- Page 1 Model: 52444...
-
Page 2: About The Product
INTRODUCTION Thank you for your trust and for choosing the Qoltec combination lock. We are confident that the product will meet your expectations. This manual will guide you through the installation and use of the unit. It contains important safety instructions for operation and correct installation. If you have any questions after reading the manual, please contact Customer Service. -
Page 3: Installation
Operating current < 100mA Dimensions 125mm x 84mm x 23mm Weight 300g Ambient temperature Relative humidity 20% - 80% Memory 4000 users Card types (optional) EM(ID) (optional IC card) Card reading range 1 - 5cm Factory default settings Default 123456 Common slogan password Lock unlocking... -
Page 4: Programming Manual
To install the MIMAS combination lock correctly, refer to the information in the table below and Figure 1. Designation Colour Function +12V Power supply + black Power supply - PUSH blue Low-level output OPEN yellow Door unlocking BEL+ grey Bell BEL- violet Bell... - Page 5 Set a common # programming password # There is only one common access password 21 new common access access password. password # Opening method: Common Access Password #. Delete all users # programming password # Remove all cards and PINs 40 0000 # except the common access password.
- Page 6 (optional) 04 ## password reader (W26 output). Safety function # programming password # 7 XX can be set to 01/02 (safety settings function OFF/ON) and 03/04 (disassembly alarm OFF/ON). Setting the alarm Note: enabling the security function will lock the system for 5 before minutes if the wrong card is continued to be read or the wrong dismantling...
- Page 7 MDC READ >> MAC READ >> MDC To delete all users in standby mode READ User identification number The user ID is an automatically generated 4-digit number starting from 0001. This number increases as users are added and does not take into account the deletion of users.
- Page 8 ATTACHMENT...
