  • Page 1 User Manual Xcellent Plus-US A02 VERSION Renon Power Technology Inc. © Renon Power Technology Inc. All Rights Reserved Specifications are subject to change without notice.
  • Page 2 PROVIDE INNOVATIVE, storage solutions to global customers. At Renon, we believe that sustainable energy is the future. We are RELIABLE, AND passionate about reducing carbon emissions and preserving our planet for future generations. That's why we invest heavily in research and...

  • Page 3: Table Of Contents

    Table of Contents 1 Safety Instructions ..........................6 1.1 General Safety Precautions ......................6 1.2 Transportation and Storage Precautions ................... 6 1.3 Installation Precautions ......................7 1.4 Usage Precautions ........................8 1.5 Response to Emergency Situations ................... 8 1.6 Qualified Personnel ........................9 2 Preparation Before Installation ......................10 2.1 Safe Handling Guide ........................
  • Page 4 5.3.2 Power Button ........................34 5.3.3 LED ..........................34 5.4 Function Introduction ......................36 5.4.1 Protection ........................36 5.4.2 Heating ......................... 36 5.4.3 Forced Discharge ......................36 5.4.4 Full Charge ........................36 5.4.5 Charging Self-Adaptation Control .................36 5.4.6 Safety Lock ........................36 5.5 Interface Information ......................

  • Page 6: Safety Instructions

    1 Safety Instructions For safety reasons, installer and user are responsible for familiarizing themselves with the contents of this document and all warnings before installation and usage. 1.1 General Safety Precautions • Please carefully read this manual before any work is carried out on the product, and keep it located near the product for future reference.

  • Page 7: Installation Precautions

    • If the product needs to be moved or repaired, the power must be cut off and completely shut down. • The product must be transported in its original or equivalent package; • The modules are heavy. Ensure adequate and secure mounting and always use suitable handling equipment for transportation.

  • Page 8: Usage Precautions

    • Handle with care because Li-ion Battery is sensitive to mechanical shock. 1.4 Usage Precautions • Before starting the system, the operator should strictly check the connection terminals to ensure that the terminals are firmly connected. • If here's a circuit breaker between battery and inverter, the breaker is supposed to be on before powering on the battery.

  • Page 9: Qualified Personnel

    • In case of ingestion: Induce vomiting and seek medical attention. 1.6 Qualified Personnel The installation guide part described herein is intended for use by skilled staff only. Skilled staff is defined as a trained and qualified electrician or installer who has all the following skills and experience: •...

  • Page 10: Preparation Before Installation

    2 Preparation Before Installation 2.1 Safe Handling Guide 2.1.1 Familiarize yourself with the Battery Be careful when unpacking the system. Every module of the product is heavy. Don't lift them with a pole. The weight of the modules can be found in the chapter "Specifications". Familiarize yourself with the battery.

  • Page 11: Safety Gear

    Torque Wrench Hydraulic Clamp Spirit Level Crimping Pliers Use properly insulated tools to prevent accidental electric shock or short circuits. If insulated tools are not available, cover the all exposed metal surfaces of the available tools, except their tips, with electrical tape.

  • Page 12: Installation Location

    Figure 2.2.1. Installation distance 2.3 Installation Location Make sure that the installation location meets the following conditions: • The surface of the wall is smooth and perpendicular to the ground, which can bear the weight. • The area is completely water proof. (Recommended) •...

  • Page 13: Package Items

    Xcellent Plus Packing List: Item Specification Usage Diagram Xcellent Plus R-XC016161(-H)-US Battery User manual Xcellent Plus-US User manual Secure mounting panel on Embedded Screw M6*16 the wall Secure holder to the Embedded Screw M5*12 battery...
  • Page 14 RJ45, 35.43 in (900mm) Cable cable Communication Battery communication RJ45, 27.56 in (700mm) Cable cable to inverter Lock or unlock junction box Positioning 3mm, 82.68x22.05 in Use for locating the Cardboard (2100x560mm) mounting hole positions. Quick Installation Xcellent Plus-US Installation Manual Manual...

