Installation Manual

(Translation of original

instructions)

N420494B - Rev. 03 - 01/2024

Filomuro Slim

Fit XL

SW XL 800

Table of Contents

Need help?

Do you have a question about the Filomuro Slim Fit XL and is the answer not in the manual?

Questions and answers

Summary of Contents for Innova Filomuro Slim Fit XL

Page 1 Installation Manual (Translation of original instructions) N420494B - Rev. 03 - 01/2024 Filomuro Slim Fit XL SW XL 800...
Page 2 By following the suggestions contained in this manual, the product you have purchased will operate without problems giving you optimum room temperatures with minimum energy costs. INNOVA S.r.l. Conformity This unit complies with the European directives: •...
Page 3: Table Of Contents
TABLE OF CONTENTS Coding p. 7 1.1 Product related coding .
Page 4 4.11.1 Preliminary warnings ........p. 19 4.11.2 Device preparation .
Page 5 M7 series control Code EGB749 p. 39 7.1 Interface .
Page 6 10 0-10 V connection p. 60 10.1 Connection diagram .
Page 7: Coding P
This instruction manual refers to the following product Check the correspondence with the technical rat- ing plate on the product. See chapter "Identifica- codes. tion" p. 11. Filomuro Slim Fit XL For connection with M7 series Bluetooth remote Right-handed fittings FAWB08DC1II0B00 SW XL 800...
Page 8: General Information P
gEnERAL InfoRMATIon GENERAL INFORMATION 21 About the manual I nthefigures This manual was written to provide all the explanations for the correct management of the appliance. 1 The numbers indicate the individual components. A The capital letters indicate component assemblies. This instruction manual forms an integral part of the The white numbers in black marks indicate a se- device and therefore must be carefully preserved and...
Page 9: General Warnings
gEnERAL InfoRMATIon Configuration accessories It contains specific warnings and all the information nec- essary for positioning, mounting and connecting the ap- It is addressed to the installer and the Technical Assistance pliance. Centre. It contains specific warnings and all detailed information Commissioning, maintenance and troubleshooting on configuration accessories.
Page 10: Disposal
gEnERAL InfoRMATIon 24 Disposal The symbol on the product or its packaging indicates that the product must not be treated as normal household waste, but must be taken to the appropriate collection point for the recycling of electrical and electronic equip- ment.
Page 11: Product Presentation P
33 Description of the appliance filomuro Slim fit XL fancoils range are designed for wall mounting. The units are produced only in size 800, suitable for instal- lation on two-pipe systems.
Page 12: Components
PRoDUCT PRESEnTATIon 34 Components Air intake filter Air outlet deflector Electrical box ø 14 mm condensate drain Aesthetic sides Condensation drain tray Heat exchanger on-unit control panel predisposition (only available for some Cosmetic front panel versions) 35 Compatible accessories The accessories table refers to all products in the filo- muro Slim fit range.
Page 13 PRoDUCT PRESEnTATIon Accessory description Combinable products Code Wall-mounted control panels M7 series Control panels LED electronic control panel with touch interface, wall-mounted comple- te with thermostat and room temperature and relative humidity probe. EEB749II Cable connection. Colour white LED electronic control panel with touch interface, wall-mounted comple- te with thermostat and room temperature and relative humidity probe EFB749II with integrated WiFi module, InnovAPP.
Page 14 PRoDUCT PRESEnTATIon Accessory description Combinable products Code Filomuro Slim Fit XL I20205II (2) 2 way valve group with manual closure Filomuro Slim Fit I20686II (2) 2 way valve group (water inlet valve, shut off valve and electro thermal Filomuro Slim Fit XL...
Page 15: Installation P
InSTALLATIon INSTALLATION 41 Preliminary warnings This section is dedicated to the Installer. The fea- During the installation, it is necessary to observe the tures of the installer are described in the "Recipi- precautions mentioned in this manual, and on the la- ents"...
Page 16 InSTALLATIon Models m.u. Dimensions and weight for shopping 1420 Width Height Total depth 25,0 Weight 44 Handling with packaging In manual operation it is compulsory to respect always 441 Preliminary warnings the maximum weight per person provided for by the The appliance must be handled only by qualified per- national laws and standards.
