ASSEMBLY INSTRUCTIONS
ITEM NO. 30197
164WAITRS5BK
164WAITRS5WL.
PART LIST:
ADEXA DIRECT LIMITED
SIZE: 31in x 22in
(3) /1PC
Top Board
SIZE: 24in x 23in
(6)/4PC
Rack Holders
SIZE: 2in x 3in x 19in
(9) /1PC
Right Drawer Side
SIZE: 12in x 4in
HARDWARE LIST:
(A)
(B)
Small Cam
Cam Lock
Screws
Screw (26PCS)
Lock (2PCS)
(12PCS)
(1) /1PC
Left Side Board
(10) /1PC
Left Drawer Side
SIZE: 12in x 4in
(E)
(C)
(D)
Machine
Shelf Pin
Screw (2PCS)
(6PCS)
(4) /1PC
Kick Board
SIZE: 24n x 3in
(7) /1PC
Bottom Board
SIZE: 22in x 22in
(11) /1PC
Front Drawer Side
SIZE: 24in x 4in
(G)
Drawer
Track (1PC)
(F)
Cam Lock
(26PCS)
(2) /1PC
Right Side Board
SIZE: 31in x 22in
(5) /1PC
Back Board
SIZE: 36in x 24in
(8) /1PC
Shelf Bottom
SIZE: 20in x 12in
(12) /1PC
Back Drawer Side
SIZE: 20in x 4in
TOOLS
REQUIRED:
(H)
Handle
(1PC)
Phillip's Head
Screwdriver
(not included)
Advertisement
Related Manuals for Lancaster 164WAITRS5BK
Summary of Contents for Lancaster 164WAITRS5BK
- Page 1 ASSEMBLY INSTRUCTIONS ITEM NO. 30197 164WAITRS5BK 164WAITRS5WL. PART LIST: ADEXA DIRECT LIMITED (1) /1PC (2) /1PC Left Side Board Right Side Board SIZE: 31in x 22in SIZE: 31in x 22in (5) /1PC Back Board SIZE: 36in x 24in (3) /1PC...
- Page 2 ITEM NO. : 30197 STEP 1. Screw Cam Lock Screws (Ax16) onto side boards (1) & (2) and top board (3) and back board (5). a. Attach tracks onto predrilled holes on side 1 and 2 using the pilot holes to guide you. A=4PCS A=2PCS A=2PCS...
- Page 3 ITEM NO. : 30197 STEP 3. 1. Lay top Board (3) on ground. Add sideboards (1 &2): line up cam lock screw (Ax4) and cam lock (Fx4). Tighten cam lock (Fx4) with screwdriver once boards are in place. 2. Align bottom board (7) with remaining cam lock screws(A). Tighten cam locks with screwdriver. BEFORE ASSEMBLE TIGHTEN ALL THE A SCREWS AFTER THEY ARE...
- Page 4 ITEM NO. : 30197 STEP 6. 1. Place 4 cam locks (F x4) into back drawer (12) and Place 4 cam lock screws into front drawer (11) 2. Place 2 cam locks and 2 cam lock screws into 9 and 10. (12) (10) (11)
