  • Page 2 REVEL SAUNAS USER MANUAL...
  • Page 3 EDEN Outdoor Barrel Due to our continued product improvement, product illustrated on this instruction manual may vary slightly from the actual product.
  • Page 4 RECOMMENDATIONS Read this manual carefully before using your sauna for the first time. We recommend you keep it in a safe place for future reference. • Wood is a living element, to maintain its original appearance, it is important to treat the outside of the wood against moisture.
  • Page 5 SAFETY IMPORTANT : Please read the safety instructions carefully before installing and using your sauna cabin. They are essential for your safety, so please adhere strictly to them. Beware of hyperthermia, heat stroke or heat exhaustion which can be caused or aggravated by noncompliance with the safety instructions.
  • Page 6 DESCRIPTION SAUNA...
  • Page 7 EDEN OUTDOOR BARREL (426x398x30mm)2x (1400x300x33mm) 2x (1590x585x40mm)1x (1800x93x30mm)2x (520x330x65mm)2x (1800x93x30mm)1x (1800x93x30mm)60x (560x300x40mm)1x (378x300x40mm)2x (1800x93x30mm)1x 3x Barrel hoop (1758x575x30mm)1x (1650x575x30mm)1x (3000x1800mm)1x (1758x952x30mm)1x (1000x320mm)60x (1404x80x20mm)1x (250x50x45mm)1x (1404x80x20mm)1x (350x50x45mm)1x) 1x Sauna stove (1574x448x30mm)1x (1758x783x30mm)1x 1x Wooden barrel (1574x488x30mm)1x 1x Wooden spoon (1672x425x50mm)2x (177x80x30mm)1x...
  • Page 8 EDEN OUTDOOR BARREL 1x Water pan 1x Hygrometer 2x Explosion proof 1x Hourglass lampshade 2x Cup plate Ø5x50 Ø4x50 Ø4x30 Ø3x35 Ø4x12 Ø6x70 240x...
  • Page 9 EDEN OUTDOOR BARREL Read the assembly instructions carefully before starting. Choice of location Designed solely for exterior installation. Select a space: • In a dry area, on a flat stable surface that can support the weight of your sauna. • The height must be sufficient for you to reach the ceiling and carry out electrical connections and maintenance.
  • Page 10 ASSEMBLY INSTRUCTIONS...
  • Page 11 ASSEMBLY INSTRUCTIONS Ø 5 x 50 20PCS Ø 3 x 35 2PCS Ø 5 x 50 18PCS The front and rear panels need to be assembled as a whole first. The front panel is divided into three parts on the left and right, and the rear panel is divided into three parts on the top and bottom.

  • Page 12: Assemble Instructions

    ASSEMBLE INSTRUCTIONS ASSEMBLY INSTRUCTIONS Assemble steps Ø 5 x 50 2PCS Undersupport AD=BC AB=BD Front Each slat is numbered and labeled. The left side is L01 L02 L03..L38 from bottom to top; The right side is R01 R02 R03..R38 from bottom to top.
  • Page 13 ASSEMBLY INSTRUCTIONS Assemble steps Ø 5 x 50 4PCS Under slat The top Flat shall be temporarily installed as a fixed protective measure during installation.
  • Page 14 ASSEMBLY INSTRUCTIONS Assemble steps 1. The slats of the barrel body, please be placed tightly when installing, which is conducive to the top installation and tightness. Ø 3 x 35 32PCS 2. Screws (M3*35 64PCS ) are used to fix the slats L8-L23 and R8-R23, R8-R23 Ø...
  • Page 15 ASSEMBLY INSTRUCTIONS Assemble steps Stainless steel bands Ø 4 x 50 4PCS Footrest...
  • Page 16 ASSEMBLY INSTRUCTIONS Assemble steps The support of the seat plate has been pre installed on the front and rear plates, and a support frame is needed in the middle of the seat plate. The seat plate needs to be locked onto the support side of the front and rear plates with screws.
  • Page 17 ASSEMBLY INSTRUCTIONS or / oder or / oder >80 mm SW45, SW45E, SW60, SW60E:...
  • Page 18 ASSEMBLY INSTRUCTIONS The sauna stove is a universal cable connected to an external customer power supply. The wires of the lamp should be connected to the wiring base of the sauna stove and powered through the sauna stove. Sauna stove lamp line Cable...
  • Page 19 ASSEMBLY INSTRUCTIONS Waterproof cloth Asphalt shingle Ø 4 x 12 200PCS 1800mm...
  • Page 20 ASSEMBLY INSTRUCTIONS Timer knob Thermostat knob 1.1 Turning the heater on immediately Turn the timer knob clockwise to the "on" section (section A in figure 2, 0-4 hours). The heater starts heating until the timer returns to 0 and the lights turn on. 1.2 Presetting the time To preset heating time, turn the timer knob clock- wise to the preset section (section B in figure 2, 0-8 hours).

  • Page 21: Maintenance

    SAUNA MAINTENANCE...

  • Page 22: Sauna Maintenance

    SAUNA MAINTENANCE Protection of wood Brush each exterior barrel slat and apply a wood stain when full assembly to protect the wood. This wood stain had to be renewed according to the recommendations of the product used Maintenance IMPORTANT : Disconnect the cabin’s power supply cable before undertaking any work.
  • Page 23 REVEL SAUNAS USER MANUAL...
