RENON Xtreme LV 1.0 User Manual

A10 version
Hide thumbs Also See for Xtreme LV 1.0:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual.
Xtreme LV 1.0
A10 VERSION
Renon Power Technology Inc.
© Renon Power Technology Inc.
All Rights Reserved Specifications are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Xtreme LV 1.0 and is the answer not in the manual?

Questions and answers

Related Manuals for RENON Xtreme LV 1.0

Summary of Contents for RENON Xtreme LV 1.0

  • Page 1 User Manual. Xtreme LV 1.0 A10 VERSION Renon Power Technology Inc. © Renon Power Technology Inc. All Rights Reserved Specifications are subject to change without notice.
  • Page 2 PROVIDE INNOVATIVE, storage solutions to global customers. At Renon, we believe that sustainable energy is the future. We are RELIABLE, AND passionate about reducing carbon emissions and preserving our planet for future generations. That's why we invest heavily in research and...

  • Page 3: Table Of Contents

    Table of Contents 1 Safety Instructions .......................... 5 1.1 General Safety Precautions ......................5 1.2 Transportation and Storage Precautions ................... 6 1.3 Installation Precautions ......................6 1.4 Usage Precautions ........................7 1.5 Response to Emergency Situations ................... 8 1.6 Qualified Personnel ........................8 2 Introduction ............................10 2.1 Product features ........................
  • Page 4 3.1 Safe Handling Guide ........................ 21 3.1.1 Familiar with the product ..................... 21 3.1.2 Precautions before installation ..................21 3.1.3 Tools ..........................21 3.1.4 Safety Gear ........................22 3.2 System Premeasurement ......................22 3.3 Installation location ......................... 23 3.4 Package items .......................... 23 3.5 Installation ..........................

  • Page 5: Safety Instructions

    1 Safety Instructions Safety Instructions For safety reasons, installer and user are responsible for familiarizing themselves with the contents of this document and all warnings before installation and usage. 1.1 General Safety Precautions ●Please carefully read this manual before any work is carried out on the product, and keep it located near the product for future reference.

  • Page 6: Transportation And Storage Precautions

    1.2 Transportation and Storage Precautions ● The batteries must be transported according to UN3480, they must be packed according to packaging requirements of Special Regulation 230 of IMDG CODE (40-20 Edition) for maritime transport, and P965 IA for air transport (SOC less than 30%). The original packaging complies with these instructions.

  • Page 7: Usage Precautions

    ●Handle the battery wearing insulated gloves. ●Use insulated tools. Do not wear any metallic items such as watches, bracelets, etc. ● Please turn-off related circuit breakers before and during the installation to avoid electric shock. ● Do not connect any AC conductors or photovoltaic conductors directly to the battery pack.

  • Page 8: Response To Emergency Situations

    1.5 Response to Emergency Situations ●Damaged batteries are dangerous and must be handled with extreme care. They are not suitable for use and may cause danger to persons or property. If the battery pack appears to be damaged, place it in the original container and return it to an authorized dealer.
  • Page 9 ● Knowledge of and adherence to this guide and all safety precautions and best practices. For safety reasons, installers are responsible for familiarizing themselves with the contents of this document and all warnings before performing installation and usage.

  • Page 10: Introduction

    2 Introduction The Xtreme LV series is a lithium iron phosphate battery-based energy storage product developed and produced by RENON, it can supply reliable power for nearly all kinds of household appliances and equipment. The Xtreme LV series consists of a main controller and several battery modules, each...

  • Page 11: Specifications

    2.2 Specifications 2.2.1 Specifications1(16 series cells) R-XL010021 R-XL015031 R-XL020041 R-XL025051 R-XL030061 Item (-H) (-H) (-H) (-H) (-H) Controller Model R-MC300-XTL01 Battery Module Model R-EM51100-XTL01 (-H) Battery Chemistry LiFePO4 Module Quantity Nominal Energy (kWh) 10.24 15.36 20.48 25.60 30.72 Nominal Capacity (Ah) Max.

