Landoll 9650FH-60 Operator's Manual

Field cultivator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
'
Model 9650FH-60
Field Cultivator
Operator's Manual
LANDOLL COMPANY, LLC
1900 North Street
Marysville, Kansas 66508
(785) 562-5381
800-428-5655 ~ WWW.LANDOLL.COM
F-1174-2411

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9650FH-60 and is the answer not in the manual?

Questions and answers

Related Manuals for Landoll 9650FH-60

Summary of Contents for Landoll 9650FH-60

  • Page 1 ‘ Model 9650FH-60 Field Cultivator Operator’s Manual LANDOLL COMPANY, LLC 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM F-1174-2411...

  • Page 2: Instructions For Ordering Parts

    The Data Plate, which lists the model and serial number of the equipment. It is located on the front of the machine. See Figure 1-1 SERIAL NUMBER NOMENCLATURE The Following information will help decode the 9650FH-60 FC serial number. 96H2400100 = xxmyysssss = model series (i.e. 96 for FH Field Cultivator) = month of manufacture (ex.
  • Page 3 DANGER DO NOT operate or perform any maintenance tasks on this equipment until you have completed the following: 1. Receive proper training to operate this equipment safely. 2. Read and understand the operator’s manual. 3. Be thoroughly trained on inspection and repair procedures. Failure to comply with this warning may result in serious injury or possibly death.
  • Page 5 Table of Contents Introduction and Safety Introduction ............1-1 Using This Manual .
  • Page 6 9650FH-60 Gauge Wheels........

  • Page 7: Introduction And Safety

    Landoll parts. Have the Serial Number and complete maintenance will provide you with satisfactory use for Model Number available when ordering parts from your seasons to come. Landoll dealer. If items covered in this manual are not understood, contact your local Landoll Dealer. DANGER DANGER...
  • Page 8 Landoll Company, LLC Warranty Department within ten (10) days of the first retail sale. As stated above, Landoll Company, LLC Warranty Staff will identify components listed on a Warranty Claim required to be returned for further analysis. All parts returned to Landoll Company, LLC must be shipped with a Return Materials Authorization (RMA) provided by the Landoll Company, LLC Warranty Staff.
  • Page 9 This exclusive remedy shall not be deemed to have failed of its essential purpose so long as Landoll Company, LLC is willing and able to repair or replace defective parts in the prescribed manner.

  • Page 10: Transporting Safety

    TABLE OF CONTENTS Safety Decal Safety • Examine safety decals and be sure you have the cor- Understanding Safety rect safety decals for the implement. Statements • Keep these signs clean so they can be observed readily. It is important to keep these decals cleaned You will find various types of safety information on the more frequently than the implement.

  • Page 11: Attaching, Detaching, And Storage

    TABLE OF CONTENTS • Attach the safety chain to the tractor recommended • Block implement so it will not roll when unhitched drawbar support. Provide only enough slack in the from the tractor. chain for turning. • Store in an area where children normally do not play. WARNING Maintenance Safety Do not attach the safety chain to an intermediate...

  • Page 12: Chemical Safety

    TABLE OF CONTENTS Chemical Safety Safety Chain • Agricultural chemicals can be dangerous. Improper • Use a chain with a strength rating equal to or greater use can seriously injure persons, animals, plants, soil than the gross weight of towed machinery, which is and property.
  • Page 13 TABLE OF CONTENTS Safety Decals and New safety signs may be ordered from your Landoll dealer. Refer to this section for parts and proper safety Reflectors sign placement. To Install new safety signs: The Field Cultivator is equipped with all safety signs installed for safe operation.
  • Page 14 TABLE OF CONTENTS P/N 144193 SIS 20 MPH Front of center frame, middle. QTY. 1 P/N 2-573-010037 Danger: Folding Wing. Front side, front hinge plate, center frame, both sides. QTY. 2 P/N 2-573-010037 Danger: Folding Wing Backside, rear hinge plate, center frame, both sides. QTY.
  • Page 15 TABLE OF CONTENTS P/N 528934 Yellow Reflector Left front, center frame, both sides QTY. 2 P/N 528934 Yellow Reflector Left front, amber light bracket, both sides. QTY. 2 P/N 528934 Yellow Reflector Left rear, center lift plate, both sides. QTY. 2 P/N 528938 Orange Reflector Backside, light brackets, top, both sides.
  • Page 16 TABLE OF CONTENTS P/N 528933 Red Reflector Backside, light brackets, bottom, both sides. QTY. 4 P/N 224589 SIS 20 MPH Backside of SIS 20 MPH mount plate. QTY. 1 P/N 70260977 SMV Emblem Backside, SMV mount plate. QTY. 1 P/N 247227 Danger: Crushing Hazard DANGER CRUSHING HAZARD...
  • Page 17 TABLE OF CONTENTS P/N 247227 Danger: Crushing Hazard DANGER CRUSHING HAZARD To prevent serious injury or death: • Stay clear of moving parts. • Lower elevated components or install cylinder lockouts before servicing. 247227 Wing lift arm plate, outer side, inner and outer wings. QTY.
  • Page 18 TABLE OF CONTENTS Table provided for general use. NOTES: 1-12 F-1174-2411...

