CS9100 Installation in Toyota & Lexus Cars (Produced After 2005)
Disconnect the negative terminal of the accumulator before installing the CS9100 to avoid errors
in the ECU. In order to install CS9100, remove the original navigation system.
Remove the original navigation system
• Under the front passenger seat;
• In the glove compartment (top right corner);
• In the trunk (e.g. in the Lexus RX series);
• Below the multi-display.
In some cases the original navigation system will differ from the illustrations below. If the original
navigation system connectors don't fit, consult the service manual for your car and connect the device
according to the pin layout, or contact Car Solutions Technical Support.
Before you connect the device, be sure to activate the appropriate protocol of the NAV2NAV adapter using
the DIP switches
(Fig. 3,
Set the DIP switches
(Fig.
DIP Switch #
Switch Setting
© 2011 www.car-solutions.com
Using the NAV2NAV Adaptor
(Fig. 1,
Figure 1
4).
Figure 3
4) on your NAV2NAV adapter according to the following table 1.
1
OFF
2). You can find it at one of the following locations:
2
3
4
ON
OFF
OFF
1
Version 4.0 22/01/2011
Figure 2
Figure 4
5
6
7
ON
OFF
OFF
support@сarsolutions.com.ua
Table 1
8
OFF
Advertisement
Related Manuals for Car Solutions CS9100
Summary of Contents for Car Solutions CS9100
- Page 1 CS9100 Installation in Toyota & Lexus Cars (Produced After 2005) Using the NAV2NAV Adaptor Disconnect the negative terminal of the accumulator before installing the CS9100 to avoid errors in the ECU. In order to install CS9100, remove the original navigation system.
- Page 2 Version 4.0 22/01/2011 Connect the CS9100 navigation system to the NAV2NAV adapter (Fig. 3), to the GVIF interface, and to the original navigation system connectors’ wiring* (Fig. 5), according to Table 2 or the connection diagram (Fig. Figure 5 Wire numbers of the original navigation system connectors.
- Page 3 Version 4.0 22/01/2011 Figure 9. The wire connection diagram for CS9100, NAV2NAV adapter and GVIF video interface Be sure to properly set the DIP switches (Fig. 10) of the GVIF Interface depending on the added equipment and originally installed equipment.
- Page 4 Figure 9 Figure 10 On the other hand, you can use CS9100 with the GPS antenna that comes with it. For better signal pickup, install the new GPS antenna in the rear spoiler (Fig.
- Page 5 Version 4.0 22/01/2011 When you switch on the CS9100 navigator for the first time, handle all setup procedures using the remote control or a USB mouse. If CS9100 doesn’t respond to the remote control, you’ll need to synchronize them. Press Return and Home simultaneously and hold for 1s. Synchronous flashing of LEDs indicates a successful synchronization.
