- Page 1 Series Thermal Monocular Cyclone Series User Manual...
-
Page 3: Legal Information
fitness for a particular purpose. The use of the product by you is at your own risk. In no event will ThermTec be liable to you for any special, consequential, incidental, or indirect damages, including, among others, damages for loss of business profits, business interruption,... - Page 4 You acknowledge that the nature of the internet provides for inherent security risks, and ThermTec shall not take any responsibilities for abnormal operation, privacy leakage or other damages resulting from cyber-attack, hacker attack, virus infection, or other internet security risks; however, ThermTec will provide timely technical support if required.
-
Page 5: Table Of Contents
5.1 Appearance of Cyclone 9. MEMORY ACCESS 5.2 Description of Controls 6. OPERATION GUIDE 10. HOTSPOT FUNCTION 6.1 Power On/Off 11. DOWNLOAD “ThermTec Outdoor” APP 6.2 Image Correction 12. TECHNICAL INSPECTION 6.3 Standby Mode 13. MAINTENANCE 6.4 Lens Focus Adjustment... -
Page 6: Safety Information
SAFETY INFORMATION Environmental influences Notes: Never point the lens of the device directly at intense heat sources such as the sun or laser equipment. The objective lens and eyepiece can function as a burning glass and damage the interior components. Risk of swallowing Caution: Do not place this device in the hands of small children. -
Page 7: Intended Use
disposal of this product serves to protect the environment and prevents possible harmful effects on human beings and their surroundings, which may arise as a result of incorrect handling of waste. More detailed information on your nearest collection point is available from your local authority. In accordance with state legislation, penalties may be imposed for the improper disposal of this type of waste. -
Page 8: Regulatory Information
REGULATORY INFORMATION This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the Directive 2014/53/EU(RED), Directive 2014/30/EU(EMC), Directive 2014/35/EU(LVD), Directive 2011/65/EU(RoHS). This product and - if applicable - the supplied accessories too are marked with “UKCA” and comply therefore with the following directives: Radio Equipment Regulations 2017, Electromagnetic Compatibility Regulations 2016, Electrical Equipment (Satety) Regulations 2016, the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012. -
Page 9: Description
Moreover, using Cyclone series thermal monocular includes several benefits over night observation with traditional optics or even night vision devices. The device avails its prominent features dominating various applying occasions, like rescuing, night hunting, hiking, and exploration. -
Page 10: Specifications
3.SPECIFICATIONS Function Model Cyclone315 Photo/video Microbolometer playback Resolution 384x288 Language Multiple-languages Pixel Pitch 12µm Inbuilt Memory 32GB NETD 20mK@300k Audio Calibration Auto/Manual Spectral range 8-14µm Frame rate 50HZ AI Distance Detection 750m Measurement Range Optics Heat Track Objective lens 15mm/F1.0 OSD Recording Field of view 17.5°... - Page 11 Function Model Cyclone325 Photo/video Microbolometer playback 384*288 Resolution Language Multiple-languages Pixel Pitch 12µm Inbuilt Memory 32GB NETD 20mK@300k Audio Calibration Auto/Manual Spectral range 8-14µm Frame rate 50HZ AI Distance Detection 1300m Measurement Range Optics Heat Track Objective lens 25mm/F1.0 OSD Recording Field of view 10.5°...
-
Page 12: Packing List
4.PACKING LIST... -
Page 13: Components And Controls
5. COMPONENTS AND CONTROLS 5.1 Appearance of Cyclone Lens cover USB Port Focusing Knob Power Calibration Zoom in/out Menu up button Menu Pseudo Colors Diopter Menu down button Controller Eyepiece Cover Battery Compartment... -
Page 14: Description Of Controls
5.2 Description of Controls Before entering the main menu After entering the main menu Short press Long Press Double click Short press Long Press Double click Standby Mode Turn On/Off Calibration Standby Mode Turn On/Off Calibration Zoom In/Out AI Rangefinder Cursor Up Capture Record... -
Page 15: Operation Guide
6.OPERATION GUIDE WARNINGS Cyclone series has been designed for long-term use. To ensure sustainable performance, please adhere to the following: Due to it the thermal monocular, no aiming behaviour to the hot resources is allowed. Store with the lens cap on in the carrying case. -
Page 16: Lens Focus Adjustment
6.4 Lens Focus Adjustment Open the lens cover, rotate the lens focus knob to focus on the object being observed. 6.5 Pseudo Color Switch Short press to change the pseudo colors. There are totally six pseudo colors (white hot, black hot, red hot, green, golden, violet) for user choice. White Black Golden... -
Page 17: Target Outline Mode
6.6 Target Outline Mode Long press to turn on/off the Target Outline Mode. 6.7 AI Rangefinder AI rangefinder function is used to check the distance of the target. Double click to turn on/off the AI rangefinder function. You will see distance information on the display after activating this function. -
Page 18: Device Charging
6.10 Device Charging There are two means to charge the device, no matter charge the device from a type-c cable directly or take out the battery and charge the battery with the given charger. Charge through the device Charge the battery Connect the given type-c cable with the device and The battery can be easily taken off... - Page 19 The icon will be turned into blue when Wlan is selected. Wlan Short press menu button “M” to switch the status of Hotspot. When the Hotspot is turned on, it can be connected with “ThermTec Outdoor” APP. The default hotspot password is 12345678.
