Qoltec TITAN Manual

Hide thumbs

Advertisement

Table of Contents

Model: 52440, 52441

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TITAN and is the answer not in the manual?

Questions and answers

Related Manuals for Qoltec TITAN

Summary of Contents for Qoltec TITAN

  • Page 1 Model: 52440, 52441...

  • Page 2: About The Product

    INTRODUCTION Thank you for your trust and for choosing the Qoltec combination lock. We are confident that the product will meet your expectations. This manual will guide you through the installation and use of the unit. It contains important safety instructions for operation and correct installation.
  • Page 3  Three-colour LED status indicator  Integrated alarm output and buzzer  Pulse mode, switching mode  Possibility of transferring user data (except for fingerprint users)  Possibility to lock 2 devices for 2 doors  Built-in light dependent resistor (LDR) for tamper protection ...

  • Page 4: Technical Specifications

    8888, which is reserved) User deletion 2 (fingerprint) # 2 (load card) # 2 (PIN code) # Output With what to open the door User fingerprint Fingerprint Card Load card PIN code Enter PIN# TECHNICAL SPECIFICATIONS Model: 52448 Parameter Value Type Transmission type RFID...

  • Page 5: Installation

    Type Transmission type RFID Fingerprint/PIN Mode of operation code/card/key fob Degree of protection IP68 Nominal voltage DC 12 - 24V Frequency 125kHz Number of relays Load Number of users 10000 Proximity reader Touch keyboard Fingerprint reader Otivering via smartphone Operating temperature ℃...
  • Page 6 violet Common Common door relay contact (potential-free) orange Door relay NC contact (potential-free) yellow OPEN Output request input (REX) Pass-through cabling (Wiegand reader or controller) green Date 0 Wiegand output (pass-through) Data 0 white Date 1 Wiegand output (pass-through) Data 1 Advanced input and output functions grey Alarm...

  • Page 7: Standalone Mode

    1. Enter programming mode (Admin code) 2. Change of admin code 0 (New admin code) (Repeat new admin code) (The code consists of 6 digits) 3. Exit programming mode Set operating mode Notes: The device has 3 modes of operation: standalone mode, controller mode, Wiegand reader mode, select the mode you use.
  • Page 8 Access control power supply (Figure 4) Programming Programming will vary depending on your access configuration. Follow the instructions appropriate to your access configuration. Comments: User ID number: Assign a user ID to a fingerprint / card / PIN to keep track of the user. Common user ID: - Fingerprint user ID: 0 ~ 98 - PIN / card: 100 ~ 987...
  • Page 9 Add user with fingerprint 2. Using the Auto ID function 1 (Fingerprint) (Fingerprint (Allows the device to assign a repeat) (Fingerprint repeat) fingerprint to the next Fingerprints can be added available user ID number). continuously. 1. Select a specific ID (allows 1 (User ID) # (Fingerprint) the Master to define a (Repeat fingerprint) (Repeat...
  • Page 10 For added security, we allow the correct PIN to be hidden with other digits, up to a maximum of 10 digits. Example PIN: 123434) You can use ** (123434) ** or ** (123434) ("*" can be any number from 0 ~ 9) Add primary fingerprint (by specific identifier: 99) Programming Key combination...
  • Page 11 Programming Key combination 1. Enter programming mode (Admin code) 2. Add card 1 (user ID) (0 ~ 9) (load card/enter card number) 2. Add PIN 1 (User ID) (0 ~ 9) (PIN) (0 ~ 9 indicates the number of guest inputs, where 0 indicates 10 inputs) 3.
  • Page 12 2. Deletion of all users 2 (Admin code) 3. Output Relay configuration setting Adjustment of the door opener release time. Programming Key combination 1. Enter programming mode (Admin code) 2. Pulse mode 3 (1-99) # (factory settings) 1-99 setting of the time for which the electric door strike is released, factory setting is 5 seconds 2.
  • Page 13 2. Multi-user access (Only after correct reading of 2 ~ 9) users will the door be opened) 2. Access by fingerprint, card (Factory settings) or PIN code 3. Output Setting the scare alarm The alarm sounds after 10 unsuccessful entry attempts (factory disabled).
  • Page 14 Detection of forced opening of doors If the lock is equipped with an optional magnetic contact or built-in magnetic contact, when the door is opened, the internal buzzer and external alarm (if any) will sound and can be interrupted by the administrator or user, otherwise the beep will continue for the duration of the alarm.
  • Page 15 Keyboard backlighting on Keyboard backlighting automatically switched off (factory settings) after 20 seconds 3. Output Keyboard backlighting automatically switched off after 20 seconds Using the master fingerprint/card to add and remove users Adding and deleting users 1. Data entry (master fingerprint/card) with a master 2.

  • Page 16: Controller Mode

    © If an Administrator card has not been added, press the * button for at least 5 seconds before releasing the button (this will invalidate the previously registered master card). CONTROLLER MODE The unit can operate as a controller connected to an external Wiegand reader.
  • Page 17 - There are some exceptions that should be noted: Device connected to external card reader -EM cards: users can be added/deleted both on the device and on the external reader. - HID cards: users can only be added/removed at the external reader. Connecting an external fingerprint reader to the device 1.
  • Page 18 3. Output Notes: 4 means 4 bits, 8 means 8 bits, 10 means 10 bits - Adding PIN users: To add PIN users, after entering the programming mode on the device, the PIN(s) can be entered/added on both the device and an external keypad reader.

  • Page 19: Advanced Network

    8 (4 /8 /10) (factory setting is 4 PIN encryption type bits) 3. Disable the parity bit Enable parity bit 81# (factory settings) 4. Output Note: When connecting a Wiegand controller with a 32, 40, 56 bit input, the parity bits must be disabled. ADVANCED NETWORK Transfer of user information (applies to card/PIN users) The unit supports User Information Transfer, and registered users...
  • Page 20 secondary device Within 30 seconds, the green LED will light up and after one beep the LED will turn red, indicating that the user data has been transmitted successfully. 3. Output Wiring diagram (figure 8) Note: The door reed switch must be installed and connected according to the diagram.
  • Page 21 closed the user must scan a fingerprint/read a card or enter a PIN code on device/reader B to release electric door strike 2.
  • Page 22 ATTACHMENT...
