- Page 1 Installation Manual (Translation of original language) N420307A - Rev. 02 - 08/2024 FÄRNA SMALL - BIG...
- Page 2 By following the suggestions contained in this manual, the product you have purchased will provide trouble free operation, giving you optimum room temperatures with minimum energy costs. INNOVA S.r.l. Conformity This unit complies with the European directives: • EMC 2014/30/EU •...
-
Page 3: Table Of Contents
TabLE of ConTEnTS TABLE OF CONTENTS Coding p. 5 4.11.1 Installation position ..p. 16 1.1 Product related coding . - Page 4 TabLE of ConTEnTS Technical information p. 29 8.1 Technical data ....p. 29 8.2 Dimensions ....p. 30 8.3 Installation template .
-
Page 5: Coding P
1. Coding 1. CODING 11 Product related coding This instruction manual refers to the following product codes. Check the correspondence with the technical rating plate on the product. See chapter "identi昀椀cation" p. 9. FÄRNA FARNABSC1II left FARNASSC1II SMALL left... -
Page 6: General Information P
2. generAl informAtion 2. GENERAL INFORMATION 21 About the manual I nthe昀椀gures This manual was written to provide all the explanations for the correct management of the appliance. 1 The numbers indicate the individual components. a The capital letters indicate component assemblies. This instruction manual forms an integral part of the The white numbers in black marks indicate a se- device and therefore must be carefully preserved and... -
Page 7: General Warnings
2. generAl informAtion it contains speci昀椀c warnings and all the information nec- Coding It addresses all recipients. essary for positioning, mounting and connecting the ap- It contains the list of products and/or accessories referred pliance. to in the manual. Commissioning, maintenance and troubleshooting General information They are addressed exclusively to the Technical assistance It addresses all recipients. -
Page 8: Disposal
2. generAl informAtion It is forbidden to modify the safety or adjustment de- It is forbidden to open the access doors of the device's internal parts without 昀椀rst having set main switch of the vices, or adjust without authorisation and indications of the manufacturer. system to "off". It is forbidden to pull, unplug or twist the device's elec- It is forbidden to incorrectly dispose of the packaging, tric cables, even if it is disconnected from the mains. -
Page 9: Product Presentation P
3. ProduCt PreSentAtion 3. PRODUCT PRESENTATION 31 I denti昀椀cation the appliance can be identi昀椀ed by the rating plate: Technical rating plate Technical rating plate tampering with, removal of, or lack of identi昀椀cation plates will not allow for the safe identi昀椀cation of the product by its serial number and therefore invalidates the warranty. -
Page 10: Components
3. ProduCt PreSentAtion 34 Components wall 昀椀xing bracket Cover cabinet filter Grill Electrical panel Liquid drain pipe M7 on-board control (accessory) Heat exchanger... -
Page 11: Compatible Accessories
LED electronic control panel with touch interface, wall-mounted complete with thermostat and room temperature and relative humidity probe with integrated EFB749II WiFi module, App Innova Butler. Cable connection. Colour white LED electronic control panel with touch interface, wall-mounted complete with thermostat and room temperature and relative humidity probe. Bluetooth EGB749II connection. -
Page 12: Installation P
4. inStAllAtion 4. INSTALLATION 41 Preliminary warnings This section is dedicated to the Installer. The fea- During the installation, it is necessary to observe the tures of the installer are described in the "Recipi- precautions mentioned in this manual, and on the la- ents"... -
Page 13: Handling With Packaging
4. inStAllAtion Models m.u. SMALL Dimensions and weight for shipping Width Height Total depth Weight 15,0 19,0 44 Handling with packaging In manual operation it is compulsory to always respect 441 Preliminary warnings the maximum weight per person provided for by the the appliance must be handled only by quali昀椀ed per- national laws and standards. -
Page 14: Handling Without Packaging
4. inStAllAtion 462 Remove the package Protective elements ► remove protective elements Remove the packing: ► open the cardboard packaging ► extract the supplied material ► remove the metal brackets ► remove the appliance from the box Accompanying material Inside the packaging are: Check the presence of the individual components. -
Page 15: Installation Mode
4. inStAllAtion The unit should not be installed in a position where the Provide the following: air 昀氀ow is aimed directly at the people nearby. • a nearby drain for the out昀氀ow of condensate • a compliant power supply nearby • 昀椀xing elements suitable for the type of support 49 Installation mode for ideal installation and performance levels, carefully failure to do so may cause system malfunctions and follow the instructions in the manual. -
Page 16: Installation Position
4. inStAllAtion 4111 Installation position Upper grille 4112 Preliminary warnings Ensure that: • the wall supports the weight of the appliance • the section of 昀氀oor or wall does not contain piping or electrical lines • the functionality of load-bearing elements is not com- promised 4113 Device preparation before proceeding with the installation, it is necessary to remove some elements from the appliance. -
Page 17: Installation Arrangement