- Page 20 Turn MIC function on/off Double click the menu button “M” to enter the main menu. Select the MIC option with the “ / ” button. Short press menu button “M” to shift its status. Voices info will be recorded in recordings if the MIC feature has been turned on.
- Page 21 Turn the Logo on/off Double click the menu button “M” to enter the main menu. Select the Logo option with the “ / ” button. Short press menu button “M” to enter turn on/off the Logo Logo. Depend on ones using preference, you can decide whether the logo should be displayed in the right corner or not.
-
Page 22: Advanced Menu
Access Further Sets in Advanced Menu Double click the Menu button “M” to enter the main menu. Select the Advanced Menu option with the “ / ” button. Advanced Image Menu Short press menu button “M” to enter Advanced Menu. - Page 23 We can set various parameters here, such as images parameters, color, ranging, Blind Pixel, OLED, Correction, Shutdown. Select Image and enter the image set. We can set various image parameters here, such as brightness, contrast, sharpness, denoise and image mode here.
- Page 24 Also, we can set the model size in the AI rangefinder Ranging under the advanced menu. Some small dead pixels can be erased by the function of Blind Pixel. Keep pressing the Replace Advanced until the dead pixels are removed, attention: The Menu Blind whole dead pixel removing process is not a...
- Page 25 Here are 4 choices of OLED colors for us under the OLED settings. Also the OLED brightness can be set here too, the adjustable ranges from 1-5. Correction The image correction can be set by Auto and Advanced Manual. Menu Shutdown function can save battery power for you, if you don’...
- Page 26 System setting Double click the menu button “M” to enter the main menu. Select the System option with the “ / ” button. M-YD System Short press menu button “M” to enter System. And press one more time to set the system unit. Here we can select M/YD.
- Page 27 The device time can be set in the Time setting. Time The device date can be set in Date setting System Date The supported language can be set in the language Language setting.
- Page 28 We can check the device SN(serial number) and Version in the Version setting. Version Reset function is available in Reset setting. System Reset The upgrading operation is required to be carried manually after copying the upgrading package to Update the file of storage via PC.
-
Page 29: Capturing And Recording
8.CAPTURING AND RECORDING A built-in 32GB storage space set for image capturing and video recording. The files of images and videos will be named by the device time, so it is recommended to set the time in the main menu before using the image capturing and video recording function. - Page 30 Video recording Press and hold down the camera button “M” to start a video recording. A recording timer displays on the top of the screen. The time format is HH:MM:SS (Hour:Minute:Second). You may enter the menu and enable other functions during video recording. Press and hold down the camera button “M”...
-
Page 31: Memory Access
9.MEMORY ACCESS When the device is turned on and connected to a computer, it is recognized by the computer as a flash memory card, which is used to access the device's memory and make copies of pictures and videos. Turn on the Cyclone and connect it with the computer via Type-C cable. There is an extra disk in the disk zone, enter the disk. -
Page 32: Download "Thermtec Outdoor" App
Turn on “ThermTec Outdoor” APP, select Wi-Fi, and type in the password on the mobile device to finish the connection. The initial password is 12345678. When Wi-Fi is successfully connected, you can control the device via “ThermTec Outdoor” APP. 11.DOWNLOAD “ThermTec Outdoor” APP You may search "ThermTec Outdoor"... -
Page 33: Technical Inspection
14.FIRMWARE UPGRADE Cyclone series thermal monocular is supported by the “ThermTec Outdoor” APP, which allows you to transmit the images and videos from the device to the smartphone or tablet via Hotspot in real time. The electronic version of this User Manual and the latest firmware can be downloaded from the ThermTec website: www.thermeyetec.com. - Page 34 After finishing the update, the device will reboot automatically. Instructions for detailed upgradation can also be downloaded from the official website or you can access our social media for firmware upgradation on ThermTec Outdoor. Upgrading via PC Please download corresponding upgrading package from official website.
- Page 36 ThermTec Technology Co., Ltd. Email: info@thermeyetec.com Web: www.thermeyetec.com COPYRIGHT © 2024 ThermTec Technology Co., Ltd. ALL RIGHTS RESERVED.
