Summary of Contents for UNI-T MSO3000HD Series

  • Page 1 Quick Start Guide MSO3000HD Series Quick Start Guide MSO3000HD Series Mixed Signal Oscilloscope This manual applies to model: MSO3000HD Series V1.0 August, 2024...
  • Page 3: Copyright Information

    Foreword Dear Users, Hello! Thank you for choosing this brand-new UNI-T instrument. To ensure safe and correct usage, please read this manual thoroughly, paying particular attention to the Safety Requirements section. After reading this manual, it is recommended to keep the manual at an easily accessible place, preferably close to the device, for future reference.
  • Page 4: Warranty Service

    This warranty is written by UNI-T for this product, and it is used to substitute any other express or implied warranties. UNI-T and its distributors do not offer any implied warranties for merchant ability or applicability purposes.
  • Page 5: Safety Requirements

    Users must follow the following conventional safety precautions in operation, service and maintenance of this device. UNI-T will not be liable for any personal Warning safety and property loss caused by the user’s failure to follow the following safety precautions.
  • Page 6 Quick Start Guide MSO3000HD Series Safety Sign It indicates possible danger of electric shock, which may cause Danger personal injury or death. It indicates that you should be careful to avoid personal injury or Warning product damage. It indicates possible danger, which may cause damage to this...
  • Page 7 Quick Start Guide MSO3000HD Series Primary circuit of large equipment directly connected to the distribution board and circuit between the distribution board and the socket (three-phase distributor circuit includes a single commercial lighting circuit). Fixed CAT III equipment, such as multi-phase motor and multi-phase fuse box; lighting equipment and lines inside large buildings;...
  • Page 8 Power fuse meets the specified specifications by the maintenance personnel authorized by UNI-T. There are no components available to operators inside. Do not Disassembly and cleaning remove the protective cover.
  • Page 9: Environmental Requirements

    Caution If this device may be faulty, please contact the authorized maintenance personnel of UNI-T for testing. Any maintenance, Abnormality adjustment or parts replacement must be done by the relevant personnel of UNI-T.
  • Page 10: Connecting Power Supply

    Quick Start Guide MSO3000HD Series Overvoltage Category II. This is a typical requirement for connecting devices via power cords and plugs. In operating: altitude lower than 3000 meters; in non-operating: altitude lower than  15000 meters Unless otherwise specified, operating temperature is 0 to +40℃; storage temperature ...
  • Page 11 Quick Start Guide MSO3000HD Series electrostatic discharge during transportation, storage and use. The following measure can reduce the damage of electrostatic discharge. Testing in anti-static area as far as possible.  Before connecting the power cable to the instrument, inner and outer conductors of the ...
  • Page 12 Quick Start Guide MSO3000HD Series 3. MSO3000HD Series MSO3000HD series mixed signal oscilloscope has 3 models. Analog channel Model Analog bandwidth Digital number MSO3054HD 500 MHz ● ○ MSO3034HD 350 MHz ● ○ MSO3024HD 200 MHz ● ○ ●:Standard ○:Option ×:Not support...
  • Page 13: Getting Started Manual

    (2) Check Attachment Please check appendix for the list of accessories. If any of the accessories are missing or damaged, please contact UNI-T or local distributors of this product. (3) Machine Inspection If the instrument appears to be damaged, not working properly, or has failed the functionality test, please contact UNI-T or local distributors of this product.
  • Page 14 Quick Start Guide MSO3000HD Series (3) Connecting Probe This oscilloscope provides 2 pieces of compensating signal probe. Connect the BNC of the probe to the BNC of oscilloscope’s CH1 and connect the probe to the “probe compensating signal connection clip”, and then connect the ground alligator clip of the probe with the ground terminal of compensating signal connection clip.
  • Page 15: Front Panel

    Quick Start Guide MSO3000HD Series If the displayed waveform resembles the above “Insufficient Compensation” or “Excessive  Compensation”, use a non-metallic screwdriver to adjust the probe’s variable capacitance until the display matches the "Correct compensation" waveform. Warning:To avoid electric shock when using the probe to measure high voltage, please ensure that the probe insulation is in good condition and avoid physical contact with any metallic part of the probe.
  • Page 16: Rear Panel

    Quick Start Guide MSO3000HD Series Signal output area Power soft switch key Probe compensation signal connection terminal and ground terminal:Connect the BNC end of the probe to the BNC connector on Channel 1 of the oscilloscope. Attach the probe tip to the "Probe Compensation Signal Terminal,"...
  • Page 17: Operation Panel

