- Page 1 Model: 52440, 52441...
-
Page 2: About The Product
INTRODUCTION Thank you for your trust and for choosing the Qoltec proximity reader. We are confident that the product will meet your expectations. This manual will guide you through the installation and use of the unit. It contains important safety instructions for operation and correct installation. - Page 3 Operating voltage DC 10-24V Idle current <-45mA Active current <-150mA Card type EM or Mifare or EM,Mifare card Card frequency 125kHz or 13.56MHz Max. number of users 3000 Reading range 30 tilda 80mm Operating temperature tilde Humidity during operation 10% tilde 99% 10 Dimensions 120×78×22(mm) 11 Net weight...
-
Page 4: Installation
INSTALLATION 1. Draw the location of the hole and drill the hole at the installation site in line with the hole in the back cover 2. Attach the back cover to the wall using the wall plugs provided in the accessory bag. -
Page 5: Standalone Mode
Programming stage Key combination Enter programming *administrator mode code# Modification of the 0 # (New admin code) Orange flashes admin code (Factory setting is 123456) Exit mode Red flashes Note: The administrator code can consist of any 6 digits and the administrator must bear this in mind. - Page 6 Using the add/remove card users function Using administrator tabs to add and remove users Adding Step 1: Read the administrator's charter users Step 2: Reading the user card Step 3: Re-read the administrator's card to complete the Deletion of Step 1: Read the administrator card twice in standby mode users Step 2: Read user cards (Repeat step 2 for additional user cards)
- Page 7 1. The ID number is the number assigned to each user and is usually useless. However, if you want to delete a specific user, you should enter the ID number or card number. 2. When adding users, the ID number will be assigned automatically from small to large.
- Page 8 Delete user Programming Key combination step Enter programming code *Administrator mode Remove card user: Orange (Read card) ... with card flashes Delete card user: by (Enter 8/10-digit card number) card number #..Delete user: ID (Identification number) number Delete all users (Admin code) Exit programming Red flashes...
- Page 9 3. Impulse mode: the door will close automatically when it is momentarily opened. Switching mode: In this mode, once the door is opened, the door will not be automatically closed until the next valid user input. This means that a valid card must be swiped or a valid fingerprint entered to open or close the door.
- Page 10 Alarm output mode 8 Exit programming Red flashes mode Attention: Lock mode: If the card is swiped/fingerprinted 6 times by an incorrect user within 1 minute, the device will be locked for 10 minutes. In lock mode, pressing the exit button allows the door to be opened. Alarm output: If the card is swiped/fingerprinted 6 times by the wrong user within 1 minute, the device will beep.
-
Page 11: Wiegand Reader Mode
1. Both devices must be manufactured by us and support this function. 2. Both devices have the same administrator code 3. Connect the Wiegand cable of both devices and switch the power on Example: Devices A and B have the same administrator code. Add a new card user to device A and B, then turn the power on. - Page 12 Wiegand format 26 tilde 44,56,58) Exit programming Red flashes mode Note: EM Wiegand output: 26 bit. Mifare Wiegand output range: 26 tilde 44 bits, 56 bits, 58 bits. Used not only for card reader output, but also for access controller input.
- Page 13 ATTACHMENT...
