Operating Instructions

DRILL PRESS

JPW Tool Group Hong Kong Limited

98 Granville Road, Tsimshatsui East, Kowloon, Hong Kong, PRC

www.jettools.com

Импортёр в РФ: ООО «ИТА Технолоджи»

105082, Москва, Переведеновский пер., д. 17

www.jettools.ru

Made in PRC / Сделано в КНР

M-50000960T

2024-09

Table of Contents

Need help?

Do you have a question about the GHD-30PFB and is the answer not in the manual?

Questions and answers

Summary of Contents for Jet GHD-30PFB

Page 1 DRILL PRESS GHD-30PFB Original: Operating Instructions JPW Tool Group Hong Kong Limited 98 Granville Road, Tsimshatsui East, Kowloon, Hong Kong, PRC www.jettools.com Импортёр в РФ: ООО «ИТА Технолоджи» 105082, Москва, Переведеновский пер., д. 17 www.jettools.ru Made in PRC / Сделано в КНР...
Page 2 Make sure that the power cord does not securely on the machine, always check General safety notes impede work and cause people to trip. before switching the machine on. Milling machines can be dangerous if Keep the floor around the machine Provide workpieces with center holes not used properly.
Page 3: Drill Press
Drill Press Model：GHD-30PFB Operation Manual Max. Drilling Diameter: 30mm Series Number:...
Page 4: Table Of Contents
Total Operation Manual page Contents 1. Main use and features of the machine 2. Main technical data 3. Brief description of the driving system and its structure 4. Electrical system 5. Lubrication and coolant system 6. Hoisting and installation 7. Use and operation of the machine 8.
Page 5 Total Operation Manual page Dear end-user, Thank you very much for choosing our products. Please let us have the model of your machine, series number, as well as the name, address and correspondence method of your company in order to facilitate us to let you have a good service. Important notice: 1.
Page 6: Main Use And Features Of The Machine
Total Operation Manual page 12. We will much appreciate if you could salve some problems of the machine. In order to facilitate us for the service, please let us know the details regarding the places and phenomenon of the troubles if you could not solve problems. 1.
Page 7 Total Operation Manual page 1.9 An adjustable safety protection clutch in the spindle feed device is available in order to prevent the machine and tools from damage when overloaded. 1.10 A safety protection guard under the spindle box is available as it is not only prevent coolant splash while cutting but also could observe the machining status.
Page 8: Brief Description Of The Driving System And Its Structure
Total Operation Manual page 2.2 For the machine appearance and its main technical data, see diagram 1. 3. Brief description of the driving system and its structure: The machine consists of spindle box, column, machine base, worktable, bracket, electric cabinet, coolant device and machine accessories, total seven component parts.
Page 10 Total 21 Operation Manual page 6 Double Teeth Motor Double Teeth Triple dentition Triple dentition Rack Spindle sleeve Worm Worm Gear Worm gear Worm gear Spindle sleeve Gear Worm Transverse gear Worm gear Rack drawing 2 .picture of transmission...
Page 11 Total 21 Operation Manual page drawing 3 . picture of roll bearing...
Page 12 Total Operation Manual page Roller bearing table Table (2) Model Name Specification Q’ty Accuracy Deep racing ball bearing 180108K；GB276 40×68×15 AS3552；GB/T4605 35×52×1 Roller bearing AXK3552； GB/T4605 35×52×2 Deep racing ball bearing 1180909K；GB276 45×68×12 Thrust bearing 36104；GB292 20×42×12 Deep racing ball bearing 101；GB276 12×28×8 Thrust bearing...
Page 13 Total 21 Operation Manual page 9 limiting switch SQ2 shift switch QSA1 spindle box M1 moving button SB3 electrical box B1 stop button SB2 pump switch SX1 emergent switch SB1 switch of power supply QS1 limiting switch SQ1 lamp EL1 SB2 pump motor M2 wiring boxB2 drawing 4.picture of element of machine...
Page 15 Total Operation Manual page Electric components list: Table (3) Code of Name Specification Q’ty Remark elements Instruction switch JCH13-20 Breaker JCM6-25-2.5/4A Breaker JCM6-25-0.4/0.63A QSA1 Convertiblewitch 3LBB-20 ,V1710.7 Connector LC1N1201B5N(AC24V) Emergency stop button LA42J-01/R Push button CP1-10R-01 Push button CP1-10G-10 SX1, Selection switch LA42XL2-30/B Micro switch...