Page 17 • the installation site of the unit must be chosen with force. the utmost care to guarantee adequate protection The Filomuro Slim Fit XL fancoil has to be installed from shocks and consequent damage only in high position on the wall, with a maximum •...
Page 18 InSTALLATIon The unit should not be installed in a position where the Provide the following: air flow is aimed directly at the people nearby. • a nearby drain for the outflow of condensate • a compliant power supply nearby • fixing elements suitable for the type of support 49 Installation mode The assembly steps described below and their drawings failure to do so may cause system malfunctions and refer to a version of the machine with connections on the automatically voids the warranty, and relieves the con- right side.
Page 19: Remove The Side Panels
InSTALLATIon 411 Positioning The filomuro Slim fit XL fancoil has to be installed only in Aesthetic front panel high position on the wall, with a maximum height of 2,2 m (except for use in cooling only). The units are supplied with a paper template for marking the holes necessary for installation.
Page 20: Connections
InSTALLATIon 4113 Installation arrangement Plugs Brackets To install the appliance, use a recessed box to contain the connections. If the appliance is installed later, leave the connecting pipes plentiful so as not to make joints. Built-in cistern Connecting water pipelines Condensation drainage pipe –...
Page 21 The water flow rate to the heat exchanger must always be constant. 4122 Position and dimensions Filomuro Slim Fit XL Models m.u. Pipeline diameter for dimensional information, refer to chapter "Techni- cal information" p. 67.
Page 22 InSTALLATIon 4124 S hut-offvalves 4123 Connection to the system Normally, unit comes without any shut-off valve. To make the connections: – hydraulic lines positioning In other case, depending of the request, the unit can be – use the "wrench against wrench" method supplied with valves already assembled or supplied sepa- –...
Page 23 InSTALLATIon If using a jug for collecting the condensation: Drainage tube Connecting stub Avoid the hermetic closure of the container. Prevent the end of the drainage tube from falling below the water level. If draining into the sewage system: Make a siphon to prevent bad smells returning up the pipe towards the room.
Page 24 InSTALLATIon Thermostatic head Valve body red plastic tool 415 Electric connections The device leaves the factory fully wired up and needs only • the power supply voltage and system frequency the connection to the power supply, to any controls and match to the values indicated on the device's plate accessories.
Page 25 InSTALLATIon 4153 Access to the terminal block To connect the power supply: fixing screws Cover of the electrical box Terminal block for wiring Before doing any work, make sure that the supply pow- Remote control for Bluetooth wall control M7 series er is disconnect.
Page 26 TOuChPAD AND rEMOTE CONTrOl CODE ECA789 TOUCHPAD AND REMOTE CONTROL CODE ECA789 51 Interface The touchpad control is supplied as standard on board the unit and does not require any connections. Display area Keys area...
Page 27 TOuChPAD AND rEMOTE CONTrOl CODE ECA789 52 Printed circuit board ECA789 The PCB is included in the supply. fan motor DC Inverter with 1 minute delay when the fancoil is in heating mode and is Earth connection on call (potential-free contact max. 1 A). 230 V/50 Hz electrical power supply connection Presence contact (normally open) Water electrovalve (voltage output 230 V / 50 Hz / 1 A) Step Motor...
Page 28 TOuChPAD AND rEMOTE CONTrOl CODE ECA789 53 Connections when closing the CP contact, connected to a po- Presence contact CP – tential-free contact, the device switches to stand- Trough this contact it is possible connect an external device by mode that inhibits the operation of the device, for example: CP appears on the display.
Page 29: Menu Items
TOuChPAD AND rEMOTE CONTrOl CODE ECA789 to confirm and log in press – This takes you to the settings menu. To navigate in the menu use the icons – To select a menu item and to confirm the changes made press for 2 seconds – Confirming the change takes you to the next item. To exit the menu press for about 10 seconds...
Page 30 M7 SErIES CONTrOl CODE EEB749 M7 SERIES CONTROL CODE EEB749 61 Interface Display area Keys area 62 Installation 621 Description the wall-mounted remote control is an electronic LED ther- mostat with a touch interface, with the possibility of control over multiple appliances equipped with the same electron- ic board.