  • Page 15: Installation

    3 Installation 3.1 Device Installation Step 1: 1) Make sure the wall is sufficient to support the installation weight of the device. For product weight, check 5.2. Specifications for detail. 2) Pre-drill the holes in the wall according to the diagram, including the locations for the battery and inverter.
  • Page 16 Figure 3.1.2. Mounting panel 4) Mounting leveling feet. Figure 3.1.3. Leveling feet 5) Attach holder 1 and holder 2 using 6*M6x16 and 4*M5x12 screws.
  • Page 17 Figure 3.1.4. Holder installation Figure 3.1.5. Left side screws 6) Mount the battery to the mounting panel using 2*M5x12 screws.
  • Page 18 Figure 3.1.6. Install battery to the mounting panel 7) If slight misalignment is detected in the mounting holes after installation, a flush installation can be achieved by adjusting the leveling feet. Note: The leveling feet can support the battery and be adjusted upward by 0.2 in (5mm). Step 2: 1) Remove the cover of the junction box connected to the inverter above the battery.
  • Page 19 Figure 3.1.7. Remove cover of the junction box Step 3: 1) Mount the inverter directly to the pre-drilled holes to ensure a secure installation. Note: Refer to the Sol-Ark 15k-2P-N inverter installation guide. Figure 3.1.8. Battery...

  • Page 20: Connection

    3.2 Connection Cable Color Coding Specification: 1. Unlock waterproof cover of junction box. Figure 3.2.1. Unlock waterproof cover 2. Connect to inverter’s power cable, communication cable and ground cable. Power cable: 2/0 AWG 1) Connect the battery negative terminal to the inverter negative terminal. 2) Connect the battery positive terminal to the inverter positive terminal.

  • Page 21: Power On

    Figure 3.2.2. Single stack 3. If there is generator, load, or grid that needs to be connected, connect the inverter through the junction box to the corresponding external device directly. 4. Lock the waterproof cover of junction box and tighten the retention screws at both ends. Figure 3.2.3.

  • Page 22: Application Scenarios

    The DC breaker position shown in the diagram is specific to Sol-Ark 15k-2P-N inverter. For other brands or models, refer to the respective product's user manual. Figure 3.3.1. DC breaker Step 2: Press the power button to use. Figure 3.3.2. Power button 3.4 Application Scenarios Note: If multiple battery units need to be connected in parallel, simply repeat the installation procedure described in Step 1 on both sides.

  • Page 23: Two Batteries

    3.4.1 Two Batteries Figure 3.4.1. Two batteries in parallel connect with inverter 3.4.2 Multiple Parallel Figure 3.4.2. Multiple batteries in parallel connect with inverter...

  • Page 24: Cloud Platform Configuration

    4 Cloud Platform Configuration 1) Download App Download and install Renon app from Google play or App Store by searching “Renon Smart”. Figure 4.1.1. Install Renon App Figure 4.1.2. Android QR code Figure 4.1.3. IOS QR code 2) Register For new account registration, please retrieve the Registration Code from your installer. Existing users...
  • Page 25 Figure 4.1.4. Register &Log in 3) Log in This is a general user account. Figure 4.1.5. General user 4) Binding Merhod 1: a. Distribution To register as an end user, scan the binding QR code provided by your installer, then request device assignment to your account.
  • Page 26 Figure 4.1.6. Scan upper-level account, Confirm binding & Become end user b. Scan QR code Select "Scan code binding" and scan the QR code using your device camera. Contact the installer if unsuccessful. Figure 4.1.7. Scanning QR code Method 2: Click "My device"...
  • Page 27 Figure 4.1.9. QR code, upper-level account & binding successfully If the above methods are not successful, please contact Renon, email address: support@renon- usa.com, Renon Power Support: +1 (833) 736-6687. Be sure to write your account name/email address and device serial number clearly. 5) WiFi configuration Set the inverter dial code to 63 (111111) as shown below before WiFi configuration.
  • Page 28 Turn to the “Me” page, click Network Configuration, then click Bluetooth, followed by WiFi configuration. Figure 4.1.10. Bluetooth network setting Enable Bluetooth on your mobile device, then select the detected device to access its Bluetooth network configuration page Figure 4.1.11. Connect battery Bluetooth...
  • Page 29 Enter your private WiFi credentials (SSID and password) to connect the master controller. Note：Devices assigned to end users will auto-populate the authentication key. Figure 4.1.12. Connecting private WiFi 6) Create a power station Navigate to the Power Station page on the app, create a new station by setting its name, type, pricing, superior view, address, and uploading station images.
  • Page 30 Figure 4.1.14. Manage your power station & Confirm your device The device can be managed both through the app and the web portal (contact your installer for the website URL). Figure 4.1.15. Manage your device Once WiFi connected, the device enables real-time monitoring of operational status, instantaneous power, and energy consumption (daily/cumulative) via the network platform or mobile app, while also supporting remote parameter configuration.
  • Page 31 Figure 4.1.16. Monitoring device Set the inverter dial code to match the inverter brand after WiFi configuration is complete (Please refer to the chapter 5.5.5 Inverter Dial Switch). 7) Lock the waterproof cover After completing the grid connection, lock and securely fasten the waterproof cover of the junction box.

