1.4 DS-2100 Pro Series ................5 1.1.5 DS-4200 Pro Series ................6 1.1.6 DS-4200-RM Pro Series ..............
  • Page 3 2.3.2 Network Settings ................38 2.3.3 Server Settings ................39 2.3.4 Date &Time ..................40 2.3.5 Disk Management ................41 2.3.6 Camera Settings ................49 2.3.7 Finish ....................58 Others ......................59 2.4.1 NVRCheck ..................59 2.4.2 NVRPlayer ..................60 Chapter 3.
  • Page 4 3.4.5 Zooming with Mouse Scroll ............92 Others ......................92 3.5.1 Screenshot on Local Display ............92 3.5.2 System Upgrade on Local Display ..........92 3.5.3 USB Backup by Software USB BACKUP Virtual Button ....93 Chapter 4. Use NVR by Remote Web Browser ........94 Live View .....................
  • Page 5 5.1.1 Camera Settings ................140 5.1.2 Camera Parameter ............... 141 5.1.3 Camera Status ................144 Recording & Events ................. 145 5.2.1 Recording Settings ..............146 5.2.2 Recording Schedule..............148 5.2.3 Event & Action Management ............151 5.2.4 Advanced Setting ................. 160 5.2.5 Event Schedule ................
  • Page 6 System ....................... 202 5.7.1 Device Information ............... 202 5.7.2 System Upgrade ................203 5.7.3 Language ..................207 5.7.4 Date &Time ................... 207 5.7.5 Buzzer ................... 209 5.7.6 Reboot &Shutdown ..............210 Appendix: Notice and Warning ..............211...

  • Page 7: Chapter 1. Introduction

    Chapter 1. Introduction Before You Use This Product When you first open the product’s package, verify that all the accessories listed on the “Package Contents” of “Quick Installation Guide” are included. Before installing the NVR, please read the instructions in the “Quick Installation Guide” to avoid misuse and then follow the instructions in the “Hard Disk Installation”...

  • Page 8: Hardware Description

    1.1 Hardware Description 1.1.1 DS-2000 Series DS-2005/DS-2009/DS-2012/DS-2016/DS-2020/DS-2025/DS-2032 Figure 1-1. Front & Rear View of DS-2000 Series Figure LED indicators: LAN, eSATA, HDD1, HDD2 Power button USB BACKUP button- Auto video backup USB 2.0 X1(Support auto video backup) HDD1 HDD2 Gigabit LAN USB 2.0 x 2...

  • Page 9: Ds-4000 Series

    1.1.2 DS-4000 Series DS-4005/DS-4009/DS-4012/DS-4016/DS-4020/ DS-4025/ DS-4032 Figure 1-2. Front & Rear View of DS-4000 Series LED indicators: LAN, eSATA, HDD1, HDD2, HDD3, HDD4 Power button USB BACKUP button- Auto video backup USB 2.0 x 1 (Support auto video backup) HDD1 HDD2 HDD3 HDD4...

  • Page 10: Ds-1100 Pro Series

    1.1.3 DS-1100 Pro Series DS-1105Pro/ DS-1109Pro/ DS-1112Pro/ DS-1116Pro/ DS-1120Pro/ DS-1125 Pro/ DS-1132 Pro/ DS-1136 Pro Figure 1-3. Front & Rear View of DS-1100 Pro Series Power button LED indicators: HDD USB 2.0 x1 (Support auto video backup) USB 2.0 x1 Power connector USB 3.0 x 2 DVI-I...

  • Page 11: Ds-2100 Pro Series

    1.1.4 DS-2100 Pro Series DS-2105Pro/ DS-2109Pro/ DS-2112Pro/ DS-2116Pro/ DS-2120Pro/ DS-2125 Pro/ DS-2132 Pro/ DS-2136 Pro Figure 1-4. Front & Rear View of DS-2100 Pro Series Power button LED indicators: HDD USB 2.0 x1 (Support auto video backup) USB 2.0 x1 Power connector USB 3.0 x 2 DVI-I...

  • Page 12: Ds-4200 Pro Series

    1.1.5 DS-4200 Pro Series DS-4205Pro/ DS-4209Pro/ DS-4212Pro/ DS-4216Pro/ DS-4220Pro/ DS-4225Pro/ DS-4232 Pro/ DS-4236 Pro Figure 1-5. Front & Rear View of DS-4200 Pro Series LED indicators: LAN1, LAN2, eSATA, HDD1, HDD2, HDD3, HDD4 Power button USB BACKUP button - Auto video backup USB 2.0 x 1(Support auto video backup) USB 2.0 x 1 HDD1...

  • Page 13: Ds-4200-Rm Pro Series

    1.1.6 DS-4200-RM Pro Series DS-4209-RMPro/ DS-4212-RM Pro/ DS-4216-RM Pro/ DS-4220-RM Pro/ DS-4225-RM Pro/ DS-4232-RM Pro/ DS-4236-RM Pro Figure 1-6. Front & Rear View of DS-4200-RM Pro Series 1. LED indicators: LAN1, LAN2, eSATA, HDD1, HDD2, HDD3, HDD4 2. Power button 3.

  • Page 14: Ds-8200-Rm Pro Series

    1.1.7 DS-8200-RM Pro Series DS-8209-RMPro/ DS-8212-RM Pro/ DS-8216-RM Pro/ DS-8220-RM Pro/ DS-8225-RM Pro/ DS-8232-RM Pro/ DS-8236-RM Pro Figure 1-7. Front & Rear View of DS-8200-RM Pro Series 1. LED indicators: LAN1, LAN2, eSATA, HDD1, HDD2, HDD3, HDD4, HDD5, HDD6, HDD7, HDD8 2.

  • Page 15: Led Indicators Status

    1.2 LED Indicators Status 1.2.1 DS-2000 Series DS-2005/ DS-2009/ DS-2012/ DS-2016/ DS-2020/ DS-2025/ DS-2032 Figure 2-1. DS-2000 Series Front Panel & RJ-45 Port LED on Front Panel LED Color & Status Indicate LAN Link is not established Orange LAN Link is established...
  • Page 16 LED on RJ-45 Port on Rear Panel LED Position LED Status Indicate LAN Link is not established Link/Activity Yellow LAN Link is established (Right LED) Yellow blinking LAN Activity is occurring 10M/100Mbps connection or no Speed connection (Left LED) Orange 1000Mbps connection Note: **USB BACKUP will beep and process after long pressing BACKUP button for 3...

  • Page 17: Ds-4000 Series

    1.2.2 DS-4000 Series DS-4005/ DS-4009/ DS-4012/ DS-4016/ DS-4020/ DS-4025/ DS-4032 Figure 2-2. DS-4000 Series Front Panel & RJ-45 Port LED on Front Panel LED Color & Status Indicate LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed No data transmission eSATA...
  • Page 18 LED on RJ-45 Port on Rear Panel LED Position LED Status Indicate LAN Link is not established Link/Activity Yellow LAN Link is established (Right LED) Yellow blinking LAN Activity is occurring 10M/100Mbps connection or no Speed connection (Left LED) Orange 1000Mbps connection *USB BACKUP will start and beep after 3 seconds user presses BACKUP button.

  • Page 19: Ds-1100 Pro Series

    1.2.3 DS-1100 Pro Series DS-1105 Pro/ DS-1109 Pro/ DS-1112 Pro/ DS-1116 Pro/ DS-1120 Pro/ DS-1125 Pro/ DS-1132 Pro/ DS-1136 Pro Figure 2-3. DS-1100 Pro Series Front Panel Note: **To turn off your NVR, long pressing power button at least 2 seconds. **To turn on your NVR, long pressing power button at least 3 seconds.