  • Page 19: Model Specifications

    Chapter 2 TABLE OF CONTENTS Specifications Model Specifications Field Cultivator Model Number 9650FH-60 Working Width 60 Ft 6 in (18.4 m) Transport Width 18 Ft 5 in (5.6 m) Transport Height 16 Ft 2 in (4.9 m) Number of Shanks...

  • Page 20: General Torque Specifications

    TABLE OF CONTENTS General Torque Specifications LANDOLL SAE TORQUE SPECIFICATIONS (FOOT POUNDS) [ ] Indicates specifications for Prevailing Torque Nuts. FASTENER TORQUE SPECIFICATIONS (Rev. 23/04) This chart provides general torque specifications for UNF Size Grade 2 Grade 5 Grade 8...

  • Page 21: Hydraulic Fitting Torque Specifications

    TABLE OF CONTENTS Hydraulic Fitting Torque Specifications LANDOLL LANDOLL LANDOLL HYDRAULIC FITTING TORQUE HYDRAULIC FITTING TORQUE HYDRAULIC FITTING TORQUE SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS (REV . 23/04) (REV . 23/04) (REV . 23/04) AEROQUIP BRAND FITTINGS GATES BRAND FITTINGS PARKER BRAND FITTINGS 37°...
  • Page 22 20” 20” 2” 25-1/4” 14” 50” 20” 8” 26” 14” 2” 2” 2” 2” 2” 2” 26” 2” 8” 8” 14” 14” 14” 8” 8” 8” 14” 38” NOTE: Location Of Shank Extensions Figure 2-1: Shank Placement 9650FH-60 LH F-1174-2411...
  • Page 23 2” 8” 8” 14” 14” 14” 14” 2” 2” 32” 8” 8” 20” 20” 20” 26” 2” 2” 2” 2” 8” 8” 8” 14” 14” 8” 8” 8” NOTE: Location Of Shank Extensions Figure 2-2: Shank Placement 9650FH-60 CENTER F-1174-2411...
  • Page 24 20” 20” 8” 14” 25-1/4” 20” 8” 50” 26” 26” 2” 2” 14” 2” 2” 2” 2” 14” 14” 8” 8” 8” 14” 14” 8” 8” 2” 38” NOTE: Location Of Shank Extensions Figure 2-3: Shank Placement 9650FH-60 RH F-1174-2411...
  • Page 25 On Front Gang Bars Only Harrow Assembly Harrow Assembly 9 Tine 3 Row 9 Tine 3 Row Reel Assembly Reel Assembly Reel Assembly Reel Assembly 75 inch 60 inch 60 inch 60 inch Figure 2-4: 3 RCT and Conditioner Reel Placement 9650FH-60 LH F-1174-2411...
  • Page 26 28-15/16 28-15/16 21-1/16 NOTE: Location Of 1/2 x 4-1/2 Bolts On Front Gang Bars Only Harrow Assembly 10 Tine 3 Row Reel Assembly Reel Assembly 75 inch 90 inch Figure 2-5: 3 RCT and Conditioner Reel Placement 9650FH-60 CENTER F-1174-2411...
  • Page 27 On Front Gang Bars Only Harrow Assembly Harrow Assembly 9 Tine 3 Row 9 Tine 3 Row Reel Assembly Reel Assembly Reel Assembly Reel Assembly 60 inch 60 inch 60 inch 75 inch Figure 2-6: 3 RCT and Conditioner Reel Placement 9650FH-60 RH F-1174-2411...
  • Page 28 Denotes Use Of Bar Clamp W/Tabs (P/N 186200) NOTE: For Proper Spike Harrow Placment. Be Sure To Count Both Round And Square Spike Holes. Catch Trays Point Inward, Hooks Point Outward. Figure 2-7: 5 Row Spike Harrow Placement 9650FH-60 LH 2-10 F-1174-2411...
  • Page 29 Denotes Use Of Bar Clamp W/Tabs (P/N 186200) NOTE: For Proper Spike Harrow Placment. Be Sure To Count Both Round And Square Spike Holes. Catch Trays Point Inward, Hooks Point Outward. Figure 2-8: 5 Row Spike Harrow Placement 9650FH-60 CENTER F-1174-2411 2-11...
  • Page 30 Denotes Use Of Bar Clamp W/Tabs (P/N 186200) NOTE: For Proper Spike Harrow Placment. Be Sure To Count Both Round And Square Spike Holes. Catch Trays Point Inward, Hooks Point Outward. Figure 2-9: 5 Row Spike Harrow Placement 9650FH-60 RH 2-12 F-1174-2411...
  • Page 31 Bar Clamp W/Tabs (P/N 186200) NOTE: For Proper Spike Harrow Placment. Be Sure To Count Both Round And Square Spike Holes. Catch Trays Point Inward, Hooks Point Outward. Figure 2-10: 3 RSD and Conditioner Reel Placement 9650FH-60 LH F-1174-2411 2-13...
  • Page 32 Bar Clamp W/Tabs (P/N 186200) NOTE: For Proper Spike Harrow Placment. Be Sure To Count Both Round And Square Spike Holes. Catch Trays Point Inward, Hooks Point Outward. Figure 2-11: 3 RSD and Conditioner Reel Placement 9650FH-60 CENTER 2-14 F-1174-2411...
  • Page 33 Bar Clamp W/Tabs (P/N 186200) NOTE: For Proper Spike Harrow Placment. Be Sure To Count Both Round And Square Spike Holes. Catch Trays Point Inward, Hooks Point Outward. Figure 2-12: 3 RSD and Conditioner Reel Placement 9650FH-60 RH F-1174-2411 2-15...
  • Page 34 Bar Clamp W/Tabs (P/N 186200) NOTE: For Proper Spike Harrow Placment. Be Sure To Count Both Round And Square Spike Holes. Catch Trays Point Inward, Hooks Point Outward. Figure 2-13: 3 RS Double Flat Reel Placement 9650FH-60 LH 2-16 F-1174-2411...
  • Page 35 Bar Clamp W/Tabs (P/N 186200) NOTE: For Proper Spike Harrow Placment. Be Sure To Count Both Round And Square Spike Holes. Catch Trays Point Inward, Hooks Point Outward. Figure 2-14: 3 RS Double Flat Reel Placement 9650FH-60 CENTER F-1174-2411 2-17...
  • Page 36 Bar Clamp W/Tabs (P/N 186200) NOTE: For Proper Spike Harrow Placment. Be Sure To Count Both Round And Square Spike Holes. Catch Trays Point Inward, Hooks Point Outward. Figure 2-15: 3 RS Double Flat Reel Placement 9650FH-60 RH 2-18 F-1174-2411...
  • Page 37 Chapter 3 TABLE OF CONTENTS Assembly Instructions Assembly WARNING It is very important that your new Field Cultivator be Do not attempt to lift heavy parts (such as the properly assembled, adjusted and lubricated before use. frame, rock shaft, and pull hitch) manually. Use a Illustrations in this section show proper assembly hoist or a forklift to move these parts into procedures.

