Revision: 1
GPS Features
Host-based multi-global navigation satellite system:
SBAS Satellite-based augmentation systems:
Built in self-generated orbit prediction (Faster TTFF up to 3days)
Built in jamming removing
GPS Interfaces
Geodetic datum
Protocol
NMEA messages:
GGA
GLL
GSA
GSV
RMC
VTG
GPS Performance Data
Receiver type 33tracking/99 acquisition- channel GNSS receiver
Update rate
Sensitivity
Tracking:
Reacquisition:
Cold starts:
Time-To-First-Fix
Cold starts:
Warm starts:
Hot starts:
GPS Accuracy
Automatic Position
Speed
Operation temperature:
Ultrasound
Distance (max) to transponder T4
Distance (max) to T4 with 360° adapter
Resolution
Accuracy
Transponder T4
Size: Diameter
Weight
Battery
Power consumption
Other
Adapter/Spreader
Monopod/plot staff
Monopod non-magnetic
Case
© 2024, Haglöf Sweden AB
Vertex Laser Geo2 & Laser Geo2
GPS(USA)/GLONASS(Russia)/Galileo(EU)/QZSS(Japan)
WAAS(USA), EGNOS(EU), GAGAN(India), MSAS(Japan)
WGS84
NMEA
Time, position and fix type data.
Lat, long, UTC time of position fix and status.
GNSS receiver operating mode, satellite used, DOP values.
Number of satellites in view ID numbers, elevation, azimuth
and SNR values.
Time, date, position, course and speed data.
Course and speed information relative to the ground.
1Hz
-165 dBm
-160 dBm
-147 dBm
(All SV @ –130 dBm)
28s up to 15min (open sky)
26s (open sky)
<1s (open sky, <2h since last start)
2.5m CEP (circular error probable) (50% 24 hr static, -
130dBm)
-40℃~+85 ℃
0.1m/s (50%@30m/s)*
>30m/100ft
>20m/60ft
0.01m/0.1ft
1% or better when calibrated
70mm / 2.8"
85g/5oz (battery included)
1x 1,5V AA Alkaline
9mW
Plastic, weight app. 30g/1oz
Four sections, 33-140cm, around 270g/9.5oz,
aluminium/plastic. A monopod staff with a foot support and
a 1/4-20 mount.
Two-piece non-magnetic monopod with ¼ 20" threads for
attaching to device
Soft instrument carrying case. Transport case in aluminium.
36
2024-04-30