  • Page 32: Battery Specifications

    5 Battery Specifications The Xcellent Plus is a lithium iron phosphate LFP battery-based energy storage product developed and produced by RENON, it can supply reliable power for nearly all kinds of household appliances and equipment. The Xcellent Plus consists of a built-in BMS battery management system, which can manage and...

  • Page 33: Specifications

    5.2 Specifications Item R-XC016161-US / R-XC016161-H-US Battery Chemistry LiFePO4 Nominal Energy (kWh) Nominal Capacity (Ah) Max. Charging/Discharging Current (A) Nominal Voltage (V) 51.2 Recommend Charging Voltage (V) 56.8 Max. Charging Voltage (V) 58.4 Discharge Cut-off Voltage (V) 43.2 Heating Power(W) Heating Start Temperature 41/5 (-H model only) (℉/℃)

  • Page 34: External Introduction

    5.3 External Introduction 5.3.1 Explosion-proof Valves Figure 5.3.1. Explosion-proof valves 5.3.2 Power Button The power button is used to power-on/power-off the device. The power button is located in right corner of device. Figure 5.3.2. Button 5.3.3 LED The LEDs are used to display current state. The LEDs are located on the right side of device.
  • Page 35 Figure 5.3.3. Light Item Specification Shut down: Off WiFi disconnect router: On RUN (Blue) WiFi has connected router: 0.5s on, 0.5s off WiFi has connected cloud: 0.5s on, 1.5s off No protection, alarm, fault: off Alarm: 0.5s on, 1.5s off ALM (Red) Protection: 0.5s on, 0.5s off Fault: On...

  • Page 36: Function Introduction

    5.4 Function Introduction 5.4.1 Protection The battery system is equipped with comprehensive protection features, including but not limited to overcharge/overdischarge protection, high/low temperature protection during charging/discharging, overcurrent protection during charging/discharging, and short circuit protection, ensuring the safety and stability of the battery under various usage conditions. 5.4.2 Heating When the battery is equipped with a heating film, the system will continuously monitor cell temperature.

  • Page 37: Interface Information

    5.5 Interface Information Figure 5.5.1. Battery ports Instructions Instructions LINK IN Inverter Port INV COM Debug Port LINK OUT Dry Contact Power Negative INV.SET Power Positive FUN.SET Ground Addr.SET...

  • Page 38: Link In Parallel Communication Port

    5.5.1 LINK IN Parallel Communication Port Terminal type: RJ45 Usage: Communicate with the last battery when parallel used. Port definitions RJ45 Pin Function BMS_CAN1L BMS_CAN1H BMS_CC_GND BMS_CC_GND BMS_PW_IN1 BMS_CC_GND BMS_XUNZIN- /Emergency stop node 1 BMS_XUNZIN+/Emergency stop node 2 5.5.2 LINK OUT Parallel Communication Port Terminal type: RJ45 Usage: Communicate with the next battery when parallel used.

  • Page 39: Inverter Communication Port

    5.5.3 Inverter Communication Port Terminal type: RJ45 Usage: Communicate with inverter. Before connect inverter with battery by communication cable, users need to check its cable sequence at first. Definition of battery side as below: Port definitions RJ45 Pin Function RS485_2B RS485_2A COM_SGND WAKEUP +...

  • Page 40: Inverter Dial Switch

    Code 0~26 of this Dial Switch are used to match which brand of inverter is using. The definitions of code 0 ~ 26 are shown as Inverter dial code table. Code Dial Switch Position Brand Logo APP setting (Default: Renon Flex) Renon Schneider Gateway Sol-Ark Solis Studer Xtender...