    Quick Start Guide MSO3000HD Series AUX Out LAN port 10MHz REF Power switch USB HOST port AC power input socket HDMI port Safety lock 4.5. Operation Panel (1) Vertical Control :Analog channel setting key  respectively represents CH1, CH2, CH3, and CH4. Four channel’s tab are identified by different colors and it also...
  • Page 18 Quick Start Guide MSO3000HD Series (2) Horizontal Control Menu :Horizontal menu key is used to display the  horizontal scale, time base mode (XY/YT), horizontal, auto roll, quick roll time base, horizontal position, time base extension and time base selection.
  • Page 19 Quick Start Guide MSO3000HD Series (4) Control Area Auto/Normal:Press the Auto/Normal key to switch the  oscilloscope trigger mode between Auto and Normal. Run/Stop:This key is used to set the operating mode of the  oscilloscope to “Run” or “Stop”.
  • Page 20 Quick Start Guide MSO3000HD Series their default values. Multipurpose A:Multi-function knob A. When a numerical menu is selected in the function  popup window, the LED on the multi-function knob will light up, allowing the user to adjust values using the knob.
  • Page 21: User Interface

    Quick Start Guide MSO3000HD Series 4.6. User Interface User Interface Table 3 User Interface Description Description Description Waveform display window Multi-window display area Trigger state Digital label Ref label Horizontal base label Sampling rate and storage depth FFT label label...
  • Page 22 Quick Start Guide MSO3000HD Series The user can access the help system by following these steps. In Home menu, click on the help icon “ ” to open the help menu.  In each function menu popup, click on the help icon “...
  • Page 23: Parameter Setting

    Quick Start Guide MSO3000HD Series 5. Parameter Setting MSO3000HD series supports use the Multipurpose rotary knob and touch screen to set the parameter, the setting steps as follows. (1) Multipurpose rotary knob For the parameter of time and voltage, once the parameter is selected, rotating the Multipurpose rotary knob on the front panel to enter the parameter value.
  • Page 24 Quick Start Guide MSO3000HD Series Keyboard name Text field Clear key Backspace Tab key Caps lock Enter key Shift key Virtual keyboard Space key Arrow keys: left, right 1. Enter numeric value When setting or editing a parameter, use the numeric keyboard to enter the numeric value.
  • Page 25 Quick Start Guide MSO3000HD Series Delete the entered parameter value. Set the parameter to the maximum or minimum value (sometimes specifically the maximum or minimum value for the current state). Set the parameter to the default value. Clear the parameter input field.
  • Page 26: Touch Screen

    MSO3000HD Series 6. Touch Screen MSO3000HD series provides 10.1-inch super capacitive touch screen, multiple point touch control and gesture control. MSO3000HD has easily operating system with flexible and high-sensitive touch screen features for great waveform display and excellent user experience.
  • Page 27 Quick Start Guide MSO3000HD Series (3) Drag Use one finger to press and drag the selected item to the aimed position as shown in the following figure. Drag gesture can use for: Drag the waveform to change the waveform position ...
  • Page 28: Remote Control

    Quick Start Guide MSO3000HD Series 7. Remote Control MSO3000HD series mixed signal oscilloscopes can communicate with a PC via USB and LAN port for remote control. Remote control is implemented using SCPI (Standard Commands for Programmable Instruments). MSO3000HD series has three methods for remote control.
  • Page 29: Troubleshooting

    Restart the oscilloscope after completing the above steps. If the product still does not work properly, contact the UNI-T Service Center for assistance. (2) After signal acquisition, the waveform of the signal does not appear on the screen.
  • Page 30 Quick Start Guide MSO3000HD Series exceeds the waveform range. If the trigger mode is in normal or single and the trigger level is in the center, set the trigger mode to AUTO. Press the Autoset key to automatically complete the above settings.
  • Page 31 MSO3000HD Series 9. Contact Us If you experience any issues with this product and are in mainland China, you can contact UNI-T directly. Our service support is available from 8 a.m. to 5:30 p.m. (UTC+8), Monday to Friday, or via email at infosh@uni-trend.com.cn.
  • Page 32 110401112667X...
  • Page 33 说明书菲林做货要求: 序号 项目 内容 尺寸 外尺寸:(148x210)±1mm. 材质 封面封底 128G 双铜 内页 60g 书纸 颜色 黑色,双面印刷 外观要求 印刷完整清晰,版面整洁.无分层.残损.毛边等缺陷 装订方式 骑马订装 表面处理 无 其它 版本 REV.0 MODEL 设 计 110401112667X art NO. 机型: MSO3000HD 审 核 优利德科技(中国)股份有限公司 APPRO UNI-TREND TECHNOLOGY (CHINA) CO.,LTD 批...
