- Page 1 Series Thermal Imaging Monocular Wild-D Series User Manual...
- Page 3 Content About This Manual 3.3.3.2 AI Ranging Regulatory Information 3.3.3.3 Pseudo Color Switch 1. Introduction 3.3.3.4 Target Outline Mode 1.1 Device Description 3.3.4 Capture/Record 1.2 Features 3.4 Set 1.3 Application Scenarios 3.4.1 Setting 1.4 Appearance 3.4.2 System Setting 2. Packing List 3.4.3 Network Connection 3.
- Page 4 Any and all information, including, among others, wording, pictures, graphs are the properties of ThermTec Technol- ogy Co., Ltd. or its subsidiaries (hereinafter referred to as “ ThermTec” ). This user manual (hereinafter referred to be “the Manual” ) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of ThermTec.
- Page 5 Regulatory Information This product and, if applicable, the supplied accessories are marked with “CE” and comply therefore with the applicable harmonized European standards listed under the Radio Equipment Directive 2014/53/EU, the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU. This product and - if applicable - the supplied accessories too are marked with “UKCA” and comply therefore with the following directives: Radio Equipment Regulations 2017, Electromagnetic Compatibility Regulations 2016, Electrical Equipment (Safety) Regulations 2016, the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012.
- Page 6 Introduction 1.1 Device Description Wild-D Series Thermal Imaging Monocular is designed with NETD less than 18mK, and equipped with a 12μm uncooled infrared detector, a 1024x768 high-definition OLED display, as well as a variety of lenses with different focal lengths. With its AI image recognition algorithm, Wild-D ensures clear views over long distances, even in harsh environ- ments, poor visibility, or total darkness, providing reliable and high-quality visuals for night activities.
- Page 7 1.4 Appearance ② ① ③ ① ④ Lens cover ⑤ ② Power button ⑥ ③ Focusing knob ④ Joystick ⑤ Capture/Record button ⑦ ⑥ Diopter knob ⑧ ⑦ Eyepiece cover ⑧ Compartment of replaceable battery ⑨ Type-C port Dual FOV Switch ⑨...
- Page 8 Packing List Monocular (x1) User manual (x1) Lanyard(x1) Hand strap (x1) Bag (x1) Charger (X1) Series Lens cloth (x1) USB cable (x1) Lithium battery (X2)
- Page 9 Operation Guide 3.1 Charging Device Charging Battery Charging. Here are two methods we could take to charge the device. Device Charging: Connect the device and power adaptor directly with a type-C cable to power on the device. Alternatively, connect the device and PC to export files.
- Page 10 3.2 Power on/off Press and hold the power button to power on/power off the device. 3.3 Buttons and Controls 3.3.1 Buttons Combinations and Introduction Before entering the main menu Short Press Long Press Double Press Power Button Standby Mode On/Off Capture Button Capture Record...
- Page 11 3.3.2. Lens Adjustment Diopter Adjustment Objective Lens Focusing Looking through the eyepiece, adjust the position of Manually adjust the objective lens focus when you diopter level to optimize the image sharpness on the can’ t see the scene clearly. OLED display. FOV Selection and Switch Shift the FOV from FOV Successfully Switched...
- Page 12 3.3.3 Joystick Operation 3.3.3.1 Zoom Push the joystick to the front to zoom in, vice versa. 3.3.3.2 AI Ranging Push the joystick to the left to activate AI rangefinder. 3.3.3.3 Pseudo Color Switch Brief push joystick to right to switch pseudo colors.
- Page 13 There are totally six pseudo colors (white hot, black hot, red hot, green, golden, violet) for user choice. White Black Golden Green Violet 3.3.3.4 Target Outline Mode Long push the joystick to right to enter the target outline mode.
- Page 14 3.3.4 Capture/Record Image Capturing Video Recording Press Capture button to take photos. Then the photo icon in Press and hold Capture button to take videos. Then the record- the upper left corner will flash once. ing icon starts flashing in the upper left corner, and the record- ing starts timing.