  • Page 12: Specifications1(15 Series Cells)

    2.2.2 Specifications1(15 series cells) R-XL009021 R-XL014031 R-XL019041 R-XL024051 R-XL028061 Item (-H) (-H) (-H) (-H) (-H) Controller Model R-MC300-XTL01 Battery Module Model R-EM48100-XTL01 (-H) Battery Chemistry LiFePO4 Module Quantity Nominal Energy (kWh) 14.4 19.2 28.8 Nominal Capacity (Ah) Max. Charging/Discharging Current (A) Nominal Voltage (V) Recommend Charging Voltage (V) 53.25...

  • Page 13: Interface Information

    2.3 Interface Information Figure 2.3.1. Interface definition of Controller module Instructions Instructions On/Off Inverter1 Communication Port (RJ45) WIFI Antenna Port Inverter2 Communication Port (RJ45) Inverter Dial Switch Parallel Communication Port A Address Dial Switch Parallel Communication Port B Function Dial Switch Power Negative Inverter Communication...

  • Page 14: Inverter Dial Switch

    Code 0~26 of this Dial Switch are used to match which brand of inverter is using. The definitions of code 0 ~ 26 are shown as below table. Code Dial Switch Position Brand Logo (Reserved) Renon Schneider Gateway Sol-Ark Solis_LV Studer_Xtender Victron_color control SMA_LV...

  • Page 15: Address Dial Switch

    MEGAREVO Aiswei Phocos Voltronic Power Fronius Afore Lux Power CHISAGE ESS Code 63 is used for special function, defined as below: Dial Code Switch Code Definition Position The battery enters WiFi configuration mode, see chapter 3.6 for more information. 2.3.4 Address Dial Switch 1) Use this Dial Switch to set the address of each master controller and then turn on to activate the system when it needs to be in parallel with other stack units.

  • Page 16: Function Dial Switch

    Code Dial Switch Position Definition Set as Cluster 1 (communicate with inverter by this cluster) Set as Cluster 2 Set as Cluster 3 Set as Cluster 4 Set as Cluster 5 Set as Cluster 6 Set as Cluster 7 Set as Cluster 8 Set as Cluster 9 Set as Cluster 10 Set as Cluster 11...

  • Page 17: Parallel Dial Code

    Code Dial Code Switch Position Definition ① When used as single cluster; ② When used in a parallel system and not being the first or last cluster. ① When used as the first or last cluster in a parallel system. 2.3.6 Parallel dial code Sample: When three devices are connected in parallel to SOL-ARK inverter.

  • Page 18: Debug Port

    6pin Terminal Usage RS485_2A RS485_2B RS485_2GND CAN2GND CAN2L CAN2H 2.3.8 Debug Port Terminal type: 6-Pin terminal block Usage: reserved for our technical to debug. Defined as below: 6pin Terminal Usage DIN+ DIN- BAT_SW_IN BAT_SW_OUT CAN1H CAN1L 2.3.9 INVERTER1 Port (RJ45) Terminal type: RJ45 Usage: communicate with inverter, PCS or other equipment.

  • Page 19: Inverter2 Port (Rj45)

    Port definitions RJ45 Pin Function RS485_2B RS485_2A SGND SGND SGND SGND CAN2H CAN2L 2.3.10 INVERTER2 Port (RJ45) Terminal type: RJ45 Usage: Communication with inverter internet port and upload inverter data to our platform. Port definitions RJ45 Pin Function RS485_2B RS485_2A SGND RS232RIN1 RS232OUT1...

  • Page 20: Power Negative

    Usage: Link A & Link B are parallel communication ports with same definition. When more than one cluster connected in parallel, use these ports to connect the clusters one by one. Defined as follows: Port definitions RJ45 Pin Function CAN2L CAN2H CAN2GND CAN2GND...

  • Page 21: Installation And Usage

    3 Installation and Usage 3.1 Safe Handling Guide 3.1.1 Familiar with the product Be careful when unpacking the system. Every module of the product is heavy. Don't lift them with a pole. The weight of the modules can be found in the chapter "Specifications".

  • Page 22: Safety Gear

    Use properly insulated tools to prevent accidental electric shock or short circuits. If insulated tools are not available, cover the entire exposed metal surfaces of the available tools, except their tips, with electrical tape. 3.1.4 Safety Gear It is recommended to wear the following safety gear when dealing with the product: Insulated gloves Safety goggles Safety shoes...