  • Page 20: Ds-2100 Pro Series

    1.2.4 DS-2100 Pro Series DS-2105 Pro/ DS-2109 Pro/ DS-2112 Pro/ DS-2116 Pro/ DS-2120 Pro/ DS-2125 Pro/ DS-2132 Pro/ DS-2136 Pro Figure 2-4. DS-2100 Series Front Panel Note: **To turn off your NVR, long pressing power button at least 2 seconds. **To turn on your NVR, long pressing power button at least 3 seconds.

  • Page 21: Ds-4200 Pro Series

    1.2.5 DS-4200 Pro Series DS-4205Pro/ DS-4209Pro/ DS-4212Pro/ DS-4216Pro/ DS-4220Pro/ DS-4225Pro/ DS-4232 Pro/ DS-4236 Pro Figure 2-5. DS-4200 Pro Series Front Panel & RJ-45 Port LED on Front Panel LED Color & Status Indicate LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed No data transmission...
  • Page 22 LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection or no connection LAN1 Speed Green 100Mbps connection LAN2 (Left LED)

  • Page 23: Ds-4200-Rm Pro Series

    1.2.6 DS-4200-RM Pro Series DS-4209-RM Pro/ DS-4212-RM Pro/ DS-4216-RM Pro/DS-4220-RM Pro/ DS-4225-RM Pro/ DS-4232-RM Pro/ DS-4236-RM Pro Figure 2-6. Front View of DS-4200-RM Pro Series & RJ-45 Port LED on Front Panel LED Color & Status Indicate LAN Link is not established Orange LAN Link is established Orange blinking...
  • Page 24 LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection or no connection LAN1 Speed Green 100Mbps connection LAN2 (Left LED)

  • Page 25: Ds-8200-Rm Pro Series

    1.2.7 DS-8200-RM Pro Series DS-8209-RM Pro/ DS-8212-RM Pro/ DS-8216-RM Pro/DS-8220-RM Pro/ DS-8225-RM Pro/DS-8232-RM Pro/ DS-82326-RM Pro Figure 2-7. Front View of DS-8200-RM Pro Series & RJ-45 Port LED on Front Panel LED Color & Status Indicate LAN Link is not established Orange LAN Link is established Orange blinking...
  • Page 26 LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection or no connection LAN1 Speed Green 100Mbps connection LAN2 (Left LED)

  • Page 27: Dual Display Solution: Hdmi/Vga/Dvi-I Connection

    1.3 Dual Display Solution: HDMI/VGA/DVI-I Connection DS-4200 Pro Series, DS-4200-RM Pro Series and DS-8200-RM Pro Series provide HDMI and VGA port for local display. Users can connect both of HDMI and VGA at the same time for video output. DS-1100 Pro Series and DS-2100 Pro Series provide HDMI and DVI-I port for local display.

  • Page 28: Chapter 2. Nvr Installation

    Chapter 2. NVR Installation 2.1 Remote PC System Requirements The following information is the minimum required specification for remote Windows PC, which users can open a remote browser from the PC to access the Linux NVR server on the network. Operating System ...

  • Page 29: Connect To Nvr

    2.2 Connect to NVR To begin, please insert the product CD-ROM in a PC to access the Quick Guide, User Manual and install the utilities. As user runs the product CD, the following menu is displayed. 2.2.1 Quick Guide Click “Quick Guide” to enter the folder and double click the file to open.
  • Page 30 When installing EZ Search, Shield Wizard window for EZ Search will pop up. Click “Next” to continue installation. Read the license agreement and click “I accept the terms of the license agreement”. Click “Next” to continue installation.
  • Page 31 Select a location of destination and select a folder where the setup can install files. The default location is: C:\Program Files (x86)\DIGIEVER\EZ Search. Users can also install EZ Search in other folder by clicking “Change” and select a location as below.
  • Page 32 The window shows that the InstallShield Wizard is installing EZ Search. Please wait until the Wizard completes the installation. The InstallShield has successfully installed EZ Search. Select “Create Desktop Shortcut”/ “Create Quick Launch Shortcut”/ “Create Start Menu Shortcut” and please click “Next” to continue.
  • Page 33 The installation is complete. Please click “Launch application when done installing” to execute EZ Search. After finishing the setup, the window of EZ Search will pop up. Easy Search will execute automatically and show NO., Name, IP Address, Mac Address and Model name of connected NVR. Users can click “Search”...
  • Page 34 Introduction of EZ Search EZ Search provides three kinds of toolbars for users: File You can click “Exit” to leave EZ Search and close the window. 2. Setting Configure UPnP and Network by clicking “Setting” in the top left or in the middle right.
  • Page 35 When accessing the NVR setting, users will be prompted to enter username and password. For the first-time use, the default username and password are admin/admin. When the correct username and password have been entered, click “Login” to continue. 1) UPnP Universal Plug and Play (UPnP) simplifies the process of adding a NVR to a local area network.
  • Page 36 2) Network Two models are provided for setting the network: DHCP and Static IP.
  • Page 37 3. Option Option provides several languages Once you click “Connect” or double click the selected NVR list, IE browser will pop up automatically for the web-based interface.

  • Page 38: Install S-Nvr Decoder

    2.2.3 Install S-NVR Decoder Click “Install S-NVR Decoder” to install decoder and follow the instructions to setup. Install Shield Wizard window will pop up and please click “Next” to continue installation. Read license agreement and click “I accept the terms of the license agreement.” Click “Next”...

  • Page 39: User Manual

    The installation Wizard is installing S-NVR Decoder. The installation is complete. Please click “Finish” to close the window. 2.2.4 User Manual Click “User Manual” to open the folder and double-click on user manual file to read. 2.2.5 Browse CD Click “Browse CD” to open the folder of current Autorun.exe file.
  • Page 40 2.2.6 Activate Live View Service 1. Connect to NVR After setting the EZ Search and S-NVR Decoder, users can connect to the web-based interface by the following two options: EZ Search or IE browser 1) EZ Search Once you click “Connect” or double click the selected NVR list, the IE browser will pop up automatically.
  • Page 41 4. Allow ActiveX Control After logging in the NVR, users are recommended to install ActiveX control for the first-time installation. 1) Left-click on the description “This website wants to run the following add-on: ‘NVR ActiveX’ from…..” 2) Left-click on the description “Run Add on.”...
  • Page 42 3) Left-click “Run” to use licensed ActiveX controls.

  • Page 43: Quick Configuration

    2.3 Quick Configuration After users log in NVR and install the ActiveX control, the system will direct you to set Quick Configuration in five main steps. Follow the instructions of the Overview of wizard to complete system setup. 2.3.1 Start System will lead you to “Start”...

  • Page 44: Network Settings

    2.3.2 Network Settings Please select “Network Settings” from the drop-down menu of Configuration Utility to begin. Users need to adjust the settings in the Network Setup page in order to let NVR work properly within network. There are 2 methods to configure IP address ...

  • Page 45: Server Settings

    To assign a static IP address to the NVR: 1. Select “Specify an IP address” 2. Enter the IP address, Subnet Mask, Default Gateway IP Address and DNS server address. 3. If IP Address is changed, user needs to log out NVR and login in again. Click “Next”...

  • Page 46: Date &Time

    2.3.4 Date &Time Please select “Date & Time” from the drop-down menu of Configuration Utility to begin. Manual setting Use the drop-down list and configure the time manually. Select the Year, Month, Date and Time. Time setting will be effective when you click “Next.” Time Zone: Synchronize with an Internet time server automatically.

