Summary of Contents for ThermTec Wild Series
- Page 1 Series Thermal Imaging Monocular Wild Series User Manual Android GET IT FOR...
-
Page 4: Table Of Contents
Content About This Manual 3.3.3.2 AI Ranging and Laser Rangefinder Regulatory Information 3.3.3.3 Pseudo Color Switch 1. Introduction 3.3.3.4 Target Outline Mode 1.1 Device Description 3.3.4 Capture/Record 1.2 Features 3.4 Set 1.3 Application Scenarios 3.4.1 Setting 1.4 Appearance 3.4.2 System Setting 2. -
Page 5: About This Manual
Any and all information, including, among others, wordings, pictures, graphs are the properties of ThermTec Technol- ogy Co., Ltd. or its subsidiaries (hereinafter referred to as “ThermTec” ). This user manual (hereinafter referred to be “the Manual” ) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of ThermTec. -
Page 6: Regulatory Information
Regulatory Information This product and, if applicable, the supplied accessories are marked with “CE” and comply therefore with the applicable harmonized European standards listed under the Radio Equipment Directive 2014/53/EU, the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU. This product and - if applicable - the supplied accessories too are marked with “UKCA” and comply therefore with the following directives: Radio Equipment Regulations 2017, Electromagnetic Compatibility Regulations 2016, Electrical Equipment (Safety) Regulations 2016, the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012. -
Page 7: Introduction
Introduction 1.1 Device Description Wild Series Thermal Imaging Monocular is designed with a NETD less 18mk, 12μm uncooled infrared detector and 1024x768 OLED high-definition display. With AI image recognition algorithm, it gets clear views under various lighting conditions, even in complete darkness, providing reliable and high-quality visual images for night activities. It can also view the moving target and meet the outdoor conditions. -
Page 8: Appearance
1.4 Appearance ② ③ ① ④ ⑤ ① Lens cover ⑥ ② Power button ③ Focusing knob ④ Joystick ⑦ ⑤ Capture/Record button ⑥ Diopter knob ⑧ ⑦ Eyepiece cover ⑧ Compartment of replaceable battery ⑨ Type-C port Laser module ⑨... -
Page 9: Packing List
Packing List Monocular (x1) User manual (x1) Lanyard(x1) Hand strap (x1) Bag (x1) Charger (X1) Series Lens cloth (x1) USB cable (x1) Lithium battery (X2) -
Page 10: Operation Guide
Plug the opposite end of the cable into a USB power source. Battery Charging: Wild series have adopted replaceable and changeable battery design. The batteries could be taken off and charged directly, from which dramatically improves the device life. Note: The battery should be fully charged prior to use. -
Page 11: Power On/Off
3.2 Power on/off Press and hold the power button to power on/power off the device. 3.3 Buttons and Controls 3.3.1 Buttons Combinations and Introduction Before entering the main menu Short Press Long Press Double Press Power Button Standby Mode On/Off Capture Button Capture Record... -
Page 12: Lens Adjustment
3.3.2. Lens Adjustment Diopter Adjustment Objective Lens Focusing Looking through the eyepiece, adjust the position of Manually adjust the objective lens focus when you diopter level to optimize the image sharpness on the can’ t see the scene clearly. OLED display. 3.3.3 Joystick Operation 3.3.3.1 Zoom Push the joystick to the front to zoom in, vice versa. -
Page 13: Ai Ranging And Laser Rangefinder
3.3.3.2 AI Ranging and Laser Rangefinder Push the joystick to the left to activate AI rangefinder or laser rangefinder. Note: the laser rangefinder is only available for Wild LRF series. 3.3.3.3 Pseudo Color Switch Brief push joystick to right to switch pseudo colors. -
Page 14: Target Outline Mode
There are totally six pseudo colors (white hot, black hot, red hot, green, golden, violet) for user choice. White Black Golden Green Violet 3.3.3.4 Target Outline Mode Long push the joystick to right to enter the target outline mode. -
Page 15: Capture/Record
3.3.4 Capture/Record Image Capturing Video Recording Press Capture button to take photos. Then the photo icon in Press and hold Capture button to take videos. Then the record- the upper left corner will flash once. ing icon starts flashing in the upper left corner, and the record- ing starts timing. - Page 16 Image Settings Forest The image details would be enhanced in a way. Adjust image sharpness to make the image edge sharper. The recommended value is 5. Sharpness 0-10 Adjust image noise to make the image cleaner. The recommended value Denoise 0-10 is 5.
