- Page 1 INSTALLATION AND OPERATION MANUAL Caution: Please read this manual carefully before operating. Damage caused by misuse is not covered by the warranty.
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS • Be sure to read the instructions in this section carefully before use. The included conventions of safety symbols and messages are regarded as essential precautions. • We recommend that you keep this instruction manual handy for future reference. SAFETY SYMBOL AND MESSAGE CONVENTIONS Safety symbols and messages described below are used in this manual to prevent bodily injury and property damage that could result from mishandling. - Page 3 12" coaxial LF and a 1.5" HF driver, this 2-way outdoor loudspeaker delivers high-output sound, supported by a built-in 300W 70V/100V multi-tap transformer with an 8-ohm bypass. The S12 is perfect for music, paging, and general public address in stadiums, gymnasiums, schools, parks, warehouses, factories, and other outdoor commercial applications.
-
Page 4: Specifications
SPECIFICATIONS Power Rating 300 Watts RMS; 600 Watts Peak Frequency Response (±10 dB) 70Hz - 20kHz Sensitivity (@ 1w/1m) 105 dB Max SPL 120 dB Dispersion 90° x 90° Impedance 8 Ohms 70V: 18.75W, 37.5W, 75W, 150W, 300W Transformer Taps 100V: 37.5W, 75W, 150W, 300W 8 Ohm Bypass Woofer... - Page 5 INSTALLATION & OPERATION GUIDE MOUNTING THE BRACKET 409.6 mm 60 mm 44 mm 23 mm 12.9 mm 60 mm 9 mm 30 mm M8 Screw x6 M12 Bolt x1 CONNECTING THE SPEAKER TO YOUR SYSTEM 1. Remove the screws on the back of the speaker. Then, remove the waterproof seal and plastic cover from the terminal.
- Page 6 SPEAKER CONNECTIONS Figure 1. Figure 2. Speaker Wiring Speaker Wiring For Low Impedance Operation For 70V High Impedance Operation (18.75W, 37.5W, 75W, 150W, 300W) Select the wattage based on the number of speakers and available amplifier wattage. Figure 3. Figure 4. Daisy-Chain Speaker Wiring Wiring the Screw Terminal Connector Be careful not to cross wires when installing your speakers.
-
Page 7: Limited Warranty
OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PRACTICAL PURPOSE. This warranty gives you specific legal rights. You may have other rights which vary from state to state. PURE RESONANCE AUDIO ® (866) 676-7804 sales@pureresonanceaudio.com...
