OPERATION OF THE DEVICE
EODO: EPS Discharge Depth
EPSbuffer: Safety Buffer
Application:
When the local power grid is unstable or generators are used.
7.3.7 Manual Genset Mode
(energy storage mode → generator mode)
Applicable scenario 2: Users want to manually switch the power grid and
generator. When the power grid is powered off, the generator is manually
started. When the power grid is restored, the generator is manually closed
and connected to the power grid.
Scenario 2：The user manually controls the start and stop of the generator.
1. Connect according to the wiring diagram. The address of Chint
electricity meter is set to 01, and the address of Ankeri electricity meter
is set to 05（If you need to configure other meters, please contact us
for specific adaptation）
2. Select energy storage mode in the menu → Manual generator mode →
Set generator input power
3. The user manually starts the generator
HYD 5...20KTL-3PH 87