  • Page 41: Function Dial Switch

    Aiswei Phocos Voltronic Power Afore Lux Power CHISAGE ESS 5.5.6 Function Dial Switch The dial switch settings for a single are as below: Single device Usage Code 5.5.7 Address Dial Switch 1) Use this Dial Switch to set the address of each battery and then turn on to activate the system when it needs to be in parallel with other battery units.
  • Page 42 Code Dial Switch Position Definition Set as battery 1 (communicate with inverter by this battery) Set as battery 2 Set as battery 3 Set as battery 4 Set as battery 5 Set as battery 6 Set as battery 7 Set as battery 8 Set as battery 9 Set as battery 10 Set as battery 11...
  • Page 43 Set as battery 16 Set as battery 17 Set as battery 18 Set as battery 19 Set as battery 20 Set as battery 21 Set as battery 22 Set as battery 23 Set as battery 24 Set as battery 25 Set as battery 26 Set as battery 27 Set as battery 28...

  • Page 44: Inv Communication Port

    5.5.8 INV Communication Port Terminal type: 6-Pin terminal block Usage: Reserved for direct connection with inverter, same function as the RJ45 port (chapter " Inverter Communication Port (RJ45)"), only one of these two need to be used, leave it open if not used.

  • Page 45: Power Positive & Negative

    If you are using the pin order select box, please refer to the table below to set the dial switch, according to the inverter brand. If the inverter brand is not shown in the table, please refer to the inverter manual or consult Renon's engineer. Dail switch position...
  • Page 46 DEYE Growatt SPF RS485 Growatt SPH Must MEGAREVO Aiswei Phocos RS485 Voltronic Power RS485 Afore Lux Power CHISAGE ESS...

  • Page 47: Emergency Stop

    5.5.12 Emergency Stop The first battery (Address 1)'s LINK IN port (Pins 7-8) can be connected to the normally open (NO) contacts of an external emergency stop button. When activated, this will disconnect all battery outputs. When multiple batteries are connected in parallel, the ESS disconnect only needs to be connected to the master battery.

  • Page 48: Troubleshooting & Maintenance

    6 Troubleshooting & Maintenance 6.1 Regular Maintenance 1) Check the battery modules every 3 months to verify whether there are damages. 2) Check the battery modules every 3 months to verify that the operating parameters are normal and there is no abnormal heating. 3) Fully charge and discharge the battery system every 3 months.

  • Page 49: Status Code

    1. Make sure power cable connection is correct; 2. Check whether inverter has faults; 3. Check whether grid or PV is available; 4. Make sure Time of Use of the inverter setting is correct; Unable to be charged by inverter 5.
  • Page 50 1. Make sure the battery temperature shown on the inverter or the app is Low charge temp alarm above 32℉ (0℃), otherwise turn off the battery until the temperature is above 32℉ (0℃), and then try to charge battery. 1. Make sure the battery temperature shown on the inverter or the app is above -4℉...

  • Page 51: Error Codes

    6.3.2 Error Codes Code Error Type Investigation & troubleshooting 1. Restart the battery, and if error code F102 still remains or reappears, F102 Battery cell fault contact your installer. 1. Restart the battery, and if error code F103 still remains or reappears, F103 NTC fault contact your installer.
  • Page 52 Master and EMS communication 1. Restart the battery, and if error code F130 still remains or reappears, F130 lost contact your installer. 1. Restart the battery, and if error code F131 still remains or reappears, F131 Pack disconnect fault contact your installer. 1.

  • Page 53: Protection Codes

    6.3.3 Protection Codes Code Error Type Investigation & troubleshooting Battery cell undervoltage 1. Low voltage level and needs to be charged. protection 1. Restore to factory setting; Overcurrent charge protection 2. Make sure the inverter’s setting of max current does not exceed the max charge current of the battery.
  • Page 54 Low SOC protection 1. Low voltage level, and needs to be charged. Overcurrent discharge 2 protection 1. Make sure the power of the load does not exceed the power of battery. Positive connector high temp 1. Reduce the ambient temperature, and restart the battery. protection Negative connector high temp 1.
  • Page 55 P/N: 118.601.00.0131...
  • Page 56 Renon Power Technology Inc. 5900 Balcones Drive Suite 100, Austin, TX 78731 USA Renon Power Solutions Sp.z o.o. ul. ELBLĄSKA 1, 93-459, ŁÓDŹ, POLAND Renon Power Technology B.V. Rietbaan 10, 2908 LP Capelle aan den IJssel Renon Power 株式会社 東京都中央区日本橋箱崎町 20-5 VORT 箱崎 5F...