-
Page 17: System Setting
3.4.2 System Setting Press joystick to confirm Setting to enter the System Setting menu. Select by moving the joystick, and short-press the joystick to confirm the selection. System Setting The image correction mode could Correction be set by Auto or Manual. Enable this feature to decide if the On-screen menu icons display in the recorded... - Page 18 Detector anti-burn function, it could be set by on/off. Anti-Burn Once it detects harmful rays to the detector, the system will enable protection automatically.
- Page 19 Electronic Image Stabilization. It could Electronic be switched on/off in the system Image setting. Stabilization Turn on heat tracking to mark the target with the highest temperature Tracking in real time in the screen. In the picture, the image is 2x enlarged Picture in from the center of the cross.
- Page 20 Customize the size of targets, and they AI-Set all could be set by on/off. It includes the default information of LRF location. Warning: No modification Ranging LRF-Set is allowed in this section. Combined with an AI rangefinder, it could measure the aimed target LRF Boost precisely with laser rangefinder and calculate the distances of various...
- Page 21 Gray, Blue, Purple and Red are optional for OLED hue. OLED The brightness could be adjusted here to make the image brighter or darker. Brightness The value could be set by 1-5. The blind pixel in the picture can be replaced.
- Page 22 The device could be set to shutdown Shutdown after 30mins, 60mins, or you could turn off the function. System Customize the sensitivity range of Joystick joystick towards each direction, so it could be better adjusted to every individual needs and requirements.
- Page 23 The logo on the screen could be Logo turned on or turned off. Time System Time and Date could be set here. Date The measuring distance unit could be M/yd set by meter or yard.
- Page 24 Lang System language could be set here. System We could check the information of Version current version here. The settings of images could be reset Reset here.
-
Page 25: Network Connection
You can adjust and upgrade the device System Update system. EIS function: Turn on the EIS function to reduce the impact of body shaking on the image and keep the image stable when observing distant targets. 3.4.3 Network Connection Select Internet icon to and press joystick to enter the Network Connection menu. -
Page 26: App Download
3.4.3.1 App Download You may download the "ThermTec Outdoor" APP through the QR code shown on the packing box, user manual or below. Android GET IT FOR 3.4.3.2 Connect via Hotspot Turn on device’ s hotspot. Connect mobile client with device’ s hotspot. -
Page 27: File Management
3.4.4 File Management Select Files and press the joystick to enter the Files. Select the image and video sub-menus to view the images and videos and play the videos. Image Viewing Press the joystick to enter image files. After selecting a certain image, press joystick to access further operations of the image, we could delete it, check next one or delete all the images. - Page 28 Video Viewing Select Record and press joystick to enter video files. Choose a certain video and press joystick to check the video. Further operations could be accessed here, we could delete it, check next one, pause the video or delete all the videos.
-
Page 29: External Video & Data Reading
Note: Videos, images and rav videos taken will be saved separately in folders named “record” , “image” and “rav” 3.6 System Software Upgrade Wild series thermal imaging monocular supports “ThermTec Outdoor” APP, which allows you to transmit the image from the thermal imager to the smartphone or tablet via Hotspot in real time mode. - Page 30 Upgrading via PC Please download corresponding upgrading package from official website. www.thermeyetec.com. Connect the device to PC via Type-c data cable. Copy the related updating firmware to the storage file of Wild. Press joystick to select Update icon, and the system will prompt “Update”...
-
Page 31: Technical Data
Technical Data 4.1 Product Size & Drawing Note: Wild325, Wild335 and Wild635 are of the same size. - Page 32 Note: Wild335L & Wild635L are of the same size.
-
Page 33: Specifications
4.2 Specifications Specifications - Wild Function Model Wild325 Wild335 Wild635 Wild650 Photo/video Microbolometer playback Language Multiple-languages Resolution 384x288 640x512 Built-in Memory 64GB Pixel Pitch 12µm NETD 18mk@300k AI Distance Measurement Spectral range 8-14µm Heat Track Frame rate 50HZ Real-time Notification Detection Range 1300m 1800m... - Page 34 Specifications - Wild Model Wild335L Wild635L Wild650L Language Multiple-languages Built-in Memory 64GB Microbolometer 384x288 640x512 Resolution LRF Boost Pixel Pitch 12µm Heat Track NETD 18mk@300k Real-time Notification Spectral range 8-14µm OSD Recording Frame rate 50HZ Burn prevention Detection Range 1800m 1800m 2600m Optics...
- Page 36 ThermTec Technology Co., Ltd. Email: info@thermeyetec.com Web: www.thermeyetec.com COPYRIGHT © 2023 ThermTec Technology Co., Ltd. ALL RIGHTS RESERVED.