  • Page 38: Center Frame Assembly

    TABLE OF CONTENTS Center Frame Assembly 3. Remove any shank assemblies or extensions that have been turned around or mounted inside the frame for shipping, and reposition, See Figures 2-1 IMPORTANT through See Figures 2-3 for shank placement. Read all safety precautions at the front of the section 4.
  • Page 39 TABLE OF CONTENTS Bolt, 1/2 x 4-1/2 2 Hole Fold Manifold Assembly Plate Center Frame Lift/Fold Assembly Assembly RH Bolt, 1/2 x 3-1/2 Spacer Locknut, 1/2 Locknut, 1/2 Locknut, 3/4 Center Frame Hose Mount Assembly LH Clamp Extension 5/8” Spacer Bolt, 5/8 x 2 Bolt, 3/4 X 6 Locknut, 5/8...
  • Page 40 TABLE OF CONTENTS Center Lift Assembly NOTE All lifts, walking beam assembly and hubs/spindle come IMPORTANT already assembled from the factory. Read all safety precautions at the front of the section 8. Install the 400/60R18 tire/wheel assemblies to all before attempting any of the following procedures. hub/spindle assemblies using 5/8 wheel nuts.
  • Page 41 TABLE OF CONTENTS Radius Rod Assembly Radius Rod Assembly Bolt, 1 x 8 Locknut, Locknut, 54” Bolt, 5/16 x 5-1/2 Bolt, Bolt, 5/8 x 3 1 x 3-1/2 Depth Stop Guide Depth Stop Assembly, Locknut, Bearing Cap 168 in Length Bolt, 5/8 x 4 Locknut,...