Page 31 M7 SErIES CONTrOl CODE EEB749 – Close the control panel Base of control Wall-mounted control panel Pay attention not to crush the conductors when you close the control. Before wall installation: – separate the control base from the control panel fixing screws Base of control holes for fixing to electrical box Electric box 503 For wall mounting of the control panel:...
Page 32: Single Connection Diagram
M7 SErIES CONTrOl CODE EEB749 63 Single connection diagram fan motor DC Inverter with 1 minute delay when the fancoil is in heating mode and is Step Motor on call (potential-free contact max. 1 A). Earth connection +BA- Serial connection for wall-mounted remote control (respect Power supply connection 230 V / 50 Hz / 1 A polarisation AB) Water electrovalve (voltage output 230 V / 50 Hz / 1 A)
Page 33: Multiple Connection Diagram
M7 SErIES CONTrOl CODE EEB749 64 Multiple connection diagram M7 series wall control panel Terminal block for device connection Board for pairing control and device...
Page 34 M7 SErIES CONTrOl CODE EEB749 65 Connections Terminal block position: 651 Preliminary warnings Terminal block ( Back view panel) The terminals for connecting the control panel and the presence contact CP are placed in a plastic bag and po- sitioned inside the cover of the electrical box. Terminal blocks Terminal blocks The terminals accept:...
Page 35: Rs485 Serial Connection
M7 SErIES CONTrOl CODE EEB749 The CP presence contact can be configured for heating and – connect respecting the indication A and B cooling operation via the "To select digital input" settings Use a bipolar shielded cable suitable for the RS485 se- menu item (digital input). rial connection with a minimum section of 0,35 mm². 654 RS485 Serial Connection Keeping the bipolar cable separate from power supply cables.
Page 36 M7 SErIES CONTrOl CODE EEB749 The volume changes after confirm the modification. Adjusting the volume To change the volume select – press to change settings – increase or decrease the value with the icons – to confirm press – The volume setting range is from 00 (min) to 03 (max). 662 Advanced Menu To access the Setup menu, it is necessary to access Ac: not used the Basic menu.
Page 37: Reset Pairing
M7 SErIES CONTrOl CODE EEB749 To reset all fancoils Red LED green LED Appears Black button Electrical box press until appears – Appears press to access the menu – use the icons to move inside the menu – select no to maintain all fancoils –...
Page 38 M7 SErIES CONTrOl CODE EEB749 LED on – Wall control on and no alarm present. lED continuous flashing with pause between – flashes Unsuitable water temperature alarm. lED 1 flash / pause – Fan stop alarm for unsuitable water temperature probe H2/T2. lED 2 flashes / pause – Internal fan motor alarm faulty or disconnected. lED 3 flashes / pause –...
Page 39 M7 SErIES CONTrOl CODE EGB749 M7 SERIES CONTROL CODE EGB749 71 Interface Display area Keys area 72 Installation 721 Description the wall-mounted remote control is an electronic LED ther- mostat with a touch interface, with the possibility of control over multiple appliances equipped with the same electron- ic board.
Page 40 M7 SErIES CONTrOl CODE EGB749 The wall control is provided inside the package already Electric box 503 Base of control assembled. Wall-mounted control panel Base of control Wall-mounted control panel – Close the control panel Pay attention not to crush the conductors when you Before wall installation: close the control.
Page 41 M7 SErIES CONTrOl CODE EGB749 73 Single connection diagram fan motor DC Inverter with 1 minute delay when the fancoil is in heating mode and is Step Motor on call (potential-free contact max. 1 A). Earth connection Potential-free input 1(not active) Power supply connection 230 V / 50 Hz / 1 A H2/T2 2-pipe water temperature probe Water electrovalve (voltage output 230 V / 50 Hz / 1 A) Presence contact (normally open)
Page 42 M7 SErIES CONTrOl CODE EGB749 74 Multiple connection diagram M7 series wall control panel Terminal block for device connection Board for pairing control and device 12 V-DC 1A...
Page 43 M7 SErIES CONTrOl CODE EGB749 75 Connections Terminal block position: 751 Preliminary warnings Terminal block ( Back view panel) The terminals for connecting the control panel and the presence contact CP are placed in a plastic bag and po- sitioned inside the cover of the electrical box. Terminal blocks Terminal blocks The terminals accept:...
