- Page 1 Installation Manual V3 BCAP Series IP Clock 201.934.8500 P. 201.934.9832 F. www.bogen.com...
-
Page 2: Table Of Contents
Power over Ethernet Wiring Information—13 Bogen Clock Monitor—14 Bogen Clock Monitor (continued)—15 Bogen Clock Monitor - Error Messages—16 Bogen Clock Monitor - DHCP and Static IP—17 Web Interface - Log In—18 Web Interface - Clock Settings—19 Web Interface - Network Settings—20 Web Interface - Network Servers—21... -
Page 3: Wall Mount Installation -3
201.934.8500 P. 201.934.9832 F. www.bogen.com Wall Mount Installation 12” Clock 16” Clock 1. Connect the Ethernet cable as shown on the wiring diagram 2. Mount both plastic anchors in the wall. 3. Insert the sheet metal screws (#10) through the mounting bracket into the plastic anchors. -
Page 4: Wall Mount Installation - Square Clock (Wired Applications)-4
201.934.8500 P. 201.934.9832 F. www.bogen.com Wall Mount Installation - Square Clock (wired applications) -
Page 5: Wall Mount Installation - Square Clock (Wired Applications)-5
201.934.8500 P. 201.934.9832 F. www.bogen.com Wall Mount Installation - Square Clock (wired applications) Separate the front of the clock from the back case - Locate the four (4) tabs (two (2) on the left side and two (2) on the right side of the clock) and disengage those tabs by pressing down on them with a flathead screw driver no further than 1/4 inch. -
Page 6: Metal Double Mount Installation -6
201.934.8500 P. 201.934.9832 F. www.bogen.com Metal Double Mount Installation 1. Screw the mounting bracket to the double gang box using four (4) inner holes on mounting bracket, or mount the mounting bracket directly to the wall or ceiling using the four (4) outer holes. -
Page 7: Plastic Double Mount Installation -7
201.934.8500 P. 201.934.9832 F. www.bogen.com Plastic Double Mount Installation... -
Page 8: Plastic Double Mount Installation-8
201.934.8500 P. 201.934.9832 F. www.bogen.com Plastic Double Mount Installation *For metal mounting bracket: Use anchor that can support 50 lbs with a maximum screw size of 10/1.5” Install metal mounting bracket - First, remove the metal mounting bracket from the inside of the double mount base by unscrewing the two (2) 6-32 x 1/2”... -
Page 9: Plastic Double Mount Installation-9
201.934.8500 P. 201.934.9832 F. www.bogen.com Plastic Double Mount Installation Plug and secure wiring to clock - Loosen and slip excess wiring through provided wire clamp (comes attached to each clock adaptor) and tighten the clamp. After securing excess wiring, plug the jack at the end of the wiring into the appropriate jack on the back of the clock. If using IP clocks, wiring will not be supplied with the clocks - the installer will be responsible for supplying all Ethernet wiring. -
Page 10: Square Double Mount Installation -10
201.934.8500 P. 201.934.9832 F. www.bogen.com Square Double Mount Installation... -
Page 11: Square Double Mount Installation -11
201.934.8500 P. 201.934.9832 F. www.bogen.com Square Double Mount Installation... -
Page 12: Square Double Mount Installation -12
201.934.8500 P. 201.934.9832 F. www.bogen.com Square Double Mount Installation Snap and screw base to metal mounting bracket - Snap the base to the metal mounting bracket by first making contact with the lip in the upper side of the base and the metal mounting bracket. When the base has been snapped onto the bracket, take the two (2) 6-32 x 1/2”... -
Page 13: Power Over Ethernet Wiring Information-13
Power over Ethernet Wiring Information Connecting when using a PoE Injector Back of BCAP Series IP Clock 1. Plug in the power injector to a power outlet. 2. Using a CAT5 or CAT6 patch cable, connect one end to the switch/router connected to the network, and the other end into the IN on the power injector. -
Page 14: Bogen Clock Monitor-14
201.934.8500 P. 201.934.9832 F. www.bogen.com Bogen Clock Monitor *To access the IP Monitor, launch the Monitor.exe program from the CD provided on a computer that is connected to the same network as the IP clocks. Monitor Screen - Displays all the clocks that are both active and inactive in the system. The monitor screen displays the name of the clock, serial number, type of clock, IP address, last updated time, how long the clock has been running and the status. -
Page 15: Bogen Clock Monitor (Continued)-15
201.934.8500 P. 201.934.9832 F. www.bogen.com Bogen Clock Monitor (continued) *To access the IP Monitor, launch the Monitor.exe program from the CD provided on a computer that is connected to the same network as the IP clocks. Send Countdown to Digital Clocks - N/A - For digital IP clocks only... -
Page 16: Bogen Clock Monitor - Error Messages-16
