- Page 1 Assembly Instructions 49421+49355 Crescent Collection 49421+49357 Merax Collection 49421+49356 Crescent Collection 275 lbs...
- Page 2 49355 Metal Legs 49356 (Footers + 4 Star Base + Gas Lift + Seat Plate) 49421 Seat & Back Cushion 49357 (Casters + 5 Star Base + Gas Lift + Seat Plate)
- Page 3 Option 1: 49421 + 49355 1. Attach Metal Legs (1A & 1B) to the bottom of the Seat Cushion (2) by using 1-1/2” Screws (3) and tighten the screws. 2. Periodically (every 90 days) tighten all screws in the chair. ATTENTION: Make certain all screws are fully tightened before using chair.
- Page 4 Option 2: 49421 + 49356 1. To begin assembly, place the Base (2) upside down and insert Footers (1) into bottom of Base (2). 2. Turn Base (2) right side up on the floor and insert Gas Lift (3) into center hole on Base (2). 3.
- Page 5 Function for 49421 + 49356 Operating Instructions Function Instruction - 1 To Adjust Seat Height: While seated, lean forward and reach under the right side of the chair to find the handle. Lift the handle and raise your body up slightly to allow the chair to rise to the desired height.
- Page 6 Option 3: 49421 + 49357 1. To begin assembly, place 5 Star Base (2) upside down and insert Casters (1) into bottom of Base (2). 2. Turn Base (2) right side up on the floor and insert Gas Lift (3) into center hole on Base (2). 3.
- Page 7 Function for 49421 + 49357 Operating Instructions Function Instruction - 1 To Adjust Seat Height: While seated, lean forward and reach under the right side of the chair to find the handle. Lift the handle and raise your body up slightly to allow the chair to rise to the desired height.