  • Page 47: Disk Management

    Configure the time and date by verifying and adjusting current local time and daylight saving to avoid the following errors: Incorrect display time for playback videos.  Inconsistent display time of event logs and when they actually occur.  Please enter the hostname of a valid NTP server to synchronize the server time with an Internet time server.
  • Page 48 Once an available hard disk drive is inserted into the tray, Disk Information will show in Device Information and users can start to create new RAID Disk. Disk Information Device Information provides details of the hard disk drive: HDD Model, Serial NO., Capacity and Status.
  • Page 49 The selected hard disk drive in the Free HDDs field will be marked in blue and please click to recruit the hard disk drive into Assigned HDDs field.
  • Page 50 The selected hard disk drive in Assigned HDDs field will be marked in blue. Meanwhile, Target RAID Disk is ready to build RAID disk and it shows five types of disk configuration. The introduction of disk configuration is in the below table. Disk Configuration Big Drive Big Drive is a collection of hard disk drives and does not provide...
  • Page 51 Select a type of disk configuration, and please click “Apply” to execute building new RAID disk. Note: Don’t turn off the server or unplug any hard drives when RAID Disk is in building process. Please wait. The disk configuration is in a process. The progress is under “formatting….20%”.
  • Page 52 The progress is in “Create swap” and is going to finish the disk building. Finally, the RAID disk building is complete. After the RAID disk is created, RAID List shows RAID Name and available storage devices. Device Information provides status of the hard drive: RAID Name, Level, Capacity, Status-Active, Action State, Background Activity and Progress-none.
  • Page 53 Remove  Click “Remove” to delete RAID Disk. Once “Remove” is clicked, a window will pop up to ensure the execution. To delete RAID Disk, click “OK” to proceed. Please wait. The deletion is in a process. If users want to change the RAID level setting, please click ‘‘Remove.’’ After the RAID Disk is removed, the Status in Device information shows “Ready,”...
  • Page 54 Format  Click “Format” to format the RAID disk, all recorded videos will be deleted. Once “Format” is clicked, a window will pop up to ensure the execution. To format RAID disk, click “OK” to continue. Hard disk drive is formatting. Please wait for formatting until 100%.

  • Page 55: Camera Settings

    2.3.6 Camera Settings NVR provides two options to add new cameras: UPnP Search and Detect Detect: In this option, users are asked to enter IP Address. Check correct username and password. Then, click “Apply” button to start adding camera. Vendor, Username and Password are editable. After clicking “Apply”...
  • Page 56 Streaming Parameters  NVR provides two options to set up stream parameters: Optimization by NVR and Settings from camera. (1) Optimization by NVR By selecting this option, NVR will optimize settings to perform the best surveillance efficiency. (2) Settings from camera If users have already set up camera settings from camera webpage, NVR can adopt camera setting by selecting “Setting from Camera.”...
  • Page 57 After successfully adding cameras, NVR will display camera information in camera list. If there is any error occurred in entering the following information, the notification window will pop up as below. When an inappropriate address is entered, a window will pop up as below. When an inappropriate user name is entered, a window will pop up as below.
  • Page 58 Delete  If any camera should be deleted from camera list, please click the column turning into blue and click “Delete” button. A window will pop up to ensure the action. To delete the camera, click “OK” to proceed. The camera has been deleted from camera list. Generic RTSP/ Generic MJPEG ...
  • Page 59 Follow by entering the Generic URL column with proper RTSP or MJPEG URLs. If Generic RTSP is selected, RTSP port should be filled out too. Click “Apply” button to make parameters enable The most correct URLs should be provided from each camera vendors. Users may also refer to websites https://www.soleratec.com/rtsp/ http://www.ispyconnect.com/sources.aspx...
  • Page 60 UPnP Search: Click “UPnPSearch” to find out UPnP devices within the LAN. Please make sure IP camera supports UPnP Search function. Please go to IP Camera web page to enable UPnP search function. Please wait. The UPnP search is in a process. The available cameras in the network will be displayed.
  • Page 61 Please check camera information in Group add page. Then, Click “Add All” button to start adding cameras Note: NVR will automatically fill in default username and password of each vendor. Camera No., Camera Name, User Name and Password can be modified by users.
  • Page 62 Status column in camera list will display “Successful” when cameras are successfully added in NVR. Please click “Go to Camera Settings” button to check all camera information camera list that is successfully added in NVR. Multi-channel Video Server  NVR supports multi-channel video server feature to connect analog cameras to NVR. Please click “Enable”...
  • Page 63  Delete User can click “Delete” button to remove the camera from NVR. Please click a camera and click “Delete” button. A window will pop up to ensure the execution. Please click “OK” to proceed.

  • Page 64: Finish

    2.3.7 Finish Please select “Finish” from the drop-down menu of Configuration Utility to begin. Once five steps of Quick Configuration are completed, the window will show the completed status. You can click “Back” to return to the previous steps to modify the configuration or click “Start Live view”...

  • Page 65: Others

    2.4 Others 2.4.1 NVRCheck While NVR is recording video and snapshot files, the digital watermark will be embedded automatically in the images. To ensure the security of videos and snapshots, NVRCheck is a useful tool to verify whether the files are originated from NVR. Please double click the icon to start the application.

  • Page 66: Nvrplayer

    2.4.2 NVRPlayer NVRPlayer allows users to view the recorded videos exported from NVR. NVRPlayer is a portable tool with no need to install on PC. Please right-click to run NVRPlayer as administrator Click “Open” button to select one video to playback.
  • Page 67 Users can move “Time Bar” to desired time when playing recorded video Feature introduction  Frame by Frame Playback Please click “Pause” button and click “Next Frame” or “Previous Frame” to find the desired video accurately. Snapshot  Please click “Snapshot” button to take desired video to your PC.

  • Page 68: Chapter 3. Use Nvr By Local Display

    Chapter 3. Use NVR by Local Display NVR can be connected to a monitor via HDMI and VGA port to execute quick configuration and display live view. Note: Local display feature is supported in DS-1100 Pro, DS-2100 Pro, DS-4200 Pro Series, DS-4200-RM Pro Series and DS-8200-RM Pro Series. To start local display, please check the steps below: 1.

  • Page 69: Anonymous Login

    3.1.1 Anonymous login Anonymous login allows users to login without username and password. Anonymous user can only view live monitoring and playback page in local monitor, however, the configuration page will be disable. While anonymous login is applied, system will automatically log in without authorization process after boot up. Start to setup the anonymous login A.

  • Page 70: Virtual Keyboard

    3.1.2 Virtual Keyboard Users can choose to use USB keyboard for typing in local display of NVR, or fill out columns with virtual keyboard. The virtual keyboard in local display can be enabled from the right side of each column. There are 3 types of virtual keyboard can be chosen, including Upper case, Lower case and Symbols.

  • Page 71: Quick Configuration

    3.2 Quick Configuration After you log in local display of NVR, the system will direct you to set Quick Configuration in five main steps. Follow the instructions of the Overview of wizard to complete the system setup. 3.2.1. Start To initial NVR’s configuration, please study the Overview of wizard first. Through five steps, the wizard will guide you to set up the system quickly.

  • Page 72: Camera Settings

    3.2.6. Camera Settings NVR provides two options to add new cameras: UPnP Search and Detect Detect: In this option, users are asked to enter IP Address. Check correct username and password. Then, click “Apply” button to start adding camera. Vendor, Username and Password are editable. After clicking “Apply”...
  • Page 73 Streaming Parameters  NVR provides two options to set up stream parameters: Optimization by NVR and Settings from camera. (1) Optimization by NVR By selecting this option, NVR will optimize settings to perform the best surveillance efficiency. (2) Settings from camera If users have already set up camera settings from camera webpage, NVR can adopt camera setting by selecting “Setting from Camera.”...
  • Page 74 After successfully adding camera, NVR will display camera information in camera list. If there is any error occurred in entering the following information, the notification window will pop up as below. When an inappropriate address is entered, a window will pop up as below. When an inappropriate user name is entered, a window will pop up as below.
  • Page 75 Delete  If any camera should be deleted from camera list, please click the column turning into blue and click “Delete” button. A window will pop up to ensure the action. To delete the camera, click “Yes” to proceed. The camera has been deleted from camera list. Generic RTSP/ Generic MJPEG ...
  • Page 76 Follow by entering the Generic URL column with proper RTSP or MJPEG URLs. If Generic RTSP is selected, RTSP port should be filled out too. Click “Apply” button to make parameters enable The most correct URLs should be provided from each camera vendors. Users may also refer to websites https://www.soleratec.com/rtsp/ http://www.ispyconnect.com/sources.aspx...
  • Page 77 UPnP Search: Please go to Camera Search page and click “UPnPSearch” to find out UPnP devices within the LAN. Please make sure IP camera supports UPnP Search function. Please go to IP Camera web page to enable UPnP search function. The available cameras in the network will be displayed.
  • Page 78 Memorize modified username and password: NVR will memorize username and password which is modified by users after users click “Apply” button. Then, the default username and password of that vendor will be replaced by the modified one. Next time when users add new camera of the specific vendor, username and password will be automatically filled in by new modified one.
  • Page 79 Please click “Go to Camera Settings” button to check all camera information camera list that is successfully added in NVR. Multi-channel Video Server  NVR supports multi-channel video server feature to connect analog cameras to NVR. Please click “Enable” Video Server and choose the channel number. Please click “Add All”...