Page 16 Total Operation Manual page 4.2 Explanation of the circuit(refer to drawing4、5) The spindle of the machine is moving by two-speed motor, it is controled by switch(QSA1) AC contactors(KM1) and so on. When using the machine, the breaker QF1, fuse FU1,FU2,FU3 which is in the electrical box must be put on, when examining and repairing, it could be put off.
Page 17: Lubrication And Coolant System
Total Operation Manual page Lubrication and coolant system: 5.1 There are two types of lubrication in this machine: a. Grease b. Lubrication by manual filled oil 5.2 Gears in the spindle box are lubricated by grease,it uses NO.3 Lithium industrial grease, for the new machine, washing and grease replacement after six months running.
Page 18 Total 21 Operation Manual page 14 mm/r 0.10 0.20 0.30 drawing 6 .picture of lubrication Chart of lubrication position No.of Grease designation lubrication position lubrication period lubrication position Bearing on the main spindle box add oil every three months ZL-3 lithium base grease main drive gear Once every six months feed gear...
Page 19 Total 21 Operation Manual page 15 mm/r 0.10 0.20 0.30 drawing 7.picture of hoisting...
Page 20 Total 21 Operation Manual page 16 mm/r 0.10 0.20 0.30 1600×1000 4-14 drawing 8. foundation of installation of machine...
Page 21: Use And Operation Of The Machine
Total Operation Manual page 6.2 Installation: Working area of the machine shall be the size when the spindle box rounds its column in one cycle. Its diameter is about Ø2000mm. Further more, space for the work pieces, toolbox, and machine accessories as well as operating and maintenance space must be considered. The machine should be placed on a solid ground.
Page 22 Total Operation Manual page In case too tight mesh between tool shank and spindle taper and the tool cutter could not fall down after several strokes, then you have to use the normal way by using a taper wedge to dismounting the tool cutter.
Page 23: Machine Adjustment
Total Operation Manual page 7.5 Cutting depth control: For the batch production, you need control cutting depth. A scale in front of spindle box could meet your requirements. Loosening knurled screw ( 8 ) by turning nob ( 2 ), moving the scale to the required depth, then fastening the knurled screw( 8 ).
Page 24: Machine Use And Maintenance
Total Operation Manual page 9 Machine use and maintenance: 9.1 Before running the machine, carefully read the Operation Manual first, fully understand the structure of the machine and its performance and needs to familiar with locations for all levers and buttons. 9.2 Lubrication of the machine is very important.
Page 25: Machine Accessories
Total Operation Manual page 9.9 Do not extend spindle quill too much, instead, a proper working table height is suggested .Clean the spindle taper hole and tool taper shank first before tool mounting. Unqualified or rusted or damaged taper shank is forbidden to use. 9.10 Dry agent inside of the electric box and regularly removing dustiness are necessary.
Page 26: Drill Press
Drill Press Model：GHD-30PFB Certificate of Inspection Max. Drilling Diameter: 30mm Series Number:...
Page 27 We certified that the machine has been inspected and all items of the machine are in conformity With Q/320684FNC01-2006 standard. Delivery is permitted. Director of the company: Date: Director of quality inspection department: Date:...
Page 28 Total 3 Certificate of Inspection Page 1 Precision Inspection Record Geometrical Precision Test: Precision Brief Drawing Allowance Item Actual (mm) Test 0.06 at any tested Length of 300(flat or concave) Parallelism of the base surface 0.04 at any tested Length of 300(flat or concave) Parallelism...
Page 29 Total 3 Certificate of Inspection Page 2 Precision Inspection Record Germetrical Precision Test: Precision Brief Drawing Allowance Item Actual (mm) Test Spindle bore axis runout a ） Close to spindle surface L=200 b）at a distanc a）0.02 of L to spindle b）0.035 surface Perpendicularity...
