Summary of Contents for Qoltec 52440
- Page 1 Model: 52440, 52441...
-
Page 2: About The Product
INTRODUCTION Thank you for your trust and for choosing the Qoltec proximity reader. We are confident that the product will meet your expectations. This manual will guide you through the installation and use of the unit. It contains important safety instructions for operation and correct installation. -
Page 3: Installation
Transmission type RFID Mode of operation Proximity card / keyring Degree of protection IP68 Nominal voltage DC 10-24V Frequency 125kHz Number of relay outputs Load <100mA Max. number of users 2000 10 Installation Surface mounting 11 Operating temperature tilde 12 Dimensions 100×43×20 (mm) 13 Net weight of appliance 290g... - Page 4 4. Cover the front cover and fix the front and rear covers with a screwdriver and screws. Markings shown in Figure 1. Wires Definition Function Colour Comments Green NC relay Brown COM relay White NO relay Black Negative pole Power input 10-24 VDC Opening Yellow Exit button...
-
Page 5: Standalone Mode
STAND-ALONE MODE Connection diagram Special power supply (Figure 2) Universal power supply (figure 3) Note: The electrical locks must be connected using a diode (1N4004), otherwise the device may be damaged. The white end of the diode must be connected to the negative pole of the electrical lock. The diode is included in the packaging. - Page 6 Programming Key combination step code Enter programming *Administrator mode Administrator code 0 (new admin code) # (repeat new Orange update admin code) # flashes (The administrator code consists of any 6 digits Exit programming Red flashes mode For security reasons, you must change the administrator code and then remember this.
- Page 7 Remove card user: Orange 2 (Read card) with card flashes Delete user: ID 2 (Enter ID number) number Delete all users 2 0000 Exit programming Red flashes mode Pulse and switching mode setting Programming Key combination step code Enter programming *Administrator mode Pulse mode...
- Page 8 Exit programming Red flashes mode Attention: 1. The factory default setting is 1 minute. 2. Alarm time includes: anti-vandalism alarm time, safe mode time and lockout reminder time. 3. By inserting a valid card, the alarm can be deactivated. Safe mode settings Programming step Key combination code...
- Page 9 ATTACHMENT...
