Alemlube AdBlue EL Series Owner's Manual

Automatic metered shut-off nozzle
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
AdBlue
DESCRIPTION
The Alemlube AB80070 AdBlue
metering that will automaticallty shut off when a tank is full. The AB80070 is suitable for dispensing AdBlue® up to
50L/min.
PRODUCT SPECIFICATIONS
Automatically shuts off on back pressure
3/4" fitting connection
Digital meter with 5-digit current dispensed total
Cumulative total up to 999999.9
Resettable digital meter
Flow rates up to 50L/min.
Digital meter powered by 2 x AA batteries
Digital display accurate up to ±5%
Lightweight at only 0.65kg
Adjustable coefficient LCD display
Push button options to reset data
Switching between total and shift accumulation totals
Auto-Sleep mode activated to turn off the display
Operating temperature range -20ºC to +40ºC
Operating pressure of 22psi to 36psi
Efficient and accurate filling of AdBlue
NSW/ACT (02) 9677 1555
WA (08) 9302 4199
OWNER'S MANUAL
Automatic Metered Shut-Off Nozzle
®
Automatic Shut-off Nozzle with Digital Meter is uniquely designed with built-in digital
®
®
QLD/PNG (07) 3491 2600
SA/NT (08) 8241 7111
VIC/TAS (03) 8787 8288
NZ (09) 447 1007
AB80070
October 2024
www.alemlube.com.au
www.alemlube.co.nz
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the AdBlue EL Series and is the answer not in the manual?

Questions and answers

Related Manuals for Alemlube AdBlue EL Series

Summary of Contents for Alemlube AdBlue EL Series

  • Page 1 ® October 2024 DESCRIPTION The Alemlube AB80070 AdBlue Automatic Shut-off Nozzle with Digital Meter is uniquely designed with built-in digital ® metering that will automaticallty shut off when a tank is full. The AB80070 is suitable for dispensing AdBlue® up to 50L/min.

  • Page 2: Performance Characteristics

    3. Performance characteristics 3.1 Light weight and easy disassembly. NSW/ACT (02) 9677 1555 QLD/PNG (07) 3491 2600 VIC/TAS (03) 8787 8288 www.alemlube.com.au www.alemlube.co.nz WA (08) 9302 4199 SA/NT (08) 8241 7111 NZ (09) 447 1007 Barrels are interchangeable (original large port. Additional small port).
  • Page 3 4.7 Battery installation (see Figures a b c d). NSW/ACT (02) 9677 1555 QLD/PNG (07) 3491 2600 VIC/TAS (03) 8787 8288 www.alemlube.com.au www.alemlube.co.nz WA (08) 9302 4199 SA/NT (08) 8241 7111 NZ (09) 447 1007...

  • Page 4: Installation And Commissioning

    NSW/ACT (02) 9677 1555 QLD/PNG (07) 3491 2600 VIC/TAS (03) 8787 8288 www.alemlube.com.au Connection of the first tube into the inlet connector, in the connector and the tube www.alemlube.co.nz WA (08) 9302 4199 SA/NT (08) 8241 7111 NZ (09) 447 1007 overlap parts of the hose clamp and you force locking clamp;...
  • Page 5 Oil, and vice versa NSW/ACT (02) 9677 1555 QLD/PNG (07) 3491 2600 VIC/TAS (03) 8787 8288 www.alemlube.com.au coefficient decreases will be less apparent number, more oil. www.alemlube.co.nz WA (08) 9302 4199...
  • Page 6 NSW/ACT (02) 9677 1555 QLD/PNG (07) 3491 2600 VIC/TAS (03) 8787 8288 www.alemlube.com.au www.alemlube.co.nz WA (08) 9302 4199 SA/NT (08) 8241 7111 NZ (09) 447 1007...
  • Page 7 NSW/ACT (02) 9677 1555 QLD/PNG (07) 3491 2600 VIC/TAS (03) 8787 8288 www.alemlube.com.au www.alemlube.co.nz WA (08) 9302 4199 SA/NT (08) 8241 7111 NZ (09) 447 1007...
  • Page 8 Note: The faults marked with "*" in the table should be returned to the factory by contacting the dealer if they occurred during the product's effective period of use. NSW/ACT (02) 9677 1555 QLD/PNG (07) 3491 2600 VIC/TAS (03) 8787 8288 www.alemlube.com.au www.alemlube.co.nz WA (08) 9302 4199 SA/NT (08) 8241 7111 NZ (09) 447 1007...