  • Page 80: Finish

    3.2.7. Finish Once five steps of Quick Configuration are complete, the window will show a completed status. User can either click “Back” button to modify NVR configuration or click” Start Live View” to start monitoring. 3.3 Live View After the Quick Configuration is complete, users can successfully monitor IP cameras. In live view page, users can monitor cameras in various display modes and control PTZ cameras.

  • Page 81: Select View Modes On Live View Page

    3.3.1 Select View Modes on Live View Page On top right of live view, users can select four view modes. Mode Description Live View: Click “Live View” to control the monitoring instantaneously. Playback: Click “Playback”to play and to export the recorded video files. Configuration: Click “Configuration”to configure camera, recording, event, management, network, quick configuration and system.

  • Page 82: Main Functions For Live View

    3.3.2 Main Functions for Live View Camera status Icon Description Camera name: The name of the camera is located in the top left corner in each video window. Users can rename the camera via the path “Configuration->IP Camera->Camera Settings.” Video compression format: M-JPEG/MPEG-4/H.264 Audio: Once camera supports audio, NVR shows audio in blue.
  • Page 83 Disk and CPU loading indicator: Users can find out Disk and CPU loading directly without entering configuration page. Disk and CPU loading indicator shows blue when loading is 70% or under, and shows red as a warning when it reach to more than 70%. With changing the video configuration, like resolution, FPS and video quality or changing RAID type, can influence the CPU loading, and users can easily find the best balance in NVR.
  • Page 84 Icon Description Full Screen 1 screen 4 screen 9 screen 12 screen 16 screen 20 screen 25 screen 5+1 screen Sequential mode Click to choose the page of liveview PTZ Control Panel If the IP camera supports PTZ function, user can use the control panel to adjust the viewing angle.
  • Page 85 Preset positions: Select the preset positions which are defined in PTZ camera and the camera will move to the position that user selects. Optical zoom in/ out: If camera supports PTZ control, users can adjust PTZ camera to zoom out or zoom in. Focus near / far: If camera supports PTZ control, users can adjust the focus of the PTZ camera to focus near or focus far.
  • Page 86 Users can view all detailed list of motion detection in both local display and remote web browser. At the same time, the icon will stop blinking. Option Option button can let users directly to do live-view setting such as warning setting, windows setting and sequential mode setting.
  • Page 87 warning frame which will pop out on the channel when an event is detected. When the motion event is awarded, user can simply click on the channel with mouse, the warning frame will be stopped.  Liveview event notification with video pop-out window Once the feature is enabled, a new window will pop out when an event is triggered so as to inform users of event happened at the very first time.
  • Page 88 If user enable event pop-out window for all cameras, all channels in NVR camera list will pop-out a video when events happen. Note: NVR will pop-out video event window once a time, depending on which event happens earlier when more than one event happens at the same time.

  • Page 90: Right Click Functions On Video Window

    3.3.3 Right Click Functions on Video Window 1. Video Size: Original or Fit 2. Streaming change: NVR allows users to setup the dual streaming configurations in camera parameter page if cameras support dual stream. It is suggested stream 1 is set for higher resolution and stream 2 for lower resolution, which helps users to choose the proper streaming in live view with intuitive control.

  • Page 91: Zooming With Mouse Scroll

    3.3.4 Zooming with Mouse Scroll In addition to digital zoom in/out button, users can use mouse scroll to prevent potential crisis in live-view monitoring. Note: For PTZ cameras, zooming with mouse in live-view is adopted optical zoom in/out. If users would like to view more detailed image, please use zooming with mouse scroll first and then click digital zoom in/out button.

  • Page 92: Playback

    Playback Playback is a function that allows users to view recorded videos from cameras connected to NVR. NVR offers synchronized playback up to four cameras and easy steps provided to help user sort through the recorded videos quickly. 3.4.1 Steps to Playback Videos Users can easily search recorded videos by following playback steps.
  • Page 93 1. Select cameras from camera list Users can select up to four cameras to play the recorded video. 2. Select date and time Users can designate the specific date and time to playback video. If the selected cameras have recorded videos, the date will be shown in a blue background in default (Normal Record).
  • Page 94 Frame by Frame Playback 1 Follow above four steps of Playback 2 Click “Pause” 3 Click “Previous image” or “Next image”...

  • Page 95: Main Functions For Playback

    3.4.2 Main Functions for Playback 1. Display mode The screen shows the recording time of each channel in the top of each grid. Click to view the video in full screen. One-screen and four-screens are also provided to display playback. 2.
  • Page 96 4. Video playback speed control (1) Pause: to temporarily stop the playback. (2) Previous Image: to show the earlier image. (3) Slow motion: to play in slower speeds. (4) Play: to play video file. (5) Fast forward: When you click “speed up,” the recorded video will play faster.

  • Page 97: Export Files

    3.4.3 Export Files Export function allows users to export file to USB device or USB type DVD burner directly. Please select cameras, video file types, date and the time period first, and then click the export button to copy the files. Users will be asked whether NVRPlayer and NVRCheck should be downloaded with video files.

  • Page 98: Snapshot

    3.4.4 Snapshot Users can have the snapshot while having the playback in local display. It needs to plug in USB device for the export of snapshot images and it will have 10 sequential images to be saved in the USB dongle. 3.4.5 Zooming with Mouse Scroll In addition to digital zoom in/out button, users can use mouse scroll to find out crucial proof in incident site in playback...

  • Page 99: Usb Backup By Software Usb Backup Virtual Button

    NVR supports system upgrade in local display. For more information, please refer to Chapter 5 - 5.7.2 System Upgrade. Note: System upgrade in local display is supported in DS-8200-RM Pro Series, DS-4200-RM Pro Series, DS-4200 Pro Series, DS-2100 Pro Series and DS-1100 Pro series.

  • Page 100: Chapter 4. Use Nvr By Remote Web Browser

    Chapter 4. Use NVR by Remote Web Browser Users can adopt multiple web browsers ( IE/ Chrome/ Firefox/ Opera browser in Windows) to monitor the network camera and view playback. Live View After the Quick Configuration is complete, NVR will guide you to live view. Users can view live video stream from IP camera via network and monitor the instantaneous view remotely.

  • Page 101: Select View Modes On Live View Page

    4.1.1 Select View Modes on Live View Page On top right of live view, users can select four view modes. Mode Description Live View: Click “LiveView” to control the monitoring instantaneously. Playback: Click “Playback” to play and to export the recorded video files. Configuration: Click “Configuration”...