  • Page 23: Installation Location

    3.3 Installation location Make sure that the installation location meets the following conditions: ●The floor is flat and level. ●The surface of the wall is smooth and perpendicular to the ground, which can bear the weight. ●The area is completely water proof. ●The area shall avoid direct sunlight.
  • Page 24 (1) Main controller: Item Specification Usage Diagram Main Controller of the battery R-MC300-XTL01 controller cluster 25.0*9.4*5.7inches Bottom base of the battery Base /635*238*145mm cluster Mounted at the rear of the Mounting 3.1*1.6*0.9inches controller, used to stabilize bracket A /80*40*22mm the cluster Combine the mounting Mounting 3.1*2.2*1.2inches...
  • Page 25 battery and inverter, cooperate with 2 standard network cable User manual Xtreme Lv series User manual Main control 163x26,Aluminium,T= Main control sides layer Pedestral 163x15,SPCC,T=2.0 Aluminium board sides layer T2red copper,nickel plating,64x48x3,T=3 mm.,pitch- Output busbar Busbar row27.5,2circular hole,M8 swage nut M8x18,philips,outer Screw hexagon,carbon steel...

  • Page 26: Installation

    3.5 Installation 1) Preparation of master controller: Fastened 2 mounting brackets A to the top back of the controller and screw those properly. Figure 3.5.1. Fastened the mounting bracket A 2) Preparation of the controller module: Fastened 2 mounting brackets B to mounting bracket A and screw those properly.
  • Page 27 4) Fasten the 4 mounting holes of the base on the floor in a stable condition. Figure 3.5.4. Mounting holes of the base 5) Stack up the battery modules, and then place the master controller unit on the top finally. Figure 3.5.5.
  • Page 28 6) Fasten the 6 mounting holes of the mounting bracket B on the wall in a stable condition. Figure 3.5.6. Mounting holes of the base 7) Install the side panel connector between the bottom battery module and the base via 8 screws in each battery cluster. Figure 3.5.7.

  • Page 29: Connections Of Cable And Power

    9) Connect the ground wire as the diagram shown below. Figure 3.5.9. Ground wire connection 3.6 Connections of Cable and Power 1) Remove the side cover panel. Note:This position as a whole is welded to the battery, only the side panel can be removed.
  • Page 30 If you are using the pin order select box, please refer to the table below to set the dial switch, according to the inverter brand. If the inverter brand is not shown in the table, please refer to the inverter manual or consult Renon's engineer. Comm...
  • Page 31 DEYE Growatt_SPF RS485 Growatt_SPH&SPA Must MEGAREVO Aiswei Phocos RS485 Voltronic Power RS485 Afore Lux Power CHISAGE ESS...
  • Page 32 5) Cross the power cable trough the black rubber. Figure 3.6.4. Power line connection 6) Please pay attention to the mark communication via, you need to remove the via first before install.The via part consists of three parts, respectively block shot, via rubber pad and plastic parts.
  • Page 33 Figure 3.6.5. Communication cable connection&via parts Figure 3.6.6. Via rubber pad&via installation diagram 7) Please turn on the DC breaker of the inverter, then press the power button then wait for the beeper sound occurred and then master controller show the distinguish number of battery modules successfully.

