Lancaster Ladderback Swivel Barstool Assembly Instructions

Ladderback Swivel Barstool
A S S E M B LY I N S T R U C T I O N S
PA R T S L I S T
Seat 1/PC
A
Seat Frame 1/PC
B
S T E P 1
To Start, place the seat (A) upside down on a table
and set the seat frame (B) upside on top of the cushion.
Be sure to center the frame on top of the cushion.
The front edge of the cushion should be parallel to the
front edge of the seat frame.
L A D D E R B A C K S W I V E L B A R S T O O L • A S S E M B LY I N S T R U C T I O N S
Seat Screws 6/PC
C
Base with Swivel Plate 1/PC
D
2
E Bolts 4/PC
2
F Nuts 4/PC
N O T E S
1. Before starting, make sure you have all the required pieces.
2. A screwdriver is required for assembly (not included).
A drill is optional for easier assembly.
3. Use caution when assembling the base as the swivel plate
has moving parts.
S T E P 2
Using a screwdriver or drill, attach the 6 seat screws (C)
and secure the cushion to the frame through the screw
holes on the seat frame.
W W W . L A N C A S T E R TA B L E A N D S E A T I N G . C O M
2
G Wrench 1/PC
H 2 Allen Key 1/PC
