Saxby Lighting Nocula CCT Instruction Manual

Wiring
Having correctly identified the wiring from your existing light fitting, Pull the mains wire through the hole and connect to the
quick connection terminal in the following way.
SUPPLY
INSERT CABLE
LIVE (Brown or Red)
EARTH (Green & Yellow)
NEUTRAL (Blue or Black)
Check that...
You have correctly identified the wires. The connections are tight. No loose strands have been left out of the connection block.
Technical data
Supply
220-240 V~, 50 Hz
Voltage:
Bulb
2 x 5W LED module (COB) CCT, 3000/4000/6500K This product contains a light source of energy efficiency class F.
Type:
Non-replaceable light source
Conformity with all relevant UKCA
Directive requirements.
This product is Class 1, must be connected to earth.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is not suitable for dimming.
This product is rated at IP54.
54
IP
This product is rated at IK06.
06
IK
Care and Safety
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before cleaning.
This bulb is protected by a glass shade. This part must be replaced immediately should the glass
shade become cracked or damaged. This fitting must not be used without the glass shade in place.
Replace Cracked Glass
For further information, please visit https://www.lighting-info.co.uk/114574
V1 01/08/2024
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
Push Down
LIGHT FITTING
Non-replaceable control gear
Conformity with all relevant EC
Directive requirements.
Instruction manual
Nocula CCT
114574
LIVE
EARTH
NEUTRAL
www.saxbylighting.com