  • Page 102: Main Functions For Live View

    4.1.2 Main Functions for Live View 1. Camera status Icon Description Camera name: The name of the camera is located in the top left corner in each video window. Users can rename the camera via the path “Configuration->IP Camera->Camera Settings.” Video compression format: M-JPEG/MPEG-4/H.264 Audio: Once camera supports audio, NVR shows audio in blue.
  • Page 103 (2) Current time Users can find out current time directly. (3) Disk and CPU loading indicator: Users can find out Disk and CPU loading directly without entering configuration page. Disk and CPU indicator shows blue when loading is70% or under, and shows red as a warning when it reach to more than 70%.
  • Page 104 2) Save: To save image to default path. 3) Cancel: To cancel snapshot. Digital zoom in/ out: Select a channel to enable digital zoom function Drop: Drop the camera from monitoring. Drop all: Drop all cameras from monitoring. Add all: Add all cameras from monitoring.
  • Page 105 Icon Description Full Screen 1 screen 4 screen 9 screen 10 screen 12 screen 16 screen 20 screen 25 /30/ 36/49 screen 5+1 screen 7+1 screen 12+1 screen Sequential mode Click to choose the page of liveview . In option, Users can set sequential interval in user-defined seconds for display mode.
  • Page 106 6. PTZ Control Panel If IP camera supports PTZ function, users can use the control panel to adjust the viewing angle. The following functions are available depending on the camera models. Icon Description PTZ panel: PTZ allows users to monitor large areas with a single network camera.
  • Page 107 By clicking the button, a window will pop up to display the list of event log as below. Users can easily read detailed information from the window. At the same time, the icon will stop blinking. Enable Alert sound If users enable the function, the remote web browser will sound the alarm to notify users when motion detection is triggered.
  • Page 108 Automatically reorder Liveview windows  To rearrange video in order without blank grid after users drop video from live-view. Resize all video sizes at the same time  Only a right click on the video, users can set "all" video size either in original size or fit size.
  • Page 109 Liveview event notification with video pop-out window  Once the feature is enabled, a new window will pop out when an event is triggered so as to inform users of event happened at the very first time. By clicking button at the top-right corner, users can manually close the pop-out window.
  • Page 110 All cameras in the NVR will have event pop-out window. If user enable event pop-out window for all cameras, all channels in NVR camera list will pop-out a video when events happen. Note: NVR will pop-out video event window once a time, depending on which event happens earlier when more than one event happens at the same time.
  • Page 111 4) Joystick Users are able to manipulate PTZ camera with USB joystick. Choose the joystick column and select joystick model then press ‘‘Apply’’ Joystick can work on PTZ cameras as the status bar is with PTZ icon. Note: NVR supports joystick in remote web client.

  • Page 112: Right Click Functions On Video Window

    4.1.3 Right Click Functions on Video Window 1. Mute: To mute the audio of the video 2. Video Size: Original or Fit 3. Streaming change: To exchange the streaming resource. (1) Exchange Streaming NVR allows users to setup the dual streaming configurations in cameras parameters page if cameras support dual stream.
  • Page 113 When “Optimize” is disabled, users can manually adjust streaming type, which will be memorized in different display modes. (2) Stream from Server In case that NVR performance is violated by camera limitation, stream from server is an optional choice for users to view video images. It is highly recommend to use “Enable Optimization”...

  • Page 114: Zooming With Mouse Scroll

    b. Choose dewarp Type : (2) Dewarp for Immervision Lenses a. Choose dewarp type: b. Chosse display mode: 4.1.4 Zooming with Mouse scroll In addition to digital zoom in/out button, users can use mouse scroll to prevent potential crisis in live-view monitoring. Note: For PTZ cameras, zooming with mouse in live-view is adopted optical zoom in/out.

  • Page 115: Multi-Nvr Server

    View enlarged images: To press and hold left mouse button, drag the image to the place that you would like to monitor. 4.1.5 Multi-NVR server NVR can be a multi-NVR server to connect other NVR in LAN and WAN by clicking “Search NVR”...
  • Page 116 NVR in LAN will appear, including the local NVR. Please choose NVR and camera which you are going to add to the local server and click “OK” button. New added channels will display in the cameras list on remote liveview webpage as below.
  • Page 117 Add NVR in WAN  Please click “Add Server” button to add NVR in WAN. Please enter IP address, port, username and password, then click “OK” to apply. Note: NVR can be manually added in WAN or LAN. You can see the NVR in Multi-Server list.
  • Page 118 Please choose NVR and camera which you are going to add to the local server and Click “OK” button. Then, new added channels will display in the cameras list on remote liveview webpage.

  • Page 119: Quick Navigation With Dynamic E-Map

    4.2 Quick Navigation with Dynamic E-Map NVR provides Dynamic E-Map feature on live-view monitoring as a quick navigation to indicate the physical location of cameras. Users can drag and drop camera icons to multi-layer E-Maps and enable pop-out event window to receive the latest event situation once event occurs.
  • Page 120 Icon Description Pin to Fasten: To display and fasten the panel. Pin to Hide: To hide the panel to the edge of the window. Click the panel name to display the panel when needed. Delete: To close the panel. Note: Users can drag the panels to the suitable place. Settings: to enable or disable automatically pop-up event window.

  • Page 121: Add Or Delete Multi-Layer E-Maps

    Available Camera: Camera in device panel is available to drag to map. Camera in map panel has successfully added in the map. Camera on Map: Camera in device panel is unable to drag to map since the camera has already added to one of maps. 4.2.2 Add or Delete Multi-layer E-Maps E-Map allows users to expand multi-layer maps in different perspectives and deploy cameras on the maps.

  • Page 122: Deploy Cameras

    Zoom in / out the E-Map To zoom in or zoom out the E-Map, users can use the mouse scroll to enlarge or reduce the view of E-Map. 2. Delete a Map NVR provides two methods to quickly delete map and its camera. (1) Delete Map Button: Select a map and click “Delete Map”...
  • Page 123 Camera Information When you move the mouse cursor on a camera icon, camera information will display in a yellow column such as NVR IP address, Camera name and Camera IP address. Note: Users can use the mouse scroll to zoom in/ out the map to enlarge or reduce the view of the E-Map when deploying IP cameras on the map.

  • Page 124: Enable/ Disable Automatically Pop-Up Event Window

    4.2.4 Enable/ Disable Automatically pop-up event window When a motion is triggered from IP camera on the map, a window will pop out to notify users and to display recording video. To enable or disable automatically pop-up event window on E-Map, please click the option. Note: The maximum of pop-out event window is 3.

  • Page 125: Event Log History

    To close the window, users can manually close the pop-out event window. 4.2.5 Event Log History Event log history offers a detailed and latest list of event history in event panel to make users easily control event situation. The event panel includes Server Name, Date &...

  • Page 126: Playback

    4.3 Playback Playback is a function that allows users to view recorded videos from cameras connected to NVR. NVR offers synchronized playback up to four cameras and easy steps to help users sort through the recorded videos quickly. Playback video can be viewed in full screen;...
  • Page 127 Please follow four steps below to quickly search recorded videos: 1. Select cameras from camera list 2. Select date and time period 3. Select recording type 4. Click “Play” 1. Select cameras from camera list Please select channel number from channel list to search recorded videos. Up to 4 channels can be selected at the same time.
  • Page 128 If there is an event recording in the specific date, the date will be remarked as blue with red stripe aside. Users can also select specific time period from time searching list (start time to end time.) Start time and end time layout is Hour: Minute: Second. The default time period is from 00:00:00 to 23:59:59.
  • Page 129 Frame by Frame Playback 1 Follow above four steps of Playback 2 Click “Pause” button 3 Click “Previous image” or “Next image” button Scale bar  Users can move the bar to enlarge or narrow down time period to check video files from Time table.

  • Page 130: Smart Search

    From the thumbnail, users can also read the related information such as date, time and camera name. The thumbnail will be shown while pointer moves on the footage. 4.3.2 Smart Search In addition to intuitive multi-channel playback, Smart Search can efficiently save users’...
  • Page 131 Select a specific camera, detection mode, time period and settings. Then, click “Search” button to start smart search. Introduction of settings: (1) Region of interest: the location for quick detection Note: Motion detection, foreign object detection and missing object detection is needed to arrange region of interest. Except motion detection which has 3 region of interest, others one have one region of interest.) (2) Sensibility: the capability to detect event (3) Interval: the amount of time that the object exists in the region...

