Heatstore HSDPD Installation And Operating Instructions

MODEL
HSDPD500WIFI
HSDPD750WIFI
HSDPD1000WIFI
HSDPD1500WIFI
HSDPD2000WIFI
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
IMPORTANT SAFETY ADVICE
When using electrical
precautions should
reduce the risk of fire, electrical shock, and
injury to persons, including the following:
IMPORTANT: The wall bracket supplied with
the appliance must be used.
WARNING: Do not use this heater in the immediate
surroundings of a bath, a shower or a swimming pool.
IMPORTANT: If the heater is installed in a room
containing a bath or shower, it must be installed
so that switches and other controls cannot be
touched by a person using a bath or shower.
WARNING: In order to avoid overheating, do
not cover the heater. Do not place material
or garments on the heater, or obstruct the
air circulation around the heater, for instance
by curtains or furniture, as this could cause
overheating and a fire risk.
NEVER cover or obstruct in any way the heat
outlet slots at the top of the heater or the air
inlet slots in the base of the heater.
This heater carries the warning symbol indicating
that it must not be co vered.
CAUTION: Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
This appliance can be used by children aged
from 8 years and above and by persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved.
Cleaning and user maintenance shall not be carried
out by children without supervision.
Dimensions
A (mm) B (mm)
527 164
627 164
727 214
1027 214
1127 264
appliances,
always be followed
Installation and Operating Instructions
Fig. 1
C (mm)
200
300
300
600
600
Children of less than 3 years should be kept away unless
continuously supervised.
basic
Children aged from 3 years and less than 8 years
to
shall only switch on/off the appliance provided
that it has been placed or installed in its intended
normal operating position and they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Children aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance or perform
user maintenance.
Note that due care and consideration must be taken
when using this heater in series with a thermal control,
a program controller, a timer or any other device that
switches on the heat automatically, since a fire risk
exists when the heater is accidentally covered or
displaced.
If the supply cord is damaged it must be replaced
by the manufacturer or service agent or a similarly
qualified person in order to avoid a hazard.
WARNING: Servicing and product repairs should only
be undertaken by the manufacturer's approved service
agent or a similarly qualified person, using only exact
manufacturer approved spare parts.
IMPORTANT: The supply circuit to the heater must
incorporate a double pole isolating switch having a
contact separation of at least 3mm.
WARNING: Packaging should be disposed of responsibly
as the EPS used could be a potential choking hazard
for children.
WARNING: Do not locate the heater immediately below
a fixed socket outlet or connection box
WARNING: This appliance must be earthed.
HSDPD WIFI Panel Heater
300004732
A
B C B
50mm (min)
(IP24)
ISSUE:4 Series: A
400
200
75
