IMPORTANT NOTE:
Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched
Check that you have all parts and hardware.
Remove all wrapping materials, including staples & packing straps before you start assemble.
Do not tighten all screws or bolts untill all completely assembled.
Keep all hardware parts out of reach of children.
Last Updated: 11/2022
3
1
2
M8 Nut
Stand-off Ø20*76
16 PCS
2 PCS
8
9
7
Screw
Screw
M8*40mm
M8*20mm
8 PCS
8 PCS
C
A
B
EVT6AGG
EVTBBK
Top Panel
Leg
2 PCS
1 PC
EVT6AGG EVTBBK
72" Sitting Height Conf. Table
4
5
Wire Management
Leveler
Tray 870mm
2 PCS
1 PC
10
11
Wrench
Screw
4mm
M6*15mm
1 PC
10 PCS
EVT6AGG
Frame (1028mm)
2 PCS
MODEL NO. EVT6AGG
6
Grommet
Screw
(Pre-assembly)
M6*65mm
2 PCS
4 PCS
12
Wrench
Wrench(M8)
5mm
1 PC
1 PC
OFFICESOURCE.COM
P.1
Advertisement
Table of Contents
Related Manuals for OfficeSource EVT6AGG
Summary of Contents for OfficeSource EVT6AGG
- Page 1 ASSEMBLY INSTRUCTIONS MODEL NO. EVT6AGG EVT6AGG EVTBBK 72" Sitting Height Conf. Table Grommet Screw Wire Management M8 Nut Stand-off Ø20*76 Leveler (Pre-assembly) M6*65mm Tray 870mm 16 PCS 2 PCS 2 PCS 2 PCS 4 PCS 1 PC Wrench Wrench Screw...
- Page 2 ASSEMBLY INSTRUCTIONS MODEL NO. EVT6AGG EVT6AGG EVTBBK 72" Sitting Height Conf. Table Use Screw (7 、 8) to connect Leg (B), Frame (C) together; Install Stand-off (2) on Top Panel (A), Use the Leveler (3) to connect the Wire Management Tray (4) with the Stand-off (2);Use the screw (9) to connect the Leg (B) and Top (A).