  • Page 132: Main Functions On Playback

    Instant Playback Please double-click on one of the smart search result to play the video. 4.3.3 Main Functions on Playback Display mode NVR supports multi-display modes for playback. When you click a display mode, the mode icons will turn into blue. Icon Description Full Screen...
  • Page 133 4 screen 9 screen 16 screen Video playback speed control (1 ) (2) (5) (6) (1) Pause: to temporarily stop the playback. (2) Previous Image: to show the earlier image. (3) Slow motion: to play in slower speed. (4) Play: to play video file. (5) Fast forward: to play in faster speed.
  • Page 134 Snapshot Users can save the image of playback by clicking “Snapshot”. Before taking snapshot from NVR, users are recommended to set snapshot path from “Setting.” ” Sequential snapshot in remote playback  Users can have the sequent images from recording video while in playback, which helps users to catch the key frame in the recording files.
  • Page 135 c. Choose the display mode Change OSD color and font size Users can select different OSD color while having the playback of recording files. 1) Click “Setting” 2) Click OSD “color” setting button the select the OSD color and click “OK” 3) Select font size and click “OK”...
  • Page 136 4) All OSD color will shown as the selection Default button  By clicking “Default” button, users can default OSD setting. Default font size is 20 in orange color.

  • Page 137: Zooming With Mouse Scroll

    4.3.4 Zooming with Mouse scroll In addition to digital zoom in/out button, users can use mouse scroll to find out crucial proof in incident site in playback. Zoom in/out: To click on the video window and use mouse scroll to enlarge the image.

  • Page 138: Play Video Files

    2. Select cameras and time period Users can indicate which cameras and what time range is to export the recording file. 3. Start to export files from the NVR By pressing the Export button, the process of export will start. NVRPlayer and NVRCheck will also be downloaded with video files.

  • Page 139: Windows Networking

    4.4.1 Windows Networking Through Windows Networking, users can search video files in LAN via choosing a computer of NVR or entering IP address from Windows Start menu. Choose a Computer of NVR  Please go to “Network” folder and choose NVR. If more than one server exists in the same network, “Network”...
  • Page 140 For example, the computer name is NVR005043000203. Thus, users can select a NVR in Network folder by this computer name. As you select the NVR, a window will pop up and ask to enter network password. If users don’t amend the user name and password, please enter the default ones:“admin/admin.”...
  • Page 141 After entering “videodata1,” the folder displays RecordFolderchronologicallyby recording dates. Please select a folder to enter. All video files lists chronologically by recorded time and video length of each chunk is five minutes. Select a video file to play. Enter IP Address to Search ...
  • Page 142 As you enter the IP address, a window will pop up and ask for network password. If you don’t amend the user name and password, please enter the default ones:“admin/admin.” After users enter accurate user name and password, the folder of NVR displays the folder “videodata1.”...

  • Page 143: Ftp Service

    4.4.2 FTP Service To access FTP service in a web-based interface, please open Windows Internet Explorer and enter NVR IP address which users configure. Note: To access FTP service in WAN, please enable router’s Internet access and specify the same port as NVR. (The default is 21) As you enter the IP address, a window will pop up and ask to type a user name and password to log in FTP server.
  • Page 144 Please click “Log On” to proceed. IE browser shows the folders on FTP server. Please select folder “videodata1”.
  • Page 145 The folder displays RecordFolder chronologically by recording dates. Please select a folder to enter. All video files lists chronologically by recorded time and video length of each chunk is five minutes. Select a video file to play.

  • Page 146: Naming Rule Of Video Files

    4.4.3 Naming Rule of Video files NVR writes and memorizes videos to HDD in every 5 minutes. This way can ensure all videos are well saved when encountering power outage or other accidents. Besides, when exporting videos, each videos file is in around 5 minutes as well. In this way, it is clear for users to search for the videos they are aiming for.

  • Page 147: Camera Parameter

    5.1.2 Camera Parameter Please select “Camera Parameter” from the drop-down menu of IP Camera to begin. NVR supports multi-stream for monitoring and recording. Users can modify camera’s configuration such as video format, frame rate and resolution video quality via NVR in this page.
  • Page 148 As you click one column turning into blue, please wait and the window below will appear to allow users configure multi-stream. After loading camera’s information, users can modify camera parameter. Camera No.  Select a desired camera no. to add camera in NVR’s camera list. Stream 1/ Stream 2 (Recording Stream) ...
  • Page 149 Video Format  Choose a video compression format for live view and recording: MPEG4, H.264 and MJPEG. Note: Types of video format varies depending on the camera brands and models. Frame Rate  Select frame rate from drop-down list .Frame rate of IP camera will be influenced by the network surroundings.

  • Page 150: Camera Status

    5.1.3 Camera Status Please select “Camera Status” from the drop-down menu of IP Camera to begin. Camera List shows connection status of recording.

  • Page 151: Recording & Events

    Recording & Events Recording & Events can provide different event modes and recording schedule for users to configure IP camera. Event & Action Management also allows users to combine various events and its triggered actions to achieve the security surveillance. If the hard disk is not installed, the following window will pop up when you click “Recording &...

  • Page 152: Recording Settings

    5.2.1 Recording Settings Please select “Recording Settings” from the drop-down menu of Recording & Event to begin. Recording Mode Users can set the mode of “No Recording,” “Event Recording”, “Schedule Recording” and “Always Recording” for each connected cameras. No Recording: Once “No Recording” is selected, all cameras will be disabled to ...
  • Page 153 Video Format NVR provides two video formats of recording videos for different safety concerns. Please select a suitable video format to record videos in NVR. Can be played in NVR’s player: For higher security concern, NVR provides a  specific video format that users can only view the video via NVRPlayer. Can be played in general player: User can also view videos via general video ...

  • Page 154: Recording Schedule

    5.2.2 Recording Schedule Users can configure Recording Schedule to define time range for all channels. Insert schedule Select time range and channel for recording schedule and click “Insert.”...
  • Page 155 After inserting time range and channel, the time/camera bar displays the selected time. Click “Apply” to finish setting or “Reset” to rearrange time and camera channel. Note: A camera can set multi-recording schedule at same time as below picture. Delete schedule Users can erase the specific time in recording schedule by selecting the time then click"Delete".

  • Page 157: Event & Action Management

    5.2.3 Event & Action Management Please select “Event & Action Management” from the drop-down menu of Recording & Event to begin. “Event & Action Management” allows users to define alarm setting that manage events and its corresponding action. When an event occurs, NVR will perform certain actions.
  • Page 158 5. NVR event: Recording Error 6. NVR event: Digital Input 7. External event(HTTP-in) An event type is a set of parameters that defines different actions. Check an event type and click “Add” to select NVR Action. Note: The action will be only triggered when the action is added to the event. 1.
  • Page 159 If “Attached with the snapshot” is enabled, the Email will be sent with snapshot of the event. Click “Apply” to finish the configuration. E-Mail action will be triggered once per 20 seconds as the event is happening, which means if an event is lasting for one minutes, NVR will send email 3 times per every 20 seconds.
  • Page 160 User Defined Action  User Defined Action allows users to send the specific HTTP command out when an event is triggered in order to manage devices such as power controller, fire/smoke protection device, etc.
  • Page 161  SMS stands for Short Message Service. Users can be notified by short message service while the event is triggered. The service is supported by Clickatell users need to register for the service. It supports only for English message currently. Settings: 1.
  • Page 162 Event Triggered Record  You can enable Event trigger record and Video Clip. Event triggered record: When event is triggered, NVR records video and records every five minutes as the event continues happening. Video Clip: Video clip will be sent by E-mail and you can change the Pre-time and Post-time through “Advanced Settings.”...
  • Page 163 Note: One event can be set up to 3 camera preset points 3. Digital Input You can set action as “Event Trigger Record,”“Send E-Mail” and “Digital Output”, “User Defined Action” and “SMS.” Once Digital Input is detected from camera, various actions can be triggered. 4.
  • Page 164 5. NVR event : Recording Error You can set action as “Send E-Mail” and “SMS.” Once NVR fails in recording, the actions can be triggered. 6. NVR event: Digital Input You can set action as “Event Trigger Record,” “Send E-Mail” and “Digital Output”, “User Defined Action”...
  • Page 165 7. External event(HTTP-in) You can set action as “Event Trigger Record,” “Send E-Mail” and “Digital Output”, “User Defined Action” and “SMS.” Once Digital Input is detected from camera, multiple actions can be triggered. Event could be triggered by external HTTP-in CGI command. It allows users to define up to 5 different HTTP-in events.