  • Page 34: Wi-Fi Configuration

    Figure 3.7.1. WIFI wiring position Set the inverter dial code (INV SET) to 63(111111) as shown below before Wi-Fi configuration. 1) Download APP Download and install RENON APP from Google or Apple Store by searching Renon Smart. Figure 3.7.2. Install RENON APP...
  • Page 35 Figure 3.7.3. Android QR code Figure 3.7.4. IOS QR code 2) Register You may acquire the Register Code from your installer for new account registration. If you already had an account, you may use it to login the APP directly otherwise you need to create an account.
  • Page 36 Figure 3.7.6. Binding a. Distribution Contact your upper-level installer to get a binding QR code, and scan the QR code to become an end user.After becoming an end user, ask the installer to assign the device to your end user account. Figure 3.7.7.
  • Page 37 Figure 3.7.8. Scanning Bar Code c. Contact Renon If the above methods are not successful, please contact Renon for processing, email address: Support@renonpower.com.Be sure to write your account name/email address and device serial number clearly. 4) WiFi configuration a. Bluetooth Turn to the page Mine, click the Network configuration, then click Bluetooth Model, and following by the instruction of network setting for WiFi configuration.
  • Page 38 Connect your mobile phone to the Bluetooth and wait for it.If the device is found, click it and turn to the Bluetooth network configuration page. Figure 3.7.10. Connect Battery Bluetooth Enter the WiFi name and password of your private WiFi for connecting master controller.
  • Page 39 b. WiFi If you can not find the Bluetooth from the battery. Please go back to Distribution network interface, and click WiFi model. And following by the instruction of network setting for WiFi configuration. Figure 3.7.12. WIFI Network Setting Please fill in the serial number of the device you want to WiFi configuration and enter the device Verification code.
  • Page 40 5) Create a power station Turn to Power Station page of the APP, create a power station, and set a station name, select a power station type, enter price configuration,superiors view, power station address and upload power station pictures for it. Figure 3.7.14.
  • Page 41 Now you can manage your device in the APP, and you can also manage them in Website, ask your installer for the site URL. Figure 3.7.16. Manage Your Device After the device is connected to WiFi, the running status, real-time power, daily power consumption and cumulative power of the product can be monitored in real time on the network platform or mobile APP.

  • Page 42: Paralleled Connection (Optional)

    Set the inverter dial code to match the inverter brand after WiFi configuration finished (Please refer to the chapter 2.3.3 Inverter Dial Switch). 3.8 Paralleled connection (Optional) 1) Plan the distance between the two units and no less than 12inches(300mm), and 20inches(500mm) is recommended.
  • Page 43 Figure 3.8.2. Diagram of the cables connection between two adjacent equipment 5) Set the first cluster and the last cluster of the system's function dial code as code 33 and set function dial code of the rest of clusters as code 32. 6)Make sure all clusters are turned on except first one.

  • Page 44: Monitoring Screen

    4 Monitoring Screen 4.1 LCD Screen Introduction Figure 4.1.1 LCD Screen Introduction Instructions SOC, SOH and Upgrading State Version and Accumulated Discharge Energy ESS status, Power, and Voltage Battery Operation State 4.2 SOC, SOH and Upgrading State 1) The percent number displays current SOC when underneath SOC sign lights on and current SOH when underneath SOH blinking lights on, respectively.

  • Page 45: Version And Accumulated Discharge Energy

    2) The “UPGRADING…” sign will show up when the battery is in the upgrade. The percentage indicates the progress of the upgrade. 4.3 Version and Accumulated Discharge Energy The number shows version of software and hardware for LCD, master, and slave, accumulated discharged energy counted in kWh or MWh, respectively.

  • Page 46: Screen Display Code

    Status Instructions Cloud platform connection Light on WiFi connection Flashing Not connection Light off 4) Rated Capacity Rated Capacity indicates the nominal capacity of current cluster. 4.6 Screen display code Figure 4.6.1 Screen Warning Code (Sign like “�”) Code Warning Type Battery cell undervoltage protection Overcurrent charge protection Overcurrent discharge protection...
  • Page 47 High discharge temp protection Low charge temp protection Low discharge temp protection High ambient temp protection Excessive voltage difference protection Excessive temp of main control relay Overtemp protection of master DC busbar Low insulation resistance protection Low total voltage protection Low ambient temp protection High MOS temp protection Battery cell overvoltage protection...
  • Page 48 NTC fault Current sensor fault Pack disconnection Short circuit fault Internal total voltage detection fault Heating fault Battery module conflict Cluster address conflict Charge MOS fault Discharge MOS fault Addressing failure Precharge fault Cluster disconnection Battery reverse connection fault External total voltage detection fault Address non-1 fault Address break-sign failure Microelectronic fault...
  • Page 49 Charge high temp safety lock Charge low temp safety lock Discharge high temp safety lock Discharge low temp safety lock Charge overcurrent safety lock Discharge overcurrent safety lock...