  • Page 42: Hitch Assembly

    TABLE OF CONTENTS Hitch Assembly 5. Slide the hose holder bracket over the screw and secure with another 3/4 flange nut. 6. Install a 3/8 x 3-1/2 all-thread bolt in the front of the IMPORTANT hose holder bracket and secure with a 3/8 nut. Read all safety precautions at the front of the section 7.
  • Page 43 TABLE OF CONTENTS Hitch Pin U-Bolt, 5/8 x 3-11/16 x 5-1/2 Nut, 5/8 Spring Pin, 5/16 x 2-1/2 Hitch Pin, 1-7/16 x 6-1/4 Machine Bushing Hitch Extension Adapter, Wing Nut, 3/8 8 FJIC Swivel x 8 MOR Bolt, All-Thread, 1/4 x 1 Adapter, Hose Holder Hose Clamp...
  • Page 44 TABLE OF CONTENTS Gauge Wheel Assembly 3. Connect the rod, cylinder anchor to the gauge wheel mount, secure with 1-3/4 jam nuts. Initially set the Center cylinder anchor to the dimension shown Figure 3-4. IMPORTANT Read all safety precautions at the front of the section Locking Nut, 1-3/4 Adjusting Nut, 1-3/4 before attempting any of the following procedures.
  • Page 45 TABLE OF CONTENTS Jam Nut, Cylinder, Rephase, Rod, Cylinder Locknut, 3/4 1-3/4 Anchor 4 x 10 Bolt, Locknut, 3/4 x 3 U-Bolt, 5/8 x 3-11/16 x 5-1/2 Bolt, Flat Washer, 1 Spring Pin, 3/4 x 5-1/2 5/16 x 2-1/2 Gauge Wheel Pin, 1 x 7-7/8 Mount Locknut, 3/4...
  • Page 46 TABLE OF CONTENTS Inner Wing Frames Wing Gauge Wheel Installation 1. Attach inner wing frame assemblies to center frame using flat washers, 1-1/4 x 6-1/8 pin and 5/16 x 2-1/2 1. Attach the 6-bolt gauge wheel assembly to the front of spring slotted pins See Figure 3-6.
  • Page 47 TABLE OF CONTENTS Fold Pin, 1-1/4 x 6-1/8 Flat Washer, 1-1/4 Spring Pin, 5-16 x 2-1/2 Shank Assembly Inner Wing Frame Assembly Radius Rod Lift Assembly Hub/Spindle Assembly 21” Locknut, 1 Stand Bolt, Tire/Wheel Assembly, Gauge Wheel 3/4 x 5-1/2 280/70R15 Assembly Bolt, 1 x 7-1/2...
  • Page 48 TABLE OF CONTENTS Outer Wing Frames Wing Gauge Wheel Installation 1. Attach outer wing frame assemblies to center frame using 2, flat washers on front wing hinge, 1-1/4 x 7 1. Attach the 6-bolt gauge wheel assembly to the front of bolt and 1-1/4 locknut, Insert the hinge bolts in the wing gauge wheel mount with 3/4 x 5-1/2 bolts and direction shown,...
  • Page 49 TABLE OF CONTENTS Locknut, 1-1/4 Shank Bolt, Assembly 1-1/4 x 7 Outer Wing Frame Bolt, Assembly 1-1/4 x 7 Locknut, 1-1/4 Flat Washer, 1-1/4 Bolt, 1-1/4 x 7 Radius Rod Lift Assembly 21” Hub/Spindle Locknut, 1 Assembly Gauge Wheel Tire/Wheel Assembly, Stand Bolt, Assembly...
  • Page 50 TABLE OF CONTENTS Center Fold Bracket 2. Attach wing stabilizer assembly to center frame assembly using 5/8 x 3-11/16 x 5-1/2 U-bolts and 5/8 Assembly locknut. Install the hydraulic cylinder end to the right side of the center frame. 1. Attach fold cylinder mounts to center frame assembly using 5/8 x 3-11/16 x 5-1/2 U-bolts and 5/8 locknut See Figure 3-8.