  • Page 166: Advanced Setting

    The format of external HTTP-in event CGI : http://<NVR_IP>/login.cgi/cgi_main.cgi?cgiName=event_ipc.cgi&eventName=Defined_ <int> - <NVR_IP>is the IP of NVR that command need to be delivered to. - <int>is defined for what number(1~5) of external HTTP-in event need to be triggered. For example : http://192.168.1.245/login.cgi/cgi_main.cgi?cgiName=event_ipc.cgi&eventName= Defined_3 - The CGI is for sending message to the NVR with IP 192.168.1.245 and trigger the...

  • Page 167: Event Schedule

    When “Event Triggered with Audio” is enabled, camera audio will be recorded when an event is triggered. When the event stops, the audio will be disabled again automatically. Click “Apply” to apply setting. Event Schedule 5.2.5 Users can setup the event detection for certain period of duration. Setup event schedule A.
  • Page 168 Select the type of event Schedule By Day  1. Select the camera 2. Designate the time period 3. Click Insert button to be effective 4. Designated duration will be displayed 5. Designated duration is shown on chart Press “Apply” By Week ...
  • Page 169 1. Select the schedule as “Week” 2. Select the day for the specific recording schedule 3. Designate the time period 4. Select the camera for adaption 5. Click insert to be effective 6. The designated duration will be displayed 7. The designated duration will be shown in chart Press “Apply”...
  • Page 170 1. Designate the time period on chart by clicking on it 2. Click the Delete button 3. The designate period is removed Remove all alarm periods in one camera 1. Click any period of the camera 2. Select Delete All checkbox 3.

  • Page 171: E-Mail

    5.2.6 E-Mail Please select “E-Mail” from the drop-down menu of Recording & Event to begin. SMTP Server Server Address: Enter the Server Address of the SMTP server.  Sender: Specify sender’s E-Mail in the “Sender” field.  Subject: Enter the Subject. ...

  • Page 172: Disk Management

    Contact List will show the information you entered. Please click “Apply” to finish settings. Result will show in the following Contactors List and users can delete the contactor or continue to add a new contactor. 5.2 Disk Management NVR can create new RAID disk or delete/format the RAID disk. Also, users can manage NVR’s storage device for data transmission and file sharing service.

  • Page 173: File System Management

    The steps for creating and deleting hard disk, please refer to the disk management of Quick Configuration. Please select “Disk Management” from the drop-down menu of Quick configuration to begin. 5.3.2 File System Management Please select “File system Management” from the drop-down menu of Disk Management to begin.
  • Page 174 File system provides an efficient method to organize data expected to be retained after a program is terminated by providing procedures to store, retrieve and update data, as well as manage the available space on the device.

  • Page 175: File Sharing Service

    5.3.3 File Sharing Service Please select “File Sharing Service” from the drop-down menu of Disk Management to begin. Arrange data transmission service including Windows Networking and FTP service. When there is no hard disk installed in the NVR, the screen will show “No Filesystem.”...
  • Page 176 Windows Networking In Windows Networking field, users can enable or disable the services and Computer Name is already shown. Computer Description and Domain or Workgroup Name can be changed. FTP Service In FTP Settings, users can enable or disable FTP Services. User can arrange Command Port and Passive Port and configure language interface in Client Coding Type.

  • Page 177: Cloud

    5.3 Cloud NVR provides cloud backup to upload recorded files to Dropbox. With cloud backup, users can share recorded files with a link. Please select “Dropbox” from the drop-down menu of Cloud to begin. 5.4.1 Setup Dropbox Service Please click “Apply” to start Dropbox webpage connection and to establish a folder in Dropbox.

  • Page 178: Share Files To Dropbox Server

    After successfully connecting with NVR, Dropbox will automatically create a file named “Dropbox”. Quit Setup  When NVR is accessing to Dropbox, the NVR will display as below: If users want to cancel the Dropbox setting, please click “Apply” to remove setup.

  • Page 179: Remove Configuration And Online Sync

    5.4.3 Remove Configuration and Online Sync Please press“F5 button” on the keyboard to refresh the webpage. You can see the webpage as below: Remove Configuration and Data Please Click “Apply” to remove Dropbox service from NVR. All configuration and data of Dropbox in NVR will be deleted.

  • Page 180: Network Setup

    A warning will pop up when the folder cannot open. Please enter the same Lan domain as NVR. 5.4 Network Setup 5.5.1 Network Setup Please select “Network Setup” from the drop-down menu of Network to begin. This section explains how to configure network connection with NVR. Information Network information displays present network configuration including: Computer Name, IP address, Subnet mask, Default Gateway, Primary and Secondary DNS.
  • Page 181 Setup NVR supports dual IP application to connect different network segments to maximize network efficiency. Dual IP application allows users to efficiently communicate between internet and surveillance system. Dual IP application largely increased the resistibility of unauthorized data theft and the unavailability of accessing to cameras.
  • Page 182 there is more than one NVR in the network. Separated IP Please enter two IP address to in LAN1 and LAN2 to set up different network environments. Please click “Apply” to execute the settings. DHCP Setup Built-in DHCP server allows users to easily install IP surveillance systems without connecting another router providing network parameters.

  • Page 183: Network Service

    Port Setup Please set up transmission port to access NVR. Default port for NVR connection is 80. 5.5.2 Network Service Please select “Network Service” from the drop-down menu of Network to begin. Black/ White List Edit White or Black List to allow or block different IP address.
  • Page 184 As White List is enabled, a window will pop up to make sure the execution. As Black List is enabled, a window will pop up to make sure the execution. Please enter the IP address range to add to White List or Black List. Note: The above IP address is only an example for reference.

  • Page 185: Ddns

    UPnP Enable or disable UPnP search. Rename UPnP. Note:The maximum character limitation for UPnP Name is 32 characters. Please click “Apply” to execute the settings. 5.5.3 DDNS Please select “DDNS” from the drop-down menu of Network to begin. DDNS links a domain name to an IP address, allowing users to easily access their camera even with a changing IP address.

  • Page 186: Management

    5.5 Management In Management, users can easily create, modify and change users' live view access and playback access. Also, users can read various log information through log system and quickly save or load configuration of NVR. Emergent backup of the latest video files as well as the external input and output control can also be set here.
  • Page 187 Click “Apply” to add new Power User. After the Power User is created, user list will display the information as below.
  • Page 188 User  Administrator can select a group from “Group” drop-down list to assign a new User. Please enter a username and password in “User List.” And select Live View Access and Playback Access for the new User. After User is created, user list will display the information as below.
  • Page 189 Modify Users Please go to Modify User page. Select an account to modify the Power User or User. The selected account will turn to blue and the page for modifying user will appear as below. You can change Live View Access and Playback Access. Please click “Apply” to proceed.
  • Page 190 Change Password Each NVR comes with a built-in “admin” account with password “admin” for administrators. It’s highly recommended to change the password upon the initial login. Select an account from “User Name” drop-down list to change password. Enter a new password in the “New Password” and enter it again in “Retype Password.” Click “Apply,”...