  • Page 50: Troubleshooting & Maintenance

    5 Troubleshooting & Maintenance 5.1 Regular maintenance 1) Check the battery modules every 3 months to verify whether there are damages. 2) Check the battery modules every 3 months to verify whether the operating parameter is normal or there is no abnormal heating. 3) Fully charge and discharge the battery system every 3 months.
  • Page 51 1. Try to charge the battery by the activation charging function Unable to turn on the battery of the inverter when power is on. 1. Make sure the antenna is screwed properly; 2. Make sure the WIFI configuration is correct; 3.

  • Page 52: Status Code

    1. Make sure the connection of cables is correct and circuit breaker is ON; 2. Check whether inverter has faults; Unable to discharge while SOC is 3. Make sure the inverter setting is not back up mode; not zero. 4. Check whether SOC is lower than the shutdown value of the inverter;...
  • Page 53 1. Make sure the battery’s temperature shown on the inverter or the APP is below 55℃, otherwise turn off the High charge temp alarm battery till the temperature is below 55℃ and then try to charge battery. 1. Make sure the battery’s temperature shown on the inverter or the APP is below 55℃, otherwise turn off the High discharge temp alarm battery till the temperature is below 55℃...
  • Page 54 High MOS temp alarm 1. Reduce the ambient temperature and restart the battery. Battery cell overvoltage alarm 1. High voltage level and needs to be discharged. High total voltage alarm 1. High voltage level and needs to be discharged. Low SOC alarm 1.

  • Page 55: Error Codes

    Negative high temp alarm for 1. Restart the battery, and if the error code W28 still remaining discharge port or reappear, contact your installer. 1. Restart the battery, and if the error code W400 still W400 PCS disconnection remaining or reappear, contact your installer. 5.3.2 Error Codes Code Error Type...
  • Page 56 1. Restart the battery, and if the error code F105 still remaining F105 Pack disconnection or reappear, contact your installer. 1. Make sure the external connection for both battery and inverters are proper; F106 Short circuit fault 2. Disconnect all external connections and restart the battery, and if the error code F106 still remaining or reappear, contact your installer.
  • Page 57 1. Restart the battery, and if the error code F113 still remaining F113 Addressing failure or reappear, contact your installer. 1. Restart the battery, and if the error code F114 still remaining F114 Precharge fault or reappear, contact your installer. 1.
  • Page 58 1. Restart the battery, and if the error code F123 still remaining F123 Microelectronic fault or reappear, contact your installer. 1. Restart the battery, and if the error code F124 still remaining F124 Smoke sensor fault or reappear, contact your installer. The number of slave voltage 1.
  • Page 59 1. Restart the battery, and if the error code F132 still remaining F132 EMS SN is empty or reappear, contact your installer. 1. Restart the battery, and if the error code F133 still remaining F133 Master SN is empty or reappear, contact your installer. 1.

  • Page 60: Protection Codes

    Discharge high temp safety 1. Restart the battery, and if the error code F204 still remaining F204 lock or reappear, contact your installer. Discharge low temp safety 1. Restart the battery, and if the error code F205 still remaining F205 lock or reappear, contact your installer.
  • Page 61 1. Make sure the battery’s temperature shown on the High discharge temp inverter or the APP is below 55℃, otherwise turn off the protection battery till the temperature is below 55℃ and then try to discharge battery. 1. Make sure the battery’s temperature shown on the inverter or the APP is above 0℃, otherwise turn off the battery Low charge temp protection till the temperature is above 0℃...
  • Page 62 High MOS temp protection 1. Reduce the ambient temperature and restart the battery. Battery cell overvoltage 1. High voltage level and needs to be discharged. protection High total voltage protection 1. High voltage level and needs to be discharged. Low SOC protection 1.
  • Page 63 Positive high temp protection 1. Reduce the ambient temperature and restart the battery. for discharge port Negative high temp 1. Reduce the ambient temperature and restart the battery. protection for discharge port Charger overvoltage 1. Restart the battery, and if the error code P30 still remaining protection or reappear, contact your installer.
