OfficeSource EVT10AHALFGG Assembly Instructions

®
OFFICE FURNITUR E
1
M8 Nut
12 PCS
7
Screw
M8*40mm
6 PCS
13
Bracket
260*100*3mm
A
End Leg
IMPORTANT NOTE:
Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched
Check that you have all parts and hardware.
Remove all wrapping materials, including staples & packing straps before you start assemble.
Do not tighten all screws or bolts untill all completely assembled.
Keep all hardware parts out of reach of children.
Last Updated: 11/2022
2 3
Stand-off Ø20*76 Leveler
2 PCS
8
9
Screw Screw
M8*20mm M6*15mm
15 PCS
6 PCS
1 PC
EVTCBK
B
Middle Leg
2PCS 1PC
MODEL NO. EVT10AHALFGG/EVT10DBK
EVT10AHALFGG EVT10DBK
60" Half top for 10ft Conference table
5
4
Grommet
Wire Managemennt
(Pre-assembly)
Tray 570mm
2 PCS
1 PC
1 PC
11
10
Wrench
Wrench
4mm
1 PC
EVT10AHALFGG
C
D
Top Panel
1 PC
ASSEMBLY INSTRUCTIONS
6
Screw
M6*65mm
4 PCS
12
wrench(M8)
5mm
1 PC
1 PC
EVT10DBK
E
Right Frame Left Frame
(1111mm) (1111mm)
2 PCS 2 PCS
OFFICESOURCE.COM
P.1