  • Page 191: Log System

    Configuration page timeout period  NVR allows users to freely set up the idle time to automatically log out NVR. 5.6.2 Log System Please select “Log System” from the drop-down menu of Management to begin. If the hard disk is not installed, the following window will pop up when you click “Log System.”...
  • Page 192 NVR Log  The log information in NVR Log includes time zone, daylight, system, firmware upgrading, configuration IP, recording files export and storage. Event Log  The log information in Event Log includes “Camera is connected,” “The camera is disconnected,” “Digital Input,” “Motion detected” and “Storage usage is out of limit,”...
  • Page 193 Current User  The log information in Current User shows the current users logged in the NVR with IP address. Historical User Log  The log information in Historical User Log records any user who has logged in the NVR. For example, “Execute detect,” “Motion detected,” “FTP service is configured,” “Account is created,”...
  • Page 194 File Access Log  The message occurred is related to other method to get in NVR such as SAMBA or FTP. Export the log files Users can export and save log files from Log System page. And each log types correspond to one log file.

  • Page 195: Save/Load Configuration

    5.6.3 Save/Load Configuration Please select “Save/Load Configuration” from the drop-down menu of Management to begin. If the raid disk is not built, the following window will pop up. Save Configuration  Select Volume and Folder to save configuration in a format of cfg file and specify the File Name.
  • Page 196 Load Configuration  Load configuration can help users duplicate the same settings from one NVR to another without configuring system manually. Users can select Load Type as “Load Default Settings” or “Load Configuration.” Once you select “Load Default Settings” and click “Apply,” configuration of Camera Setting, Recording Settings, Event &...

  • Page 197: Usb Backup

    5.6.4 USB Backup Users can preset the latest duration and channels of USB Backup button on Remote Web Browser for quick backup the latest video files locally in the future. With USB Backup button setting, when users inserts USB device or USB type DVD burner into the USB port in the NVR (front panel backup area) and press “USB BACKUP”...
  • Page 198 USB Backup Button Setting in Remote Web Browsers  Enable: USB Backup button function can be enabled or disabled, for security concern.  The latest duration of recordings: Users can set a maximum of days, hours and minutes to backup the latest video files. ...
  • Page 199 Device Information status When a USB device is inserted to the NVR, the USB Backup Device Information in Remote Browser will show the status “Wait..” When the USB is ready to begin, the Device Information will show the status “Ready,” and the USB LED indicator will show blue.
  • Page 200 If there is no USB inserted into NVR, the screen will show “There is no USB device…” as below picture: Note: NVRPlayer and NVRCheck will be downloaded with video files. DVD Backup USB Backup Button Setting in Remote Web Browsers ...
  • Page 201 Software DVD Backup Virtual Button By clicking “USB Backup” button, NVR will save the settings (The latest duration of recordings and Channel selection) and export videos to USB device now. Please insert a USB device to start to backup the latest video files. Device Information status When a USB type DVD burner is inserted to NVR, Device Information of DVD Backup in Remote Browser will show the status “Wait...
  • Page 202 Advance Settings Encryption of Exported Files Users can encrypt exported files to USB or DVD device as ZIP files in playback page. Users need to decide password when exporting files in remote playback. Please enable the function and click “Apply” to finish the setting. A window will pop up after users click export button in playback page.

  • Page 203: Remote Backup

    5.6.5 Remote Backup To ensure the security of confidential videos, NVR provides remote backup to back up important recorded videos to NAS so as to storage confidential videos for a longer time. Note: ASUSTOR NAS is supported for now in LAN. Please select “Remote Backup”...
  • Page 204 Enter IP Address and Volume Path of the device that you set up in advance to execute remote backup, then click “Connect” button. Once NVR successfully connects to the device, the status will show “Connected” and display the total size of the device as well as and the available size for remote backup.

  • Page 205: External Io Device

    3. Check Job information on Remote Device page > Archive Information Archive Information is a remote backup history designed for users to record past remote backup jobs. Clicking “Detail” button in Jon Description column can view detailed information of remote information. 5.6.6 External IO Device Please select “External IO Device”...

  • Page 206: Ups Management

    Enter necessary information to add devices manually, including: Device Name, IP Address, User Name and Password. Click “Detect” to check whether connection is successful or not. Please click “Apply ”to finish the setting. "Vender" and "Model" will show up automatically, if detectable. Camera List shows all available device information including: Camera Name, IP Address, Port, Vender and Model.
  • Page 207 Note: YEC UPS device is supported by NVR.  UPS Device Information Users can obtain basic UPS information from UPS device information, including brand, model, AC power status, battery capacity and estimated protection time. Estimated protection time allows users to realize the estimated time to progress regular monitoring.

  • Page 208: System

    5.6 System 5.7.1 Device Information Please select “Device Information” from the drop-down menu of System to begin. System Information  System Information shows Operating System, OS Version, NVR Version, CPU, Network Adapter, MAC Address, and Network Flow. Locate Click "Locate", the NVR buzzer will be triggered for 3 seconds. It helps the user to locate the NVR.

  • Page 209: System Upgrade

    Upgrade via Remote Web Browser in Windows OS(Windows IE / Chrome / Firefox / Safari/ Opera browser) (1) Download latest firmware file from DIGIEVER website www.digiever.com DIGIEVER offers new firmware for NVR to update functions. Please download the latest firmware from the DIGIEVER website www.digiever.com and save the firmware file to a local computer.
  • Page 210 A window will pop up to ask for the folder to upload the firmware. (5) Click “Upgrade” After selecting the file, please click “Upgrade” to renew the NVR. Once system upgrade is finished, NVR will reboot itself. Users could go to “Device Information” from the drop down list of “System” so as to double check NVR firmware version.
  • Page 211 DS-4200-RM Pro Series, DS-4200 Pro Series, DS-2100 Pro Series and DS-1100 Pro Series. (1) Download latest firmware file from DIGIEVER website www.digiever.com DIGIEVER offers new firmware for NVR to update functions. Please download the latest firmware from the DIGIEVER website www.digiever.com and save the firmware file to a local computer.
  • Page 212 Note: To recognize the USB device well, please format the USB device to FAT32 file system first, and make sure you delete all other files and keep only “update.bin”) Instructions to format a USB device to FAT32 file system: Click on the "My Computer" shortcut on the desktop of your computer Right-click the flash drive and choose the "Format"...

  • Page 213: Language

    5.7.3 Language Please select “Language” from the drop-down menu of System to begin. NVR provides different languages for users. Users can configure the language as AUTO or other languages. Please click “Apply” and the language will be changed. 5.7.4 Date &Time Please select “Date &...
  • Page 214 1. Set up Select from the drop-down list and configure the time manually and the setting will be effective when you click “Apply”. 2. Time zone Users can set the time and date according to the correct time zone and adjust clock for daylight saving changes for your preference.

  • Page 215: Buzzer

    Automatically sync  Users can also decide when to automatically synchronize with external NTP  sever by selecting “Automatically Sync.” Based on users’ preference, NVR provides three selections to automatically synchronize with external NTP server: Monthly, Weekly or Daily (1) Select “Automatically Sync” (2) Set up when to automatically synchronize with external NTP sever (3) Fill in the number to start auto synchronize when time difference is over user defined seconds...

  • Page 216: Reboot &Shutdown

    Select “Enable” or “Disable” to set Buzzer Notice Once the buzzer notice is disabled, the buzzer action of digital output will not be performed. Note: To stop the buzzer sound, user can press “USB BACKUP” button on the front panel of NVR for one second. 5.7.6 Reboot &Shutdown Please select “Reboot &...

  • Page 217: Appendix: Notice And Warning

    Appendix: Notice and Warning Notice ＊This equipment is for home use, and has acquired the electromagnetic conformity registration. So, it can be used not only in residential area, but also other areas. ＊ 이기기는가정용(B 급) 전자파적합기기로서주로가정에서사용하는것을목적으로하며, 모든지역에서사용할수있습니다. Warning ＊Risk of explosion if battery is replaced by an incorrect type. Please dispose of used batteries according to the instructions.

This manual is also suitable for:

Ds-2005Ds-2025Ds-2032Ds-2012Ds-2016Ds-2020 ... Show all

Table of Contents
