Cisco Catalyst GNSS External Antenna
(CW-ANT-GPS1-M-00)
First Published: 2024-10-22
Cisco Catalyst Global Navigation Satellite System (GNSS) External Antenna
(CW-ANT-GPS1-M-00)
This document outlines the specifications for the Cisco Catalyst GNSS External Antenna
(CW-ANT-GPS1-M-00) and provides instructions for mounting them. The antenna is designed for indoor or
outdoor use depending on the country. CW-ANT-GPS1-M-00 is used on the CW-ACC-GPS1 accessory
module. The primary use case for CW-ANT-GPS1-M-00 is as an indoor window mount. This antenna will
provide geolocation information for the AP to be used by the AFC systems as required for standard power
operation in 6-GHz band.
Figure 1: CW-ANT-GPS1-M-00-NS Antenna: Different Views
Technical Specifications
Table 1: Cisco Catalyst GNSS External Antenna (CW-ANT-GPS1-M-00) Specifications
Operating frequency range
1164.45–1188.45 MHz (L5)
1559.05–1610.5 MHz (L1)
Cisco Catalyst GNSS External Antenna (CW-ANT-GPS1-M-00)
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cisco Catalyst CW-ANT-GPS1-M-00
Summary of Contents for Cisco Catalyst CW-ANT-GPS1-M-00
- Page 1 Cisco Catalyst Global Navigation Satellite System (GNSS) External Antenna (CW-ANT-GPS1-M-00) This document outlines the specifications for the Cisco Catalyst GNSS External Antenna (CW-ANT-GPS1-M-00) and provides instructions for mounting them. The antenna is designed for indoor or outdoor use depending on the country. CW-ANT-GPS1-M-00 is used on the CW-ACC-GPS1 accessory module.
-
Page 2: System Requirements
This antenna is designed for use with CW-ACC-GPS1 accessory module. Note The model CW-ANT-GPS1-M-00 is supported only on Cisco Catalyst 9800 Series Wireless Controllers running an IOS-XE 17.4.1 release or a later release. This antenna model is not supported on Cisco AireOS Wireless Controllers. Safety Precautions... -
Page 3: Installation Notes
Cisco Catalyst Global Navigation Satellite System (GNSS) External Antenna (CW-ANT-GPS1-M-00) Installation Notes 1. Before you install an antenna, contact your Cisco account representative to explain which mounting method to use for the size and type of antenna that you are about to install. -
Page 4: Installing The Antenna
Cisco Catalyst Global Navigation Satellite System (GNSS) External Antenna (CW-ANT-GPS1-M-00) Installing the Antenna • Signals will likely reflect off a thick metal wall and may not penetrate it at all. • Signals will likely reflect off a chain link fence or wire mesh spaced between 1 and 1 1/2 in. (2.5 and 3.8 cm). - Page 5 Cisco Catalyst Global Navigation Satellite System (GNSS) External Antenna (CW-ANT-GPS1-M-00) Mounting the Antenna Note For outdoor installations, position the antenna bracket assembly facing upwards. Figure 2: Indoor Installation Figure 3: Outdoor Installation Procedure Step 1 Clean the mounting surface. Step 2 Attach the four adhesive pads to the bottom surface of the bracket and attach it to the surface.
-
Page 6: Communications, Services, And Additional Information
Cisco Bug Search Tool (BST) is a gateway to the Cisco bug-tracking system, which maintains a comprehensive list of defects and vulnerabilities in Cisco products and software. The BST provides you with detailed defect information about your products and software.