4. inStAllAtion Make sure that the wall is not crossed by pipelines, Cover cabinet load-bearing construction elements or power lines. Plugs fixing brackets ► lift the cover cabinet ► Disconnect the on-board display connector (if pres- ent) ► remove the cover cabinet ►... -
Page 18: Hydraulic Connections
4. inStAllAtion ► Attach the unit to the 昀椀xing brackets fixing brackets ► check right attachment to the 昀椀xing brackets Unit fixing screws ► Secure the unit with the 昀椀xing screws 412 Hydraulic connections The engineer is responsible for choosing the right water The hydraulic pipes connecting to the appliance must be suitably sized for the actual water 昀氀ow required by lines and their size, in accordance with good installation practices and the applicable law. -
Page 19: System Connection
4. inStAllAtion for dimensional information, refer to chapter "Techni- Carefully check that the insulation is tight, in order to cal information" p. 29. prevent the making and dripping of condensate. 4124 S hut-o昀昀valves 4123 System connection As standard, the unit is supplied without shut-o昀昀 valves To make the connections: ►... -
Page 20: Filling The System
4. inStAllAtion Install a pump if the drain pipe is higher than lower level 4133 Check of the collection pan. Make sure that: • the unit is installed perfectly level, or with a slight for vertical installations, the pump must be installed slope in the direction of condensate drainage under the side drain pan. -
Page 21: Electric Connections
4. inStAllAtion Thermostatic head Valve body red plastic tool 415 Electric connections The device leaves the factory fully wired and needs only the • the cables must be appropriate for the type of instal- connection to the power supply, to any controls and acces- lation in accordance with the applicable IEC standards sories. -
Page 22: Access To The Terminal Block
4. inStAllAtion 4153 Access to the terminal block fixing screws Cover of the electrical box before carrying out any works, please ensure the power Connection supply is disconnected. Terminal block for wiring access to the electrical panel is only permitted to qual- Power supply cables i昀椀ed personnel. -
Page 23: Connecting The Controls
4. inStAllAtion Cable gland For 昀椀xing cables: ► use the cable glands provided ► 昀椀x the cables 4155 Connecting the controls Refer to the installation manual of the control to make the connection of the control. -
Page 24: Maintenance P
5. mAintenAnCe 5. MAINTENANCE routine maintenance is essential to keep the device e昀케- cient, safe, and reliable over time. 51 Preliminary warnings This section is dedicated to the Authorised Service Warnings: Centre. The features of the Authorised Service Cen- • Do not lean or sit on the fancoil to avoid damaging tre are described in chapter "Recipients"... -
Page 25: Air Intake 昀椀Lter Cleaning
5. mAintenAnCe 522 A irintake昀椀ltercleaning Cleaning the 昀椀lter must be carried out: To reassemble the 昀椀lter: ► proceed in reverse order • after prolonged operation, consider the concentra- tion of impurities in the air Check that the 昀椀lter is 昀椀tted correctly. • when you plan to restart the system after prolonged it is forbidden to use the device without its mesh 昀椀lter. -
Page 26: Preliminary Warnings
6. trouBleShooting 6. TROUBLESHOOTING 61 Preliminary warnings For detailed information on accessories please re- Follow the instructions below: fer to the "Con昀椀guration accessories" p. 27 sec- ► disconnect the device from power supply immediate- tion. ► isolate the water supply Should you encounter any of the anomalies below: ►... -
Page 27: Configuration Accessories P
7. ConfigurAtion ACCeSSorieS 7. CONFIGURATION ACCESSORIES 71 S hut-o昀昀valves As standard, the unit is supplied without shut-o昀昀 valves The motorized valve can be omitted, inside the unit, if there is a motorized valve in the distribution manifold The 2-way and 3-way motorized valves are mandatory of the system and connected to the regulation card of for the correct operation of the unit. -
Page 28: Moelectric Motor
7. ConfigurAtion ACCeSSorieS 712 Connection with 2-way valves with thermoelectric motor 2 way valve group (water inlet valve, shut o昀昀 valve and elec- • electrical connection are required • connect to the 昀氀ow at the bottom tro thermal motor) In case of choice for the 2-way valve and thermoelectric motor: 713 Connection with 3-way diverter valves with thermoelectric motor 3-way diverter valve group with thermoelectric motor •... - Page 29 8. teChniCAl informAtion 8. TECHNICAL INFORMATION 81 Technical data FÄRNA Models m.u. SMALL Cooling performances (W 7/12 °C; A 27 °C) (1) Total cooling capacity 1,50 2,80 Sensible cooling capacity 1,26 2,32 Water 昀氀ow 253,00 473,00 Pressure drop 9,00 17,00 Maximum absorbed power Maximum sound power level dB(A) Heating performances (W 45/40 °C;...
- Page 30 8. teChniCAl informAtion 82 Dimensions front view Lateral view FÄRNA Models m.u. SMALL Product dimensions and weight Width Height Total depth Net weight 13,1 17,3 83 Installation template The units are supplied with a paper template for mark- ing the holes necessary for installation.
- Page 31 650,00 LATO SINISTRO LATO DESTRO LEFT SIDE RIGHT SIDE FARNA SMALL 832 Installation Template FÄRNA BIG INSTALLATION TEMPLATE FÄRNA BIG Condensate drain outlet with 3-way valve (with 90 elbow) ø8 holes for wall 昀椀xing dowels outlet with 2-way valve (with 90 elbow) ø8 holes for wall bracket 昀椀xing dowels...
- Page 32 InnoVa S.r.l. Via I Maggio 8 - 38089 Storo (Tn) - ITaLY tel. +39.0465.670104 – fax +39.0465.674965 info@innovaenergie.com...