- Page 15 Image Settings Forest The image details would be enhanced in a way. Adjust image sharpness to make the image edge sharper. The recommended value is 5. Sharpness 0-10 Adjust image noise to make the image cleaner. The recommended value Denoise 0-10 is 5.
- Page 16 3.4.2 System Setting Press joystick to confirm Setting to enter the System Setting menu. Select by moving the joystick, and short-press the joystick to confirm the selection. System Setting The image correction mode could Correction be set by Auto or Manual. Enable this feature to decide if the On-screen menu icons display in the recorded...
- Page 17 Detector anti-burn function, it could be set by on/off. Anti-Burn Once it detects harmful rays to the detector, the system will enable protection automatically.
- Page 18 Electronic Image Stabilization. It could Electronic be switched on/off in the system Image setting. Stabilization Turn on heat tracking to mark the target with the highest temperature Tracking in real time in the screen. In the picture, the image is 2x enlarged Picture in from the center of the cross.
- Page 19 Gray, Blue, Purple and Red are optional for OLED hue. OLED The brightness could be adjusted here to make the image brighter or darker. Brightness The value could be set by 1-5. The blind pixel in the picture can be replaced.
- Page 20 The device could be set to shutdown Shutdown after 30mins, 60mins, or you could turn off the function. System Customize the sensitivity range of joystick towards each direction, so it Joystick could be better adjusted to every individual needs and requirements.
- Page 21 The logo on the screen could be Logo turned on or turned off. Time System Time and Date could be set here. Date The measuring distance unit could be M/yd set by meter or yard.
- Page 22 Lang System language could be set here. System We could check the information of Version current version here. The settings of images could be reset Reset here.
- Page 23 You can adjust and upgrade the device System Update system. EIS function: Turn on the EIS function to reduce the impact of body shaking on the image and keep the image stable when observing distant targets. 3.4.3 Network Connection Select Internet icon and press joystick to enter the Network Connection menu.
- Page 24 3.4.3.1 App Download You may download the "ThermTec Outdoor" APP through the QR code shown on the packing box, user manual or below. 3.4.3.2 Connect via Hotspot Turn on device’ s hotspot. Connect mobile client with device’ s hotspot. After the connection, you could control devices freely with APP (ThermTec Outdoor).
- Page 25 3.4.4 File Management Select Files and press the joystick to enter the Files. Select the image and video sub-menus to view the images and videos and play the videos. Image Viewing Press the joystick to enter image files. After selecting a certain image, press joystick to access further operations of the image, we could delete it, check next one or delete all the images.
- Page 26 Video Viewing Select Record and press joystick to enter video files. Choose a certain video and press joystick to check the video. Further operations could be accessed here, we could delete it, check next one, pause the video or delete all the videos.
- Page 27 Note: Videos, images and rav videos taken will be saved separately in folders named “record” , “image” and “rav” 3.6 System Software Upgrade Wild series thermal imaging monocular supports “ThermTec Outdoor” APP, which allows you to transmit the image from the thermal imager to the smartphone or tablet via Hotspot in real time mode.
- Page 28 Upgrading via PC Please download the corresponding upgrade package from the official website, www.thermeyetec.com. Connect the device to your PC via a Type-C data cable. Copy the related updating firmware to the storage file of Wild. Press joystick to select Update icon, and the system will prompt “Update”...
- Page 29 Technical Data 4.1 Product Size & Drawing Note: Wild350D, Wild650D are of the same size.
- Page 31 4.2 Specifications Specifications - Wild Function Model Wild350D Wild650D Wild660D Photo/video Microbolometer playback Language Multiple-languages Resolution 384x288 640x512 Built-in Memory 64GB 12µm Pixel Pitch NETD 18mK@300k AI Distance Measurement Spectral range 8-14µm Heat Track Frame rate 50HZ Real-time Notification Detection Range 1300m/2600m 1300m/2600m 1300m/3000m...
- Page 32 ThermTec Technology Co., Ltd. Email: info@thermeyetec.com Web: www.thermeyetec.com COPYRIGHT © 2024 ThermTec Technology Co., Ltd. ALL RIGHTS RESERVED.
