Model:F150-6 / F150-12
Model:F300-12 / F300-24
This is the original instruction, please read all manual instructions carefully before operating.
VEVOR reserves clear interpretation of our user manual. The appearance of the product shall
be subject to the product you received. Please forgive us that we won't inform you again if
there is any technology or software updates on our product.
01
Thank you very much for choosing this F-clamp. Please
F-CLAMP
read all of the instructions before using it.The informa-
tion will help you achieve the best possible results.
WORK AREA
1.Operate in a safe work environment. Keep your work
area clean, well-lit and free of distractions.
PERSONAL SAFETY
WARNING! Always Wear personal protective equip-
ment.
PERSONAL PRECAUTIONS
Control the F-clamp, personal movement and the work
environment to avoid personal injury or damage to
F-clamp.
1. Do not operate any F-clamp when tired or under the
influence of drugs, alcohol or medications.
2. Avoid wearing clothes or jewelry that can become
entangled with the moving parts of a tool. Keep long
hair covered or bound.
SPECIFIC SAFETY PRECAUTIONS
1. Use the correct F-clamp for the job. This F-clamp
was designed for a specific function. Do not modify or
alter this F-clamp or use it for an unintended purpose.
2. Keep body parts away from pinch areas while using.
3. Children are not allowed to operate this product
unless accompanied by an adult
4. Pay attention to safety during use to avoid crushing
fingers.
WARNING!
DO NOT let comfort or familiarity with product (gained
from repeated use) replace strict adherence to the tool
safety rules. If you use this tool unsafely or incorrectly,
you can suffer serious personal.
02
INSTRUCTIONS
Warning-To reduce the risk of injury, user
must read instructions manual carefully.
Model and Parameters
Model F150-6 F150-12
Flamping Force 150lbs 150lbs
Maximum 6inches 12inches
Clamping Size (15.24cm) (30.48cm)
2-3/8" 2-3/8"
Throat Depth
(6.03cm) (6.03cm)
Structure Diagram
①Trigger Handle ②Handgrip ③Braking Lever
④Fixed Jaw Assembly ⑤Slide Bar ⑥ Movable Jaw
Assembly L1:Clamping Size L2:Throat Depth
Assembly and Use
1.When the trigger handle ① is squeezed between
a user's hand (not shown) and the handgrip ② ,
the movable jaw assembly ⑥ moves in the direction
of the arrow ← .
2. By squeezing the Braking Lever ③ thoroughly ,
the movable jaw assembly ⑥ can be moved in the
direction of the arrow → by hand.
3.Press this button. Fixed jaw assembly ④ can be
unloaded and Assemble to the other end of the
slide bar as shown .
03
F300-12 F300-24
330lbs 330lbs
12inches 24inches
(30.48cm) (60.96cm)
3-1/3" 3-1/3"
(8.46cm) (8.46cm)