  • Page 51: Hydraulic Installation

    TABLE OF CONTENTS Hydraulic Installation Refer to Figures 3-14 3-21 for lift and fold hydraulic diagrams Hose Mount 1. Attach the base end of each 5 x 30 hydraulic cylinder to the fold cylinder mount on the center frame with clevis and roll pins provided with each cylinder as shown in 3-13.
  • Page 52 TABLE OF CONTENTS 7. Install lift system hoses See Figure 3-13 9. Attach hose clamps to the center and wing frames Figure 3-14. Wrap lift system hoses with blue hose See Figure 3-15, 3-16, 3-20 3-21 using 3/8 x wrap. 2-3/4 hex head cap screws and 3/4 locknuts.
  • Page 53 TABLE OF CONTENTS Cylinder, 5 x 30 Pin, 1-1/4 x 6-1/8 Spring Pin, 5/16 x 2-1/2 Flat Washer, 1-1/4 Cylinder, Wing Extension 4 x 16 Roller Bushing Locknut, 1-1/4 Flat Washer, 1-1/4 Wing Fold Link Bolt, 1-1/4 x 7 Figure 3-12: Fold Cylinder Installation F-1174-2411 3-17...
  • Page 54 TABLE OF CONTENTS Hose Asm, Union, Elbow, 90° 1/2 x 170 #8 O-Ring SAE 37 8 x 8 Hose Asm, Hose Asm, Hyd Cyl, 1/2 x 157 1/2 x 58 4-1/2 x 10 Hose Asm, 1/2 x 160 Hose Asm, 1/2 x 184 Hose Asm, Hyd Cyl,...
  • Page 55 TABLE OF CONTENTS Hose Asm, 1/2 x 184 Hose Asm, 1/2 x 64 Hyd Cyl, 4-1/2 x 10 Union, SAE 37 8 x 8 Hose Asm, 1/2 x 174 Hose Asm, 1/2 x148 Hose Asm, 1/2 x 184 Hose Asm, 1/2 x 160 Union, SAE 37 8 x 8...
  • Page 56 TABLE OF CONTENTS NOTE: Run Hoses Through All Hose Clamps & Loops NOTE: Run Hoses Through All Hose Clamps & Loops NOTE: Aproximate Location Of Union Hose Fittings NOTE: Run Hoses Through All Hose Clamps, Loops, Hose Mounts And Hole Of Bearing Cap Weldments Figure 3-15: Hydraulic Lift Layout LH 3-20 F-1174-2411...
  • Page 57 TABLE OF CONTENTS NOTE: Aproximate Location Of Union Hose Fittings NOTE: Run Hoses Through All Hose Clamps, Loops, Hose Mounts And Hole Of Bearing Cap Weldments Figure 3-16: Hydraulic Lift Layout RH F-1174-2411 3-21...
  • Page 58 TABLE OF CONTENTS Elbow, 90° Adapter, Tee #10 x #8 1/16 RES Hyd Cyl, 1/2 #8 JIC x Adapter, Tee Elbow, 90° 4 x 16 #8 JIC Swiv 1/2 #8 JIC x 1/16 RES #8 JIC Swiv Elbow, 90° #8 Swiv Elbow, 90°...
  • Page 59 TABLE OF CONTENTS Elbow, 90° #10 x #8 1/16 RES Elbow, 90° #10 x #8 Hyd Cyl, 5 x 30 Elbow, 90° #10 x # 8 Hyd Cyl, Hose Asm, 5 x 30 Hose Asm, 3/8 x 67 3/8 x 58 Elbow, 90°...
  • Page 60 TABLE OF CONTENTS Elbow, 90° #8 O-Ring Manifold, 24 Port Adapter, #8 TO #8 Hyd Cyl, Hyd Cyl, 4 x 6 1-1/2 x 1-1/2 Adapter, #8 TO #8 Hose Asm, 3/8 x 40 Adapter, #6 TO #6 Hose Asm, NOTE: Lock Cylinder Hoses 3/8 x 37 Connect To Rear 2 Ports Of 24 Port Manifold...
  • Page 61 TABLE OF CONTENTS Table provided for general use. NOTES: F-1174-2411 3-25...
  • Page 62 TABLE OF CONTENTS NOTE: Run Hoses Through All Hose Clamps & Loops NOTE: Run Hoses Through All Hose Clamps & Loops Figure 3-20: Hydraulic Fold Layout LH 3-26 F-1174-2411...
  • Page 63 TABLE OF CONTENTS NOTE: Run Hoses Through All Hose Clamps & Loops Figure 3-21: Hydraulic Fold Layout RH F-1174-2411 3-27...
  • Page 64 TABLE OF CONTENTS 7-PIN 4-PIN CIRCUIT WIRE COLOR CONN. TOWER GROUND WHITE – WORK LAMPS BLACK LEFT FLASHING YELLOW & TURN – STOP LAMPS RIGHT FLASHING GREEN & TURN TAIL LAMPS BROWN SWITCHED – BLUE POWER (12 V) MAIN WARNING LIGHT HARNESS - WIRING CHART (NOTE: The Color Of The Wire Jacket Does Nor Necessarily Match The Color Of The 7 Pin Connector) RIGHT...
  • Page 65 See Figures 3-24 for light harness routing. light mount. 10. Install the Landoll decal to the rear of the rear side of 4. Install the light mount and ag flasher control module the rear fold cylinder mount See Figures 3-23.
  • Page 66 Reflector Assembly Locknut, 5/8 Emblem Tail Light Mount Locknut, Locknut, LED Amber Light Assembly, Right Main Harness Ag Flasher Landoll Bolt, Decal Module 5/8 x 2-1/2 Bolt, 1/4 x 1-1/2 Tail Light Mount Rear Harness Reflector Assembly LED Ag Lamp,...
  • Page 67 TABLE OF CONTENTS NOTE: Run Light Harness Through All Hose Loops Along Hydraulic Hoses NOTE: Run Light Harness Through All Hose Loops Along Hydraulic NOTE: Secure Hoses Light Harness With Tie Straps To Keep Clear Of Any Moving Parts NOTE: Run Light Harness Through Hose Clamps...

