UM3447
User manual
EV-VNH90xxAQ motor driver
Introduction
This document describes the specifications for the EV-VNH90xxAQ easy board, which can be connected to the EV-SPC582B to
create a full bridge motor driver evaluation tool intended for a wide range of automotive applications. To simplify the evaluation
of VNH90xxAQ devices, a GUI has been developed to facilitate the management of VNH90xxAQ inputs, monitor H-Bridge
status, and provide current sensing and fault diagnostic feedback. Collectively, this solution provides a powerful and flexible tool
for managing motor operations.
UM3447 - Rev 1 - December 2024
www.st.com
For further information contact your local STMicroelectronics sales office.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV-VNH90 AQ Series and is the answer not in the manual?

Questions and answers

Related Manuals for ST EV-VNH90 AQ Series

Summary of Contents for ST EV-VNH90 AQ Series

  • Page 1 VNH90xxAQ devices, a GUI has been developed to facilitate the management of VNH90xxAQ inputs, monitor H-Bridge status, and provide current sensing and fault diagnostic feedback. Collectively, this solution provides a powerful and flexible tool for managing motor operations. UM3447 - Rev 1 - December 2024 www.st.com For further information contact your local STMicroelectronics sales office.

  • Page 2: Quick Start

    Quick start Quick start The EV-VNH90xxAQ evaluation board simplifies the integration of ST VIPower M0-9 DC motor drivers into your prototype circuitry. This preassembled board includes the VNH90xxAQ, and the essential electrical components as recommended in the device datasheet. This setup allows for direct connections to the load, power supply, and microcontroller, eliminating the need for additional external component design and connections.

  • Page 3: Hardware, Schematic

    UM3447 Hardware, schematic Hardware, schematic Figure 2. VNH90xxAQ evaluation board schematic Extension Connectors Board Identification VBAT Device identification VBAT ASD Connector ASD Connector VDD_uC VDD_uC 0R NM 22K NM ID_ADC 0R NM 1K NM 11 12 11 12 R101K NM VBAT_ADC PH_OUT 13 14...

  • Page 4: Vnh90Xxaq Product Family

    UM3447 Hardware, schematic VNH90xxAQ product Family 2.1.1 Features per leg Type DS(on). VNH9030AQ 30 mΩ 35 A VNH9045AQ 45 mΩ 23 A VNH9090AQ 82 mΩ 15 A • AEC-Q100 qualified • ISO 26262 ready • CMOS compatible inputs • Undervoltage shutdown •...

  • Page 5: Description

    VNH90xxAQ is a full bridge motor driver intended for a wide range of automotive applications. The device incorporates a dual monolithic high-side driver and two low-side switches. Both switches are designed using ST proprietary VIPower M09 technology that allows it to integrate efficiently on the same die a true power MOSFET with an intelligent signal/protection circuitry.

  • Page 6: Fw Download

    UM3447 Hardware, schematic FW Download EV-SPC582B board configuration 1. Put jumper on JP3 and JP4 on the right side (5 V) 2. Connect USB cable for board communication and programming. Figure 4. EV-SPC582B UM3447 - Rev 1 page 6/22...

  • Page 7: Ude Driver Installation

    UM3447 Hardware, schematic 2.3.1 UDE driver installation Download tool: Go to https://www.pls-mc.com/service/downloads/download-spc5-udestk/ Figure 5. Download tool shema Click, download, and install the UDE tool SPC5-UDESTK 2021.05 64-bit version 2.3.2 Driver installation check If driver installation is finished, connect the USB cable to the EV-SPC582B and open the device manager in Windows OS: Figure 6.

  • Page 8: Programming Ev-Spc582B (New Workspace Creation)

    UM3447 Hardware, schematic 2.3.3 Programming EV-SPC582B (new workspace creation) 1. Plug USB cable to SPC582B 2. Execute UDE STK tool 3. Create a new workspace: go to File/New workspace 4. Configure the workspace: Click on default Figure 7. New workspace creation 5.

  • Page 9: New Workspace Creation

    UM3447 Hardware, schematic 2.3.4 New workspace creation 1. Configure the workspace: • Additional filter: Discovery kits • Select STMicroelectronics chorus 1M SPC58 discovery starter kit 2. Click OK to finish Figure 9. New workspace creation UM3447 - Rev 1 page 9/22...

  • Page 10: Check Connection

    UM3447 Hardware, schematic 2.3.5 Check connection If the workspace was correctly created and the USB channel recognized, a success message in the messages box should appear. Figure 10. Check connection UM3447 - Rev 1 page 10/22...

  • Page 11: Load .Elf File

    UM3447 Hardware, schematic 2.3.6 Load .elf file 1. Click on File/Load program 2. Browse and select the .elf file to be loaded Figure x: Elf file Figure 11. Load .Elf 3. Click OK Figure 12. Click OK 2.3.7 Program .elf file 1.

  • Page 12: Check The Programming Result

    UM3447 Hardware, schematic 2.3.8 Check the programming result 1. If the board was programmed correctly a success message appears 2. Press exit and save workspace changes for the future use Figure 14. Check System connections To ensure a successful launch of the GUI, please verify the following connections: 1.

  • Page 13: Run Gui (Graphical User Interface)

    UM3447 Hardware, schematic RUN GUI (graphical user interface) For detailed information, please refer to STSW-EV-VNH9xxx (available on www.st.com). Figure 15. Clockwise 2.5.1 Check connection After checking the connection and the power supply is ON check on the status bar below: Figure 16.

  • Page 14: Main Control And Settings

    UM3447 Hardware, schematic 2.5.2 MAIN control and settings This section of the GUI enables users to manage various aspects of motor operation. Users can control the direction of load rotation by toggling between "forward" and "reverse," which adjusts the motor's rotational direction (clockwise or counterclockwise).

  • Page 15: Figure 18. Brake To Gnd

    UM3447 Hardware, schematic Brake to GND Figure 18. Brake to GND Inputs configuration: • INA = INB = L • PWM = H Note: Setting the pin SEL1 = 1 and SEL0 = 0 (SEL1 = 1 and SEL0 = 1) it is possible to keep one leg in HiZ for half bridge configuration and diagnostic.

  • Page 16: Figure 19. Brake To Vcc

    UM3447 Hardware, schematic Brake to VCC Figure 19. Brake to VCC Inputs configuration: • INA = INB = H • PWM = L Note: Setting the pin SEL1 = 1 and SEL0 = 0 (SEL1 = 1 and SEL0 = 1) it is possible to keep one leg in HiZ for half bridge configuration and diagnostic.

  • Page 17: Figure 20. Clockwise

    UM3447 Hardware, schematic Clockwise Figure 20. Clockwise Inputs configuration • INA = H • INB = L • PWM switching Note: Correctly setting selectors it is possible to monitor current flowing through HSA. UM3447 - Rev 1 page 17/22...

  • Page 18: Figure 21. Counterclockwise

    UM3447 Hardware, schematic Counterclockwise Figure 21. Counterclockwise Inputs configuration • INA = L • INB = H • PWM switching UM3447 - Rev 1 page 18/22...

  • Page 19: Revision History

    UM3447 Revision history Table 1. Document revision history Date Revision Changes 17-Dec-2024 Initial release. UM3447 - Rev 1 page 19/22...

  • Page 20: Table Of Contents

    UM3447 Contents Contents Quick start ............... .2 Getting started .
  • Page 21 UM3447 List of figures List of figures Figure 1. EV-VNH90xxAQ board ............. . 2 Figure 2.
  • Page 22 ST’s terms and conditions of sale in place at the time of order acknowledgment. Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or the design of purchasers’...
