Mid-Century
Chair & Barstool
A S S E M B LY I N S T R U C T I O N S
PARTS LIST:
Frame
A
S T E P 1
Stand frame (A) upright, align the backrest (B) with the
four holes on the top back of the chair frame. The smaller
screw holes indicate the top of the backrest, ensure this
is aligned with the top two holes in the frame.
SM A L LE R
S C R E W H O LE S
A
M I D - C E N T U R Y C H A I R & B A R S T O O L • A S S E M B LY I N S T R U C T I O N S
B
Backrest
C
Seat
REQUIRED TOOLS:
• Screwdriver
B
HARDWARE:
(6) Bolts*
(5) Seat Screws
D
E
NOTES:
•
Ensure you have all the required pieces before assembly.
•
Inspect all pieces for damage before assembly. Do not assemble
if any pieces are broken or damaged.
•
Assembly instructions are applicable for mid-century chairs
and barstools.
S T E P 2
Secure the backrest to the frame by using 4 bolts (D)
with the allen key (F) provided.
D
S T E P 3
Place the seat (C) on a clean, elevated flat surface with
the underside of the seat facing up.
UNDERSIDE
W W W . L A N C A S T E R TA B L E A N D S E A T I N G . C O M
(1) Allen Key
F
C