  • Page 68: Shank Installation

    TABLE OF CONTENTS Shank Installation NOTE Spring shank assemblies with frame extensions (front NOTE bar) are mounted reversed for narrower shipment. These shanks must be removed and turned forward for proper See Figure 2-1 through for shank placement operation. See Figure 2-1 through for proper dimensions.
  • Page 69 TABLE OF CONTENTS U-Bolt, 5/8 X 4-11/16 X 5-1/2 Spring Shank U-Bolt, Extension 5/8 X 4-11/16 X 4-3/4 Spring Shank Assembly U-Bolt, 5/8 X 4-11/16 X 7-3/4 Bolt, 1/2 X 3-1/4 Locknut, Locknut, Flange, 3” Spring Shank Extension Shank Bolt, RDHD, 5/8 X 1-3/4 Locknut, Flange, U-Bolt,...
  • Page 70 TABLE OF CONTENTS 3 RCT and Conditioner Reel 3. Attach reel assemblies to the reel arm assemblies using 5/8 x 3-11/16 x 4-5/8 U-bolts and 5/8 locknuts. Installation 4. Refer to (See “3 RCT and Conditioner Reel Adjustments” on page 4-12.) in “Operation”...
  • Page 71 TABLE OF CONTENTS Harrow Mounting Plate Tine & Reel Clamp Bolt, Arm Assembly Bushing 3/4 x 5-1/2 Locknut, Bolt, 3/4 x 5-1/2 Reel Assembly Locknut, 5/8 U-Bolt, 5/8 x 3-11/16 x 4-5/8 Harrow Tine Assembly NOTE: Front Row Tine Shipping Postion NOTE: Remove Stop Bolts And Rotate Down With Stop Bolts Above Tines...

  • Page 72: Row Spike Harrow Installation

    TABLE OF CONTENTS 5 Row Spike Harrow 4. Refer to spike bar alignment See Figure 3-28 proper alignment of spike bar assemblies. Be sure Installation they are aligned properly on both right and left side of each section. See Figure 2-7 through for 5 Row Spike Harrow placement dimensions.
  • Page 73 TABLE OF CONTENTS Bolt, 3/4 x 9 Spike Harrow Arm Assembly Clamp Plate Catch Tray Catch Tray Hook Bolt, 1/2 x 1-1/4 Bolt, 3/4 x 5 Bar Clamp W/Tabs Bolt, 1/2 x 3 Lynch Pin Bar Clamp Pull Chain Bracket Locknut, 3/4 Flange Locknut, 1/2 Spike Harrow Arm Clamp...
  • Page 74 TABLE OF CONTENTS 3 RSD and Conditioner Reel 4. Refer to spike bar alignment See Figure 3-30 proper alignment of spike bar assemblies. Be sure Installation they are aligned properly on both right and left side of each section. NOTE See Figure 2-10 2-12 for 3 RSD and conditioner reel...
  • Page 75 TABLE OF CONTENTS Harrow Mounting Plate Clamp Bushing Bolt, 3/4 x 5-1/2 3 RSD Arm With/Out Chains Assembly 3 RSD Arm Locknut, 3/4 With Chains Assembly Bolt, 1/2 x 1-1/4 Reel Assembly Catch Tray Spike Bar Locknut, 5/8 U-Bolt, Catch Tray Hook 5/8 x 3-11/16 x 4-5/8 Bar Clamp W/Tabs Bar Clamp...
  • Page 76 TABLE OF CONTENTS 3 RS and Double Flat Reel 4. Attach flat bar reels with angled blades as shown See Figure 3-33). Installation NOTE See Figure 2-13 through 2-15 for 3 RS and double flat Reel assemblies are shipped with the front reel blades as reel for placement dimensions.
  • Page 77 TABLE OF CONTENTS Harrow Mounting Plate Clamp Bushing Bolt, 3/4 x 5-1/2 Catch Tray 3 RS & DBL Reel Locknut, 3/4 Arm Assembly Bolt, 1/2 x 1-1/4 Flat Reel Assembly Flange Locknut, Locknut, 3/4 Bar Clamp W/Tabs Clamp Tube Spike Bar Bolt, Locknut, 3/4 Catch Tray Hook...

  • Page 78: Rear Tow Hitch (Option)

    TABLE OF CONTENTS Rear Tow Hitch (Option) 4. Remove the cylinder pins from the rear fold cylinder mount See Figure 3-36. 1. Unfold and lower the field cultivator to the ground. 5. Remove the rear fold bracket by removing the 5/8 x 2.
  • Page 79 TABLE OF CONTENTS FRONT NOTE: Route Hoses Along Other Hoses, Trough Hose Clamps, Along Center Frame, And Hitch To Front Of Machine Tie-Straps U-Bolt, 5/8 x 3-11/16 x 5-1/2 Rear Fold Mount Locknut, Locknut, U-Bolt, 5/8 x 3-11/16 x 5-1/2 U-Bolt, 5/8 x 4-11/16 x 4-3/4 Locknut, 5/8...
  • Page 80 TABLE OF CONTENTS 26” 26” Tandem Light NOTE: Center Right Rear Harness Rear Tow Hitch Tail Light Mount On Center Frame Main Wiring Lighting Module Harness NOTE: Routing Of Tandem Light Harness Rear Tow Hitch Assembly NOTE: Routing Of Hydraulic Hoses Hydraulic Hoses Tandem Light...