Page 30 Total 3 Certificate of Inspection Page 3 Precision Inspection Record Germetrical Precision Test: Precision Brief Drawing Allowance Item Actual (mm) Test Perpendicularity of the vertical movement of a.0.1/300 spindle sleeve （a≤90°） to work table b.0.1/300 surface Work Acuracy: The change of Perpendicularity of spindle F=5000N...
Page 31: Packing List
Drill Press Model：GHD-30PFB Packing list Max. Drilling Diameter: 30mm Series Number:...
Page 32 Total Packing list page Case No.: 1/1 Dimension ( L ×W × H): × × Gross weight: Net weight: Q’ty Name Specification and marks Remark Machine 1 piece Drill check with lever 1-13: GB6087 1 piece Drill check adaptor 1 piece 3-2: JB3477 1 piece Tool shank adaptor...
Page 33 Drill Press Model：GHD-30PFB Ancillary page of Operation Manual Max. Drilling Diameter: 30mm Series Number:...
Page 34 Parts Breakdown For GHD-30PFB Drill Press Drawing (1) ’ ，／ ”...
Page 35 Part List for GHD-30PFB DRILL PRESS Part no. Descirption Size Qty. 1 GHD30PFB-1001 Knurled knob 2 GHD30PFB-1002 Cup head pin 3x20 3 GHD30PFB-1003 Knurled screw bolt 4 GHD30PFB-1004 Scaled bolt 5 GHD30PFB-1005 Scaled nut 6 GHD30PFB-1006 Cross recess pan head screw...
Page 36 Part List for GHD-30PFB DRILL PRESS Part no. Descirption Size Qty. 50 GHD30PFB-1050 Cylindrical coil compressionm spring 1.4x6x22 51 GHD30PFB-1051 Steel ball 52 GHD30PFB-1052 Slotted cheese-head screw M5x12 53 GHD30PFB-1053 Position Washer 54 GHD30PFB-1054 Short fort shaft 55 GHD30PFB-1055 Taper pin with internal thread...
Page 37 Part List for GHD-30PFB DRILL PRESS Part no. Descirption Size Qty. 99 GHD30PFB-1099 Gear 100 GHD30PFB-1100 Gear 101 GHD30PFB-1101 External circlip 102 GHD30PFB-1102 Spline shaft 103 GHD30PFB-1103 Bearing 104 GHD30PFB-1104 Bearing cover 105 GHD30PFB-1105 Motor LYD90S-4/2 106 GHD30PFB-1106 Washer 107 GHD30PFB-1107...
Page 38 Part List for GHD-30PFB DRILL PRESS Part no. Descirption Size Qty. 148 GHD30PFB-1148 Washer 149 GHD30PFB-1149 Bearing 8101 150 GHD30PFB-1150 Bearing seat 151 GHD30PFB-1151 Washer 47x2.65 152 GHD30PFB-1152 Bearing 8102 153 GHD30PFB-1153 Worm shaft 154 GHD30PFB-1154 External circlip 155 GHD30PFB-1155...
Page 39 Part List for GHD-30PFB DRILL PRESS Part no. Descirption Size Qty. 197 GHD30PFB-1197 Worm shaft 198 GHD30PFB-1198 Connector 199 GHD30PFB-1199 Cyclindrical coil compression spring 2.5X30X48 200 GHD30PFB-1200 Gear cover 201 GHD30PFB-1201 Screw 202 GHD30PFB-1202 Cylindrical coil compressionm spring 1.6x1.6x61.5 203 GHD30PFB-1203...
Page 40 Parts Breakdown For GHD-30PFB Drill Press Drawing (2)
Page 41 Part List for GHD-30PFB DRILL PRESS Part no. Descirption Size Qty. 1 GHD30PFB-2001G Base 2 GHD30PFB-2002 Drainage plate 3 GHD30PFB-2003 Slotted countersunk flat head screw M3X6 4 GHD30PFB-2004 Cover 5 GHD30PFB-2005 Hexagon head bolt M12x40 6 GHD30PFB-2006G Cover 7 GHD30PFB-2007...
Page 42 Part List for GHD-30PFB DRILL PRESS Part no. Descirption Size Qty. 50 GHD30PFB-2050G Worktable tray 51 GHD30PFB-2051 Drainage plate 52 GHD30PFB-2052 Cross recess head screw Cr.DM3x6 53 GHD30PFB-2053 Cover 54 GHD30PFB-2054 Outside hexagonal oil plug M14x1.5 55 GHD30PFB-2055 Washer 56 GHD30PFB-2056...
Page 43 Standard Accessories List for GHD-30PFB Drill Press Part no. Descirption Size Qty. GHD30PFB-ACC01 Key for drill chuck GHD30PFB-ACC02 Drill chuck 1-13mm B16 GHD30PFB-ACC03 Taper wedge for flat shape quill GHD30PFB-ACC04 Fuse GHD30PFB-ACC05 Double wrench 21X24 GHD30PFB-ACC06 Adapter MT3-1 GHD30PFB-ACC07 Adapter...
Page 44 GB - ENGLISH Environmental protection Protect the environment. Your appliance contains valuable materials which can be recovered or recycled. Please leave it at a specialized institution. This symbol indicates separate collection for electrical and electronic equipment required under the WEEE Directive (Directive 2012/19/EC) and is effective only within the European Union.
Page 45: Warranty / Garantie
Warranty / Garantie JPW Tool Group Hong Kong Limited guarantees that the supplied product(s) is/are free from material defects and manufacturing faults. This warranty does not cover any defects which are caused, either directly or indirectly, by incorrect use, carelessness, damage due to accidents, repairs or inadequate maintenance or cleaning as well as normal wear and tear.
