- Page 1 Model: 52440, 52441...
-
Page 2: About The Product
INTRODUCTION Thank you for your trust and for choosing the Qoltec combination lock. We are confident that the product will meet your expectations. This manual will guide you through the installation and use of the unit. It contains important safety instructions for operation and correct installation. -
Page 3: Technical Specifications
Parameter Value Type Transmission type RFID Mode of operation PIN code/card/key fob Degree of protection IP68 Doorbell button Yes (for model 52440) Nominal voltage DC 12V Frequency 125kHz Number of relay outputs Load <100mA Max. number of users 1000 Installation... -
Page 4: Installation
NO relay black Negative pole 10-24V DC power input yellow Opening Exit request button blue Bell External bell (for model 52440) grey Bell External bell (for model 52440) Sound and light signalling STATUS SOUND Standby mode Bright red light Entering programme... - Page 5 Unsuccessful operation Three beeps Factory settings Turn off the power, press the exit button, turn on the power, after 5 seconds you will hear one beep, the unit will enter standby mode, the factory reset is complete. Note: Restoring the factory settings will not delete the user information. Modification of the admin code Function Key combination...
- Page 6 Open the lock with the user's PIN (User's PIN) # (Read card) Open the lock with the user card + PIN (User's PIN) # DC power supply for access control Diagram outlined in Figure 4. Note: The electro-locks must be connected to a diode (1N4004), otherwise the device may be damaged.
- Page 7 (repeat 4-8 digit PIN) Exit Red flashes programming mode Attention: 1. When you add a user using a card, their ID will be added automatically and the ID number will be in the range (0-999). 2. When adding users with cards, PIN 1234 is automatically added. This PIN cannot be used to open the lock.
- Page 8 expires, it will be treated as the password of the regular user and will open the lock. 3. The permission to open a lock by a guest can be set from 1 to 9. Each time the lock is opened, the permission to open the lock is reduced once.
- Page 9 Pulse and switching mode setting Function Key combination Enter Lights up red (Admin code) programming mode Pulse mode Lights up red 4 (1-99) Mode switching Lights up red Exit Red flashes programming mode Attention: 1. The factory default setting is pulse mode and the access time is 5 seconds.
- Page 10 Attention: Lock mode: If an unauthorised user swipes the card/PIN 10 times within 1 minute, the device will be locked for 10 minutes. When the device is re- powered, the lock will be cancelled. Tamper alarm setting Function Key combination Enter Lights up red (Admin code)
-
Page 11: User Settings
USER SETTINGS Change of PIN Function Key combination Changing the PIN code (Read card) (Old PIN) (New PIN) assigned to card users (Repeat new PIN) Change independent (ID number) (Old PIN) (New PIN) PIN code (Repeat new PIN) Note: The PIN can be changed to any 4-8 digits, but it cannot be '1234', and the PIN attached to the card is only used in card + PIN access mode. - Page 12 ATTACHMENT...