  • Page 81: Operation

    Chapter 4 TABLE OF CONTENTS Operation DANGER DANGER DANGER DANGER Never allow anyone to ride on the Field Cultivator • When transporting the Field Cultivator, place at any time. Allowing a person to ride on the cylinder lockouts in the lock position after fully machine can inflict serious personal injury or extending the cylinders.

  • Page 82: Hydraulic Lift System

    TABLE OF CONTENTS Hydraulic Lift System NOTE The center lift lockouts operate hydraulically. See "Center The Field Cultivator is equipped with a rephasing Lift Lockouts" on page 4-4. hydraulic lift system to raise and lower the unit in the field. 3.

  • Page 83: Hydraulic Fold System

    TABLE OF CONTENTS Hydraulic Fold System positive when all air has been purged from the system. Due to large amounts of hydraulic oil The Field Cultivator is equipped with a hydraulic fold required, recheck the tractor fluid level to make sure it system to raise and lower the wing frames for narrow is within proper operating limits.
  • Page 84 TABLE OF CONTENTS Center Lift Lockouts Wing Fold Lockouts 1. The center lift is equipped with hydraulic lockout 1. The wing fold lockouts on the field cultivator operate cylinders to hold the field cultivator in the raised with a hydraulic cylinder on the wing stabilizer and are position for servicing or transporting See Figure 4-3.
  • Page 85 Replace the safety chain if SIS Decal Rear it is damaged or deformed in any way. Use only Figure 4-5: Hitch, Speed Identification Symbol, Landoll recommended safety chain. and Safety Chain WARNING • Excessive speed may result in the loss of...

  • Page 86: Tractor Preparation

    6. Check that tires are of proper size, load rating, and inflated to manufacture specifications before The Landoll Field Cultivator is designed to be pulled by transporting. Check wheel lug bolts to ensure tractor equipped with a double lip or clevis type hitch. If tightness.

  • Page 87: Leveling (Side To Side)

    TABLE OF CONTENTS Leveling (Side to Side) NOTE Initially the center frame radius rods should be set to 54 in Leveling the Field Cultivator side-to-side involves leveling (137 cm) centers before final leveling. the center frame then leveling the wing frames to the center frame.
  • Page 88 TABLE OF CONTENTS 9650FH-60 Gauge Wheels sweeps are approximately 1 in (2.5 cm) above the ground. 1. The front gauge wheels of the floating hitch cultivator raise and lower with center and wing lift wheels NOTE keeping the frames level during operation Initially the front radius rods are set to 21 in (53.4 cm) for...

  • Page 89: Depth Stop Adjustment

    TABLE OF CONTENTS Depth Stop Adjustment LED Light Operation 1. The operating depth of the Field Cultivator is 1. Attach the 7-pin plug to the socket at the rear of the controlled by a single-point depth stop. The stop is tractor.

