Summary of Contents for REVELL Tampere
- Page 1 Revel Tampere Saunas PRODUCT MANUAL Note: This manual provides assembly instructions for setups ranging from 1-person to 4-person...
-
Page 2: Table Of Contents
Contents Introduction Safety Parts List Installation Requirements Assembly Instructions 6-10 Harvia Heater & Heater Use Sauna Lighting & Sauna Stones Accessories and General Information Cleaning & Maintenance Basic Troubleshooting Guide Warranty... -
Page 3: Introduction
INTRODUCTION Congratulations on your purchase of our Revel Tampere Traditional Finnish Sauna! You’re on the path to enhanced well-being and health. Thousands of users experience the benefits of saunas daily, and now you can enjoy the soothing effects in the comfort of your own home. -
Page 4: Parts List
PARTS LIST 1 Dust Roof Panel 9 Harvia Heater 2 Left Side Wall 10 Lower Bench Seat (only on 4 Person model) 3 Front Wall 11 Upper Bench Seat 4 Hinge 12 Ceiling Panel 5 Door 13 Back Wall 6 Handle 14 Back Rest 7 Window Pain (excl. -
Page 5: Installation Requirements
INSTALLATION REQUIREMENTS The Tampere sauna is relatively easy to assemble, as the walls are secured with either a spring or sliding buckle, with two people these can be easily aligned and fixed into place. Screws are only used to fix the roof and seat backrest into place. Screws should not be overtightened and the use of a drill on a low torque setting is recommended - do not use an impact driver. -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Assembling your traditional sauna requires 1. Place the Floor Board on a flat hard at least two adults. Please read the instruc- level surface tions carefully before and during assembly to ensure proper installation. Location of the Sauna When selecting a suitable location for your infrared sauna, keep the following points in mind:... - Page 7 ASSEMBLY INSTRUCTIONS 1 - 3 PERSON MODELS 3. Install the Left Side Wall and hook the 3 outer Latch connectors (ensure left wall and back wall are square and aligned with the Floor board 4. Install the Right Side Wall and hook the 3 outer Latch connectors 4 PERSON MODELS 3.
- Page 8 ASSEMBLY INSTRUCTIONS 1 - 3 PERSON MODELS 5. Attach the seat bench to the side and back brackets, and secure the backrest to the mounts using 4 x 30mm screws. 4 PERSON MODELS 5. Attach the upper bench seat to the side and back wall brackets. Fix the lower bench seat to the side wall brackets.
- Page 9 ASSEMBLY INSTRUCTIONS ALL MODELS 6. Lift and position the front wall onto the 7. Attach the timber door handle by hanging lock. Once aligned, pull down screwing them against each other with firmly to ensure the front wall sits flush the glass door in between, ensuring with the side walls.
-
Page 10: Harvia Heater & Heater Use
ASSEMBLY INSTRUCTIONS Schematic diagram of the top switch power box and heater wiring: HARVIA HEATER The Harvia heater includes a wall mount for attaching the heater to the inside of the right side wall. Refer to the included Harvia manual for detailed instructions on attaching the wall mount and installing the heater. -
Page 11: Sauna Lighting & Sauna Stones
SAUNA LIGHTING The Harvia heater includes a wall mount for attaching the heater to the inside of the right side wall. Refer to the included Harvia manual for detailed instructions on attaching the wall mount and installing the heater. All wiring of the heater and lighting must be made by a certified electrician. SAUNA STONES The use and proper care of stones are essential to enhancing your sauna experience. -
Page 12: Accessories And General Information
ACCESSORIES AND GENERAL INFORMATION We recommend placing the provided thermometer at head height on either wall of the sauna, ensuring it is not positioned directly above the heater. Since heat rises, you will notice that the temperature varies throughout the sauna—hotter at the top and cooler at the bottom. However, with proper heat-up time and effective use of steam, the heat will distribute more evenly through- out the sauna You can place the sand timer anywhere in the sauna, except directly above the heater. -
Page 13: Basic Troubleshooting Guide
BASIC TROUBLESHOOTING GUIDE IMPORTANT: Disconnect the cabin’s power supply cable before undertaking any work. PROBLEMS EXPLANATIONS SOLUTIONS Power cable disconnected Check all Cables are con- nected Power supply issues Ensure power at the outlet is working Heater does not heat up Heater is in overheat pro- Consult Harvia Manual to or turn on. -
Page 14: Warranty
This warranty is a limited warranty given by Revel not able to resolve the issue or the customer is not Wellness for the Tampere Sauna and is valid for the able or willing to work with them, Revel Wellness period of 5 years from the date of delivery. - Page 15 Live Longer, Live Better...