Page 44 M7 SErIES CONTrOl CODE EGB749 754 Bluetooth connection The devices must be equipped with an electronic board suitable for remote control. The wall-mounted remote control can be connected via Bluetooth to one or more devices, for a maximum of 16. 76 Functions 761 Basic menu Scale To access the basic menu To change the temperature unit of measure...
Page 45 M7 SErIES CONTrOl CODE EGB749 To access the setup menu To change the settings, please refer to the Instruction Sheet of the accessory MZS - Single zone module for from the basic menu press – radiant system, code Eg1028II. Appears press the key once –...
Page 46 M7 SErIES CONTrOl CODE EGB749 press – To reset a single fancoil Appears press – Appears press to access the menu – use the icons to move inside the menu – The assignment numbers assigned to the fancoils appear. select the fancoil to be reset –...
Page 47 M7 SErIES CONTrOl CODE EGB749 Water temperature probe H2/T2 dis- – connected or failure None of the modes can be activated. fancoil block for unsuitable water – None of the modes can be activated. Module Communication Alarm – Bluetooth communication not functioning. Communication error –...
Page 48 rEMOTE CONTrOl EEA649 - EEB649 / EFA649 - EFB649 REMOTE CONTROL EEA649 - EEB649 / EFA649 - EFB649 81 Interface Display area Keys area 82 Installation 821 Description 822 Mounting The wall-mounted control panel is a thermostat with possi- bility of control on several device equipped with electronic control for remotization.
Page 49 rEMOTE CONTrOl EEA649 - EEB649 / EFA649 - EFB649 • away from doors or windows • away from heat sources (heaters, convectors, stoves, direct sunlight) The wall-mounted remote control is provided inside the package already assembled. notches Before wall installation: – Unhook the protruding notches on the back side of the control.
Page 50 rEMOTE CONTrOl EEA649 - EEB649 / EFA649 - EFB649 83 Single connection diagram The PCB is included in the supply. fan motor DC Inverter BO/C2 Heating request contact (for example boiler or heat pump). Step Motor Activated in parallel with the output of the solenoid valve (Y1) -BA+ Serial connection for wall-mounted remote control with 1 minute delay when the fancoil is in heating mode and is Earth connection...
Page 51 rEMOTE CONTrOl EEA649 - EEB649 / EFA649 - EFB649 84 Multiple connection diagram Control panel for wall control The terminal block for CP presence contact connection Terminal block for device connection 85 Connections 851 Preliminary warnings The terminals for connecting the control panel and the presence contact CP are placed in a plastic bag and po- sitioned inside the cover of the electrical box.
Page 52: Functions
rEMOTE CONTrOl EEA649 - EEB649 / EFA649 - EFB649 To connect the wall control panel to the board: Terminal blocks – connect the power supply cables to the + - terminals – connect the ModBus serial connection cables to ter- minals A and B 853 Presence contact CP Trough this contact it is possible connect an external device that inhibits the operation of the device, for example: •...
Page 53: Adjusting Buzzer Volume
rEMOTE CONTrOl EEA649 - EEB649 / EFA649 - EFB649 • changes the logic of night-time operation in heating Dip-switch B Dip-switch C mode • in the on position, ventilation is inhibited, allowing the appliance to heat rooms by radiation and natural convection as in traditional radiators • in off position the fan operates normally 86 Functions rb: Reset Modbus 861 Advanced Menu...
Page 54: Long Period Shut-Down
rEMOTE CONTrOl EEA649 - EEB649 / EFA649 - EFB649 Adjust the brightness of the display LED on – Normal operating of the device lED 1 flash / pause To adjust the brightness of the display – select Water request detected by temperature probe H2/ – T2 not fulfilled (above 20 °C in cooling and below increase or decrease the value with the icons –...
Page 55: Fixed Speed Remote Controls Code B3V151 P
FIxED SPEED rEMOTE CONTrOlS CODE B3V151 FIXED SPEED REMOTE CONTROLS CODE B3V151 91 Interface 92 Description Wall mounted control with thermostat, summer/winter and speed selectors.
Page 56: Connection Diagram
FIxED SPEED rEMOTE CONTrOlS CODE B3V151 93 Connection diagram Board B3V151 Wall control SW GRL DATA I/O N276660C MOTOR F1AT N EV1 N EV2...
Page 57: Connection Diagram With Seasonal Switching
