- Page 1 Revel NordicWave Saunas PRODUCT MANUAL This manual provides assembly instructions for the 2 & 3 person Nordicwave Saunas.
- Page 2 Contents Introduction Safety Parts List Installation Requirements Assembly Instructions Harvia Heater & Heater Use Control Panel Operation Sauna Lighting & Sauna Stones Accessories and General Information Basic Troubleshooting Guide Warranty...
- Page 3 INTRODUCTION Congratulations on your purchase of our Revel NordicWave Hybrid Sauna! You’re on the path to enhanced well-being and health. Thousands of users experience the benefits of saunas daily, and now you can enjoy the soothing effects in the comfort of your own home.
- Page 4 PARTS LIST Dust cover / roof 8. Glass door 15. Right wall 2. Control box 9. Door Hinge 16. Backrest 3. Speaker 10. Ventilation 17. Seat bench 4. Left wall 11. Temperature sensor 18. Front bench bard 5. Control panel 12.
- Page 5 INSTALLATION REQUIREMENTS The NordicWave sauna is relatively easy to assemble, as the walls are secured with either a spring or sliding buckle, with two people these can be easily aligned and fixed into place. Screws are only used to fix the roof and seat backrest into place. Screws should not be overtightened and the use of a drill on a low torque setting is recommended - do not use an impact driver.
- Page 6 ASSEMBLY INSTRUCTIONS Assembling your sauna requires at least 1. Place the Floor Board on a flat hard two adults. Please read the instructions level surface. carefully before and during assembly to ensure proper installation. Location of the Sauna When selecting a suitable location for your sauna, keep the following points in mind: •...
- Page 7 ASSEMBLY INSTRUCTIONS ALL MODELS 3. Install the left side wall and hook the 3 4. Slide in the under bench seat support / outer Latch connectors Calf Heater panel, this should fit between the notches on the side walls. 5. Fit the bench seat on top of the 6.
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS ALL MODELS 7. Attach the back rest to the side and 8. Lift and position the front wall onto back brackets, and secure the to the the hanging lock. Once aligned, pull mounts using 4 x 30mm screws. down firmly to ensure the front wall sits flush with the side walls.
- Page 9 ASSEMBLY INSTRUCTIONS 11. Installing the Ceiling 1. Carefully lift the ceiling panel and place onto the assembled wall panels 2. Once all four corners are positioned in the correct place, gently press down on the outside corners of the top panel until it fits nicely in place. 3.
- Page 10 ASSEMBLY INSTRUCTIONS Schematic diagram of the top switch power box and heater wiring: HARVIA HEATER The Harvia heater includes a wall mount for attaching the heater to the inside of the right side wall. Refer to the included Harvia manual for detailed instructions on attaching the wall mount and installing the heater.
- Page 11 CONTROL PANEL OPERATION degrees. Each press adjusts by 1 degree. After 8 seconds of inactivity, the display reverts to the current temperature. Press C/F to switch between °C/°F Time Setting: In light wave mode, use the time + - button to set a duration between 5-60 minutes, increasing by 1 minute per press.
- Page 12 SAUNA LIGHTING The Harvia heater includes a wall mount for attaching the heater to the inside of the right side wall. Refer to the included Harvia manual for detailed instructions on attaching the wall mount and installing the heater. All wiring of the heater and lighting must be made by a certified electrician. SAUNA STONES The use and proper care of stones are essential to enhancing your sauna experience.
- Page 13 ACCESSORIES AND GENERAL INFORMATION We recommend placing the provided thermometer at head height on either wall of the sauna, ensuring it is not positioned directly above the heater. Since heat rises, you will notice that the temperature varies throughout the sauna—hotter at the top and cooler at the bottom. However, with proper heat-up time and effective use of steam, the heat will distribute more evenly throughout the sauna.
- Page 14 BASIC TROUBLESHOOTING GUIDE IMPORTANT: Disconnect the cabin’s power supply cable before undertaking any work. PROBLEMS EXPLANATIONS SOLUTIONS Power cable disconnected Check all Cables are connected Power supply issues Ensure power at the outlet is working Heater does not heat up Heater is in overheat Consult Harvia Manual to or turn on.
- Page 15 WARRANTY This warranty is a limited warranty given by Infrared Panels (6 Years) & Electrical (5 Years). Revel Wellness for the Revel NordicWave Accessories including Hygro-thermometer, Infrared & Traditional Hybrid Sauna and is Bucket, Ladle and hour glass are covered for a valid for the period listed under ‘Covered Parts’...