201.934.8500 P. 201.934.9832 F. www.bogen.com Bogen Clock Monitor - Error Messages *To access the IP Monitor, launch the Monitor.exe program from the CD provided on a computer that is connected to the same network as the IP clocks. Characters are Red - When the characters of a clock have turned red, this means that the clock has not synchronized within the last 10 minutes. -
Page 17: Bogen Clock Monitor - Dhcp And Static
IP address and click submit. Then cycle the power off and on to reboot the clock. To access the web interface, type in the new IP address in the web browser. DHCP - If DHCP is being utilized, load the Bogen Monitor software on a PC that is connected to the network. Launch the Monitor.exe file and follow step 4. -
Page 18: Web Interface - Log
201.934.8500 P. 201.934.9832 F. www.bogen.com Web Interface - Log In Password -This field is where the user enters their password. The default password is 6063. This password can always be used, even if the password is changed from within the settings. -
Page 19: Web Interface - Clock Settings-19
201.934.8500 P. 201.934.9832 F. www.bogen.com Web Interface - Clock Settings User Password - This field allows for the password for entering the web interface to be changed, however, 6063 will always be a master password. This password cannot exceed 16 characters. -
Page 20: Web Interface - Network Settings-20
201.934.8500 P. 201.934.9832 F. www.bogen.com Web Interface - Network Settings Gateway IP Address - This field allows for the gateway IP address to be set. Subnet Mask - This field allows for the subnet mask to be set. DNS Router - This field allows for the DNS router address to be set. -
Page 21: Web Interface - Network Servers-21
201.934.8500 P. 201.934.9832 F. www.bogen.com Web Interface - Network Servers Retry Failed Server After - This field will allow the user to set how often it attempts to connect to a server that has not communicated with the clock. Server Addresses - These fields allow for the (S)NTP servers to be set. -
Page 22: Web Interface - Clock Status-22
201.934.8500 P. 201.934.9832 F. www.bogen.com Web Interface - Clock Status NTP Details - This button, when clicked, provides additional details about the NTP synchronization. Resync NTP Now - This button, when clicked, forces a synchronization with the NTP server. Reset NTP History - This button, when clicked, resets all the data in the NTP Details window. -
Page 23: Web Interface - Dst - Daylight Saving Time-23
201.934.8500 P. 201.934.9832 F. www.bogen.com Web Interface - DST - Daylight Saving Time Day of Week in Month DST Option - This Daylight Saving Time setting is used when the clock is to change time on the specific day, month and time. This method is typically used in some international countries. Once the option is selected, click Submit to confirm. -
Page 24: Web Interface - Email Alerts-24
201.934.8500 P. 201.934.9832 F. www.bogen.com Web Interface - Email Alerts Email Recipient - This field is where the user name of the email recipient will be inserted. Do not enter the domain and suffix. (correct: johnsmith) (incorrect: johnsmith@domain.com) Email Domain - This field is where the user will enter the domain name of the email server. (i.e. domain.com) Email Server - This field is where the email server address will be placed. - Page 25 201.934.8500 P. 201.934.9832 F. www.bogen.com Web Interface - Email Alerts Clear Log - When clicked, this button will clear the events recorded by the system.
-
Page 26: Frequently Asked Questions-26
201.934.8500 P. 201.934.9832 F. www.bogen.com Support Frequently Asked Questions How are IP clocks controlled? IP clocks are independent and receive their time from a NTP/SNTP server. If a setting is adjusted using the Monitor program, does it effect only the selected clock or the entire system? The IP clock series has the capabilities to allow the user to adjust the settings to an individual clock or apply those settings to the entire system. -
Page 27: Troubleshooting
201.934.8500 P. 201.934.9832 F. www.bogen.com Support Troubleshooting What do I do if I cannot connect to the web interface? Verify that the IP address your attempting to access is correct by connecting via a cross-over cable. See page 19. If the IP address is correct, verify that there aren’t any provisions in the firewall preventing you from accessing it. - Page 28 201.934.8500 P. 201.934.9832 F. www.bogen.com 24V/110V/220V Wiring Information Back of BCAP Series IP Clock 1. Connect one end of the CAT5 or CAT6 patch cable to the IP board and the other to a router/ switch. 2. Connect the power to the 5 pin Molex BCAP Series IP Clock connector provided to the unit.