FIxED SPEED rEMOTE CONTrOlS CODE B3V151 94 Connection diagram with seasonal switching 230 V / 50 Hz power supply Mobile aspiration panel control (230 V / 50 Hz / 1 A voltage Consent input output) Maximum fan speed (1400 rpm) RS version wiring HRS rS water probe (10 kΩ) Medium fan speed (1100 rpm) Minimum fan speed (680 rpm) fan motor DC Inverter...
Page 58: Generic Thermostat Connection Diagram
FIxED SPEED rEMOTE CONTrOlS CODE B3V151 95 Generic thermostat connection diagram The PCB is included in the supply. 230 V/50 Hz electrical power supply fan motor DC Inverter Step motor (diffuser) Solenoid valve permission input Maximum fan speed 1.400 rpm 3 speed room thermostat (to buy, install and connect by the Medium fan speed 1.100 rpm installer) Minimum fan speed 680 rpm...
Page 59: Connection With 3 Speed Thermostats
FIxED SPEED rEMOTE CONTrOlS CODE B3V151 96 Connections 961 Connection with 3 speed 962 Water probe management Through the water temperature probe (10 kΩ) positioned thermostats in the compartment on the unit's coil, the functions can be regulated: CV input • minimum temperature in heating mode (30 °C) The CV input is the ON/OFF of the board. •...
Page 60: Connections
0-10 V CONNECTION 0-10 V CONNECTION 101 Connection diagram The PCB is included in the supply. fan motor DC Inverter Water electrovalve (voltage output 230 V / 50 Hz / 1 A) Step Motor Input 0-10 V Earth connection Electronic board on the machine Power supply connection 230 V / 50 Hz / 1 A Electrical board for step motor connection Impedenza d’ingresso 25 kΩ...
Page 61 0-10 V CONNECTION 102 Connections The 10 V input activates the Y1 electrovalve and regulates the fan speed. The speed range provides a linear adjustment from the minimum value (400 rmp) to the maximum value (1500 MAX rpm rmp) for voltage values ≥ 1,1 V ÷ 10 V DC. The solenoid valve Y1: •...
Page 62: Routine Maintenance
MAInTEnAnCE MAINTENANCE Routine maintenance is essential to keep the device always efficient, safe and reliable over time. 111 Preliminary warnings This section is dedicated to the Technical Service Warnings: Assistance. The features of the Technical Ser- • Do not lean or sit on the fancoil to avoid damaging vice Assistance are described in chapter "Recipi- the appliance.
Page 63: Air Intake Filter Cleaning
MAInTEnAnCE 114 A irintakefiltercleaning Cleaning the filter must be carried out: – rotate until the complete exit from the housing – remove the filter • after prolonged operation, considered the concentra- tion of impurities in the air To clean the filters: •...
Page 64: Troubleshooting Table
TRoUBLESHooTIng TROUBLESHOOTING 121 Preliminary warnings For detailed information on accessories please re- Follow the instructions below: fer to the "Configuration accessories" p. 65 sec- – disconnect the device from power supply immediate- tion. – close the water taps Should you encounter any of the anomalies below: –...
Page 65: Configuration Accessories P
ConfIgURATIon ACCESSoRIES CONFIGURATION ACCESSORIES 131 S hut-offvalves Normally, unit comes without any shut-off valve. The motorized valve can be omitted, inside the unit, if there is a motorized valve in the distribution manifold The 2-way and 3-way motorized valves are mandatory of the system and connected to the regulation card of for the correct operation of the unit.
Page 66: Connection With 2-Way Valve And Thermoelectric Actuator (V20687)
ConfIgURATIon ACCESSoRIES 1312 Connection with 2-way valve and thermoelectric actuator (V20687) V20139II - 2 way valve group (water inlet valve, shut off electrical connection are required • connect to the flow at the bottom valve and electro thermal motor) In case of choice for the 2-way valve and thermoelectric actuator: Water outlet pipe fitting Unit...
Page 67: Technical Information
TECHnICAL InfoRMATIon TECHNICAL INFORMATION 141 Technical data Filomuro Slim Fit Models m.u. Cooling performances (W 7/12 °C; A 27 °C) (1) Total cooling capacity 3,12 Sensible cooling capacity 2,51 Water flow 674,00 Pressure drop 12,00 Maximum sound power level dB(A) Maximum absorbed power Heating performances (W 45/40 °C;...
Page 68 TECHnICAL InfoRMATIon 142 Dimensions Lateral view front view Models m.u. Product dimensions and weight 1215 Width Height Total depth Net weigth 24,0 143 Installation template The units are supplied with a paper template for mark- ing the holes necessary for installation. Minimum distance to the ceiling outlet for installation with 2-way valve Holes for dowels, ø...
Page 69 noTE...
Page 70 noTE...
Page 71 noTE...