  • Page 90: Spring Shank

    TABLE OF CONTENTS Spring Shank Bolt, 5/8 x 3 1. The Field Cultivator may be equipped with spring 1/8” shanks. The spring shanks feature a 185 lb (83 kg). Spring Plate point load and a 10” trip height to clear field obstructions.
  • Page 91 TABLE OF CONTENTS Table provided for general use. NOTES: F-1174-2411 4-11...
  • Page 92 TABLE OF CONTENTS 3 RCT and Conditioner Reel Each coil tine harrow may be adjusted for spring pressure as well See Figure 4-11. Adjustments • Raise the tine harrow off the ground. 1. The optional 3 RCT and conditioner reel attachment •...
  • Page 93 TABLE OF CONTENTS Reel Spring Pressure Assembly Angle Adjustment Plate 1 Nuts 1/2” 21-3/4” Harrow Heavy Adjustment Pin Clevis Pin Reel Light Assembly Tine Spring Pressure Assembly Gang Bar Plate 1/2 x 1-1/4 RD Head SQ Neck Bolt 1/2 x 1-1/4 RD Head SQ Neck Bolt (Place Bolt In Rear Middle Hole) (Place Bolt In Front Middle Hole) More...
  • Page 94 TABLE OF CONTENTS 5 Row Spike Harrow For the most aggressive spike to action, install the harrow adjustment pin in the forward mounting hole over each bar Adjustments clamp for each spike bar See Figure 4-12. This will position the spike teeth to be in the most vertical position. The 5 row spike harrow optional attachment consists of 5 •...
  • Page 95 TABLE OF CONTENTS Tooth Angle, Tooth Angle, Tooth Angle, Carrying Chain Least Middle Most Harrow Adjustment Spike Bar Assembly Forward Pull Chain Bar Clamp W/Tabs Harrow Bar Clamp Adjustment Pin Figure 4-12: 3 Row Coil Tine and Reel Adjustments F-1174-2411 4-15...
  • Page 96 TABLE OF CONTENTS 3 RSD and Conditioner Reel The forward pull chain will also influence how the 3 row spike operates as well. Adjustments • A taller pull point and shorter adjusted pull chain can help to start residue through the harrow. The optional 3 RSD and conditioner reel attachment consists of a 3 row spike and finishing reel combination •...
  • Page 97 TABLE OF CONTENTS Tooth Angle, Tooth Angle, Tooth Angle, Least Middle Most Spring Assembly Carrying Chain 1 Nuts 1/2” 21-3/4” Reel Assembly Forward Pull Chain Harrow Adjustment Pin Reel Assembly Forward Pull Chain Spike Bar Assembly Bar Clamp W/Tabs Harrow Adjustment Pin Bar Clamp Figure 4-13: 3 RSD and Conditioner Reel Adjustments...
  • Page 98 TABLE OF CONTENTS 3 RS Double Flat Reel NOTICE Adjustments • Make sure the pull chains are set evenly for The optional 3 RS double flat reel attachment consists of each section. a 3 row spike and finishing reel combination harrow that •...
  • Page 99 TABLE OF CONTENTS Tooth Angle, Tooth Angle, Tooth Angle, Least Middle Most Spring Assembly Carrying Chain 1 Nuts Double Flat Reel Assembly 3/4” 21” Forward Pull Chain Harrow Adjustment Pin Double Flat Reel Assembly Forward Pull Chain Spike Bar Assembly Bar Clamp W/Tabs Harrow...
  • Page 100 TABLE OF CONTENTS Table provided for general use. NOTES: 4-20 F-1174-2411...

  • Page 101: Maintenance And Lubrication

    Chapter 5 TABLE OF CONTENTS Maintenance and Lubrication Wheel Bearing Maintenance - Wheel Bearing Maintenance - Non Triple-Lip Triple-Lip Wheel bearing maintenance should be performed at the Transport tires use a self-contained seal with multiple beginning of every season of use. Check the wheel lips.
  • Page 102 TABLE OF CONTENTS Lubrication fittings before greasing. Replace any lost or broken fittings immediately. 1. A proper maintenance schedule will ensure a long 3. Wheel seals, when properly installed, will allow operating life and peak performance. Performing the grease to pass without harm to seals. Regular following lubrication will ensure maximum operating lubrication will extend service life, particularly in life of the Field Cultivator...
  • Page 103 TABLE OF CONTENTS Storage 1. The service life of the Field Cultivator will be extended by proper off-season storage practices. Prior to storing the unit, complete the following procedures: • Completely clean the unit. • Inspect the machine for worn or defective parts. Replace as needed.
  • Page 104 TABLE OF CONTENTS Table provided for general use. NOTES: F-1174-2411...

  • Page 105: Troubleshooting Guide

    Chapter 6 TABLE OF CONTENTS Troubleshooting Guide The Troubleshooting Guide, shown below, is included to in the previous sections when making any adjustments to help you quickly locate problems that can happen using your machine. your Field Cultivator. Follow all safety precautions stated PROBLEM PROBABLE CAUSE SOLUTION...
  • Page 106 TABLE OF CONTENTS PROBLEM PROBABLE CAUSE SOLUTION SWEEPS NOT CUTTING, LEAVING Shanks not positioned correctly Check for proper shank placement SKIPS Sweeps not wide enough Use wider sweeps Sweeps set too shallow Increase operating depth Incorrect sweep angle Use 47 degree sweeps Incorrect shank spring adjustment Adjust spring shank.
  • Page 108 The Data Plate, which lists the model and serial number of the equipment. It is located on the front of the machine. See Figure 7-1 SERIAL NUMBER NOMENCLATURE The Following information will help decode the 9650FH-60 FC serial number. 96H2400100 = xxmyysssss = model series (i.e. 96 for FH Field Cultivator) = month of manufacture (ex.
  • Page 109 Document Control Revision Log: Date Form # Improvement(s): Description and Comments 07/03/2024 F-1174 New Manual 11/04/2024 F-1174-2411 Initial Release...
  • Page 110 Equipment from Landoll Company, LLC is built to exacting standards ensured by ISO 9001:2015 registration at all Landoll manufacturing facilities. Model 9650FH-60 Field Cultivator Operators Manual Re-order Part Number F-1174 LANDOLL COMPANY, LLC 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM...
