- Page 1 Model: 52445...
-
Page 2: About The Product
INTRODUCTION Thank you for your trust and for choosing the Qoltec combination lock. We are confident that the product will meet your expectations. This manual will guide you through the installation and use of the unit. It contains important safety instructions for operation and correct installation. If you have any questions after reading the manual, please contact Customer Service. - Page 3 Coloured LEDs indicating operating status Brief programming instructions Action Comments To enter the programming Administrator code mode 999999 is the default master code Exit programming mode Note: To perform the following actions, the root user must be logged in Change of master code New code New code...
-
Page 4: Technical Specifications
Door unlocking by cardholder Apply the card TECHNICAL SPECIFICATIONS Technical specifications Parameter Value Nominal voltage DC 12 - 24V Number of users 2000 Card reading range 3 - 6 cm Load <60mA Load on the lock relay Max 3A Load on the alarm relay Max 20A Operating temperature -40 - 60... - Page 5 Cable connection Colour Function Description pink BELL_A Doorbell button (first line) light blue BELL_B Doorbell button (second line) green WG output D0 white WG output D1 grey ALARM Alarm - (alarm + connect to 12 V+) yellow OPEN Opening button, first cable (connect second cable to GND) brown D_IN...
- Page 6 Anti-removal alarm The device uses the LDR (light sensor) as an anti-removal alarm. If the keypad is removed from the cover, the anti-removal alarm will sound. Sound and light signalling STATUS OF YELLOW RED LIGHT GREEN LIGHT BRZĘCZYK OPERATIONS LIGHT shines signal Standby...
- Page 7 Action Comments Enter programming mode Administrator code 999999 is the default master code Exit programming mode Note: To perform the following actions, the root user must be logged in Change of master code New code New code The master code may contain from 6 to 8 digits Mode setting: Entry by card only...
- Page 8 Adding a PIN user User ID number The ID number is any number between 1 and 2000. The PIN code is any four digits between 0000 and 9999, except 1234, which is restricted. Users can be added continuously without leaving programming mode as follows User ID No.
- Page 9 Adding a user card Method 4: In this method, the user ID is assigned to the card number. Only one user identifier may be assigned to A user can be added continuously without a card number leaving the programming mode. Card-by-card deletion of users.
- Page 10 Adding a card user in card mode Adding and deleting a card user The operation is the same as adding and deleting a card user Deletion of all users Deletion of all users. Note: this is a dangerous option and should be used 0000 with caution.
- Page 11 or built-in magnetic contact, if the door is opened but not closed after 1 minute, an internal buzzer will sound an automatic tone to remind you to close the door. Warning of forcible door opening. When using a lock with optional magnetic contact or built-in magnetic contact, if the door is forcibly opened, both the internal buzzer and the alarm output signal will sound.
- Page 12 In this mode, the device supports a 26-bit Wiegand output, so the Wiegand data lines can be connected to any controller that supports a 26-bit Wiegand input. The diagram can be seen in Figure 3.
- Page 13 ATTACHMENT...
