- Page 1 INSTALLATION AND OPERATION MANUAL Caution: Please read this manual carefully before operating. Damage caused by misuse is not covered by the warranty.
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS • Be sure to read the instructions in this section carefully before use. The included conventions of safety symbols and messages are regarded as essential precautions. • We recommend that you keep this instruction manual handy for future reference. SAFETY SYMBOL AND MESSAGE CONVENTIONS Safety symbols and messages described below are used in this manual to prevent bodily injury and property damage that could result from mishandling. - Page 3 CAUTION! Although these speakers are designed to withstand the elements, you should take precautions to optimize their long-term performance. • If soil or dust accumulates on the grill, it can be rinsed away with low water pressure. • Chemicals commonly used outdoors can damage the speaker. Avoid spraying such chemicals onto or near the speaker.
- Page 4 DESCRIPTION The Pure Resonance Audio S6 2-way 70V surface mount outdoor speaker is designed to provide high-end, robust audio performance for indoor and outdoor commercial installations. The durable UV and weather-re- sistant enclosure makes this speaker ideal for challenging environments. The S6 includes a 6.5" woofer and 1"...
-
Page 5: Specifications
SPECIFICATIONS Power Rating 60 Watts RMS; 180 Watts Peak Frequency Response (±10 dB) 80Hz - 18kHz Sensitivity (@ 1w/1m) 92 dB Max SPL 111 dB Dispersion (H x V) 110° x 110° Impedance 8 Ohms 70V: 3.75W, 7.5W, 15W, 30W, 60W Transformer Taps 100V: 7.5W, 15W, 30W, 60W 8 Ohm Bypass... -
Page 6: Speaker Placement
INSTALLATION & OPERATION GUIDE SPEAKER PLACEMENT • If you desire music over a wide area, it is best to have a larger number of speakers playing at low volume rather than a few speakers playing at high volume. Keep this in mind when designing your system. •... -
Page 7: Speaker Connections
SPEAKER CONNECTIONS Figure 1. Figure 2. For Low Impedance Operation For 70V High Impedance Operation (3.75W, 7.5W, 15W, 30W, 60W) Select the wattage based on the number of speakers and available amplifier wattage. Figure 3. Figure 4. Correct Speaker Wiring Wiring the Screw Terminal Connector Be careful not to cross wires when installing your speakers. -
Page 8: Limited Warranty
OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PRACTICAL PURPOSE. This warranty gives you specific legal rights. You may have other rights which vary from state to state. PURE RESONANCE AUDIO ® (866) 676-7804 sales@pureresonanceaudio.com...
